Microsoft Academic Days

1
Microsoft Academic Days Segrate 22-14 November
2004
Speaker Pierluigi RitrovatoResearch and
Technology Director
2
Agenda

• The motivation
• Analysis of current learning practices and
  e-learning solutions
• Our vision of the Learning
• The innovation in IWT
• The Architecture
• The personalisation of the learning experience
• The adaptability of the platform for learning in
  a specific domain
• IWT Grid aware

3
Analysis of Current Learning practices

• Based on the information transfer paradigm with
  focus on the content and the teacher
• Find the best way for presenting contents in
  order to transmit information to learners
• Contents are passive books, pictures, audio,
  etc.
• Passive role of the learner

• No individual support of the students learning
  process
• Everything is predetermined
• No possibility to change the process for
  accommodating specific needs

listen read imitate memorise rehearse recall
4
Analysis of Current e-Learning practices

• Technology driven approach
• e-Learning becomes an activity in which teachers
  produce, and students consume, multimedia books
  on the Web
• Missing specific didactical models
• Not any support of pedagogical aspects
• Suppose that the cognitive transfer occurs
  without evaluating the effectiveness

5
Analysis of Current e-Learning practices

• Inappropriate use of technology
• Available solutions supports actively the
  contents management only
• Finds its perfect technical mirror in the Web
  page oriented approach
• Personalisation and individualisation of the
  learning path is a myth
• Solutions are closed and difficult to integrate

6
How we conceive the Learning
There is a common thread in the development of
our understanding of learning

• The learner as active agent in the learning
  process
• Knowledge construction through conversations,
  collaborations and direct experience in a social
  context

• Learners need to be
• engaged in goal-oriented tasks
• practising skills
• exploring and experimenting
• using feedback to adapt what they do
• discussing what they do
• reflecting on what happens
• articulating what happens

7
How we conceive the Learning

• We are moving our attention from a strictly
  concept oriented teaching to user centred
  learning
• the past the focus was on finding better ways
  for presenting concepts to learners
• The present recognised the learner role and they
  active participation in the process
• The future more emphasis on learning as a
  potential side effect of interactions and
  conversations, experiences and social reflections
  on them, also in Virtual Communities

8
How we conceive the Learning

• the focus will be on a constructivist learning
  theory, with a socio-cultural and situational
  approach
• Confuciuss dictum Tell me and I will forget.
  Show me, and I may remember. Involve me and I
  will understand!
• It is important to define a model that considers
  in a unified way the characteristics of the
  learning (i.e. active, situated, collaborative)
• "Situations Theory of Brousseau 1986 for
  Virtual Scientific Experiments for e-learning

9
The technical solution?
10
IWT overview

• Intelligent Web Teacher is an extensible
  application framework for building learning
  solutions
• software and technologies building blocks
• It doesnt exist a product that fit all need!
• It has been designed for supporting the emerging
  learning scenarios for knowledge constructions
• personalised learning path
• knowledge representation models
• any time, any place and any pace access to
  learning services
• Learning Objects reuse

11
Whats Really New in IWT?

• The Architecture Extensibility and
  Customisability
• At a Portal Level
• At a Content Level

• At a Services level
• At a Device level

• Building Blocks for personalising the Learning
  Experience
• Indexing Content Management through Explicit
  Knowledge Modeling and Metadata
• Student model management
• Automatic Student Evaluation
• Automatic customisability of the Didactic
  Experience on real Students Needs and Learning
  Preferences

12
IWT The Open Architecture

• Interoperable with domain specific external
  solutions
• New technologies based

• Extensible with new learning object and content
  types
• Extensible with new functionalities

13
IWT Architecture details

• Document Drivers manage IWT resources as Passive
  Learning Object, Multiple Choice Test, Didactical
  Courses, etc
• Plug-In Drivers manage IWT services as CBR, ITS,
  Collaboration Services, etc
• We add resource types to IWT coding and
  integrating document drivers
• We add services to IWT coding and integrating
  plug-in and plug-in drivers

14
IWT Architecture and technologies
15
Document Driver life cycle
Requests a Driver for Resource X
Retrieves information about type of Resource X
Instantiates a suitable driver for Resource X
Builds Web GUI for delivery of Resource X
16
Plug-in Driver life cycle
Retrieves information about engine X
Requests for service Y provided by engine X
Rendering
Instantiates plug-in driver for engine X
17
Student Modeling

• Cognitive State
• Maintains students knowledge in relation to
  domain Concepts
• It is updated after each test activity
• Preferences
• Maintains students preferences in relation to
  significant pedagogical parameters like media,
  didactic approach, interactivity level, semantic
  density, difficulty etc.
• It is updated after each sequence of testing
  activities

18
Knowledge Modelling A Sample Ontology
Third Level
MT1
MT2
MT3
MT4
MT5
MT6
Second Level
LO1
LO2
LO3
LO4
LO5
LO6
First Level
19
Personalised Learning path creation

• The teacher fixes target concepts
• IWT creates learning path (the sequence of
  concepts) removing what the student knows
• IWT creates the course (the sequence of
  resources) respecting their learning preferences

