INTRODUCTION
3D Measure Up is used to detect and extract
human body measurements e.g. height, waist size,
leg length etc. Once we have those, we can
easily slice the 3D avatars and segment the body
parts by using any open source library which
supports mesh boolean operations like PyMesh.
3
WHAT IS
3 D AVATAR?
With the evolution of new technologies, human
lifes are getting smarter and easier. Similarly
nowadays 3D body scanning technology is evolving
and many 3D scanners are now available under
reasonable prices with good quality scans. Even
now the Apple iPhone has a LiDar scanner which
is very convenient and easy to use. .
4
Using a 3D scanning application on your
smartphone or even by proper 3D scanning device
you can scan a digital representation of the
object or person. The scan has a point cloud with
depth and the color etc. This point cloud can be
converted to mesh which can be opened in a 3D
modeling application. These scanned 3D models
can be consumed by various applications. One of
them is 3D Measure Up which uses a 3D avatar of a
human body data to identify landmarks and
extract measurements.
5
ABOUT BLOG
In this blog, we discuss a simple technique to
slice and segment 3D avatar. I will describe the
technology components that are used to perform
the slicing and segmentation. As a first step,
we use 3D Measure Up to detect and extract human
body measurements e.g. height, waist size, leg
length etc. Once we have those, we can easily
slice the 3D avatars and segment the body parts
by using any open source library which supports
mesh boolean operations like PyMesh.
6
TECHNOLOGY COMPONENTS
1. 3D Measure Up is a service that makes it easy
to add powerful 3D measurement and analysis to
your applications. It lets you easily build
powerful applications to identify and measure
many landmarks on a 3D scan of a human body. 3D
Measure Up is an anthropometric measurement
service that detects various landmarks or
features of a human body such as ankle, knee,
tip of nose, shoulder point etc. It also allows
you to measure various parameters of these
landmarks e.g. position of mid- thigh from the
ground, girth of biceps, waist, bust, volume of
torso etc. 3D Measure Up is based on the proven,
highly scalable, machine learning technology
developed by ProtoTechs 3D geometry, graphics
and visualization experts.
7
2. PyMesh is a rapid prototyping platform
focused on geometry processing. It provides a
set of common mesh processing functionalities
and interfaces with a number of state-of-
the-art open source packages to combine their
power seamlessly under a single developing
environment. Mesh process should be simple in
python. PyMesh promotes human readable,
minimalistic interface and works with native
python data structures such as numpy.ndarray.
8
IMPLEMENTATION
3D Measure Up to get all the measurement Create
an application using 3D Measure Up. Provide a 3D
human body part file (mesh format example STL
file) as an input to 3D Measure Up. 3D Measure Up
will clean up mesh, do all the measurement and
output you with all the landmarks and
measurement information (like ankle, knee, tip
of nose, shoulder point, position of mid-thigh
from the ground, girth of biceps, waist, bust,
volume of torso etc) By using the 3D Measure Up
output you can create a cubical or circular
bounding for that body part that you want to
slice and provide it as input to the PyMesh task.
9

• 2. PyMesh to slice the human body part
• Create an application which imports PyMesh.
• Provide a 3D human body part file (example STL
  file) as an input to PyMesh and open the file to
  read the mesh.
• Now create another mesh in PyMesh using the
  bounding box information we calculated using 3D
  Measure Up.

4. And then perform a mesh boolean intersection
operation between both meshes. You will get
sliced human body parts as a result
5.
10
About us

• ProtoTechs 3D Measure Up is based on a
  proprietary algorithm which is a combination of
  3D geometry, computational and machine learning
  algorithms to provide you with a highly accurate
  and reliable identification and measurement.
