Title: Overview of a Patternbased Reference Architecture


1
Overview of a Pattern-based Reference Architecture
  • Carroll A. Hood
  • GEOSS Chief Architect

2
Outline
  • What is a Pattern-based Reference Architecture?
  • Example
  • Why is this relevant to GEOSS?

3
Pattern based Reference Architecture
  • Patterns Abstractions of design solutions
  • Reference Architecture (RA) Abstraction of an
    architecture with common characteristics and
    quality attributes
  • Tailorable
  • Reduces Risk
  • Encourages Reuse
  • What and Who NOT How and Why

RAs The Building Blocks for GEOSS
4
Characteristics of an RA
  • Structure
  • Entities
  • Internal/External Interfaces
  • Behaviors
  • Global Rules
  • Standards
  • Constraints

5
Reference Architecture ExampleBuilding a Taco
6
Structure Value Stream and IPO Chart
High Level Value Stream
Go to Store
Buy Stuff
Take Stuff Home
Prepare Taco
Consume Taco
Paper
Go to Store
Pencil/Pen
Shopping List
  • Check Pantry/Frig
  • Make List
  • Get in Car w/list
  • Drive to Store

Keys
ATM Card
Input-Process-Output (IPO) Chart for one Step in
Value Stream
7
Structure Domain Collaboration Diagram
Structure provides a top-level organization,
defines entities, identifies interfaces, and
scopes the enterprise
8
Behaviors List of Use Cases
  • Home
  • Put Food Away (pattern)
  • Into Pantry
  • Into Refrigerator
  • Prepare Beef
  • Heat Shells
  • Assemble Ingredients (pattern)
  • From Pantry
  • From Refrigerator
  • Build Taco
  • Ignore Cat (begging for people food)
  • Grocery Store
  • Select Commodity (pattern)
  • Ground Beef
  • Cheese
  • Beer
  • Etc.
  • Manage Cart (pattern)
  • Insert item
  • Remove Item
  • Pay for Groceries

Behaviors describe the interactions between
entities
9
Use Case Example Build Taco
Use Case ZZZ Build Taco
  • Description This use case describes the
    construction of a fully-loaded taco, ready-to-eat
  • Actors Me
  • Preconditions All ingredients have been moved to
    the island (UC XXX Assemble Ingredients, etc)
  • Flow of Events for Main Scenario
  • Take heated shell from cookie sheet
  • Spoon Beef inside empty shell
  • Pour some taco sauce on top of beef
  • Spoon dabs Sour Cream on top of that
  • Sprinkle grated cheese across top
  • Insert chopped tomato
  • Stuff chopped lettuce on top of cheese
  • Alternate Scenario
  • If taco shell breaks at any point during steps
    1-7,
  • place ingredients accumulated so far onto plate
    and continue with remaining step.
  • put ingredients accumulated so far into new shell
    and continue with remaining steps
  • Move Step 5 (cheese) to end.
  • Post Conditions Ensure beer is still cold
    before moving to Dining Room
  • Special Conditions none

10
Global Rules Standards and Constraints
  • Standards
  • To my knowledge, there are no ISO Standards that
    come into play here
  • Perhaps some USDA Regulations (Food safety)
  • Tastes Great, Less Filling (community-based
    standard)
  • Constraints
  • Budget
  • Hours of Operation of Grocery Store
  • Dinner Time

Constraints and standards do not define but help
shape the solution space
11
Relevance to GEOSS
  • GEOSS is a system of system of systems
  • No single large procurement
  • Multiple entitles evolving toward GEOSS-level
    interoperability over time
  • Some new elements will be developed hopefully
    with GEOSS-level interoperability in mind
  • Enterprise-wide optimization will require
    collaboration between Government, Academia, and
    the Private Sector
  • Reference Architectures for specific GEOSS
    elements or threads
  • Provides a blueprint for development/evolution
    within a common GEOSS interoperability framework
  • Allows for flexibility and innovation in design
    and implementation
  • Private Sector is in best position to lead (not
    own) RA development for GEOSS
  • Its what we do (This is why we are all here)
  • RAs are not static they will evolve as our
    knowledge and capabilities expand
  • Buy-in at a high level (i.e., RAs) will enable
    all of us to more forward at more detailed levels
    more smartly and will help GEOSS become real