20
Whats Really New in IWT?

• IWT Domain Platforms
• They offer resources and services to facilitate
  e-learning in a specific domain
• Available Domain Platforms
• Domain Platform for Simulation and Virtual
  Scientific Experiments integrates simulation
  environments and 2D and 3D rendering engines
• Domain Platform for Mathematics and Science
  integrates numeric and symbolic computation
  engines

21
IWT Domain Platforms
Mathematical Analysis Exercise
Examples of usage of IWT Domain Platforms
Simulation Viewer
Simulation models
22
IWT Resources and Services MS ConferenceXP
integration

• Live material is stored and assembled in a
  learning object REUSABLE in synchronous events

23
ConferenceXP integration in IWT the idea
To integrate into a Learning Object(CXPLesson)
resources created by ConferenceXP during a live
lesson
This Learning Object could be included together
with other resources within a course delivered by
the platform
24
ConferenceXP Integration in IWTLesson delivery
25
IWT Device Independence
Extensibiliy and Customisability
Examples of access through different devices
Smart Phones
Handhelds
26
IWT Grid-Aware

• What it is?
• It is an extensible, open, distributed and
  service oriented framework for building learning
  solutions
• It is compliant with the Open Grid Service
  Architecture (OGSA) and based upon the Web
  Services Resource Framework (WSRF) infrastructure
• Why IWT Grid-Aware?
• It could be a fundamental component for the
  implementation of a learning paradigm shift where
• learning is a social activity consumed in
  communications and collaborations based dynamic
  Virtual Communities
• learners, through direct experiences, create and
  share their knowledge in a contextualised and
  personalised way
• Services and resources can be selected and
  provided on the basis of their characteristics
  and taking into account quality aspects
• Openness and standards of the OGSA model allow an
  easy integration of services and contents (no
  need for plug-in mechanism)
• Improvement of scalability, computational power,
  storage capabilities,

27
IWT Grid-Aware - Architecture
28
IWT Grid-Aware Key aspects of refactoring of
each layer 1/3

• Data layer
• two OGSA Data Services (DS) to virtualize the two
  storage mechanisms of IWT
• DataBase DS to virtualize the IWT DB
• Repository DS to virtualize the Object Repository
• Based on recommendations of the OGSA-DAIS WG
• Infrastructure layer
• composed by two sets of services
• IWT Base services providing the functionalities
  of IWT
• Content management, accounting and group,
  resource and permission, user profile,
• Core OGSA Services providing functionalities to
  manage a VO
• Service and resource location, dynamic
  instantiation, service compositions,
• Both the sets rely upon WS-Standards (WSDL, SOAP,
  WS-Addressing) and interfaces and behaviors
  specified by WSRF

29
IWT Grid-Aware Key aspects of refactoring of
each layer 2/3

• Learning Services layer
• provides some services specific for the learning
  domain (e.g. LIA and CBR) that rely upon the
  functionalities of Infrastructure and Data layers
• provides services to completely manage a
  particular type of resources more or less complex
  such as learning object (LO), courses, etc..
  These services are named Drivers
• main features of a Driver
• transient and stateful ? implementing the
  interfaces and behaviors of WSRF
• able to generate events ? implementing the
  interfaces and behaviors of WS-Notification
• able to produce GUI ? implementing the behaviors
  of Web Services for Remote Portlets (WSRP)
• two kinds of Driver
• Simple Driver to manage simple resources (e.g.
  passive LO)
• Composed Drivers to manage aggregated resources
  (e.g. a course, that is aggregation of passive
  LOs)
• obtained by orchestration of Simple Drivers
  acting on the atomic resources

30
IWT Grid-Aware Key aspects of refactoring of
each layer 3/3

• Application layer
• No substantial changes
• redesign of the IWT Portal to allow aggregation
  of the GUIs produced by the Drivers ?
  implementing the behaviors of WSRP Consumer
• Security
• managed in all the architectures layers
• Single Sign On (SSO)
• secure communication among the services based on
  VO policies
• adoption of WS-Security

31
Contacts and Further Info
Info About this Talk ritrovato_at_crmpa.unisa.it
Info about IWTwww.momanet.it/iwt miranda_at_momane
t.it
32
How we conceive the Learning

• We dont reject the traditional information
  transfer approach
• Passive activities
• It Needs to be complemented with active
  activities facilitating knowledge construction
• Decide on actions needed to achieve a given goal
• Reflect on the feedback on their actions
• Adapt their actions on the basis of reflection
• Experiment to achieve a goal
• Discuss what they are doing
• Articulate their understanding of what is
  happening

33
Resources and services in IWT

• IWT Resource
• Abstraction for content (atomic) or experience
  (workflow)
• Managed by document drivers
• Examples doc, audio file, course, etc.
• IWT Service
• Abstraction for Infrastructure/Additional/Applicat
  ion services
• Managed by base services, plug-in and plug-in
  drivers
• Examples messaging, math-engine, chat, forum,
  videoconference etc.
