CrimeStar RMS Training

1
CrimeStar RMS Training

• Click Mouse to Continue
• Press END at any time to quit

2
CrimeStar RMS Training

• Presented by Surry NH Police Dept
• Written by Lt Joel Huntley

3
CrimeStar RMS Training

• This presentation pertains to the operations of
  the Surry NH Police Dept. Your operations may
  differ.

4
Introduction

• Entering Data into the CrimeStar RMS system.
• Retrieving Information From the CrimeStar RMS
  system.
• Editing Information in the CrimeStar RMS system.

5
Introduction

• This presentation is based upon a previously
  configured, and working RMS.
• Your Agency codes may differ.
• The Surry Police Dept does not use all available
  screens/modules.

6
Agenda

• Learning how to
• Log in and Quit the Program
• Use system screens, including but not limited to
  CFS (Calls for Service), Citations, FIs (Field
  Interviews), Incidents, Arrests, to input data.
• Query the system.

7
Overview

• By gathering COMPLETE and ACCURATE data and
  filling out screens in a CONSISTANT manner, we
  will have an invaluable tool which will provide
  us with extremely useful information.

CFS
CIT
RMS
MVI
MNI
FI
8
Vocabulary

• RMS Records Management System
• CFS Call For Service
• FI Field Interview
• Citation Traffic Complaint or warning/write-up
• MNI Master Name Index

9
Begin by locating the Shortcut to Launch the
CrimeStar program. This location may be
different on your computer.
10
Logging In Signing On
Enter your UNIT number here
Enter your Password Here then click Sign-On
11
Notice the toolbar is grayed out and not ready
for use
As youre logging in, this pop-up window appears.
12
After Sign-In is complete, the toolbar appears.
You are now ready to use the system.
13
Entering Data

• This section will step you through actually
  entering data into the CrimeStar RMS

14

• These are for QUERY screens

The Drop-Down menu is for Data Input
15
Using the Drop-Down menu, select the type of
data to input.

• Most of these screens will Require a CALLS FOR
  SERVICE screen to be done FIRST.

16
(No Transcript)
17
Calls For Service

• Well begin with entering a Calls For Service
  record.

18
To Begin a NEW record, click the NEW icon.
19

• To OPEN or EDIT an existing record, click the
  OPEN icon.

20
(No Transcript)
21
Most calls will Require a CFS

• Almost ALL activity that is not motor vehicle
  related, will require a CFS.
• Enter the CFS First!
• The CFS Screen will generate an EVENT number for
  your other screens.

22
Remember the EVENT Number

• Once the EVENT number is obtained by pressing
  CTRL F5, remember this number if other screens
  are to be accessed in relation to this call. For
  example, an Accident Report, an Incident Report
  or just some simple FIs.
• By inserting the EVENT number in other screens,
  the RMS will ask you if you want to transfer
  certain data from the CFS.

23

• By rolling your Mouse over the Event Field, the
  help screen will appear to assist in telling you
  what the system is looking for.

24
(No Transcript)
25

• Select Type of Call from the drop-down menu.
  In this example, well use a Burglar Alarm, 10-52A

26
Fields in RED are Mandatory and must be filled in
prior to saving the record.
27
Enter Date and Time call was Received, then using
Drop-Down Menu, select how call was received.
HINT Anytime you are working in a date or time
field, CTRL-D CTRL-T will enter the current
date and time!
28
Enter LOCATION of call. In this example well
use a partial entry of Surry and use the
Geo-Locator function.
29

• Using the Geo-Locator function, we can auto-fill
  several fields if a valid address is found in the
  list. Access by clicking on the Globe.

