Condor COD (Computing On Demand) Condor Week 5/5/2003

1
Condor COD (Computing On Demand)Condor Week
5/5/2003
2
What problem are we trying to solve?

• Some people want to run interactive, yet
  compute-intensive applications
• Jobs that take lots of compute power over a
  relatively short period of time
• They want to use batch computing resources, but
  need them right away
• Ideally, when theyre not in use, resources would
  go back to the batch system

3
Some example applications

• A distributed build/compilation of a large
  software system
• A very complex spreadsheet that takes a lot of
  cycles when you press recalculate
• High-energy physics (HEP) analysis jobs
• Visualization tools for data-mining, rendering
  graphics, etc.

4
Example application for COD
Users Workstation
Compute Farm
On-demand workers
Idle nodes
Controller application
5
Whats the Condor solution?

• Condor COD Computing on Demand
• Use Condor to manage the batch resources when
  theyre not in use by the interactive jobs
• Allow the interactive jobs to come in with high
  priority and run instead of the batch job on any
  given resource

6
Why did we have to change Condor for that?

• Doesnt Condor already notice when an interactive
  job starts on a CPU?
• Doesnt Condor already provide checkpointing when
  that happens?
• Cant I configure Condor to run whatever jobs I
  want with a higher priority on my own machines?

7
Well, yes But thats not good enough

• Not all jobs can be checkpointed, and even those
  that can take some time
• We want this to be instantaneous, not waiting for
  the batch system to schedule tasks
• You can configure Condor to run higher priority
  jobs, but the other jobs are kicked off the
  machine

8
Whats new about COD?

• Checkpoint to swap space
• When a high-priority COD job appears, the
  lower-priority batch job is suspended
• The COD job can run right away, while the batch
  job is suspended
• Batch jobs (even those that cant checkpoint) can
  resume instantly once there are no more active
  COD jobs

9
But wait, theres more

• The condor_startd can now manage multiple
  claims on each resource
• If any COD claim becomes active, the regular
  Condor claim is automatically suspended
• Without an active COD, regular claim resumes
• There is a new command-line tool to request,
  activate, suspend, resume and release these
  claims
• Theres even a C object to do all of that, if
  you really want it

10
COD claim-management commands

• Request authorizes the user and returns a unique
  claim ID for future commands
• Activate spawns an application on a given COD
  claim, with various options to define the
  application, job ID, etc
• Suspends any regular Condor job
• You can have multiple COD claims on a single
  resource, and they can all be running
  simultaneously

11
COD commands (contd)

• Suspend
• Given COD claim is suspended
• If there are no more active COD claims, a regular
  Condor batch job can now run
• Resume Given COD claim is resumed, suspending
  the Condor batch job (if any)
• Deactivate Kill the application but hold onto
  the COD claim
• Release Get rid of the COD claim itself

12
COD command protocol

• All commands use ClassAds
• Allows for a flexible protocol
• Excellent error propagation
• Can use existing ClassAd technology
• Similar to existing Condor protocol
• Separation of claiming from activation, so you
  can have hot-spares, etc.

13
How does all of that solve the problem?

• The interactive COD application starts up, and
  goes out to claim some compute nodes
• Once the helper applications are in place and
  ready, these COD claims are suspended, allowing
  batch jobs to run
• When the interactive application has work, it can
  instantly suspend the batch jobs and resume the
  COD applications to perform the computations

14
Step 1 Initial state
Users Workstation
Compute Farm
Idle nodes
Idle nodes
15
Step 2 Application spawned
Users Workstation
Compute Farm
Idle nodes
Idle nodes
Controller application spawned
16
Step 3 Compute node setup
Users Workstation
Compute Farm
On-demand workers
On-demand workers
Idle nodes
Claiming and initializing 4 compute nodes for
rendering Got reply from c1.cluster.org c6.clust
er.org c14.cluster.org c17.cluster.org SUCCESS!
request
activate
17
Step 3 Commands used

• condor_cod_request name c1.cluster.org \
• classad c1.out
• Successfully sent CA_REQUEST_CLAIM to startd at
  lt128.105.143.1455642gt
• Result ClassAd written to c1.out
• ID of new claim is lt128.105.143.1455642gt105165
  62082
• condor_cod_activate keyword fractgen \
• id lt128.105.143.1455642gt10516562082
• Successfully sent CA_ACTIVATE_CLAIM to startd at
  lt128.105.143.1455642gt

