Title: The Axial Skeleton
1
The Axial Skeleton
2
Axial Skeleton
the skull is actually several bones that come
together as an embryo develops
the cranial bones protect the brain, ears and
eyes
some cranial bones provide attachment points for
muscle ? movement of head, jaw, and neck
3
Axial Skeleton
the cranial bones are divided into the calvaria
and the cranial base
calvaria frontal, occipital, parietal,
temporal
cranial base ethmoid, sphenoid
the rest of the skull is made of 14 facial bones
4
Axial Skeleton
several of the bones of the skull contain sinuses
cavities lined with ciliated epithelial cells
that secrete mucous
5
Axial Skeleton
the left and right frontal sinuses are posterior
to the frontal bone
not present at birth
begin development from age 2 to 5
fully develop in the late teens
function lighten skull, warm air
6
Axial Skeleton
the frontal bone
forms the forehead and eyebrow ridges
flat vertical forehead
lower concave orbits (
7
Axial Skeleton
comparative anatomy note
males have a thicker orbital ridge than females
the eyebrows of a male sit lower on the orbital
ridge
8
Axial Skeleton
the temporal bone
complex shape
distinct features
noteworthy features of the temporal bones
mastoid process
styloid process
tympanic region
zygomatic process
9
Axial Skeleton
mastoid process
attachment of neck muscles
complex of cavities mastoid sinuses
mastoid sinuses connected to inner ear
vulnerable to bacterial infection that affects
ears and throat
adjust inne ear to pressure changes
10
Axial Skeleton
styloid process
varies in length from individual to individual
important attachment point for muscles and
tendons of the neck and throat
11
Axial Skeleton
tympanic region
houses the internal components of the ears
includes the 3 small bones of the
malleus (
incus (
stapes (
these bones develop from the facial bones in an
embryo
12
Axial Skeleton
zygomatic process
forms the zygomatic arch with the zygomatic bone
(facial)
forms the cheek
attachment for muscles used in chewing
13
Axial Skeleton
The parietal bone
forms the top, side, and posterior portion of the
cranium
protects the posterior portion of the brain
14
Axial Skeleton
The occipital bone
forms the posterior base of the cranial vault
series of bones fused together in an embryo
an opening is left foramen magnum or occipital
foramen
15
Axial Skeleton
The occipital bone
the spinal cord enters through the occipital
foramen
occipital condyles provide attachment of the head
to the vertebral column, allow head movement
16
Axial Skeleton
The sphenoid bone
in contact with almost all other skull bones
helps form facial features
contains sphenoidal sinuses
connected to, and help form nasal cavities
major blood vessels and nerves of the eyes and
face pass through the sphenoid
forma a structure, sella turica, which protects
the pituitary gland
17
Axial Skeleton
The ethmoid bone
passageway for the nerves that detect smell
contains the ethmoid labyrinth
cleans and moistens air that enters the nose
18
Axial Skeleton
Most of a persons facial features are determined
by the
mandible
maxillary bones
zygomatic bones
19
Axial Skeleton
zygomatic bones
zygomatic arch
maxillary bones
upper jaw
larger facial bones
form area around nose (lateral surfaces)
area under eyes (medial border of orbits)
20
Axial Skeleton
maxillary bones
passageway for major blood vessels and nerves
inferior orbital foramen
teeth develop on the lower surface
21
Axial Skeleton
palatine bones
between the maxillary and sphenoid bones
help form the
1) the walls of the nasal cavity
2) the roof of the mouth
3) the bottom of the orbits
this bone pair grows in height as facial features
mature birth ? adolescence
22
Axial Skeleton
mandible
largest facial bone
body of the mandible contains teeth
condyle of the mandible articulates with the
temporal bones
contains passageways for blood vessels and nerves
to the the chin and lower lip mental foramen
23
Axial Skeleton
mandible
only skull bone not fused to other bones of the
skull (ear bones, hyoid)
hyoid bone
horshoe-shaped bone
suspended below mandible by muscles
anchors muscles of the neck
attaches to muscles of the tongue
24
Axial Skeleton
teeth
bones that grow out of an alveolus in the
mandible or maxilla
has a crown projects above the gum
has a root embedded in the alveolus
a hard enamel covers the crown
25
Axial Skeleton
The remainder of the facial bones are tiny bones
nasal, lacrimal, vomer
26
Axial Skeleton
27
Axial Skeleton
The vertebral column and ribs
28
Axial Skeleton
vertebral column
region association/articulation
cervical 7 neck
thoracic 12 rib cage
lumbar 5 lower back
sacral 5 hip bones
coccygeal 3 - 5 tail end
29
Axial Skeleton
most vertebrae have a
vertebral body
vertebral arch
vertebral foramen
30
Axial Skeleton
vertebral body
supports weight of body
31
Axial Skeleton
vertebral arch
dorsal to the body
has several features
pedicles (2)
articular processes (4)
transverse processes (2) lateral
spinous process
processes provide muscle attachment movement of
appendages, head, neck, vertebral column
32
Axial Skeleton
vertebral foramen
passageway for spinal cord
33
Axial Skeleton
cervical
smaller body
small transverse processes
short, bifurcated spinous process
unique feature
2 transverse foramina for major blood vessels to
the skull
cervical 1 2 atlas and axis
34
Axial Skeleton
atlas
supports the skull
lacks a body
large articular surfaces attach to the occipital
bone
axis
large protrusion dens (odontoid process) ?
