Brain Development

1
Brain Development Plasticity

• Dr. Elizabeth Sheppard

2
Learning objectives

• Consider the role of brain development in the
  study of childhood
• cognitive disorders
• General principles of brain development
• Influences on brain development
• Prenatal brain development
• Structural features
• Cellular basis (proliferation, migration,
  differentiation)
• Disruptions to prenatal development
• Postnatal brain development
• Dendritic aborisation
• Synaptogenesis
• Myelination
• Specialisation or functional plasticity?

3
Developmental Cognitive NeuropsychologyThe
Neuro Dimension

• Why look at brain development?
• DCN how are cognitive functions may be
  disordered during development?
• Adult Cognitive Neuropsychology has shown there
  to be a close relationship between brain and
  behaviour (e.g., localisation of function).
  Assumes breakdown within a stable or static
  system.
• But development dynamic process. Complex
  interaction between neurological, cognitive, and
  psychosocial factors.
• Need to understand the neural mechanisms involved
  in brain development to fully appreciate the
  relationship between the developing brain and
  cognitive functions.

4
Developmental Cognitive NeuropsychologyThe
Neuro Dimension

• Key aspects of CNS development for DCN
• 1.Is there a relationship between changes in
  brain structure/function and cognitive
  development?
• 2.Recovery of impaired cognitive functions
  Higher during certain periods of brain
  development? Is neural plasticity simply a
  response to insults or a driving mechanism in
  development?
• 3.What is the role of environmental influences
  on brain maturation? Can changes in environment
  influence cognitive development and
  rehabilitation? What are the negative
  consequences of disadvantaged environments?

5
Brain Development General Principles

• 1.) Protracted period of brain development
• The CNS starts to develop early in gestation and
  continues through
• infancy and childhood to adolescence and into
  adulthood.
• Prenatal development ? structural formation
• Postnatal development ? elaboration of CNS

•
  (connectivity)

6
Brain DevelopmentGeneral principals

• 1.) Protracted period of brain development
• Ongoing process throughout gestation and
  childhood.
• Unique to humans.
• Fastest rate occurs prenatally. Approx. 250,000
  new brain cells formed every minute (Papalia
  Olds, 1992).
• Structural morphology of brain complete at birth
  but growth continues postnatally (birth approx.
  400 g early adulthood (peaking 18-30 years)
  approx. 1500 g gradual decline)
• Postnatal increase in brain weight due to
  differentiation, growth and maturation of
  existing neurons (not formation of new neurons).

7
Brain DevelopmentGeneral principals

• Stages of human brain development throughout
  gestation.
• About day 40 of embryonic life CNS begins to
  develop.
• Around day 100, brain is recognisable in its
  mature form.
• (from Johnson, 1997)

8
Developmental Cognitive NeuropsychologyThe
Neuro Dimension

• 1.) Protracted period of brain development
• 2.) Properties of brain development
• Nature of brain development is believed to be
• hierarchical (cerebellar/brain stem areas, then
  posterior areas, and lastly anterior regions,
  especially frontal cortex)
• stepwise (growth spurts in weeks 24-25 gestation
  (completion of neuronal generation), early
  infancy (dendritic synaptic development
  myelination), then again at 7-10 years, and in
  early adolescence)
• stage-like (follows a series of precise and
  genetically pre-determined stages partially
  pre-requisite sequence of complicated and
  over-lapping processes).

9
Brain DevelopmentGeneral principals

• 1.) Protracted period of brain development
• 2.) Properties of brain development
• 3.) Two major processes operate
• Process of addition
• ongoing accumulation or growth
• E.G.1. myelination (stage-like progression)
• E.G.2. dendritic aborisation (continual
  progression)
• Process of regression
• initial overproduction followed by elimination of
  redundant elements
• E.G.1. Number of neurons prenatally is in excess
  of number required by mature brain. Redundant
  neurons die off during stage of differentiation.
• E.G.2. Number of synapses formed postnatally
• Not considered detrimental. Fine-tuning of system.

