Amazon has low levels of anthropogenic emissions ..

1
The Impact of Secondary Organic Aerosol
Derivatives of Isoprene on Cloud Formation and
Albedo

• Akua Asa-Awuku
• EAS6410 Term Paper Presentation

2
Summary

• Motivation
• Biogenic Emissions
• Sources of Isoprene
• Sources of SOA from Isoprene
• The impact of SOAs on Cloud Formation
• Cloud Formation and Albedo
• Hydrological Implications

3
The Importance of Biogenic Emissions

• Amazon has low levels of anthropogenic emissions
• Isoprene emissions in US larger than
  anthropogenic particulate matter
• Eight Different Vegetation Types are major
  sources of Isoprene

4
Major Sources of NMHC
Tg C yr-1
5
What is Isoprene

• Olefinic
• Highly reactive Double Bonds
• Volatile Organic Compound (VOC)
• Non-Methane Hydrogen Carbon (NHMC)

6
Products of Isoprene Photooxidation
7
Derivatives of Photoxidation

• Assumed to be extremely volatile (e.g
  formaldehyde)
• Assumed Most likely not to be SOAs
• Two newly identified species hypothesized to be
  SOAs from photooxidation of isoprene
• Formation of SOA via acidic catalysts

8
Data Collection

• Data Samples collected from LBA-CLAIRE campaign
  July 25 -27 Claeys, 2004
• Assumptions
• Very low Anthropogenic emissions
• Tropics site of high photoxidation
• Samples Subjected to GS-MS

9
SOA from Isoprene

• Gas Chromatography results that show presence of
  a product of isoprene photo-oxidation
• Similar 5 carbon skeleton as that of isoprene

10
SOA from Isoprene

• Proposed formation of the 2-methyltetrols from
  isoprene by reaction with OHO2 followed by
  self-and cross-reactions with radicals
• Intermediate 1,2, diols have been previously
  reported under low NOx conditions Ruppert, 2000

11
Significance of (1) and (2)

• SOAs have low yield from Isoprene photooxidation
• However, large emissions of Isoprene, suggest
  significant annual formation of SOAs
• Estimated 2 Tg per year of (1) and (2) in Amazon
  Basin
• IPCC estimates 8 to 40 Tg of biogenic SOA
  annually
• Low Vapor Pressure and High Hygroscopicity

12
SOAs via Sulfuric Acid Catalysts

• Urban and Rural Areas contain sufficient amounts
  of background acidic catalysts
• Also significant emissions of Isoprene in these
  regions
• Limbeck explained that proposed pathway
  contribute to the explanation of HULIS substances
  on continental Europe

13

• Reaction Yield increases with catalyst
• Influence of ozone as competing oxidant
• Effect of Relative air Humidity

14
Short Recap

• SOAs from Isoprene Exist
• Photooxidative products have low vapor pressures
• Humic-like substances generated from acidic
  catalysts
• All SOAs from Isoprene can be considered to be
  highly hydroscopic

15
Cloud Formation

• Kohler Equation
• Kelvin Effects
• Strong functions of Surface Tension
• Humic-like aerosols decrease s

16
Decreasing Surface Tension
17
Kohler Curves
18
Consequences of Surfactants

• Great Cloud Droplet Number
• 30 decrease in s yields a 20 increase in
  droplet number
• Smaller cloud droplet Radii
• Average 6 decrease in droplet size
• Significant Change in Cloud Properties (hence
  Albedo)

19
Droplet Number and Albedo
20
Albedo and Cloud Optical Thickness
21
Susceptiblity

• defined as the sensitivity of cloud albedo in
  comparison to cloud droplet number concentration
• ten percent increase in droplet number
  concentration, leads to an increase of 0.75 in
  albedo

22
Albedo and Cloud Optical Thickness
23
Hydrological Cycle
Cloud Albedo
Cloud Formation
SOA Formation
Isoprene Emissions
Precipitation/ Water Stress
Surface Temperature
24
Conclusions

• SOAs from Isoprene do exist
• Humic-like SOAs decrease surface tensions of
  pure water by 30 increase the droplet number
  concentration by 20
• 20 increase in droplet number, correlates to a
  change in top of atmospheric cloud albedo of
  nearly 1
• a global mean forcing of almost -1 Wm-2 due to
  SOAs from Isoprene

