Intermediate and High Voltage Microscopy

1
Intermediate and High Voltage Microscopy Chapter
16
2
(No Transcript)
3
The greater the accelerating voltage the shorter
the l
Therefore, a 50,000 volt (50 kV) electron has a
wavelength of 0.0055nm and a 1MeV electron has a
wavelength of 0.00123nm!
4
A million volt (MeV) TEM must maintain an
accelerating voltage that is stable to within 0.5
volts.
5
A million volt (MeV) TEM must maintain an
accelerating voltage that is stable to within 0.5
volts. With this coupled with a field emission
source one can achieve resolutions that are in
the range of 0.5Å
6
Hitachi 3 MeV is the most powerful TEM ever made
7
Hitachi 3 MeV is the most powerful TEM ever made
Operator
8
It requires its own separate building
Operator
9
Advantages of High Voltage EM
Increased Resolution Although still a long way
from a theoretical resolution of 0.0006 nm. the
best actual resolution has been achieved with a 1
MeV field emission TEM.
Nanocrystalline structure of silicon
10
Advantages of High Voltage EM
Increased Resolution Although still a long way
from a theoretical resolution of 0.0006 nm. the
best actual resolution has been achieved with a 1
MeV field emission TEM.
1 MeV 200 kV 100kV
11
Advantages of High Voltage EM
Increased Specimen Penetration As accelerating
voltage increases the ability of the beam to
penetrate also increases.
12
Advantages of High Voltage EM
Increased Depth of Information The great depth
of information allows an entire thick section to
be viewed at once.
Dendrite in 3 mm thick section
13
Advantages of High Voltage EM
Increased Depth of Information It also allows
for stereo pairs to be created from thick
sections.
Mitotic cell stereo pair
14
Advantages of High Voltage EM
Reduced Beam Damage The increased speed of the
electrons actually decreases the likelihood of an
inelastic collision.
The same section viewed with 1 MeV vs. 100 kV
will have less contrast due to fewer scattered
electrons
15
The Boulder Laboratory for 3-Dimensional Electron
Microscopy of Cells is located at the University
of Colorado. It is a National Resource Center
supported by the National Center for Research
Resources (NCRR) at the National Institutes of
Health (NIH).
16
National  Center  for  Microscopy  and   Imaging
Research - University of California, San Diego
Lenzi D, Crum J, Ellisman MH, Roberts WM.
Depolarization Redistributes Synaptic Membrane
and Creates a Gradient of Vesicles on the
Synaptic Body at a Ribbon Synapse. Neuron 2002
Nov 1436(4)649-59
17
U.S. Department of Energy facility located at the
University of California, Berkeley
18
Korea Basic Science Institute
http//www.kbsi.re.kr/
JEM ARM-1300S Morning Star Ultra-High Voltage
TEM Facility
Under construction (2002.3)
19
Functions of Morning Star

• Atomic resolution better than 0.12nm
• High-angle tilting 60 degree
• (a new function for 3-D structure analysis of
  materials in atomic level)
• Attachment of a new energy filtering system
• (functions for contrast enhancement, chemical
  analysis and electron structure analysis)
• Availability of various specimen holders for in
  situ study
• (capable of temperature variations from liquid He
  to 1500oC, as well as strain variations)
• Remote control operation
• (providing user-friendly system through remote
  operation, automatic alignment, and so on)

20
Remote control system FasTEM
21
U.S. HVEMs that have either shut down or are
underutilized University of Wisconsin
Madison Wadsworth Center Albany, New York SUNY
Stony Brook, New York
22
Intermediate Voltage (200-400 kV)
JEOL JEM-4000FX
Hitachi H-9000NAR
23
ESI allows an independent way to eliminate
scattered electrons from thick sections and when
combined with an intermediate voltage scope often
negates the need for a HVEM