10
Brain DevelopmentGeneral principals

• 1.) Protracted period of brain development
• 2.) Properties of brain development
• 3.) Two major processes operate
• 4.) Critical or sensitive periods
• Stage in developmental sequence during which a
  behavioural function experiences major
  progression
• If progression does not occur appropriately then
  it may never occur.
• E.G. Visual deprivation during critical periods
  results in irreversible effects on ongoing
  maturation of particular visual processes
  (Blakemore, 1974).
• E.G.2. In humans, removal of cataracts after
  early infancy affects particular visual processes
  (e.g., face processing, LeGrand et al., 2003)

11
Brain DevelopmentInfluences

• Various influences can impact on brain
  development. These include
• Direct CNS injury or insult (e.g., stroke,
  tumour, trauma)
• Environmental factors (e.g., malnutrition,
  sensory deprivation)
• Environmental toxins (e.g., lead, radiation)
• Psychosocial factors (e.g., quality of
  mother-child relationship, level of available
  stimulation, social support structures, access to
  resources etc.)

12
Brain DevelopmentInfluences

• Impact may not be static. Cascading influences on
  brain maturation may occur. For example
• meningitis or febrile convulsions ? hippocampal
  sclerosis ?
• epilepsy (Ounstead et al., 1966)
• cranial irradiation (treatment for cerebral
  tumour or
• leukaemia) ? delayed cerebral pathology,
  especially cerebral
• calcifications and other white matter pathology
  (Matsumoto et al., 1995 Paakko et al., 1992)

13
Prenatal CNS DevelopmentStructural features

• Prenatal brain development resembles that of
  other vertebrates.
• Soon after conception, the fertilized cell
  undergoes process of rapid cell division ?
  cluster of proliferating cells called the
  blastocyst.
• Within a few days, blastocyst differentiates into
  three-layered structure called the embryonic
  disc.

14
Prenatal CNS DevelopmentStructural features

• Embryonic disc further differentiates into major
  organic systems
• Endoderm (inner layer) ? internal organs (e.g.,
  digestive etc)
• Mesoderm (middle layer) ? skeletal muscular
  structures
• - Ectoderm (outer layer) ? skin surface
  nervous system

From http//www.howe.k12.ok.us/
15
Prenatal CNS DevelopmentStructural features

• CNS begins with a process called neurolation.
• Portion of ectoderm folds in on itself ? hollow
  cylinder called the neural tube.
• Disruption ? serious structural abnormalities
• incomplete closure of spinal cord
• (myelomeningocele) ? spina bifida
• incomplete closure of neural tube
• (anencephaly) ? absent skull vault i.e.
• no brain (incompatible with life)

Spina Bifida Association - Wisconsin
16
Prenatal CNS DevelopmentStructural features

• Neural tube differentiates along three
  dimensions
• Length ? major subdivisions of CNS (forebrain
  midbrain, spinal cord)
• Circumference ? sensory motor systems
• Radius ? different layering patterns cell types

17
Prenatal CNS DevelopmentStructural features

• Disruption of neural tube differentiation?
  failure of formation of structural divisions.
  Include
• - E.G.1. Failure to form two cerebral hemispheres
  (holoprosencephaly)
• - E.G.2. Incomplete fusion of the skull
  (craniosynostosis)

Holoprosencephaly Alobar From
http//www.urmc.rochester.edu
Lobar holoprosencephaly From http//uiowa.edu)
18
Prenatal CNS DevelopmentCellular basis

• CNS contains two main classes of cells
• Neurons ? produced by division of neuroblasts
• Glial cells ? produced by division of glioblasts
• Neurons
• Basic functional (computational) unit of the CNS
• Transmit impulses within complex network of
  interconnecting brain cells
• Enormous variety of neurons, depending on
  function - all with similar basic structure

19
Prenatal CNS DevelopmentCellular basis
3.

• Four primary components
• cell body
• axon
• dendrites
• presynaptic terminals
• (from Kolb Whishaw, 1996)

1.
2.
4.
20
Prenatal CNS DevelopmentCellular basis

• Structure of neurons comprise four primary
  components
• the cell body (metabolic functions of neuron,
  holds RNA DNA)
• the axon, long projection from cell body
  (conducts nerve impulses away from cell body.
  Mature axon covered by coating of myelin ? rapid
  neural transmission)
• the dendrites, branch off from cell body (receive
  and conduct impulses from other neurons towards
  cell body. Dendritic spines locus of the synapse
  ? information is transmitted between neurons)
• the presynaptic terminals (neurotransmitters are
  stored and released, cross the synaptic cleft ?
  activate neurons at postsynapse)

