Network Coding Project presentation

1
Network Coding Project presentation

• Communication Theory
• 16332545

Amith Vikram Atin Kumar Jasvinder
Singh Vinoo Ganesan
2
Outline

• Introduction
• Network coding concept
• Literature Survey
• Terminology and Notation
• Study and Implementation
• Solvability in Multicast Networks
• Algorithm and Pseudo-code
• Low Complexity Network Codes
• Network Recovery and Management
• Scope for future work

3
Network Coding Concept

• Goal To transfer data at the maximum achievable
  throughput in a network.
• Idea Process incoming data at nodes in the
  network

Introduction
4
Literature Survey

• Network Information Flow - Ahlswede, Cai, Li,
  Yeung, 2000
• Characterized the admissible coding rate region
  for multicast networks
• Proved that maximum throughput in a network can
  be achieved using coding
• Linear network Coding Li, Yeung, Cai, 2003
• Coding at nodes treated as linear transformation
  of incoming data
• Showed that individual maxflow bounds of each
  receiver can be achieved but over a time period
  of the LCM of the maxflow bounds
• Algebraic Approach Koetter and Medard, 2002
• Proposed algebraic framework to study networks
  and capacity
• Necessary and sufficient conditions for coding to
  be acheivable
• Necessary and sufficient conditions for
  robustness to link failures
• Network Management Ho, Koetter and Medard,2002
• Quantify Network Management information required
  to affect link failure recovery
• Low complexity Network Codes Jaggi, Kamal Jain,
  Philip Chou,2003
• Field size and thus arithmetic complexity is
  small link usage is lower

Introduction
5
Terminology and Notation

• Network denoted as a graph G(V,E)
• V ----- Set of vertices (nodes)
• E ----- Set of Edges (line joining pairs of
  vertices)
• Input vector at source s x x1,x2,,xn
• Information on each outgoing link e of source

Introduction
6
Terminology and Notation

• Information on outgoing link e on intermediate
  node
• where m is the number of incoming edges on
  the node e
• ye is the incoming information
  on the incoming link e
• Output vector at the destination (sink) node
• z z1,,zn

Introduction
7
Terminology and Notation

• Output vector z is z x M
• where M is the system transfer matrix
• M A G B
• where A is ai,j is a n k matrix where
  k is total number of edges in the
  network.
• G (I-F)-1 is the k k
  adjacency matrix
• B is ei,j is a k n matrix

Introduction
8
Terminology and Notation
Cut A partition of vertex set into 2 classes, S
containing source and S containing the
sink. Value of the cut where C(e) is the
rate constraint of each link
Min-Cut Max-Flow
Lemma Let G be a graph with source node s
and sink nodes t1 and t2, and rate
constraints R .Then for l1,2, the maxflow from
s to tl is the value of the min-cut between s and
tl and is denoted by maxflow(s,tl)

y
t2
Introduction
9
Study and Implementation

• Finding a network code for a given multicast
  problem
• Solvability conditions
• Single source single sink det (M) ? 0
• Single source multiple sink ? det (Mi) ? 0
• Multiple source multiple sink det (Mii) ? 0
•
  det (Mii) 0

i
Study and Implementation
10
Algorithm for finding network codes

• Given polynomial F(x), find a such that
• F(a) ? 0
• Find maximal degree ? of F in any variable xi
  and choose smallest i such that
•
  2i gt ?

Study and Implementation
11
Algorithm for finding network codes

• Find an element at in F2i such that
• F(x) ? 0 and F
  F(x)
• If t n then halt, else t t1, goto previous
  step
• a is the solution to the above problem

xtat
xtat
Study and Implementation
12
Bound on Field size

• There exists a solution to the single source
  multicast network coding problem in a finite
  field 2m with

Study and Implementation
13
Simulation Steps

• Generate a random network (single source
  multicast)
• Find the network capacity using maxflow algorithm
• Generate matrices A,G, B from the network
  topology
• Solve for the network parameters

Study and Implementation
14
Coding vs Routing

• Is coding really required?
• How to check if routing achieves capacity?
• Routing is a special case of coding with
  constraints on codes
• Put constraints on codes and solve to see if
  routing is feasible

Study and Implementation
15
Simulation results
b2
b2
Study and Implementation
16
Simulation results
AT
Study and Implementation
17
Simulation results
Study and Implementation
18
Low Complexity Network Codes

• Gives a solution to the single source multicast
  network coding problem in a finite field 2m with
• Uses only union of edge-disjoint paths to each
  receiver thus avoiding flooding

Study and Implementation
19
Network Recovery and Management

• Nodes need to change their behavior for
  recovery from link failures
• Network management involves switching between
  appropriate codes for recovery from link failures
• Management requirement can be quantified by the
  number of different codes needed

Study and Implementation
20
Network Recovery and Management

• Two formulations of quantification
• Centralized formulation
• Network behavior described by an overall code
• Network management requirement quantified by
  logarithm of the number of codes needed
• Node based formulation
• Network behavior described by the number of nodes
  which change behavior
• Quantified by the sum of the logarithm of the
  number of different behaviors of each node

Study and Implementation
21
Network Recovery and Management
Theorem For a single receiver network with r
processes and a minimum capacity of C, tight
bounds on the number of codes needed for the
no-failure scenario and all single link failures,
assuming they are recoverable are
22
To be included in the final report

• Faster implementation of the code- generating
  algorithm
• Comparison of Routing vs Coding on large number
  of random networks

23
Future direction of research

• Joint source-channel-network coding