30
Select Surry Lake from list.
31
Notice Beat, Sector District/Grid are filled in
now?
32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
Enter brief description of complaint.
36
Enter Reporting Party, Location and Phone if
known.
37
(No Transcript)
38
If the RP is a person and you DONT know their
DOB, we enter it like this.
39
However, if we DO know the DOB, we Double Click
the RP title and the field changes to.
40
THIS
41
By entering last name, first name and pressing
the tab key, CrimeStar will check against the
Master Names Index for a potential match.
However, if we DO know the DOB, we Double Click
the RP title and the field changes to.
If none is found, enter the DOB.
42
(No Transcript)
43
Select responding units from Drop-Down lists.
44
Radio Call
45
Permanent Employee ID number.
46
Insert Dates and Times as needed. (Note, by
clicking the green button icon, the current dates
and times will be inserted.)
Hint You can also use Ctrl-D to auto fill both
date time, OR F2, F3, F4 and F5 to auto fill
dates times for Primary Unit, F6 F9 for 2nd
Unit.
47
Now click the DISPOSITION icon
48
Select appropriate Disposition from Drop-Down
list.
49
Enter brief explanation of what transpired if
needed. Some CFSs can be cleared by a drop-down
selection.
50
Click Save to save the record.
51
System telling you the record is being saved.
52
Workstation Preferences

• Whether or not each form closes after you save
  it, depends on your individual workstation
  preferences.

53
Individual preferences.
54
Individual preferences.
55
Click Yes to create an Alarm Response File from
this CFS.
If this CFS is for an alarm, click the alarm Icon.
56
Notice the Data from the CFS is now present in
the list.
57
Click Save to save the Alarm Response.
58
(No Transcript)
59
Create an FI from the CFS

• Lets Enter an FI from this CFS to see how data
  is transferred to the FI screen from the CFS.

60
Field Interview Screen

• The FI screen is used any time you have occasion
  to gather an individuals name, DOB, address,
  vehicle info or additional data and you want them
  in Master Name Index to show that weve dealt
  with them before.
• An FI IS NOT needed if the persons data will be
  inserted on a citation, incident, accident, or
  any other screen that will list them
  automatically.

61
Click the Fld Interview Icon.
62
Enter the FI number.
63
An FI is typically the date and time run
together. For example. We obtained the info for
this FI on April 28, 07 at 1037
64
FI Screen Data

• FIs Can have the SAME FI
• Multiple subjects can be referenced to the same
  incident.

• Remember, Items labeled in RED are mandatory
  fields.

65
The Other number field is for the PDs case
number, or if you IDed all occupants of a
vehicle, you could put the Summons number here.
And an Officer Number.
The FI also wants a Reason for the interview.
Something brief here. Any info already here has
auto transferred from the CFS description of the
original call.
66
Enter Last Name, First Name (Given Name, not nick
names). Tab between fields.
67
If theres a match in MNI, select Match.
68
Any info in the system will transfer. Add any
additional info you gather during this interview.
If you obtain a new address, clear the old info
and add current info. A running history of
addresses will be kept with this MNI record.
69
Type of person this is
70
(No Transcript)
71
The system will remember data previously used.
Type the first few letters to jump directly to a
selection if its in the list. If not, just
enter the data.
72
Street Type
73
Street Suffix
74
Apartment Number
75
Click ID button for additional Info
76
(No Transcript)
77
Add any vehicle info you want associated with
this person.
78
Click Save
79
If you wanted to associate someone else also with
this CFS, click here..
80
(No Transcript)
81
All data and VEHICLE info transfers. Great for
multiple people in same car.
82
Close form when complete by clicking either X.
83
After closing FIs, youre returned to the
original CFS screen.
84
Close form when complete by clicking either X.
85
Ready for the Next Entry
86
Remember that EVENT Number?

• Lets Enter an FI from this CFS to see how data
  is transferred to the FI screen using the EVENT
  Number obtained on the CFS.
• Remember the EVENT Number?

87
Remember that EVENT Number?

• It was 0700002

88
Retrieve a CFS or any other screen.

• If you had forgotten the EVENT Number, you could
  retrieve it using the CFS Query Icon.

