Digital Library User Interface and Usability

1
Digital Library User Interface and Usability

• Week 8

2
Goals

• Discover elements of good interface design for
  digital libraries of various sorts
• Consider examples from DL usability evaluation as
  sources of insight.
• Look at the distinct requirements of interfaces
  to libraries of video and audio files

3
Caveat

• Note --
• We have a whole class in User System Interface
• Everything in that class is relevant to User
  Interfaces for Digital Libraries
• One evening will not replace that course, nor
  will it capture all of the relevant factors.

4
Note - to do later

• At the end of the class, I will ask you to do a
  reflection on the points raised. You will be
  asked to summarize the most important
  characteristics of a well-developed DL interface.

• As you continue your DL projects, be sure to
  apply the relevant components of these elements.

5
The challenge

• A user interface for digital libraries must
  display large volumes of data effectively.
• Typically the user is presented with one or more
  overlapping windows that can be resized and
  rearranged.
• In digital libraries, a large amount of data
  spread through a number of resources necessitates
  intuitive interfaces for users to query and
  retrieve information.
• The ability to smoothly change the user's
  perspective from high-level summarization
  information down to a specific paragraph of a
  document or scene from a film remains a challenge
  to user interface researchers.

Source http//cimic.rutgers.edu/ieee_dltf.html
6
Expectations of Digital Libraries

• Provide at least those services available in
  traditional libraries
• and more.
• A system is successful only to the degree to
  which the vast majority of its intended users are
  able to use its intended functionality

Hill 97
7
User-centered design

• User-centered design for a digital library must
  include not only systems evaluation but also an
  understanding of the process of information
  seeking and use.
• Compared to a self-evident door handle -- once
  you see it, you know what it does and how to use
  it. No instruction is necessary.

Hill 97
8
Methods of evaluation

• Surveys
• Target user groups
• Focus groups from the intended audiences
• Ethnographic studies
• Audio/video taped sessions of users
• Analysis of feedback and comments
• Demographic analysis of beta tester registration
  data
• Log analysis
• We will consider in more detail next week as we
  look at quality measures

Hill 97
9
Usability inspection of Digital Libraries

• To produce a product with high usability
• Client and user interviews
• Task analysis
• User class definitions
• Usage scenarios
• Iterative usability design
• Prototyping
• Design walk-throughs
• Usability evaluation

Unfortunately, most developers look at usability
analysis as something to do at the end of the
development process as a final test, rather than
as a part of the design process.
Source Hartson 04
10
Evaluation

• Evaulation for any purpose has two major
  components
• Formative
• During development, spot check how things are
  progressing
• Identify problems that may prevent goals from
  being achieved
• Make adjustments to avoid the problems and get
  the project back on track
• Summative
• After development, see how well it all came out
• Lessons learned may be applicable to future
  projects, but are too late to affect the current
  one.
• Needed for reporting back to project sponsors on
  success of the work.

11
Usability evaluation

• Lab-based formative evaluation
• Real and representative users
• Benchmark tasks
• Qualitative and quantitative data
• Leads to redesign where needed
• After deployment
• Real users doing real tasks in daily work
• Summative with respect to the deployed system
• Useful for later versions

12
Usability inspection

• Lower cost option than full lab-based testing
• Applies to early designs, well-developed designs,
  and deployed systems
• Does not employ real users
• Expert based
• Usability engineering practitioners
• May be guided by typical user tasks
• Seeks to predict usability problems that users
  will encounter.

Hartson 04
13
Inspection categories

• User classes
• Know your user
• Example from the cited study
• Scientific researchers in computer science
• Administrators
• Do not use the regular interface, so not
  evaluated
• User tasks
• Search for technical reports on a set of criteria
• Browse the collection
• Register
• Submit
• Harvest

Hartson 04
14
Search expanded

• Search options
• Simple search
• All bibliographic fields
• Group results by archive
• Sort
• Advanced search
• Focus on specific fields with filter options

Hartson 04
15
Results - 1

• Submit and Harvest tasks not evaluated
• Specialized domain requirements
• Need evaluation with real users to do meaningful
  testing
• Report on Problems Found
• Usability problem types
• Wording, consistency
• Functionality
• Search and browse functionality
• Problem anything that impacts the users task
  performance or satisfaction.

