Introduction Recherche dinformation

1
IntroductionRecherche dinformation

• Jian-Yun Nie
• (Based on van Rijsbergens introduction)

2
Plan

• Definition
• History
• Experimental tradition
• Methods
• Query
• Indexing
• Matching
• Results
• Evaluation
• Current situation
• Research

3
Definition
4
Important concepts

• Document an entity that contains some
  description of information, may be in form of
  text, image, graphic, video, speech, etc.
• Document collection a set of documents (may be
  static or dynamic)
• User
• Information need the users requirement of
  information
• Query (request) a description of information
  need, usually in natural language
• Relevance (relevant document) a document that
  contains the required information (Pertinence)
• Correspondence, degree of relevance, relevance
  score, the degree of belief (by the system)
  that a document is relevant
• Judge user/system
• Indexing a process that transforms a document
  into a form of internal representation
• Retrieval an operation that determines the
  documents to be retrieved
• Response (answer) the documents returned by the
  system (usually a ranked list)

5
What is IR?

• (Salton, 1968) Information retrieval is a field
  concerned with the structure, analysis,
  organization, storage, searching, and retrieval
  of information.
• (Lancaster, 1968) An information retrieval system
  does not inform (i.e. change the knowledge of)
  the user on the subject of his inquiry. It merely
  informs on the existence (or non-existence) and
  whereabouts of documents relating to his request.

• (Needham, 1977)..the complexity arises from the
  impossibility of describing the content of a
  document, or the intent of request, precisely, or
  unambiguously

6
Data retrieval v.s. IR (VR 79)
7
History
8
Important events in IR (1)

• 1952 Mooers coins IR
• 1958 International Conference on Scientific
  Information
• 1960 Cranfield I
• 1960 Maron and Kuhns paper
• 1961 (-1965) Smart built
• 1964 Washington conference on Association Methods
• 1966 Cranfield II
• 1968 Saltons first book
• 197- Cranfield conferences
• 1975 CvRs book
• 1975 Ideal test collection
• 1976 KSJ/SER JASIS paper

9
Important events in IR (2)

• 1978 1st SIGIR
• 1979 1st BCSIRSG
• 1980 1st joint ACM/BCS conference on IR
• 1981 KSJ book on IR Experiments
• 1982 Belkin et al ASK hypothesis
• 1983 - Okapi started
• 1985 RIAO-1
• 1986 CvR logic model
• 1990 Deerwester et al,LSI paper
• 1991 Inquiry started
• 1992 TREC-1
• 1998 Croft Ponte paper on language models

10
Best known researchers (Salton award)
11
Best known researchers (Salton award)
12
Best known researchers (Salton award)
13
Relevant journals and conferences

• Journals
• ACM Transactions on Information Systems (TOIS)
• Information Processing and Management (IPM)
• J. of the American Society for Information
  Science and Technologies (JASIST)
• Information Retrieval
• Conferences
• ACM SIGIR
• CIKM
• TREC
• ECIR
• ACL
• RIAO
• CORIA

14
Experimental tradition
15
Tradition of Experiments

• Strong experimental tradition (from Cranfield)
• To prove that an IR technique or IR system is
  better, the effectiveness should be measured on
  test data
• This tradition has a strong influence to other
  areas (computational linguistics, AI, machine
  translation, etc.)
• Pros
• Develop practically effective approaches
• Experimental evidence to prove a technique
• Avoid nice, but useless theories
• Cons
• Neglect theoretical development
• Difficult to develop new theories and new
  techniques to compete against established methods
• Wide use of heuristics, intuitions, manual
  tuning,, or tricks

16
Experimental Methodology

• Cleverdon Cranfield
• Developed the Cranfield Experiments (funded by
  the National Science Foundation) and introduced
  the concepts recall and precision to study the
  performance of  information retrieval systems.
• Lancaster Medlars
• Report on the evaluation of its operating
  efficiency. American documentation. 20(2)
  119-142 1969 April. Lancaster refined a
  technique of failure analysis for this
  evaluation, seeking to investigate reasons why
  relevant documents were not retrieved.
• Saracevic CWRU
• Theories and experiments related to human
  information behavior human-computer interaction
  from the human viewpoint and modeling
  interaction processes in information retrieval.
  Notion of relevance in relation to information
  and information systems. Theoretical and
  pragmatic study of value of information and
  library services. Nature of information science
  as a field.
• Salton Smart
• "Salton's Magical Automatic Retriever of Text"
• Vector space model, relevance feedback, tfidf,
• Sparck Jones Ideal Test Collection
• Big document collection, large set of various
  queries, exhaustive relevance judgments
• Blair Maron Stairs
• law documents, result analysis
• Harman TREC
• Annual experimental contest
• Large document collections, more realistic
  queries, partial relevance judgments
• Not an ideal test collection, but more realistic