21
Prenatal CNS DevelopmentCellular basis

• Glial cells
• Supportive and nutrient role
• Nine times as many glial cells as neurons
• Lack axons
• Several subtypes, including
• Astrocytes (form blood-brain barrier, support
  cellular structure of brain, direct migration of
  neurons, clean up and plug injury sites)
• Oligodendrocytes (speed up neural transmission by
  coating axons with myelin)
• Microglia (clean up tissue around injury sites,
  primarily in grey matter)
• Relatively immature in early stages of brain
  development. Continue to generate with increased
  CNS maturity.

22
Prenatal CNS DevelopmentCellular basis

• Prenatal brain development follows a genetically
  predetermined sequence involving three major
  mechanisms
• Proliferation - cell generation
• Migration - young neurons move to their permanent
  locations.
• Two forms (i) Passive cell displacement -
  oldest cells pushed away from newer cells ?
  outside-to- inside spatiotemporal gradient.
• (ii) Active migration - young cells move past
• previously generated cells ? inside-out
  gradient.
• Differentiation - complex process in which cells
  become committed to specialised systems.
  Involves (i) development of cell bodies (ii)
  selective cell death (iii) dendritic and axonal
  growth (iv) formation of synaptic connections

23
Prenatal CNS DevelopmentCellular basis

• Major developmental processes occurring prenatal
  brain development.
• Each successive process commences prior to the
  completion of the previous one.
• Final processes are heterochronous across
  cortical areas.
• (from Anderson et al.,2001)

24
Brain DevelopmentInfluences

• Risk factors affecting prenatal brain development
  include
• Maternal stress and age
• Maternal health (e.g., history of infection,
  rubella, AIDS, herpes simplex)
• Maternal drug and alcohol addiction (smoking,
  alcohol, marijuana, cocaine, heroin)
• Environmental toxins (lead, radiation, trauma)

25
Prenatal CNS DevelopmentDisruptions

• Interruptions to the major developmental
  processes of prenatal brain development can have
  severe consequences for ongoing development
  (including cognitive development).
• Timing of the insult may be more important to
  outcome than the nature and severity of the
  insult during prenatal development.
• Earlier disruption ? impact on gross cerebral
  morphology
• Later disruption ? impact on migrational activity
  neuronal differentiation

26
Prenatal CNS DevelopmentDisruptions

• Examples of differences in timing of insult on
  prenatal brain development include
• Induction (dorsal) weeks 3-4
• Myelomeningocele (spina bifida). Failure of
  closure of the spinal cord. Arises from genetic
  or nutritional factors. Results in motor
  perceptual deficits.
• Induction (ventral) weeks 5-6
• Holoprosencephaly. Failure to form two
  hemispheres. Often genetic origin. Usually
  incompatible with life.
• Proliferation 2-5 months
• Microencephaly. Early cessation of cell division
  ? abnormally small head. Genetic or trauma
  factors, e.g., infection, fetal alcohol syndrome.
  Associated with low intellectual abilities.

27
Prenatal CNS DevelopmentDisruptions

• Examples of differences in timing of insult on
  prenatal brain development include
• Migration 2-5 months
• Lissencephaly, Schizencephaly, Dysplasias
• Differentiation
• Porencephaly. Large cystic lesions, usually
  bilateral. Occurs at
• 5-7 months gestation. Usually of
  traumatic/vascular/
• infectious origin. Often results in retardation
  and epilepsy.

