Sift: A MAC Protocol for Event-Driven Wireless Sensor Networks

1
Sift A MAC Protocol for Event-Driven Wireless
Sensor Networks
Kyle Jamieson, Hari Balakrishnan, Y.C. Tay
MIT Computer Science and Artificial
Intelligence Laboratory Dept. of Computer
Science, National University of Singapore
2
Types of Traffic in Sensor Networks

• Periodic traffic
• Animal habitat monitoring
• Indoor environment
• Temperature
• Room occupancy
• Medical monitoring
• Patient vital signs

• Event-driven traffic
• Failure of mechanical structures
• Water pipes
• Airplane wings
• Medical emergencies
• Vehicle tracking

3
Airplane Wing Example
For critical systems, low latency is important!
4
Sift

• Focus of our work
• Designing MAC protocol to handle event-driven
  workload
• Challenges
• Low-latency
• Good throughput
• Good fairness

5
Problems for Traditional MAC

• Spatially-correlated contention correlation
  between geographical neighbors traffic.
• Bursty traffic the number of senders can quickly
  change.
• Suppression (counter-intuitively)

Suppression often, not all sensing nodes need to
report an event.
6
The Status Quo CSMA

• Basis of existing sensornet MAC layers
• B-MAC, S-MAC
• Timeslot opportunity for a node to begin
  transmitting
• Process repeats after each packet

Busy Medium
Time
MAC Goal only one node transmit at a time
7
The Status Quo CSMA
Time

• Pick a timeslot chosen uniformly in 0, CW
• Listen up to chosen slot
• Transmit if nobody else started transmitting
• Wait if somebody else started transmitting

8
Example A Successful Transmission

• A and B happened to choose different slots
• Node A chooses slot 4, hears nothing, transmits
• Node B chooses slot 8, hears Node A, waits

Node A
Node B
Time
Success exactly one node in first non-vacant slot
9
Example A Collision

• A and B happened to choose slot 4
• Both listen and hear nothing
• Both transmit simultaneously

Node A
Node B
Time
Collision 2 nodes in first non-vacant slot
10
High Contention Causes Collisions in CSMA
Numerical simulation
Unacceptable collision rate above 15
transmitting sensors
Uniform distribution fills up, quickly
11
Solving the Problem of Collisions in CSMA

• Create more slots
• Conventional approach
• Called binary exponential backoff (BEB)
• Change the way we pick slots
• Sift takes this approach

12
Create More SlotsBinary Exponential Backoff
(BEB)

• The basis for Ethernet, B-MAC, S-MAC, 802.11,
  MACAW, many other MAC layers

Acknowledgement?
Yes
No
Reduce CW
Double CW and resend
13
Problems with BEB

• Takes time for every node to increase CW
• Especially if traffic is spatially-correlated and
  bursty
• Waste backoff slots if collisions cause CW to
  increase
• Especially with suppression

BEB causes performance to suffer
14
Our Proposal Sift

• Sift is a MAC protocol for sensor networks
• Event-driven traffic
• Low-latency requirements
• Sifts Properties
• Extremely simple
• Offers up to 7-fold lower latency
• Maintains good channel utilization (throughput)

15
Sift Changing the Distribution

• Keep number of slots the same (simple)
• Use an increasing non-uniform slot selection
  probability distribution
• Make collisions unlikely for large range of N
• Reduce the chance of collisions
• Penalty one packet- or RTS-time (ms)
• Reduce wastage of backoff slots
• Penalty one slot time (µs)

16
Balls and Bins Analogy

• Bin represents a backoff slot in the contention
  window
• Bin height represents probability of picking that
  slot
• Ball represents a single nodes slot choice

A
Bins represent backoff slots ?
17
Why an Increasing Slot-Selection Function?
Nodes choosing each slot ?
Bins represent backoff slots ?
18
Sifts Slot Selection Distribution
19
Optimal Non-Persistent CSMA Performance
Numerical simulation
With knowledge of number of nodes (IEEE J-SAC 04)
20
Sift Approaches Optimal
Numerical simulation
Sift keeps success rate above this unacceptable
range
Sift needs no knowledge of the number of nodes
21
Experimental Setup

• Simulation-based results (ns-2)
• Compare 802.11 (BEB), Sift, and 802.11/copy
• 802.11/copy send CW in each packet, copy
  overheard CW

22
Event-driven Traffic Pattern

• Event-based traffic pattern
• Single-hop to one base station
• N nodes sense and report an event
• R N reports are required
• If a node hears R reports then it suppresses
  its own event report

E.g. N4, R3
Base Station
23
Sift Outperforms When N is Large
Experimental evaluation R1,16
R16
R1
24
Sift Outperforms as R Increases
Experimental evaluation N128
25
Exploring Sifts Performance Space
Experimental evaluation
26
Hidden Terminal Experiment Setup

• Separate 128 sensors into mutually-hidden
  clusters
• Nodes in one cluster cannot hear nodes in another

• All nodes send to the base station
• Result hidden terminal collisions at the base
  station

27
Sift Performs Well with Hidden Terminals
Experimental evaluation N128, R1
28
Sift Resilient to Jitter in Event Time
Experimental evaluation N128, R64
29
Sift Improves Fairness
Experimental evaluation
64 nodes
Eight nodes
30
Trace-Driven Experimental Setup

• Simulated vehicle tracking
• Captured live video from a street scene
• Extract motion events from image analysis
• Event trace drives ns-2 simulation
• 128 sensors laid out in a grid over the scene
• Sensors nearby each event send traffic in
  response to movement

31
Sift Outperforms When R is Large
Trace-driven experimental evaluation
32
Related Work

• TDMA suffers in terms of latency
• PTD (Mowafi et al.), TSMA (Chlamtac et al.)
• BEB-based protocols waste time in backoff
• MACAW (Bharghavan et al.), S-MAC (Ye et al.),
  FAMA (Garcia-Luna-Aceves et al.)
• The HIPERLAN standard for wireless LANs uses
  noise bursts of exponentially-distributed length
• Periodic-sleeping and other MAC protocols can
  work with Sift
• S-MAC (Ye et al.), B-MAC (Polastre)

Sift is a composable MAC primitive
33
Conclusion

• Sift is a latency- (and sometimes throughput-)
  enhancing MAC for event-driven sensor networks
• Sift can be used as a building block in many MAC
  protocols

http//nms.csail.mit.edu/projects/sift
34
Detailed Experimental Parameters

• Average of five runs with different random number
  seeds for each run
• ARQ with 5 retransmit limit
• Control packets sent at 1 MBps data at 2 MBps
• 20 µs slot time 192 bit preamble 30 byte packet
• 802.11 CWmin31, CWmax1023

35
Sift Provides Good Throughput
32 nodes
Two nodes
36
Optimal Non-Persistent CSMA

• Let s be a slot number, assume N 2 sensors
  transmitting. Define

Collision Minimizing CSMA and its Applications
to Wireless Sensor Networks. IEEE J. Selected
Areas in Comm. 226 (2004) pp. 1048-1058
