ULDBs: Databases with Uncertainty and Lineage Omar Benjelloun, etc.

1
ULDBs Databases with Uncertainty and
LineageOmar Benjelloun, etc.

• Te Li
• 4/20/2006
• ASU

2
Issues

• Motivation
• ULDB Data Model
• DL-Monotonic Queries
• ULDB Query Evaluation
• ULDB Minimization
• Probabilistic ULDBs
• Pros and Cons

3
Motivation

• Many applications require both lineage and
  uncertainty.
• Data integration
• Deduplication
• Scientific data management
• Information extraction
• Lineage is useful since it
• Offers helpful additional info to users
• Correlates uncertainty in results with base data
• Exhibits representl and computl benefits

4
ULDB Data Model (1)

• Database with Lineage (LDB)

5
ULDB Data Model (2)

• x-relation (Uncertain Database)
• x-tuples tuple alternatives
• maybe x-tuples ?

6
ULDB Data Model (3)

• ULDB Combining Lineage and Uncertainty

7
ULDB Data Model (4)

• A uncertainty model is complete if
• It is possible to represent any set of possible
  instances within the model
• This model is complete
• Given any set of possible LDBs, there exists a
  ULDB whose possible LDBs are the same as the
  given set of LDBs.

8
ULDB Data Model (5)

• Only consider a subset of the model called
  Well-Behaved ULDB
• A ULDB is well-behaved if the lineages of all its
  x-tuples satisfy
• No cycles
• All alternatives of an x-tuple have distinct
  lineages
• Their lineages point to alternatives of the exact
  same set of x-tuples

9
DL-Monotonic Queries (1)

• Only consider a subset of relational queries
  called DL-Monotonic Queries
• A DL-monotonic query is a function Q from LDBs to
  LDBs that satisfies
• The lineage of a result tuple points to the
  minimal subset of the db that produces exactly
  that tuple
• Monotonicity
• Any operation that produces its results in a
  tuple-by-tuple fashion is DL-monotonic.
• Such as multiset selection, projection, join,
  union

10
DL-Monotonic Queries (2)
11
ULDB Query Evaluation (1)

• The result of query eval includes the original db
  and the answer relation
• The algorithm
• Performs standard eval on all the possible
  instances
• Constructs the answer x-relation
• If the db is well-behaved, so is the query result

12
ULDB Query Evaluation (2)

• Semantics of Queries on ULDBs

13
ULDB Query Evaluation (3)Extraction

• The extracted set of x-relations is a
  well-behaved ULDB which preserves the possible
  instances w.r.t. data and internal lineage
• Preserve means to retain the x-tuples that are
  pointed to by the lineages
• The resulting ULDB is D-minimal

14
ULDB Minimization (1)

• Why do we need minimization?
• Extraneous ?s
• Extraneous alternatives

15
ULDB Minimization (2)

• A ULDB is D-minimal if it includes no extraneous
  ?s or alternatives
• What about lineage?
• Internal lineage external lineage
• Internal ? IDs in the database
• External ? IDs outside the database
• A ULDB is L-minimal if its internal lineage is
  the smallest

16
ULDB Minimization (3)Membership Queries

• A side-effect of minimization
• Tuple membership/certainty
• P problems (for well-behaved ULDBs)
• Instance membership/certainty
• NP-hard problems (for all complete uncertainty
  models)

17
Probabilistic ULDBs (1)The Model

• Well-behaved and D-minimized ULDB
• Alternatives of an x-tuple are disjoint
• Different x-tuples are independent
• Each base alternative has a confidence value
• The sum s of the confidence values of each base
  x-tuple is at most 1 and exactly 1 if it is not a
  maybe x-tuple
• The confidence value of ? is (1-s)
• The probability of a possible instance is the
  product of the confidences of the base
  alternatives and ? chosen in it

18
Probabilistic ULDBs (2)

• Suppose a possible instance where
• Amy saw an Acura
• Betty saw a Mazda
• Hank doesnt own an Acura

• Confidence c 0.80.6(1-0.6) 0.192

19
Probabilistic ULDBs (3)Query Evaluation

• Two-phase evaluation
• Data computation
• Confidence computation
• Why post-computes confidence?
• Feasibility. The confidence value for every
  result alternative a is a function of the
  confidence values for the base alternatives
  reachable by as transitive lineage
• Benefit. Ensures correctness

20
Probabilistic ULDBs (4)

• Query plan 1 (0.528)
• Query plan 2 (0.6048)
• Query plan 3 (0.528)
• First compute the result (Hank) with ID (71,1)
• Duplicate-elimination is not DL-monotonic,
  lineage function becomes a boolean
  formula ?((71,1)) ((51,1)?((11,1)?(12,1)))

21
Pros Cons

• The model is very simple but very expressive, in
  fact, complete

• The biggest penalty is maintenance of history. In
  case of ULDB, maintenance of lineage

• The idea of lineage is similar to that of chain
  probability, i.e. recording history

• The post-calculation of confidence is very
  similar to that in PEPX

22
Survey on Stanford InfoLab

• 2006

23
People

• 21 members
• 5 key figures Hector Garcia-Molina, Rajeev
  Motwani, Jeff Ullman, Jennifer Widom, Gio
  Wiederhold

in database area
24
11 Current Projects
25
Trio Project (2004-)

• People Jennifer Widom, 1 post-doc, 4 grads, 2
  alums
• Papers CIDR05, ICDE06, DEB06, 2 TRs
• Vision data, uncertainty, and lineage
• Goals
• To combine and distill previous work into a
  simple and usable extension to the relational
  model
• To design a query language as a well-defined
  intuitive extension to SQL
• To build a working system -- a system that
  augments conventional data management with both
  uncertainty and lineage as an integral part of
  the data

26
WebBase Project (1998-)

• People Hector Garcia-Molina, Andreas Paepcke, 7
  students, 4 alums
• Papers 16 confs (2 SIGMOD, 1 VLDB), 1 journal,
  10 TRs
• Vision crawling, storage, indexing, and querying
  of large collections of Web pages
• Goals
• Provide a storage infrastructure for Web-like
  content
• Store a sizeable portion of the Web
• Enable researchers to easily build indexes of
  page features across large sets of pages
• Distribute Webbase content via multicast channels

• Support structure and content-based querying over
  the stored collection

27
STREAM Project (2000-2006)

• People Jennifer Widom, Rajeev Motwani, 5
  students, 8 alums
• Papers 32 conf/journal (5 SIGMODR, 6 VLDBJ),
  1 TR
• Vision multiple, continuous, rapid, time-varying
  data streams
