Title: General Radiation Safety


1
Do not adjust your set
2
Radiation Safety in Medical Practice
  • John Saunderson
  • Radiation Protection Adviser
  • (TPRH ext. 6690, john.saunderson_at_hey.nhs.uk)

3
Programme
  • Introduction
  • Radiation basics and hazards
  • Organising radiation safety
  • Radioactive patients
  • Any questions?

4
  • Ionising radiations
  • x-rays
  • gamma rays (?-rays)
  • beta particles (?)
  • electron beams
  • Not ionising radiations
  • lasers
  • ultraviolet (UV)
  • infrared (IR)
  • ultrasound
  • MRI

5
Radiation basics and hazards
  • Why is it dangerous?
  • Radiation in hospitals

6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
Ionising radiation can cause chemical reactions
in the bodys cells which may
  • do no harm
  • kill the cell
  • cause the cell to multiply out of control
    (cancer)
  • cause the cell to misfunction in some other way.

12
Where very large doses kill many cells
  • radiation burns
  • cateract
  • radiation sickness.

13
Threshold risksVery large doses onlyThe bigger
the dose, the more severe the effect
Staff doses never this big
14
Cancer risksIt is assummed that any dose of
radiation could potentially cause cancer.The
bigger the dose, the more likely the effect will
occur, (but it will probably never occur).
i.e. a bit like crossing the road - the more
times you cross the more likely you are to be run
over, but probably never will.
15
Radiation in hospitals
  • Radioactive substances
  • nuclear medicine
  • pathology
  • radiotherapy
  • X-ray sources
  • Radiology
  • Radiotherapy
  • Pathology .

16
(No Transcript)
17
Leakage
18
All doses should be kept
  • As
  • Low
  • As
  • Reasonably
  • Achievable
  • The ALARA Principle .

19
Basic Principles
  • Time
  • Distance
  • Shielding

20
Distance
  • Double distance 1/4 dose
  • Triple distance 1/9th dose.

21
Shielding
22
Shielding
23
Typical Transmission through Shielding (90 kV)
  • 0.25 mm lead rubber apron ? 8.5
  • 0.35 mm lead rubber apron ? 5
  • 2 x 0.25 mm apron ? 2.5
  • 2 x 0.35 mm apron ? 1.0
  • Double brick wall ? 0.003
  • Plasterboard stud wall ? 32
  • Solid wooden 1 door ? 81
  • Code 3 lead (1.3 mm) ? 0.1.

24
Lead Apron Storage
  • Always return to hanger
  • Do not
  • fold
  • dump on floor and run trolleys over the top of
    them!!!
  • X-ray will check annually
  • But if visibly damaged, ask X-ray to check them.

25
Organising radiation safety
  • Controlled Areas
  • Local Rules
  • Radiation Protection Supervisor
  • Radiation Protection Adviser
  • Radiographer .

26
(No Transcript)
27
www.hullrad.org.uk
28
Radioactive Patients
  • Patients may be radioactive if
  • theyve been injected with or swallowed
    radioactive pharmaceuticals
  • they have solid radioactive sources surgically
    implanted
  • they have been involved in an accident with
    radioactive materials .

29
Radioactive Decay - half life
30
Nuclear Medicine Scan
  • Patient injected with or swallows a radioactive
    pharmaceutical
  • Gamma camera traces where that radiopharmaceutical
    is concentrated .

31
(No Transcript)
32
Thyroid treatments with radio-iodine
  • Hyperthyroidism / thyrotoxicosis
  • overactive thyroid - 400 MBq
  • Thyroid cancer
  • must destroy all tumour - 3000 MBq
  • c.f. thyroid scan - 0.2 MBq.

33
Other unsealed source therapies
  • Phosphorus-32 for polycythemia (too many red
    blood cells)
  • Yttrium-90 colloid for arthritic conditions
  • Strontium-90 for bone metastases.

34
Brachytherapy (radioactive implants)
  • Intracavity afterloading
  • Iridium wire afterloading
  • Iridium pins
  • Iodine-125 seeds .

35
LDR-Selectron
36
HDR-microSelectron
37
Iridium Implant
38
Casualties Contaminated by Low Level Radioactive
Substances
  • Life saving treatment will override all other
    action
  • Seek expert advice from radiation physicist
    a.s.a.p.
  • Avoid spread of contamination
  • Collect everything that comes into contact with
    radioactive substances (e.g. clothes, swabs,
    fluids, etc.).

39
f i n
