Image Information Mining in Remote Sensing

1
Image Information Mining in Remote Sensing

• Jiang Li

2
Outline

• Introduction
• Remote sensing image information mining (ReSim)
• Supervised image classification
• Texture feature extraction
• Category-based clustering
• Query-by-example and evaluation
• Summary and future work

3
Data Collected and Stored

• Technology is available to help us collect data
• Bar code, scanners, satellites, cameras,
• Technology is available to help us store data
• Databases, data warehouses,

4
We are drowning in data, but starving for
information and knowledge.
Knowledge Discovery and Data Mining
Knowledge Discovery
5
Data Mining An Iterative Process
Knowledge
Pattern Evaluation

• In theory, data (information) mining is a step in
  the knowledge discovery process. In practice,
  they are becoming synonyms.

Patterns
Data Mining
Task-relevant Data
Selection
Databases
Data Cleaning
Data Preprocessing
Data

• Learning the application domain for relevant
  prior knowledge
• Gathering, integrating, cleaning, and
  preprocessing data
• Selecting data (find useful features,
  dimensionality/variable reduction,)
• Choosing data mining functions (classification,
  clustering, association rules, )
• Interpreting and evaluating results
  (visualization, removing redundant patterns,)

6
Data Mining Confluence of Multiple Disciplines
7
Remote Sensing

• Remote Sensing is the science of acquiring
  information about the Earth's surface without
  actually being in contact with it.

recording reflected energy
images collected in multiple bands of the
electromagnetic spectrum
8
Information Mining in Remote Sensing Images

• Motivation
• Enormously growing of the volume of remotely
  sensed imagery
• Existing systems allow simple queries on sensor,
  date, location,
• Need for efficient retrieval of useful information

• Objective
• Develop integrated software tools for
  professionals in remote sensing to mine
  interesting information in remotely sensed image
  databases

• Commercial data mining packages
• IBM Intelligent Miner for Data, SGI MineSet,
• Image information mining research prototypes
• ITSC Algorithm Development and Mining (Adam)
  System
• NASA JPL Diamond Eye System
• DLR Intelligent Satellite Information Mining
  System
• Insightful VisiMine System

9
Information Mining in Remote Sensing Images
(contd)

• Image information mining is an interdisciplinary
  endeavor
• Computer vision (image processing)
• Pattern recognition (classification clustering)

• Databases (images ancillary data)
• Information Retrieval (indexing and queries)

• Challenges of mining information in remote
  sensing images
• Multi /hyper spectral (huge size, different
  formats)
• Time consuming preprocessing (correction and
  registration)
• Complex spatial / temporal associations
• Feature extraction semantic definition
  (application specific)
• Ancillary data (climate variables, digital
  elevation model)
• Interpretation (priori and domain knowledge)

10

• Introduction
• Remote sensing image information mining (ReSim)
• Supervised image classification
• Texture feature extraction
• Category-based clustering
• Query-by-example and evaluation
• Summary and future work

11
ReSim System Architecture
Spectral information land cover classes
Spatial information texture

• Image Processing
• principal component analysis
• texture feature extraction
• classification clustering

• Databases
• object-oriented database
• image database

• Graphical User Interface
• query
• browsing
• visualization

12
Multi-band Landsat Thematic Mapper (TM) images

• Radiometric and geometric rectified scenes of
  Nebraska
• Central 4096 4096 pixels in each Full Scene (6
  / 7 bands)
• Two-level split to facilitate the implementation
• Each 1024 1024 Image 64 128 128
  Regions
• 4 Full Scenes, 64 Images, 4096 Regions

13

• Introduction
• Remote sensing image information mining (ReSim)
• Supervised image classification
• Texture feature extraction
• Category-based clustering
• Query-by-example and evaluation
• Summary and future work

14
Remote Sensing Image Classification

• Supervised classification
• User first specifies the land cover types and
  training pixels in the image
• The classifier is trained and used to classify
  remaining pixels
• Unsupervised classification
• The clustering algorithm aggregate all pixels
  into clusters
• User then assigns these spectral groups into land
  cover types

supervised image classification
unsupervised image classification
15
Support vector machines classification
16
Support vector machines classification (contd)

• Maximal margin hyperplane (w, b)? - solve the
  optimization problem
• dual form representation with the primal
  Lagrangian
• Non linear separable? - Kernel method
• Transform input vectors into a higher dimensional
  feature space
• by a mapping function and then do a
  linear separation there.
• The expensive computation of inner products
  can be
• reduced significantly by using a suitable
  kernel function
• We do not need to have an explicit representation
  of , but only K

17
Support vector machines classification (contd)

• Radial Basis Function (RBF) kernel

leave-one-out model selection
18
USGS Land Use/Land Cover scheme
19
Support vector machines classification (contd)

• Radial Basis Function (RBF) kernel

• Accuracy better than Maximum Likelihood classifier

original image
classified image
land cover types
20

• Introduction
• Remote sensing image information mining (ReSim)
• Supervised image classification
• Texture feature extraction
• Category-based clustering
• Query-by-example and evaluation
• Summary and future work

21
Principal Component Analysis

• A linear transformation of a multivariate dataset
  (multispectral image) into a new coordinate
  system
• Reduce the dimensionality (decorrelation) of the
  data set while retaining most of the variance
• Eigenvalues of covariance matrix

TM image (Omaha)
1st component
eigenvalues of principal components
22
Texture Feature Extraction