89
Click the CFS Query Icon. (Note, help screens
appear as you roll your mouse over each Icon.)
90
Click Search
Enter any data that you remember, in this case
well use the date.
91
There it isIf there were more than 1 record that
matched your query, a list would appear for you
to select from.
92
Select Field Interview
93
Click NEW, just like before.
94
(No Transcript)
95
An FI is typically the date and time run
together. For example. We obtained the info for
this FI on April 28, 07 at 1037
96
Enter the EVENT number and press TAB on your
keyboard.
By Clicking Yes, data from the CFS will
transfer.
97
Notice Transferred Data from CFS
98
Same as before

• From this point on, entering an FI is the same as
  if it had originated from the CFS.

99
An Example of Multiple FIs with the same FI .
100
Citation Module

• Gathering info and completing a Citation.
• This Screen is also used for a motor vehicle
  warning.

• And when towing a car, and only license plate and
  vehicle make, type are known.

101
Citation

• Begin by opening a NEW citation record.
• The Citation Number is
• A) If you issue a traffic summons, use the number
  on the bottom of the summons. Ie DS191325
  written just like that, no spaces.
• B) Write-ups/warning numbers use the same format
  as an FI. Ie 0524011949

102
Towing Vehicles

• If you are Towing a vehicle, for example from the
  Dort Rd, you will need to complete a CFS First!

103
Select Citation from the Drop-Down menu, and
click NEW.
104
This will be a warning example. Then select the
type of violation.
105
(No Transcript)
106
Do NOT use Auto-Create buttons until original
document it completed first. (You can, but then
youll just have to enter the same data multiple
times.)
107
If there is a name match, click Match.
108
(No Transcript)
109
Same for vehicle info. Enter plate and state,
press tab. Select Match if one exists.
110
(No Transcript)
111
Click Owner Info
Fill in applicable info
112
(No Transcript)
113
Select Radar/Laser, additional info as needed and
click ADD
114
Select Violation. HINT Type first letter will
bring you to that section of violations.
115
(No Transcript)
116
Add any pertinent info here and click notes to
add officer notes in case of a trial.
117
Add any notes, and click Save
118
Close form when complete by clicking either X.
119
Accident Reports

• Complete the CFS first!
• Select Accident from the Drop-Down list.

120
(No Transcript)
121
Select Accident from the Drop-Down list
Then Click NEW
122
Accident, Incident Other s

• Surry PD uses the SAME number for the Accident
  AND Incident numbers.
• If you havent gotten an Incident (case) number
  yet, use the CTRL-F5 function and edit the report
  later.
• The CFS EVENT number will be used in the Other
  field.

123
Enter your Agency Case Number if you have it, or
CTRL-F5 to get one. (SPD uses CTRL F5, then
edits the Accident report later with the case
number.)
124
If you do happen to have your agency
case/incident number already, tabbing past this
field will ask if you want to transfer info from
the CFS screen.
125
This is all Transferred data from the Calls For
Service module
126
Select appropriate VIOLATION if applicable
127
Select appropriate WEATHER CONDITIONS
128
Select appropriate SURFACE CONDITION
129
Select appropriate LIGHTING CONDITION
130
Select appropriate ROAD CONDITION
131
Select appropriate TRAFFIC CONTROLS
132
This Field IS NOT used for the NH Accident Module
133
Select what the vehicle was INVOLVED WITH
134
Select if PEDESTRIAN Involved
135
Select any other items as needed
136
Select OTHER and continue
Enter Times
137
Select FIXED OBJECT struck if applicable
138
Select LOCATION OF 1st HARMFUL EVENT
139
Select ROAD DESIGN
140
Select any other ROADWAY FEATURES
141
Select ROAD ALIGNMENT
142
At this time, the remaining fields ARE NOT used
on the NH report
143
Click ADD
Select PERSONS tab
144
Select POSITION and VEHICLE number
145
Enter Person Info
146
After hitting the TAB on your keyboard, if there
is a potential, a selection list will appear, if
this IS the correct person, click MATCH
147
Any info that IS in the MNI, will be transferred
148
Additional Info
149
(No Transcript)
150
(No Transcript)
151
(No Transcript)
152
(No Transcript)
153
(No Transcript)
154
(No Transcript)
155
(No Transcript)
156
Add additional people
157
Complete remainder of screen including IDs and
Other tabs.
158
(No Transcript)
159
(No Transcript)
160
After entering Lic Plate and State, pressing Tab
will search for a potential match.
161
Towed by / To info
162
This Field is PLATE TYPE for the Accident Module
163
(No Transcript)
164
(No Transcript)
165
(No Transcript)
166
Complete remaining Drop-Downs
167
(No Transcript)
168
(No Transcript)
169
Spellcheck available on narrative screens.
170
Add any photos of the crash
171
(No Transcript)
172
Click report complete when it is, and click Save
to submit for case approval and case management.
173
Close the form if youre done by clicking either
X
174
But suppose you had an arrest as a result of the
crash?
175
Go back to the Persons Tab, and select the person
Click Arrest
176
Arrest Booking