rotation and free movement of the atlas and skull
35
Axial Skeleton
thoracic
larger body
long, narrow spinous process
unique features
each transverse process (2) has a facet for
articulation with a rib
another facet is located on the dorsal portion
of the body
? articulation that allows the ribs to flex
during breathing
36
Axial Skeleton
lumbar
largest
thickest
support most of the bodys weight
anchor the back muscles balance while moving,
sitting, or standing
short stubby spinous process ? bend backward
37
Axial Skeleton
sacral
form the sacrum
have large, lateral articular surfaces fuse
with hip bone
in females
sacrum is
shorter
wider
less curved
38
Axial Skeleton
In most individuals the vertebral arch is not
present on the last 2 vertebra sacral canal
The spinal cavity is exposed in the sacral canal
The spinal cord ends in the lumbar region
Result
opportunity to collect spinal fluid with minimal
risk of nerve damage
39
Axial Skeleton
coccygeal
coccyx (tailbone)
no foramen
muscle attachment of upper leg muscles
40
Axial Skeleton
The rib cage consists of
costal cartilage
ribs
sternum
serves as a protective structure
assists in breathing
41
Axial Skeleton
normally 12 ribs, but . . .
some individuals develop small cervicacl and
lumbar ribs
Why?
Scientists have discovered that each vertebra
has the genetical potential to become a rib
42
Axial Skeleton
7 upper ribs true ribs
attach directly to the sternum by costal
cartilage
ribs 8, 9, 10 false ribs
attached by costal cartilage to the rib above
last 2 ribs floating ribs
not attached ventrally
43
Axial Skeleton
The sternum serves as
an articulation with the clavicles
an articulatioin with ribs 1 7
an attachment for the chest and shoulder muscles
an attachment for the stomach muscles
44
Axial Skeleton
Write a Comment
User Comments (
0
)
Cancel
OK
OK
Latest
Latest
Highest Rated
Sort by:
Latest
Highest Rated
Page
of
Recommended
Recommended
Relevance
Latest
Highest Rated
Most Viewed
Sort by:
Recommended
Relevance
Latest
Highest Rated
Most Viewed
Related
More from user
«
/
»
Page
of
«
/
»
CrystalGraphics Presentations
World's Best PowerPoint Templates
- CrystalGraphics offers more PowerPoint templates than anyone else in the world, with over 4 million to choose from. Winner of the Standing Ovation Award for “Best PowerPoint Templates” from Presentations Magazine. They'll give your presentations a professional, memorable appearance - the kind of sophisticated look that today's audiences expect. Boasting an impressive range of designs, they will support your presentations with inspiring background photos or videos that support your themes, set the right mood, enhance your credibility and inspire your audiences.
CrystalGraphics 3D Character Slides for PowerPoint
- CrystalGraphics 3D Character Slides for PowerPoint
Chart and Diagram Slides for PowerPoint
- Beautifully designed chart and diagram s for PowerPoint with visually stunning graphics and animation effects. Our new CrystalGraphics Chart and Diagram Slides for PowerPoint is a collection of over 1000 impressively designed data-driven chart and editable diagram s guaranteed to impress any audience. They are all artistically enhanced with visually stunning color, shadow and lighting effects. Many of them are also animated. And they’re ready for you to use in your PowerPoint presentations the moment you need them. – PowerPoint PPT presentation
Related Presentations
The Axial Skeleton
- Title: PowerPoint Presentation Last modified by: student Created Date: 1/1/1601 12:00:00 AM Document presentation format: On-screen Show Other titles
| PowerPoint PPT presentation | free to view
Axial Skeleton Quiz
- Title: Anat & Phys 10/10/06 Objectives: To assess knowledge of the axial skeleton and learn about the appendicular skeleton. Class Topics Axial Skeleton Quiz
| PowerPoint PPT presentation | free to view
Bones Of The Axial Skeleton
- Bones Of The Axial Skeleton THE VERTEBRAL COLUMN
| PowerPoint PPT presentation | free to view
Axial and Appendicular Skeleton
- SC.912.L.14.13 SC.912.L.14.14 What functions distinguish the axial and appendicular skeleton? What are the major bones of the axial and appendicular?
| PowerPoint PPT presentation | free to view
Bones Of The Axial Skeleton
- Bones Of The Axial Skeleton THE SKULL
| PowerPoint PPT presentation | free to view
The Axial Skeleton
- Title: Chapter 7: The Axial Skeleton Author: Trial User Last modified by: Computer112595 Created Date: 12/31/2004 7:55:57 PM Document presentation format
| PowerPoint PPT presentation | free to view
The Axial Skeleton
- The Axial Skeleton Even craniates may have an exoskeleton and an endoskeleton Which type is derived from dermis and epidermis? Some bones have left their original ...