• Texture feature representation
• statistics model
• co-occurrence matrices
• probability model
• Markov random fields parameters
• transform-based model
• Gabor wavelets

• A two-dimensional Gabor function and its Fourier
  transform

23
Texture Feature Extraction (contd)

• Gabor wavelets
• self-similar filter dictionary obtained by
  appropriate dilations and rotations of
  through the generation function

scale factor
, K of orientations

• Feature representation
• Gabor wavelet transform of an image (PCA 1
  region)
• mean and standard deviation of the magnitude of
  the coefficients
• feature vector

S of scales
24

• Introduction
• Remote sensing image information mining (ReSim)
• Supervised image classification
• Texture feature extraction
• Category-based clustering
• Query-by-example and evaluation
• Summary and future work

25
Category-based Clustering

• Partition the texture feature space into
  subspaces in terms of the combined land cover
  classes

water/wetlands river/grassland forest/pasture
crops/pasture urban/grasslands
26
Category-based Clustering (contd)

• k-means clustering within each subspace

1) Randomly choose k patterns as each cluster
centers 2) Assign each pattern to the closest
cluster 3) Compute the cluster centers (mean). 4)
Go to 2) if not converge

• Optimization - How many clusters? Better starting
  centers?

1) Randomly choose J small sub-samples of the
data 2) Minimum validity value gives optimal
number of clusters Kopt 3) Input Kopt to the
starting centers refinement algorithm
27
The Image Database

28
The Object-oriented Database

29

• Introduction
• Remote sensing image information mining (ReSim)
• Supervised image classification
• Texture feature extraction
• Category-based clustering
• Query-by-example and evaluation
• Summary and future work

30
Pattern Retrieval using Query-by-Example
31
Pattern Retrieval using Query-by-Example (contd)

• Query-by-Example - search for similar patterns
  using a selected example

• Select a region referring to the land cover
  classes

• Example similar patterns with mixed
  crops/grasslands and water

32
Pattern Retrieval using Query-by-Example (contd)
Online Mode query example NOT in database
Batch Mode query example in database
33
Pattern Retrieval using Query-by-Example (contd)
Query example generation of a river scene
Similar patterns shown in a ranked order
34
Pattern Retrieval using Query-by-Example (contd)
Similar patterns shown in a ranked order
Query example generation of a crop scene
35
Evaluation
A high coverage value shows that system can
retrieve most of the relevant images the user
expects to see.
A high novelty value indicates that the system
can discover many new relevant images previously
unknown to the user.
36
Evaluation (contd)
Relevant patterns (agricultural lands around the
Missouri River)
37
Summary

• Introduced data mining and information mining in
  remote sensing images
• Presented a remote sensing image information
  mining framework
• Explored state-of-the-art data mining and
  databases technologies to retrieve spectral and
  spatial information from remote sensing imagery
• LCLU corresponding to spectral reflection SVM
  classification
• Texture features characterizing spatial
  information Gabor wavelets
• Optimized k-means clustering to acquire search
  efficient space
• Object-oriented databases and image databases
• K-nearest neighbor search via query-by-example
  (QBE)
• Graphical user interface (GUI)
• Validated the system effectiveness by coverage
  and novelty measures

38
Future Work

• Shape features, spatial-temporal relationships,
  trend analysis,
• More data mining functions such as association
  rules, decision trees,
• Data warehouse techniques and uniform
  object-oriented data model for hierarchy
  multi-resolution storage and retrieval
• Geographic Information System (GIS) connectivity
• To access ancillary data in vector format such as
  soil/hydrologic map,
• To update GIS databases with the retrieved
  information
• Evolve the prototype system into a practical
  software tool and apply it into specific
  applications (agricultural and environmental
  monitoring)

39
References

• U. M. Fayyad, G. P. Shapiro, P. Smyth, and R.
  Uthurusamy (Eds.), Advances in Knowledge
  Discovery and Data Mining, AAAI/MIT Press, 1996.
• J. Zhang, H. Wynne, M. L. Lee, Image mining
  issues, frameworks, and techniques, in
  Proceedings of 2nd International Workshop on
  Multimedia Data Mining, San Francisco, Aug 2001,
  pp. 13 20.
• J. R. Jensen, Introductory Digital Image
  Processing A Remote Sensing Perspective,
  Prentice-Hall, New Jersey, 1996.
• V.N. Vapnik, Statistic Learning Theory,
  John-Wiley and Sons, Inc, 1998.
• N. Cristianini, and J. Shawe-Taylor, An
  Introduction to Support Vector Machines, The
  Cambridge University Press, Cambridge, UK, 2000.
• J. Li and R. M. Narayanan, "Integrated spectral
  and spatial information mining in remote
  sensing," IEEE Transactions on Geoscience and
  Remote Sensing, vol. 42, no. 3, pp. 673 685,
  March 2004.
• J. Li and R. M. Narayanan, "A shape-based
  approach to change detection of lakes using time
  series remote sensing images," IEEE Transactions
  on Geoscience and Remote Sensing, vol. 41, no.
  11, pp. 2466 2477, November 2003.
• J. Li, R. M. Narayanan, William J. Waltman, and
  Albert J. Peters, Fuzzy feature-based image
  mining in remote sensing, in SPIE AeroSense
  Conference on Data Mining and Knowledge
  Discovery, Orlando, Florida, April 2001, vol.
  4384, pp. 46 55.
