Geographic Information System

1
Geographic Information System An Integral Part
of MVRPCs Planning Support System
Martin Kim, AICP, GISP Director of Regional
Planning Tom Harner GIS Coordinator Miami Valley
Regional Planning Commission
2
Session Agenda

• MVRPC Overview
• MVRPC Planning Support System
• Overview
• Application Examples
• MVRPC Enterprise GIS
• GIS Online Planning Support System
• GIS Application in Regional Planning - Going
  Places Initiative
• Questions and Answers

3
Miami Valley Region Planning Commission

• Voluntary association of governmental and
  non-governmental organizations serving people in
  Southwest Ohio

• Formed in 1964 under Section 713.21 of the Ohio
  Revised Code
• A total of 78 members
• Covers Darke, Greene, Miami, Montgomery, and
  Preble, Counties

4
Miami Valley Region Planning Commission

• Serves the Miami Valley Region as a Regional
  Planning Commission and Metropolitan Planning
  Organization
• In 1973, MVRPC was designated by the Governor as
  a Metropolitan Planning Organization (MPO) to
  perform transportation planning activities in the
  Dayton Metro Region

5
Planning Activities at MVRPC

• Transportation Planning
• Long Range Transportation Planning
• Short Range Transportation Planning
• Special Projects
• Land Use Planning
• Environmental Planning
• Water Quality Planning
• Air Quality Planning

6
Planning Support System Overview

• Sub-class of Decision Support System (DSS)
  serving a special purpose of assisting planning
  professionals in completing planning tasks
  through computerized systems
• Gathering information
• Evaluating courses of actions
• Preparing plans
• Monitoring results

7
Planning Support System Overview

• A system to provide rationale for a better
  decision making process

• Providing necessary support to systematically
  analyze the information
• Finding and formulating the alternative options,
  policies, scenarios, and plans
• Assessing and evaluating impacts
• Selecting and recommending a proper solution

8
MVRPC Planning Support System

• MVRPC has been increasing the use and enhancement
  of the Planning Support System over the years in
  the planning process to
• Facilitate better decision making
• Share planning related information
• Expand the public participation
• at the Regional level

9
MVRPC Planning Support System Components
10
Evolution of MVRPC PSS Application
11
Downloadable Maps Planning Atlas

• Maps ranging from a single county to more than 7
• Resource inventory
• Spatial Analysis
• Explanatory Text on the Map
• Aimed at offering
• enhanced communication
• enhanced comprehension
• better accessibility
• information at regional level

12
Interactive Maps - Web TELUS

• A web-based Transportation Improvement Program
  (TIP) project management application with
  database management and web mapping
• Database Management
• Used by MVRPC Staff to maintain TIP project data
• Allows visitors to query and view TIP data using
  our web site.
• Allows 24/7 access to most up-to-date info
• Visualization
• Interactive mapping (ArcIMS) with links to
  detailed project information

13
(No Transcript)
14
More Interactive Mapping

• Traffic Count Viewer Interactive map for users
  to obtain traffic count information in the Region

• Project Evaluation System Interactive map to
  evaluate Roadway, Bikeway and Transit Project
  Evaluation System sheets.

15
Regional Enterprise System Development

• Project Scope
• Design and implement comprehensive enterprise GIS
  architecture for centralized database management
  and community-wide regional GIS
• Geodatabase design and migration of core datasets

• Develop web-based communication application
• Project Timeline
• Began in winter of 2006 and completed in March
  2007

16
System Architecture Design and Implementation

• Upgrade to Enterprise System
• Based on a region-wide GIS Assessment
• Evaluation of existing MVRPC GIS
• Survey local jurisdictions to identify GIS usage
  and common GIS datasets
• Review of GIS best practices
• Implementation of supporting infrastructure
• Upgrade both software and hardware
• Server upgrades
• Spatial Data Engine (SDE)
• Relational Database Management System (MS
  SQL2005)