Hartson 04
16
Categories of Problems

• General to most applications, GUIs
• Wording
• Consistency
• Graphic layout and organization
• Users model of the system

• Digital Library functionality
• Browsing
• Filtering
• Searching
• Document submission functions

Hartson 04
17
Wording

• About 36 of the problems in the case
• Precise use of words in user interfaces is one
  of the most important design considerations for
  usability
• Clear, complete, correct
• Button and tab labels
• Menu choices
• Web links
• Crucial to help users learn and understand
  functionality
• Easiest problems to fix if someone with right
  skills is on the team.

Hartson 04
18
Search and Browse functionality

• Pretty basic to what a DL does!
• 18 of the problems were in that area.
• Designers consider these separate functions
• Users see them as extremely closely related
• Find the desired resource
• Should be designed together

Hartson 04
19
Usual Suspects

• Digital libraries prone to the same design faults
  as other interactive systems
• Consistency
• group and archive used interchangeably
• Different labels for the same concept used in
  different places
• Simple search on tab, Search all bibliographic
  field at function location
• Multiple terms referring to the same concept
  confuse users, slow learning
• Standardize terminology and check it carefully

Hartson 04
20
Usual Suspects - 2

• Problems with Feedback
• Clearly indicate where the user is in the overall
  system
• Clicking a tab does not result in highlighting or
  any kind of feedback about which tab is the
  currently active choice.
• Selected institution (archive) highlighted when
  chosen, but not maintained after some other
  actions.

Hartson 04
21
Usual suspects - 3

• Wording
• Use of jargon or slang, or unclear or missing
  labels
• Challenge for users
• Example in NCSTRL
• Several dates used. The labels for the dates do
  not clearly described what each represents.
• discovery date which is different from
  accession date
• Discovery date -- probably a developers term, and
  not likely to be of interest to the user.
• Use terms that are meaningful to users without
  explanation whenever possible. Resist presenting
  data that is not useful for user purposes.

Hartson 04
22
Usual suspects - 4

• Wording, continued
• Example Submit to CoRR tab
• Could be Submit Technical Report(s) to CoRR
• Example Search all bibliographic fields
• Could be Simple Search Search all bibliograhic
  fields in selected archive (or for selected
  institution
• Other examples of unclear labels
• Archives Set - technical term from OAI-PMH
• DateStamp
• Discovery Date
• Label for the user, not the developer

Hartson 04
23
Usual Suspects - 5

• Incorrect or inappropriate wording
• Search results label for browsing results
• hits (1-n) or total xxx hits displayed
• Not search results, just reports available for
  browsing
• Apparent use of combined code for browse and
  search.
• Label results appropriately, even scrupulously,
  for their real meaning.

Hartson 04
24
Usual suspects - 6

• Appropriate terms
• Use of hits for individual search (or browse)
  results
• Commonly used
• Inappropriate slang, according to usability
  experts
• Considered unattractive, even slightly offensive
• Recommended something like Matches with search
  term
• Cosmetic consideration can have a positive affect
  on users impression of the site.

Hartson 04
25
Layout and design

• The whole point of a graphical user interface is
  to convey more information to the user in a short
  time.
• The GUI must support the user needs
• Example problems in the NCSTRL evaluation
• Menu choices - no logical order
• Reorganize by task or functionality
• Organize task interfaces by categories to present
  a structured system model and reduce cognitive
  workload.

Hartson 04
26
Layout example

• Instead of randomly ordered tabs, group them by
• Information links
• About NCSTRL
• About CoRR
• OAI
• Help
• User tasks
• Simple search
• Advanced search
• Browse
• Register
• Submit technical reports to CoRR

Hartson 04
27
Graphical design

• Proximity of elements suggests associations and
  relatedness
• Search button very close to OR radio box
• Applies equally to all parts of the dialog
• Consider the implications of placement and
  association of graphical elements.