18
Step 4 Checkpoint to swap
Users Workstation
Compute Farm
Suspended worker
SELECT FRACTAL TYPE ltMandelbrotgt (more user
input)
suspend
19
Step 4 Commands used
condor_cod_suspend \ id lt128.105.143.14556
42gt10516562082 Successfully sent
CA_SUSPEND_CLAIM to startd at lt128.105.143.145564
2gt

• Rendering application on each COD node is
  suspended while interactive tool waits for input
• The resources are now available for batch Condor
  jobs

20
Step 5 Batch jobs can run
Users Workstation
Compute Farm
SPECIFY PARAMETERS max_iterations 400000 TL
-0.65865, -0.56254 BR -0.45865, -0.71254 (more
user input)
Batch queue
21
Step 6 Computation burst
Users Workstation
Compute Farm
Interactive workers
On-demand workers
Idle nodes
CLICK ltRENDERgt TO VIEW YOUR FRACTAL
RENDER
resume
Suspended batch job
22
Step 6 Commands used
condor_cod_resume \ id lt128.105.143.145564
2gt10516562082 Successfully sent
CA_RESUME_CLAIM to startd at lt128.105.143.1455642
gt

• Batch Condor jobs on COD nodes are suspended
• All COD rendering applications are resumed on
  each node

23
Step 7 Results produced
Users Workstation
Compute Farm
Interactive workers
On-demand workers
Idle nodes
Data
Display
Suspended batch job
24
Step 8 User input while batch work resumes
Users Workstation
Compute Farm
Suspended worker
Idle nodes
Idle nodes
ZOOM BOX COORDINATES TL -0.60301, -0.61087 BR
-0.58037, -0.62785
suspend
25
Step 9 Computation burst 2
Users Workstation
Compute Farm
Interactive workers
On-demand workers
Idle nodes
Data
resume
Display
RENDER
Suspended batch job
26
Step 10 Clean-up
Users Workstation
Compute Farm
Idle nodes
Idle nodes
REALLY QUIT? Y/N Releasing compute nodes 4
nodes terminated successfully!
release
27
Step 10 Commands used
condor_cod_release \ id lt128.105.143.14556
42gt10516562082 Successfully sent
CA_RELEASE_CLAIM to startd at lt128.105.143.145564
2gt State of claim when it was released
"Running"

• The jobs are cleaned up, claims released, and
  resources returned to batch system

28
Other changes for COD

• The condor_starter has been modified so that it
  can run jobs without communicating with a
  condor_shadow
• All the great job control features of the starter
  without a shadow
• Starter can write its own UserLog
• Other useful features for COD

29
condor_status cod

• New cod option to condor_status to view COD
  claims in a Condor pool
• Name ID ClaimState TimeInState
  RemoteUser JobId Keyword
• astro.cs.wi COD1 Idle 0000004 wright

• chopin.cs.w COD1 Running 0000205 wright
  3.0 fractgen
• chopin.cs.w COD2 Suspended 0001021 wright
  4.0 fractgen
• Total Idle Running
  Suspended Vacating Killing
• INTEL/LINUX 3 1 1
  1 0 0
• Total 3 1 1
  1 0 0

30
What else could I use all these new features for?

• Short-running system administration tasks that
  need quick access but dont want to disturb the
  jobs in your batch system
• A Grid Shell
• A condor_starter that doesnt need a
  condor_shadow is a powerful job management
  environment that can monitor a job running under
  a hostile batch system on the grid

31
Future work

• More ways to tell COD about your application
• For now, you define important attributes in your
  condor_config file and pre-stage the executables
• Ability to transfer files to and from a COD job
  at a remote machine
• Weve already got the functionality in Condor, so
  why rely on a shared filesystem or pre-staging?

32
More future work

• Accounting for COD jobs
• Working with some real-world applications and
  integrating these new COD features
• Would the real users please stand up?
• Better Grid Shell support
• This is really a separate-yet-related area of
  work

33
How do you use COD?

• Upgrade to Condor version 6.5.3 or greater COD
  is already included
• There will be a new section in the Condor manual
  (coming soon)
• If you need more help, ask the ever helpful
  condor-admin_at_cs.wisc.edu
• Find me at the BoF on Wednesday, 9am to Noon
  (room TBA)