17
Existing Infrastructure
18
New Infrastructure
19
Geodatabase Design and Migration

• Develop data model and migrate Core Datasets to
  Enterprise Geodatabase format
• Boundary - Jurisdiction boundary
• Census - Census Tract, Block Group, Block and
  Urban Area
• Environmental - Wastewater facility planning
  areas, hydrology, and watersheds
• Land Fabric - Existing and future land use,
  zoning, and open space
• Transportation - Roads, bikeways, traffic
  analysis zone, FHWA federal-aid urbanized area

20
Application Development Goals

• Provide user-friendly application with data
  access, data retrieval, and data display
• Metadata Explorer Data Search Engine
• GIS Online Planning Support System Data
  Visualization through a internet mapping
  application

21
Interactive, Customized Maps GIS Online
Planning Support System

• Web-based mapping application
• ESRIs ArcIMS software
• Interactive data visualization tool
• Provides user-friendly application providing data
  access, data retrieval, and data display functions

• Launched in March 2007 with updates in August
  2007
• Core Datasets as identified in previous steps

22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
Future Enhancements

• Data Enhancements
• Provide more basic demographic information
• Report/Studies data to be made available
• System Enhancements
• Data Delivery Extension
• Provides data download option
• Metadata Explorer Application
• Data Search Engine that enable users to search
  various datasets
• ESRIs Geoportal to provide collaborative
  geospatial user communities

26
OPSS Supports Regional Planning Initiatives

• The OPSS includes geodatasets that MVRPC uses for
  regional and transportation planning activities
• Making these planning data layers available to
  others (local, State and Federal) can help keep
  regional planning organizations using consistent
  base data
• OPSS data can help organizations collaborate on
  adjacent projects by lowering the data collection
  needs for those projects.

27
The Going Places is to bring the Miami Valley
Region TOGETHER to make this Region a BETTER
PLACE to live, work, and play with a Shared
Land Use Vision
28
Goals and Objectives

• Conduct a 3-phase planning process to build a
  clear and shared future land use framework for
  the Miami Valley Region
• Construct a region-based conceptual plan
  (region-based growth framework) that identifies
  desired land use patterns to
• Better achieve consistency between future
  transportation infrastructure investment and land
  development, while protecting environmental
  resources
• Provide resources and guidelines for local
  communitys future policy and/or plan development
  efforts

29
Miami Valley Land Suitability Assessment

• Assess Regions landscape from a natural and
  built environment perspective as part of the
  existing condition assessment phase of Going
  Places Initiative
• Provide a region-based comprehensive overview of
  Regions landscape
• Identify where opportunities and constraints
  exist in the Region
• Identify locations within the Region that are
  better suited for physical development than
  others

30
Factors Examined

• Depth to Bedrock
• Floodplain
• Forested Areas
• Ground Water Pollution Potential
• Ground Water Yield
• Inundation Areas
• Load Bearing Strength
• Mineral Resources
• Prime Farmland
• Slope
• Soil Drainage
• Sole Source Aquifer
• Surface Water
• Well Field Protection Areas
• Wetlands

• Airport Noise
• Educational Amenities
• Fire Protection Services
• Industrial Clusters
• Job Clusters
• Major Thoroughfare Access
• Other Amenities
• Potential Environmental Hazards
• Public Transportation Services
• Public Wastewater Services
• Public Water Services
• Recreational Amenities
• Restricted Development Lands
• Retail Clusters
• Transportation Network Connectivity

31
(No Transcript)
32
(No Transcript)
33
Suitability Measure Development
Conceptually, the Suitability Measure was
generated by overlaying spatial data representing
the Suitability Scores of all factors.
34
Land Suitability Score System Example
35
Suitability Measure Composite Maps
36
Comparative Analysis
37
Data Sharing with GIS OPSS
Map Tools
Map
Map Layers
38
(No Transcript)
39
(No Transcript)
40
For More Information

• Martin Kim, Director of Regional Planning
• mkim_at_mvrpc.org
• Tom Harner, GIS Coordinator
• tharner_at_mvrpc.org
