Title: SNS Timing System


1
  • SNS Timing System
  • EPICS Workshop
  • April 28, 2005
  • Coles Sibley
  • Dave Thompson
  • SNS Global Controls

2
Design Decisions
  • MPS and Timing systems are tightly integrated.
    Timing systems should RESPECT machine
    protection system beam power and pulse width
    limits to not challenge MPS system.
  • Timing system will run at 60 Hz. (but dont
    preclude the possibility of 120 Hz).
  • Super cycle will be 10 seconds (600 cycles, 0.1
    Hz rep-rate resolution).
  • As much as possible should be done in hardware.
  • As little as possible should be relegated to the
    client IOCs.
  • Synchronous with Ring RF, not linac RF
  • System hardware design from RHIC

3
Machine / Beam Mode Definitions
  • Machine mode selected by Key switch in control
    room, Beam Mode selected by Key or software.
    Switches read by MPS PLC system and distributed
    through timing system.
  • Machine Mode defines where the beam goes
  • MEBT Beam Stop
  • CCL Beam Stop
  • Linac Dump
  • Injection Dump
  • Ring
  • Extraction Dump
  • Target
  • Beam Mode defines allowable beam charge or power
  • Pilot pulse (10 usec)
  • Diagnostics pulse (50 usec)
  • Tuning pulse (100 usec)
  • Full Pulse Width (1 msec)
  • Full Power (Depends on Dump)

4
Timing System Components
Event
RTDL
Link
SNS Time Stamps Beam data
Experimental
Halls
Master
Timing IOC
RF Gates Extraction Kickers TxHV Gates
Timing
SNS Real
10 MHz
Slave
Time Data
Crystal
(V124S)
Link
Osc.
Master
High resolution timestamps Machine Modes
Machine
SNS Event
32 PLL
Link
Protection
(33 MHz)
System
Master
Ring RF
SNS Timestamps Remote Reset Synchronous ISRs
ICS IOC's
Timing Reference Generator
AC
SNS Utility
Module
Line
Beam Delay Beam Phase Micro pulse width Macro
pulse width
LEBT
4 PLL
Chopper
(64 MHz)
Neutron
Choppers
SNS Time stamps Delays Gates Triggers
Diagnostics
Timing System
Subsystem Hardware
Hardware
Timing System Users
Experimental Systems
5
Timeline (from the timing system point of view)
Informational Events, non critical timing
Time Critical Events, (soft events disabled)
Real-Time Data Link(RTDL)
RTDL parameter transmission(for next cycle)
RTDLTransmit
Extract
MPS Inhibit
Snapshot, 1Hz, 6Hz, etc
Beam On
MPS Fault
(Alternate) Cycle Start
End Injection
RF High Voltage Events
Cycle Start
System xxx Trigger Events
Extraction Kicker Charge
RTDL Valid
Event Link
Beam On Range
Beam On Range
Allowed Range for Variable Triggers
Anytime
Anytime
Machine
MPS Post Mortem
Line-Synch Reference Clock
beam accumulation
-60 Hz ZeroCrossing
60 Hz ZeroCrossing
0
2 ms
1 ms
6 ms
4 ms
7 ms
5 ms
8 ms
3 ms
6
RTDL Sequencer
  • Runs at 60 Hz. Driven by the RTDL Valid Event
    interrupt.
  • Loads the RTDL frames for the next cycle (the
    cycle after the upcoming Cycle Start event,
    including
  • Time of next Cycle Start (From GPS 162/3 msec)
    for time stamps
  • Ring revolution frequency (from counter module)
  • Line crossing phase error (from timing reference
    generator)
  • Beam flavor parameters (Beam profile)
  • Machine and Beam Mode (MPS Mode Masking)
  • Last frame is 24-bit CRC on all RTDL data.
  • Writes correction term (based on measured
    event-link clock speed) to timing reference
    generator.

7
Event Link Sequencer
  • Runs at 60 Hz, driven by the RTDL Valid event.
  • Enables gates for variable rep-rate events that
    are scheduled to fire on the next machine cycle.
  • Handles the bookeeping tasks required for
    setting new rep-rates.

Rep-Rate Pattern Generator
  • Actually, a set of EPICS genSub records.
  • Computes the rep-rate patterns used by the
    Event Link Sequencer to schedule which events
    should occur on each cycle.
  • Can also be used on Client IOCs to do local
    rep-rates.