17
Some References on the Web

• Cyril W. Cleverdon, The significance of the
  Cranfield tests on index languages, ACM-SIGIR,
  1991, pp. 3 12, (http//portal.acm.org/citation.
  cfm?id122861)
• David C. Blair , M. E. Maron, An evaluation of
  retrieval effectiveness for a full-text
  document-retrieval system, Communications of the
  ACM, v.28 n.3, p.289-299, March 1985
  (http//portal.acm.org/citation.cfm?id3197dlGUI
  DEcollGUIDECFID65359706CFTOKEN94782922)
• G. Salton , M. E. Lesk, Computer Evaluation of
  Indexing and Text Processing, Journal of the ACM
  (JACM), v.15 n.1, p.8-36, Jan. 1968
  (http//portal.acm.org/citation.cfm?id321441dlG
  UIDEcollGUIDECFID65359986CFTOKEN40286)
• TREC http//trec.nist.gov

18
Evaluation
Query
Document collection
Desired answers
Answers
evaluation
19
Test collection

• Document collection a large set of documents
• Query set a set of queries (usually 50 or more)
• Relevance judgments for each query, determine
  manually the relevant documents in the document
  collection
• In TREC the judgments are not known priori to
  the experiments

20
Methods
21
Indexing-based IR

• Document Query
• indexing indexing
• (Query analysis)
• Representation Representation
• (keywords) Query (keywords)
• evaluation

22
Query
23
Query Language

• Artificial/Natural (web)
• multilingual/cross-lingual
• images
• none at all!

24
Query Definition

• Complete/Incomplete
• Independence/Dependence
• Weighted/Unweighted (tf idf)
• Query expansion/one shot (feedback, web)
• Sense disambiguation
• Cross-lingual

25
Indexing
26
Marons theory of indexing

• ..in the case where the query consists of single
  term, call it B, the probability that a given
  document will be judged relevant by a patron
  submitting B is simply the ratio of the number of
  patrons who submit B as their query and judge
  that document as relevant, to the number of
  patrons, who submit B as their search query
• P(DB) P(D,B) / P(B)

27
Representation of Information

• Discrimination without Representation
  (specificity)
• Representation with Discrimination (exhaustivity)
• TFIDF
• TF importance of term for a document
• IDF Importance of document for term
  (specificity)
• ...defining a concept of information,....that
  once this notion is properly explicated a
  document can be represented by the information
  it contains (CvR, 1979)

28
Maching (query evaluation)
29
Matching (query evaluation)

• exact/partial match e.g SQL/Dice
• Boolean matching (Fairthorne, 50)
• co-ordination level matching (Cleverdon,60)
• cosine correlation (Salton, 70) VS
• probabilistic (ranking principle) (SER,80) PRP
• logical uncertainty principle (CvR, 90) LUP
• Bayesian inference (Croft,90) NET
• Language modeling (PonteCroft 98)

30
Inference

• Deduction/Induction A, A?B infer B
• Cluster Hypothesis
• Association Hypothesis
• P(term1term2)

31
Logic

• It is a common fallacy, underwritten at this date
  by the investment of several million dollars in a
  variety of retrieval hardware, that the algebra
  of Boole (1847) is the appropriate formalism for
  retrieval design..The logic of Brouwer, as
  invoked by Fairthorne, is one such weakening of
  the postulate system, (Mooers, 1961)
• Another one
• Logical Uncertainty Principle (CvR, 1986)

32
Logic

• If Mark were to loose his job, he would work less
• If Mark were to work less, he would be less tense
• If Mark were to loose his job, he would be less
  tense

33
Cluster Hypothesis

• If document X is closely associated with Y, then
  over the population of potential queries the
  probability of relevance for X will be
  approximately the same as the probability of
  relevance for Y, or in symbols
• P(relevanceX) P(relevanceY)
• Document clustering

34
Association Hypothesis

• If one index term X is good at discriminating
  relevant from non-relevant documents, then any
  closely associated index term Y is also likely to
  be good at this.
• P(relevanceX) P(relevanceY)
• Query expansion

35
Models

• Boolean
• Vector Space (metrics) - mixture of things
• Probabilistic (3 models)
• Logical (implication) - what kind of logic
• Language models
• Cognitive (users)

36
Retrieval Result
37
Items Wanted

• Matching/Relevant or Correct/Useful
• The function of a document retrieval system
• cannot be to retrieve all and only the relevant
  documents....but to guide the patron in his
  search for information (Maron)
• Topical/tasks
• Meaning/content

38
Some difficulties with relevance

• Goffman, 1969
• ..that the relevance of the information from one
  document depends upon what is already known about
  the subject, and in turn affects the relevance of
  other documents subsequently examined.
• Maron,
• Just because a document is about the subject
  sought by a patron, that fact does not imply that
  he would judge it relevant.

39
Relevance (Borlund, 2000)

• That is the relevance or irrelevance of a given
  retrieved document may affect the users current
  state of knowledge resulting in a change of the
  users information need, which may lead to a
  change of the users perception/ interpretation
  of the subsequent retrieved documents.

