Flicker

1
Flicker

• John Outram
• Outram Research Ltd
• Bosham,West Sussex (44) 1243 573050
• johnoutram_at_aol.com, www.outramresearch.co.uk

1
2
Outram Research Ltd PM7000
PM2000
PM1000
SCOUT
PM3000
PM6000
PRONTO
3
Flicker

• What is it?
• Is it important?
• How is it caused?
• Relevant Standards
• How is it measured?
• Can we do anything about it?
• Examples

3
4
Flicker What is it?

• A perceptible change in light intensity
• Generally caused by small fluctuations in voltage

• Rarely harmful to electronic equipment
• Nuisance - causing annoying, noticeable changes
  in lighting levels

4
5
Is it important?

• Yes!
• Second most common Power Quality problem
• As well as being irritating -
• Can cause Migraines,
• Bring on epileptic fits

6
Its effect depends on

• how often and how regularly the voltage
  fluctuates,
• if rapid, the frequency of the flickering
• how much of a voltage change occurs,
• ambient light levels.

6
7
and also on

• The kind of light
• Incandescent
• Fluorescent
• HID - high intensity discharge
• The gain factor of the lamp

7
8
Flicker - Early History

• 1891 Power Distribution Frequency chosen to
  prevent visible Flicker.
• 1921 Early research into human response (lt 10
  Hz)
• 1925 GE Flicker Curve from the 1921 research.

• 1937 - Comprehensive study on human perception of
  flicker, validates GE Curve
• 1950s Fluorescent lights introduced concern
  of strobe effects.
• 1964 - Modified GE Flicker Curve gt IEEE Standard

8
9
Organisations feeding IEC

• UIE - The Union Internationale dElectrotherme,
• CIGRE - Conférence Internationale des Grands
  Réseaux Electriques à Haute Tension
• CIRED - Congress International des Reseaux
  Electriques de Distribution
• Significant cross fertilisation from BSI

Nov 2, 2005
9
10
More recent history

• 1980s IEC working groups, leading to
• 1993 - EN60868 Flickermeter, Evaluation of
  Flicker
• 1994 - 61000-3-3 Flicker limits for low voltage
  eqpt lt 16A
• 1994 - 61000-3-5 Flicker limits for LV eqpt gt 16A
• 1996 - 61000-3-7 Flicker limits MV HV systems
  (1kV to 230kV)
• 1995 - EN50160 Public Supply Voltage
  characteristics
• 1998 - IEC 61000-4-15 Flickermeter
• 2005 - IEEE 1453 Flickermeter - as IEC61000-4-15
  with extensions

11
Flicker Evaluation on a product(61000-3-3 lt 16A)
12
Flicker - Terminology

• Pu - Unit of perception. The average person
  just about sees 1.0 pu
• Pst - Short term flicker perceptibility. The
  average person borders on irritation for a level
  of 1.0
• Measured over a short period, normally 10 minutes
• Plt - Long term flicker perceptibility. Same
  scale as Pst
• Measured over longer period, typ. 2 hours (12 Pst
  intervals)
• Acceptable level is lower than for Pst
• Pfs Instantaneous Flicker Sensation

12
13
Flicker
Nov 2, 2005
13
14
Flicker - causes

• Electric arc furnaces
• Induction motors w/high inrush currents (high
  efficiency AC units)
• Arc-welders, spot-welders
• Wind turbine generators
• Ovens
• Malfunctioning power electronics
• Any large-draw varying load!

14
15
Flicker - Impact

• Worse closer you are to offensive load
• Worse on weak (high impedance) systems
• Larger offensive loads cause more flicker
• Made worse by
• High gain factor lighting
• Lower-inertia lighting
• Dimmers (maybe)

15
16
Flicker
Typical Working Levels on the Network lt 0.1 Pst
is rare.
16
17
Pst evaluation for multiple motor starts
Nov 2, 2005
17
18
IEC Flickermeter
Nov 2, 2005
18
19
PM7000 ltRanger PQ
products, measurement options
20
Statistical processor
21
Flicker final calculations used in IEC model
P0.1 is flicker level exceeded for 0.1 of the
time, etc.
21
22
IEC Flickermeter
Nov 2, 2005
22
23
Plt calculation when?
Nov 2, 2005
23
24
Mitigation

• Depends on the source of the problem
• Good News!!
• 90 of problems are neutral related, or involve
  poor joints, and some are just unfortunate
  configurations

25
Mitigation

• Not so good news
• 10 are serious, and probably expensive, caused
  by heavy industrial plant
• Change feed to offending plant
• Run new feed to sensitive site
• Invest in distribution infrastructure

26
S C Electric Company

• STATCOM Static Synchronous Compensator
• Adaptive VAR Compensator (Switched capacitor - ½
  cycle response)

27
American Superconductor

• SuperVAR Dynamic Synchronous Condenser
• Flicker mitigation Steel mills, mines, arc
  furnaces.
• Reactive compensation, Dynamic Power Factor
  correction

28
Best Characteristics

• Response time 1/4 cycle, though switches can
  operate faster
• Reactive power range up to /- 150Mvar
• Shunt connection at 450V to 400kV
• Minimal harmonics, no special filtering

28
29
Example 1 - Oops!
30
Oops!
31
Oops!
32
Example 2 - Significance of Rate
33
Example 3
33
34
High Flicker levels not obvious from Voltage
34
35
Diagnose from Instantaneous Flicker and Current
35
36
Pfs Current unrelated
36
37
2 mins after midnight
37
38
Zoomed to 2 secs
½ cycle of 6 Hz Nearly worst case
38
39
Flicker

• John Outram
• Outram Research Ltd
• www.outramresearch.co.uk

39