Hartson 04
28
Start off right

• Any application should have a home page that
  explains what the site is about and gives the
  user a sense of the overall site capability and
  use.
• NCSTRL starts with the Simple Search page, with
  no introduction.

29
DL specific problems

• Searching, filtering, browsing
• User view all are aspects of finding a needed
  resource
• Developer view differences based on what must go
  in an index to support searching, how filtering
  is combined with searching to form a new query,
  etc.
• Usability suggestion combine search, browse,
  filter into one selection and navigation
  facility.
• Give users the power to combine these elements to
  serve their needs.

Hartson 04
30
Iterative search

• Search is often implemented as a one-shot
  function.
• Users want to iterate on their query string to
  improve results
• NCSTRL does not show the query that produced the
  given results.
• Users want to prune the result set by applying a
  subsequent query to just those results
• Not available in NCSTRL
• Examples where it is available?

Hartson 04
31
Browsing

• NCSTRL allows browsing only by institutions
  (archive)
• Other possibilities
• Date
• Author
• Subject
• Allow user activity that will serve user needs.
  Try to find out what users want before making
  decisions about services offered.

32
Portal

• A portal ltisgt a single point of access to
  distributed systems that provides services to
  support user needs to search, browse, and
  contribute content, often linking to shared
  existing functionality at other sites.
• Portal pass through problem
• Does the portal add service, or just provide a
  link to a collection of other sites?

Hartson 04
33
Portal - submission

• NCSTRL - submission to CoRR
• Link opens to another page, not directly offering
  the opportunity to submit.
• Disconnect for the user between the original page
  and the action promised.
• Link directly to the service offered without any
  intermediate pages unless needed in support of
  the service.

Hartson 04
34
Summary for NCSTRL case

• System exhibited many typical problems with user
  interfaces
• Investigation illuminated some issues specific to
  digital libraries or other systems for retrieving
  information.

35
Another Case - CITIDEL
36
CITIDEL

• Practical issue
• What would be the results of applying a usability
  review to CITIDEL, similar to that applied to
  NCSTRL?
• A few extra notes that come up in examining
  CITIDEL
• No way to submit a resource (only accepts
  metadata for resources located elsewhere)
• Is that an issue? Why or why not?
• Design of the front page
• Cluttered, confusing
• What is really essential? What is useful? How
  should it be organized?

37
CITIDEL continued
www.citidel.org
38
Video Digital Libraries

• Video digital libraries offer more challenges for
  interface design
• Information attributes are more complex
• Visual, audio, other media
• Indicators and controlling widgets
• Start, stop, reverse, jump to beginning/end, seek
  a particular frame or a frame with a specified
  characteristic

Source Lee 02
39
Video Interface Features

• Video browsing
• Text description
• Transcript
• Single keyframe
• Storyboard
• Option re granularity of keyframe set
• Interactive hierarchical keyframe browser
• Keyframe slide show
• Video summary playing
• Playback
• Transcript playback synch
• Keyframe playback synch
• Text search playback and/or keyframe synch

• Cataloging
• Semi-automatic tool
• Manual tool
• Threshold adjustable before automatic
  segmentation
• Textual Query
• Natural language (or keyword)
• Category or keyword list browsing
• Audio information for indexing, browsing
• Intelligent frame selection

Source Lee 02
40
Common features for Video DLs

• Most systems use a textual querying interface and
  few systems provide any form of visual query
  interface, probably indicating the need for
  further development in this area
• Most systems use keyframe(s) as their video
  browsing method
• Playback is provided in all listed systems,
  indicating that playback is regarded as a most
  important interface feature
• Whereas most systems provide more than one video
  browsing method (often transcript playback
  and/or keyframe playback), browsing aids such
  as synchronisation between different browsing
  methods are not often facilitated.