25
References

• Barth, Mary et. al., Future Scientific
  Directions Coupling between land ecosystems and
  the atmospheric hydrologic cycle through biogenic
  aerosol pathways., Bulletin of the American
  Meteorological Society, (submitted)
• Brasseur, G., J. Orlando and G. Tyndall,
  Atmospheric Chemistry and Global Change, Oxford
  Univ. Press, New York, NY,1999
• Claeys M, Graham B, Vas G, Wang W Vermeylen R,
  Pashaynshka V, Cafmeyer J, Guyon P, Andrae MO,
  Artaxo P, Maehunt W., Formation of Secondary
  Organic Aerosols through photooxidation of
  Isoprene, Science, 202 (5661)1173-1176 Feb. 20.
  2004
• Helmig, Detlev .,Ben Balsley, Kenneth Davis,
  Laura R. Kcuck. Mike Jensen, John Bognar, Tyrrel
  Smith Jr., Rosaura Vasquez Arrieta, Roldolfo
  Rodriguez, and John W. Berks., Vertical profiling
  and determination of landscape fluxes of biogenic
  non methange hydrocarbons with the planetary
  boundary layer in the Peruvian Amazon, J.
  Geophys. Res.103 (D19) 25519-25532, 1998
• Durieux, L., L.A.T. Machado, H. Laurent, The
  impact of deforestation on cloud cover over the
  Amazon arc of deforestation, Remote Sensing of
  Environ., 86, 132-140, 2003.
• Facchini, M.., M. Mircea, S. Fuzzi, and R. J.
  Charlson, Cloud albedo enhancement by
  surface-active organic solutes in growing
  droplets, Nature, 401, 257-259. 1999
• Fall, R. and M.C. Wildermuth. Isoprene synthase
  From biochemical mechanism to emission algorithm,
  J. Geophys. Res.103 (D19) 25599-25609, 1998.
• Griffin, R.J., D.R. Cocker III, J.H. Seinfeld and
  D. Dabdub. Estimate of global atmospheric organic
  aerosol from oxidation of biogenic hydrocarbons,
  Geophys. Res. Lett., 26 (17), 2721-2724, 1999.
• Guenther, A., C.N. Hewitt, D. Erickson, R. Fall,
  C. Geron, T. Graedel, P. Harley, L. Klinger, M.
  Lerdau, W.A. Mckay, T. Pierce, B. Scholes, R.
  Steinbrecher, R. Tallamraju, J. Taylor and P.
  Zimmerman, A global model of natural volatile
  organic compound emissions, J.Geophys. Res. 100,
  8873-8892,1995.
• Guenther, A., S. Archer, J. Greenberg, P. Harley,
  D. Helmig, L. Klinger, L. Vierling, M.
  Wildermuth, Biogenic hydrocarbon emissions and
  landcover/climate change in a subtropical
  savanna, Phys. Chem. Earth (B), 24, 659-667,
  1999.
• Jang, M., and R. Kamens, Atmospheric secondary
  aerosol formation by heterogeneous reaction of
  aldehydes in the presence of a sulfuric acid
  aerosol catalyst, Environ. Sci. Technol., 35,
  4758-4766, 2001.
• Klinger, L.F., J. Greenberg, A. Guenther, G.
  Tyndall, P. Zimmerman, M. MBangui, J.M.
  Moutsambot, and D. Kenfck, Patterns in volatile
  organic compound emissions along a savanna
  rainforesst gradient in central Africa, J.
  Geophys. Res., 103, 1443-1454, 1998.
• Limbeck, A., M. Kulmala, and H. Puxbuam,
  Secondary organic aerosol formation in the
  atmosphere via heterogeneous reaction of gaseous
  isoprene on acidic particles, Geophys. Res.
  Lett., 30 (19), 1996, 2003. doi
  10.1029/2003GL017738
• Otter, L.B., Guenther, A., Greenber, J.,
  Seasonal and spatial vatirations in biogeneic
  hydrocarbon emissions from southern African
  savannas and woodlands, Atmospheric Enirmonmet,
  36, 4265-4275, 2002.
• Pétron, G., P. Harley, J. Greenberg, A. Guenther,
  Seasonal temperature variations influence
  isoprene emission, Geophys. Res. Lett., 28,
  1707-1710, 2000.
• Pirjola Liisa, Effects of the increased UV
  radiation and biogenic VOC emissions on Ultra
  fine sulphate aerosol Formation, J.Aerosol Sci.,
  30, 3, 355-367, 1999.
• Roberts, G. C., M. O. Andreae, J. Zhou, P.
  Artaxo, Cloud condensation nuclei in the Amazon
  Basin Marine conditions over a continent?,
  Geophys. Res. Lett., 28, 2807-2810, 2001.
• Seinfeld, J., and N. Pandis, Atmospheric
  Chemistry and Physics From air pollution to
  climate change, John Wiley Sons, Inc., New
  York, NY 1998.