8
Variable Rep-Rates genSub Record
  • Inputs
  • Desired Rep-Rate (double)
  • Constraint Pattern (structure)
  • V124S Gate Address (card signal)
  • Mode selector
  • 0 Fixed (ignore pattern)
  • 1 Variable (use pattern)
  • Offset from Constraint Pattern (long)
  • n Precede constraint pattern by n pulses
  • n Follow constraint pattern by n pulses
  • 0 No offset (pattern must be coincident with
    constraint pattern)
  • Outputs
  • Actual Rep-Rate (double)
  • Rep-Rate Pattern (structure)

Note Constraint pattern can come from another
repRate genSub record (e.g. for the gate this
gate depends on) or from a combination of
patterns (computed by another genSub record).
9
Application Beam Control
Hardware interface between MPS and Timing
V124S
Trigger Control Chassis
Event Link

Auto Reset Latched MPS PLC
MPS Inputs
To Source
Cycle Start
Beam On
To RFQ
Source RF
Delayed Source RF
To Chopper
RFQ
From RFQ LLRF Controller
10
Event Link Monitor
  • Monitors event in a supercycle
  • Compare with event link sequence, fault on
    difference
  • Hardware check against software errors
  • Hardware read back for pattern generators

11
Application Ion Source Control
End Injection
Warm LinacLLRF
Extract
Source RF
Beam On
Cycle Start
Event Link
Growth
Source On
Growth
Delayed Source On
RFQ
Cycle Start
Beam On
0
2 ms
1 ms
6 ms
4 ms
7 ms
5 ms
8 ms
3 ms
12
Application Linac RF Control
  • Requirements
  • RF Gates should always end at End Injection
    event. Increasing the gate width decreases the
    delay (and vice versa).
  • Low-level RF gate should come on about 100 mSec
    before beam (300 mSec in super-conducting linac).
  • HV power supplies should come on about 100 mSec
    before Low-Level RF.
  • Variable rep rates replaced with fixed events
  • 1, 2, 5, 10, 20, 30, and 60 Hz
  • Modulator HV Power supplies need an upgrade
    before 31 Hz or higher permitted
  • Individual RF gate widths adjustable but sets a
    constraint on maximum beam pulse width

13
Application Linac RF Control
RF Gate Relationships
RF High Voltage Events
End Injection
Extract
Source RF
Beam On
Cycle Start
Event Link
Beam On
Source On
Warm LLRF
Warm HPRF
Cold LLRF
Cold HPRF
0
2 ms
1 ms
6 ms
4 ms
7 ms
5 ms
8 ms
3 ms
14
Typical User Defined Beam Flavors
  • Reconfiguration requires beam off, flavor
    integrated charge and power recomputed, beam
    scheduled power calculated against machine/beam
    modes.
  • Flavors used by LLRF and Ring RF for feed forward
    loops.
  • 1 - Beam Off
  • 2 - 10 usec, (Chopped) (Fast faraday cup)
  • 3 - 50 usec , (Chopped) (All wire scanners,
    faraday cups)
  • 4 - 100 usec , (Chopped)
  • 5 - Physics , (Unchopped)
  • 6 Arbitrary 1 msec gates, 50 usec beam
  • 7 - Reserved
  • 8 - Normal, ie. 1060 turns, 50 usec ramp up

15
LEBT Chopper Pattern Generator
16
Beam Profile Requirements
  • Ring Commissioning
  • 10 turns, 1 per 100usec (next generation of
    chopper)
  • Nominal beam to Linac Dump (Beam flavor 1)
  • Single turn (beam flavor 2)
  • Chopped beam to ring (beam flavor 3)

17
Pattern Generator CD4 in 2006
  • Fixed RF rep rates limited to lt 30 Hz
  • 1 Hz beam, lt 50 usec gate width thru Dec 2005
  • LEBT Chopper commissioned, Beam gate lt 1msec,
    integrated pulse width lt 50usec
  • (LEBT fails with fulll width beam)
  • Beam RR and PW must fall in safe operating
    envelope (May 2006)

18
Beam Scheduling Post CD4
  • SNS runs in loss limited mode (lt10-4), Scale back
    in power until loss limits met.
  • All beam on after trip of gt 5(?) min, pilot pulse
    and power ramp up required
  • Target has limits on machine trips, 25(?) fast
    and 5(?) slow per day. Requirements not defined
    for bad machine days.
  • Target Requirements
  • lt 100 kW, no restrictions
  • gt 100 kW and beam off lt 30 min, no restrictions
  • gt 100 kW and beam off gt 30 min, linear ramp in
    power for 10 min.
  • One diagnostics pulse per super cycle allowed
    (Monitor injection phase painting) implies pulse
    to pulse scheduling.
  • Second target station, More pulse to pulse beam
    mode scheduling required

19
SNS AC Line is being Characterized using Filter
for Neutron Chopper Response
Six day line frequency measurement
60.1 Hz
Line synch installed in controls lab timing
system for distribution to neutron chopper
lab. GPS-based filter with slew rate limit being
studied
60.0 Hz
Limiting Slew Rate results in wide frequency range
59.9 Hz
500usecs
Deviation from Grid in usecs
Deviation in slew rate in mHz/sec
Beam Phase with line delay from 0 to 800 usec in
50 usec increments (2 beam trips) /- 10deg
RFQ Minimal Effect on Beam from 0 to 800usec delay
20
New Requirements
  • Use SLS and Diamond timing hardware (Timo
    Korhonen)
  • 3 D beam bunch shape measurements
  • 12 degree longitudinal length, 402.5 MHz (83
    psec)
  • Need 1 psec stability,
  • 1 to10 psec resolution
  • Use 402.5 or 805 MHz LLRF Reference line as input
    clock
  • Synchronize Beam-On pulse using SLS Hardware