• The Arrest Booking Module gathers info dealing
  with suspects during the booking process.

177
Click Yes
178
All Pre-Filled from other screens.
179
Double Click in the text field to enter scars,
marks, tats.
180
Point your mouse over area of body where item is..
181
Enter description
Click OK when finished.
182
(No Transcript)
183
Complete MORE tab and include photo if you have
one.
184
(No Transcript)
185
Vehicle info also transferred over
186
Additional info transferred over
187
Enter Charges info
188
(No Transcript)
189
(No Transcript)
190
(No Transcript)
191
Select Violation
Remember, Items in RED are mandatory.
192
(No Transcript)
193
Inventory Items
194
Observation Log if Held in Custody
195
Configurable Questions
196
(No Transcript)
197
(No Transcript)
198
(No Transcript)
199
Click Save and close the form.
200
Back to originating form. Ready to close.
201
Incident Reports

• Complete the CFS first!
• Select Incident from the Drop-Down list.

202
(No Transcript)
203
(No Transcript)
204
Entering Incident or Event number from CFS will
transfer info
205
Transferred Data from CFS
206
Select type of Incident
207
UCR code determined by offense during set-up.
208
Completed face page
209
Complete Persons same as Accident and Arrest
Modules.
210
Add vehicles if applicable
211
Add Property
212
(No Transcript)
213
Solvability if enabled during system set-up
214
Enter your narrative here, and for a brief
synopsis, click the Synopsis tab and enter that.
The synopsis will be printed on the report face
sheet.
215
(No Transcript)
216
Complete Status page and click Save, then close
form
217
To add a supplemental report later, recall the
incident and click Add.
218
Here you can add additional info, people,
property etc
219
Creating Daily Logs

• CrimeStar RMS also allows Daily Cruiser Logs to
  be created, including cruiser mileage,
  maintenance and fuel.

220
Begin each tour of duty by creating a new daily
log and clicking Recall
221
Daily Activity - SUMMARY
The Log sheet comes up on the Summary tab, you
will want to begin on the Vehicle tab.
222
Daily Activity VEHICLE
223
Enter Begin Mileage, rounded to the nearest mile.
Enter Vehicle ID
Click Save
Click approximate fuel amount
224
Enable Daily Log entry screen
225
(No Transcript)
226
Then, Click Save
Begin by signing On Duty. The current date and
time will be the default value.
227
Anytime you change what youre currently doing,
create another Popup and Log your activity.
228
Additional Options are found by Clicking the DOWN
arrow.
229
Logging Activity using the Daily Log screen

• Lets just add a few entries to create a log
  sheet
• 1 On Duty
• 2 Routine Patrol
• 3 MVS
• 4 Federal Patrol
• 5 Routine Patrol

230
You can get quickly to an activity by typing the
FIRST letter of that activity in the window. For
example, to log Routing Patrol, just type a P.
Click Save after each activity.
231
Type M for MVS Enter Location Info Enter of
Citations Issued Add any Comments Click Save
232
Back to Routine Patrol Click Save
233
Now well patrol a Federal Area.
Click Save
This requires we use more Options and select from
the dropdown.
234
Back to Routine Patrol
235
Logging Activity using the Daily Log screen

• Weve added a few log entries

• Now lets fuel up the cruiser.
• Go back to Routine Patrol
• And finally go off duty.