| PowerPoint PPT presentation | free to view
Skeleton System
- Classification of bone Based on Location Axial and Appendicular Based on Shape Long, short, flat, Sesamoid, irregular Based on Ossification Endochondral and ...
| PowerPoint PPT presentation | free to view
Appendicular Skeleton
- Title: Slide 1 Author: Skish Last modified by: Lori McLoughlin Created Date: 10/5/2006 2:53:05 AM Document presentation format: On-screen Show (4:3)
| PowerPoint PPT presentation | free to view
Axial Skeleton
- 4 Distinct Curvatures of the Vertebral Column. Characteristic ... Manubrium. Xiphoid. process. Functions of the Axial Skeleton. Support. Protection. Respiration ...
| PowerPoint PPT presentation | free to view
Axial Skeleton Vertebral Column Thorax
- Axial Skeleton Vertebral Column Thorax Vertebral Parts Cervical Vertebrae Thoracic & Lumbar Vertebrae Vertebral Column Sacrum (5 fused vertebrae) Coccyx Rib Sternum ...
| PowerPoint PPT presentation | free to view
Skeletal System:Axial Skeleton
- 7-* The Complete Skeleton Axial skeleton Skull Hyoid bone Vertebral ... Modified from Fig. 7.21 7-* Points to Remember Two major components of the human skeleton: ...
| PowerPoint PPT presentation | free to view
Animal Skeleton and External Anatomy
- Animal Skeleton and External Anatomy
| PowerPoint PPT presentation | free to view
Assessment of Skeleton Health
- Osteoporosis Normal Osteopenia Osteoporosis Osteoporosis Normal bone Osteoporosis is defined as a skeletal disorder characterized by: ...
| PowerPoint PPT presentation | free to view
Axial Division
- spongy bone Proximal epiphysis compact bone Endosteum diaphysis epiphyseal line yellow marrow Sharpey s fibers Distal epiphysis hyaline cartilage periosteum
| PowerPoint PPT presentation | free to view
Axial Division
- spongy bone Proximal epiphysis compact bone Endosteum diaphysis epiphyseal line yellow marrow Sharpey s fibers Distal epiphysis hyaline cartilage periosteum
| PowerPoint PPT presentation | free to view
Appendicular skeleton
- Appendicular skeleton Limbs and base units Pectoral Girdle Connects upper limbs (arms) to axial skeleton. Clavicle Collar bone (2) Scapula Shoulder blade (2) http ...
| PowerPoint PPT presentation | free to view
Skeleton: Axial
- Skeleton: Axial Lab 4 Vertebral Column & Ribs Skeleton: Axial Lab 4 Vertebral Column & Ribs General Structure of Vertebrae Spinous processes project posteriorly, and ...
| PowerPoint PPT presentation | free to view
The Axial Skeleton
- Bones and Openings of Right Orbit. Modified from Fig. 7.8. Ethmoid bone. Lacrimal bone. Sphenoid bone. 7-8. Inferior View of Skull. Foramen magnum ...
| PowerPoint PPT presentation | free to view
APPENDICULAR SKELETON
- APPENDICULAR SKELETON BONES TO KNOW 2 REVIEW a scaphoid b lunate c triquetral d pisiform a hamate b capitate c trapezium d trapezoid a calcaneus b ...
| PowerPoint PPT presentation | free to view
The Appendicular Skeleton
- The Appendicular Skeleton Right foot, superior (dorsal) view and inferior (plantar) view Right foot, lateral and medial views Arches THE SKELETAL SYSTEM The ...
| PowerPoint PPT presentation | free to view
Appendicular Skeleton
- Appendicular Skeleton Appendicular Skeleton 126 bones suspended by girdles from axial skeleton Designed for movement Pectoral girdle 4 bones Upper extremity ...
| PowerPoint PPT presentation | free to view
JOINTS
- THE SKELETON ... joints
| PowerPoint PPT presentation | free to view
Appendicular Skeleton
- Appendicular Skeleton Pectoral (Shoulder) Girdle Pectoral Girdle Attach the bones of the upper limbs to the axial skeleton Consist of two bones: clavicle and scapula ...
| PowerPoint PPT presentation | free to view
Appendicular Skeleton
- Appendicular Skeleton Division of the skeleton consisting of the pectoral girdle, upper limbs, pelvic girdle and lower limbs.
| PowerPoint PPT presentation | free to view
Bones, Part 1: The Axial Skeleton
- Title: Bones, Part 1: The Axial Skeleton Last modified by: fnaim Document presentation format: On-screen Show (4:3) Company: RUser Other titles: Arial Times New Roman ...
| PowerPoint PPT presentation | free to view
The Axial Skeletal System
- The Axial Skeletal System
| PowerPoint PPT presentation | free to view