40
Evaluation
41
Error Response

• Precision error where an irrelevant is retrieved
• P(relevant doc. Retrieved)/(retrieved)
• Recall error where a relevant document is not
  retrieved
• R (relevant doc. Retrieved)/(Relevant)
• Trade-off
• F-measure F 2PR/(PR)
• How to cope with lack of recall
• Cranfield ?Ideal test collection ?TREC

42
What is a relevant document?

• Relevance is
• The correspondence between a document and a
  query, a measure of informativeness to the query
• A degree of relation (overlap, relatedness, )
  between document and query
• A measure of utility of the document to the user
• Judged by user / system
• User relevance / system relevance

43
How should relevance be judged?

• Relevance is dependent on
• Document contents
• Information need (query)
• Time constraint
• Purpose of retrieval
• Retrieval environment
• Computer/connection speed
• User interface
• Domain of application (newspaper articles, law,
  patent, medicine )
• Users knowledge
• About the domain of application
• about the system

44
How is relevance judged? (TREC)

• Candidate answers by merging the answers from
  different participating systems
• Several human assessors judge for the same query
• Agreement/disagreement
• Binary value (rel. / irrel.) / multi-valued
• Workable strategy but potential problems
• Some relevant document may not be found by any
  system
• Subjective judgments
• Disagreement between assessors and participants
  (but participants usually respect the judgments
  of assessors)

45
Practice v.s. Experiments

• Practice
• Web
• Electronic Publishing
• Task-oriented IR
• Data Mining
• Knowledge Discovery
• Distance learning
• Video/film asset management
• ExperimentsTREC
• HCI
• Visualisation
• Work in Context, Cognitive approaches
• Cross - lingual
• Cross - media
• Corpus-based IR (inc. wordnet, etc)
• Digital Libraries
• CBIR (Content-Based Image R)
• TDT (Topic Detection and Tracking)

46
Research themes

• Discrimination/Representation
• Data fusion
• Authority/importance models (e.g. PageRank)
• Logic Uncertainty models
• Filtering/Routing
• Language models
• Summarisation
• IR DBMS (inc XML etc)
• Clustering the web
• Visualising the web
• Living with single term queries
• Living with no queries
• Scale free networks
• Trading media (text helps images!)
• Temporal dimensions (topics,events)
• Evaluation (Time to dump P and R?)
• NLP in IR

47
Current situation
48
Where are we now in IR?

• Landmarks
• Hypotheses/Principles
• Postulates of Impotence
• Long-term challenges
• Areas of research

49
Landmarks

• Luhns tf weighting
• Architecture
• Relevance Feedback
• Stemming
• Poisson Model -gt BM25
• Statistical weighting tfidf
• Various models

50
Hypotheses/Principles

• Items may be associated without apparent meaning
  but exploiting their association may help
  retrieval
• P R trade-off ABNO/OBNA
• Exhaustivity/Specificity
• Cluster Hypothesis
• Association Hypothesis
• Probability Ranking Principle
• Logical Uncertainty Principle
• ASK
• Polyrepresentation

51
Postulates of Impotence(according to Swanson,
1988)

• An information need cannot be expressed
  independent of context
• It is impossible to instruct a machine to
  translate a request into adequate search terms
• A documents relevance depends on other seen
  documents
• It is never possible to verify whether all
  relevant documents have been found
• Machines cannot recognize meaning -gt cant beat
  human indexing etc

52
.more postulates

• Word-occurrence statistics can neither represent
  meaning nor substitute for it
• The ability of an IR system to support an
  iterative process cannot be evaluated in terms of
  single-iteration human relevance judgment
• You can have either subtle relevance judgments or
  highly effective mechanised procedures, but not
  both
• Thus, consistently effective fully automatic
  indexing and retrieval is not possible

53
Long-term Challenges workshop Umass. 9/2002

• Global information access Satisfy human
  information needs through natural efficient
  interaction with an automated system that
  leverages world-wide structured and unstructured
  data in any language.
• Contextual Retrieval Combine search technologies
  and knowledge about query and user context into a
  single framework in order to provide the most
  appropriate answer for a users information
  need.

54
Areas of Research

• How does the brain do it? (neuroscience)
• How do we see to retrieve? (computer vision)
• How do we reduce dimensionality in dynamic
  fashion? (Statistics)
• What is a good logic for IR? (mathematical logic)
• What is a good theory of uncertainty?
  (frequency/geometry)
• How do we model context? (HCI)
• How do we formally capture interaction?
• How do we capture implicit/tacit information?
• Is there a theory of information for IR?

55
Images not Text how might thatmake a difference?

• no visual keywords (yet)
• tf/idf issue
• aboutness revisable (eg Maron)
• relevance revisable (eg Goffman)
• feedback requires salience
• aboutness -gt relevance -gt aboutness

56
Text v.s. image

• Text Image
• Keywords Visual features
• Frequency ?
• Meaning Object/form/color
• Grammar Geometry
• Salience Salience
• Relevance Path dependent
• Query expansion Example image

57
References

• Van Rijsbergens talks
• http//ir.dcs.gla.ac.uk/oldseminars/Keith2.ppt
• http//www-clips.imag.fr/mrim/essir03/PDF/4.Rijsbe
  rgen.pdf
• S.E. ROBERTSON, COMPUTER RETRIEVAL
  (http//www.soi.city.ac.uk/ser/papers/j_doc_histo
  ry/npap.html)