236
(No Transcript)
237
After Saving the Fuel-Up entry, go back to
Admin gt Daily Activity Log
238
Select your ID and click Recall
239
Notice all of your activity that has been
recorded on your log sheet.
240
Click Save
Click the Filled box if you did, and enter the
amount of Fuel.
241
(No Transcript)
242
(No Transcript)
243
Daily Activity - DETAILS
Further details can be added to entries later, by
again, opening the main Activity Log from under
Admin on the toolbar.
244
Adding Details to an Entry
Highlight the entry you want to add detail too,
then click the Details tab.
245
In this example, we entered our agency incident
number.
246
Daily Activity HRS WORKED
Enter total number of Hours worked on the Hours
Worked tab.
247
As usual, click Save when done.
Also, dont forget to enter your Ending mileage.
248
Additional Features

• Officer Safety Warnings
• Animal Control
• Premises Contact Info
• Address Validation

249
Officer Safety Warning Flags

• To create an Officer Safety warning flag, open
  the Master Name Index file for the person.
• Click Open
• Enter Name
• Click Recall
• Edit the record under the Known Off tab
• Save and close the record

250
(No Transcript)
251
(No Transcript)
252
Select appropriate flags.
253
Warning Flags

• Now anytime this name is accessed, either
  directly or from a Match when entering in people
  info on one of the modules, you will be presented
  with Red Flashing warning flags.
• Lets select this person using a Match on an FI
  screen

254
Create a New FI

• Were going to create an FI and go directly to
  where a Match would show up.

255
After selecting Match, watch this
256
Double Click the warning flag and you can check
to see what the flags are for under the Known Off
tab.
257
See? There they are!!
258
Animal Control

• Enter dog licensing info
• Know immediately if animals vaccinations are
  current.
• Track involvements
• Ability to return loose dogs to owners

259
(No Transcript)
260
(No Transcript)
261
(No Transcript)
262
(No Transcript)
263
(No Transcript)
264
(No Transcript)
265
Premises Contact Info

• Add Contact information for locations
• Add special info and cautions for locations

266
(No Transcript)
267
Click Add
268
Enter street digits and click to select street
269
(No Transcript)
270
(No Transcript)
271
(No Transcript)
272
Even add Photos if you want
273
Retrieving Data

• How to query your system
• CrimeStar, unlike any other program Ive used,
  will allow you to search your data by virtually
  any parameter or combination of parameters.
• You can even search by text string or key
  words! Very helpful if for example, you dont
  remember what an incident was, but you remember
  mentioning something that was odd in your
  narrative. You can search by that.

274
Remember, you can use the Icons to search, or..
275
The drop down.
276
Search by ANY portion of info from face sheet of
your original report.
277
Any portion of personal information
278
Any portion of vehicle info, including if the
only thing you knew was that it was towed!!
279
Any portion of the MO info
280
Solvability, Narrative or Disposition
281
Well search for all reports containing the work
Trailer.
282
Heres the results of that query.
283
Summary

• These are only a few examples of how to make the
  CrimeStar RMS package work for you.
• Contact your system administrator for assistance
  with your system.

284
GIGO

• Just remember, the MOST important piece of having
  of a truly valuable RMS system, is accurate and
  consistent data entry.
• Garbage In, Garbage Out!!
• This include using Given names instead of nick
  names ie, Robert instead of Bob.
• Dont assume Bobby really is short for Robert
  it might be Bobby. ASK!!

285
Where to Get More Information

• Other training sessions
• The system Help Files F1
• CrimeStar RMS Users Group