28
Prenatal CNS DevelopmentMalformations of
cortical development

• Classical lissencephaly
• smooth gyral pattern and
• thickened cortex
• migrational disorder
• between weeks 11-13
• severe mental retardation,
• seizures, neuromotor
• disorders.
• (from Anderson et al., 2001)

29
Prenatal CNS DevelopmentMalformations of
cortical development

• unilateral schizencephaly
• grey matter-lined cleft in
• right posterior frontal lobe
• communicating with right
• lateral ventricle
• migration disorder at 8
• weeks
• mental retardation,
• seizures, neuromotor
• disorders.
• (from Anderson et al., 2001)

30
Prenatal CNS DevelopmentMalformations of
cortical development

• Focal cortical dysplasia
• evidence of poor grey-
• white matter differentiation
• and low white matter signal in
• the right hemisphere
• migrational disorder with
• multiple origins
• results in epilepsy, learning
• disability, schizophrenia.
• (from Anderson et al., 2001)

31
Prenatal CNS DevelopmentMalformations of
cortical development

• hemimegencephaly
• markedly abnormal left
• hemisphere with thickened,
• irregular cortex, excessive
• white matter, heterotopic
• grey matter, and a dilated,
• dysmorphic lateral ventrical
• (from Anderson et al., 2001)

32
Postnatal DevelopmentCNS elaboration

• Protracted process. Occurs throughout childhood
  and into adolescence.
• Brain quadruples in size from birth to adulthood.
  Occurs not because of increase in number of
  neurons (which is established at birth) but
  because of three processes of elaboration
  (additive)
• dendritic aborisation
• synaptogenesis
• myelination

33
Postnatal DevelopmentCNS elaboration

• Dendritic aborisation
• Additive process, no evidence of regression or
  pruning of dendrites (e.g., Huttenlocher, 1996)
• Dendritic branching begins as early as 25-30
  gestation and continues until birth.
• Major changes occur postnatally, including
  increased length and branching.
• Most dramatic development occurs between
  postnatal weeks 5-21. Adult levels at 5-6 months
  (Becker et al., 1984).
• Development in the frontal areas may continue
  until age 7 (Huttenlocher, 1996).
• Environmental stimulation/deprivation can
  increase/hinder the process (e.g., Kolb, 1995).

34
Postnatal DevelopmentCNS elaboration

• Cellular structure of visual cortex from birth to
  6 months. Shows increased connectivity in brain
  during this period. (From Johnson, 1997).

35
Postnatal DevelopmentCNS elaboration

• Synaptogensis
• Synaptic connections increase from birth, with
  bursts of rapid
• growth at various stages within different
  cerebral regions
• - V1 peak in density between 4-12 months (150
  of adult)
• - A1 (Heschls gyrus) similar
• - Prefrontal cortex density increase is much
  slower, peak only after first year
• - Begins in 2nd trimester of gestation
  (Molliver et al., 1973)
• Most development is postnatal
• Regressive process (initial over-production then
  reduction)
• Synapses initially unspecified in function
  (Huttenlocher, 1994)
• As neural circuits emerge synapses become
  utilised in these
• functional systems
• Unspecified synapses regress, starting after 1
  year

36
Postnatal DevelopmentCNS elaboration

• Synaptogensis
• Relatively immune to environmental
  stimulation/deprivation
• (Goldman-Rakic et al., 1997)
• Parallel pattern of development of
  neurotransmitter levels
• (Huttenlocher, 1994) i.e. although
  counter-intuitive, there is
• some consistency in this rise-and-fall pattern
  of development
• Redundancy of synapses may be associated with
  functional
• plasticity (Huttenlocher, 1994).

37
Postnatal Development
Additive/Regressive Processes

• Rise and fall of synaptic density for visual
  (open circles), auditory (filled circles) and
  prefrontal cortex (crossbars)
• From Huttenlocher (2002)

38
Postnatal DevelopmentCNS elaboration

• Myelination
• Mostly postnatal process, with rapid development
  in first 3
• years but continuing, at a slower pace, into
  second decade
• (Valk Van der Knapp, 1992)
• Hierarchical progression (e.g., Fuster, 1993)
• proximal before distal
• sensory before motor
• projection before association
• central before poles
• posterior before anterior
• Gradual increase in thickness of myelin sheaths
• Rate varies across cerebral regions, with
  frontal lobes
• becoming myelinated last
• Disruption to process leads to reduced speed of
  response,
• attention, processing capacity, IQ.