Source Lee 02
41
Stages of Information seeking in Video Digital
Libraries

• Browsing and then selecting video programs (as a
  collection)
• Querying within a video program (content
  querying)
• Browsing the content of a video program
• Watching (part of) a video program
• Re-querying the video digital library and/or
  within a video program

Source Lee 02
42
Summarizing stages of information seeking and the
interface elements that support them as described
in four researchers work.
Source Lee 02
43
Granularity in Video Browsing

• Abstraction
• Reducing the information available to a
  manageable, usable subset
• Traditional video audio browsing
• One point of access
• Sequential
• Fast forward
• Difficult to see the content
• Need to return to the beginning to repeat search

Source Lee 02
44
Video Abstraction

• Levels to present (from Shneiderman 98)
• Overview first
• Zoom and Filter
• Details on Demand
• Example levels (from Christel 97)
• Title text format, very high level overview
• Poster frame single frame taken from the video
• Filmstrip a set of frames taken from the video
• Skim multiple significant bits of video
  sequences
• Time reference
• Significant in video
• Options include simple timeline, text
  specification of time of the current frame, depth
  of browsing unit

Source Lee 02
45
Keyframe browsing

• Extract a set of frames from the video
• Display each as a still image
• Link each to play the video from that point
• Selection is not random
• Video analysis allows recognition
• Sudden change of camera shot
• Scenes with motion or largely stationary
• Video indexing based on frame-by-frame image
  comparison
• Similar to thumbnail browsing of image
  collections

Source Lee 02
46
Keyframe extraction for display on browsing
interface
Source Lee 02
47
Keyframe extraction

• Manual
• Owner or editor explicitly selects the frames to
  be used as index elements
• Automatic
• Subsampling - select from regular intervals
• Easy, but may not be the best representation
• Automatic segmentation - break the video into
  meaningful chunks and sample each
• Shot boundary detection - note switch from one
  camera to another, or distinct events from one
  camera

Source Lee 02
48
Displaying the frames

• Once the key frames are selected, display them
  for effective user interaction
• Storyboard
• Miniaturized keyframes in chronological order
• Aka keyframe list or filmstrip
• Slide show
• Keyframes displayed one at a time
• Hierarchically arranged
• Good when content is structured

49
More detail

• For much more detail about Video browsing and
  presentation, see Lee 02.

50
Summary

• Much of digital library user interface design and
  usability analysis is the same as that of other
  web services
• Keep the user central in the design phase
• Be careful about word use
• Organize the graphics and layout carefully
• Think about the user experience
• Some special considerations about DL usability
  have to do with DL services
• Search, filter, browse
• Connections with other collections to which this
  is a portal

51
References

• Adam, N., Holowczak, R., Halem, M., Lal, N., and
  Yesha, Y. Digital Lbrary Technical Committee
  cimic.rutgers.edu/ieee_dltf.html
• Christel 97 Christel, M., Winkler, D. and
  Taylor, C. (1997) Multimedia abstractions for a
  digital video library Proceedings of the 2nd
  ACM International Conference on Digital Libraries
  (DL 97), Philadelphia, PA July, pp 21-29
• Hartson, H. R., Shivakmar, P, and Perez-Quiñones
  (2004) Usability inspection of digital
  libraries a case study International Joural of
  Digital Libraries 4 108-123
• Hill, L., Dolin, R., Frew, J., Kemp, R.,
  Larsgaard, M., Montello, D., Rae, M., and
  Simpson, J. user Evaluation Summary of the
  Metholologies and Results for the Alexandria
  Digital Library, University of California at
  Santa Barbara. www.asis.org/annual-97/alexia.htm
• Lee 02 Lee, H., and Smeaton, A. (2002)
  Designing the User Interface for the Físchlár
  Digital Video Library Journal of Digital
  Information, Volume 2, Issue 4 May 2002
  http//jodi.tamu.edu/Articles/v02/i04/Lee/2
• Shneiderman 98 Shneiderman, B (1998) Designing
  the user interface strategies for effective
  human-computer interaction, 3rd edition (Addison
  Wesley Longman)