39
Brain DevelopmentInfluences

• Risk factors affecting postnatal brain
  development include
• Birth complications (e.g., anoxia, prematurity)
• Nutrition
• Cerebral infection
• Environmental toxins (lead, radiation, trauma)
• Environment experience (e.g. normal sensory
  experiences vs. sensory deprivation)

40
Human brain development Postnatal influences

• Sensory deprivation of input affects synaptic
  density in kittens
• From Huttenlocher (2002)

41
Specialisation or functional plasticity of the
cerebral cortex

• How do different brain areas specialise?
• Two major opposing views on functional
  specialisation within the
• cerebral cortex
• Prespecified functional organisation
• - cortical differentiation begins
  prenatally with cortical structure and function
  established prior to postnatal
• experience (Rakic, 1988), by
  intrinsic factors.
• neuronal proliferation migration suggest
  neurons are
• preprogrammed to form particular
  cerebral structures
• that subsume particular functions
  (Johnson, 1997).

42
Specialisation or functional plasticity of the
cerebral cortex

• Undifferentiated cortex
• cortex is initially undifferentiated but becomes
  increasingly specialised in function throughout
  postnatal period (e.g., Killackey, 1990 OLeary,
  1989) due to extrinsic factors like input from
  other parts of brain
• suggests cortical regions could subsume a variety
  of functions depending on the sensory input they
  receive.
• if cerebral damage occurs before specialisation
  is complete functional localisation may be
  permanently altered.

43
Specialisation or functional plasticity of the
cerebral cortex

• Considerable disagreement over these two
  viewpoints e.g. Temple vs. Johnson
• Temple - plasticity is response to brain damage
  but not a driving force in development.
  Maturational account (preformist nativist)
  Areas come online at different points in
  development, according to a genetically specified
  plan.
• - Johnson argues middle-ground position whereby
  large scale regions are prespecified, while
  establishment of small-scale functional areas
  require activity-dependent processes. Interactive
  Specialisation Account (neuroconstructivist)
  Experience is necessary to build functional
  long-range connections between areas that earlier
  in development are not connected as effectively.
  These connections drive specialisation mutually
  across areas.

44
Background Reading

• Anderson, V., Northam, E., Hendy, J., Wrennall,
  J. (2001). Developmental Neuropsychology A
  Clinical Approach. Hove Psychology Press.
  Chapter 2.
• Johnson, M.H. (2000). Developmental Cognitive
  Neuroscience. Oxford
• Blackwell Publishers Ltd. Chapter 2.
• Johnson, M.H., Munakata, Y., Gilmore, R.O.
  (Eds). (2002). Brain
• Development and Cognition A Reader. Oxford
  Blackwell Publishing. Part II.
• General principles of CNS development
  Nowakowski, R.S. Hayes, N.L.
• Intrinsic and extrinsic determinants of
  neocortical parcellation A radial model Rakic,
  P.
• Positrom Emission Tomography study of human brain
  functional development Chugani, H.T., Phelps,
  M.E. Mazziotta, J.C.
• Morphmetric study of human cerebral cortex
  development Huttenlocher, P.R.

45
References

• Anderson, V., Northam, E., Hendy, J.,
  Wrennall, J. (2001). Developmental
  Neuropsychology A
• Clinical Approach. Hove Psychology Press.
• Becker, L., Armstrong, D., Chan, F., Wood, M.
  (1984). Dendritic development in human occipital
• cortical neurons. Developmental Brain
  Research, 13, 117-124.
• Blakemore, C. (1974). Development of functional
  connections in the mammalian visual system.
  British
• Medical Bulletin, 30, 152-157.
• Fuster, J. (1993). Frontal lobes. Current
  Opinion in Neurobiology, 3, 160-165.
• Goldman-Rakic, P.S. (1997). Development of
  cortical circuitry and cognitive functions. Child

• Development, 58, 601-622.
• Huttenlocher, P.R. (1994). Synaptogenesis in
  human cerebral cortex. In G. Dawson K. Fischer
  (Eds.),
• Human behaviour and the developing brain. New
  York Guilford Press.
• Huttenlocher, P.R. (1996). Morphometric study of
  human cerebral cortex development. In M. Johnson
• (Ed.), Brain development and cognition A
  reader. Cambridge, MA Blackwell.
• Johnson, M.H. (1997). Developmental Cognitive
  Neuroscience. Oxford Blackwell Publishers Ltd.
• Killackey, H. (1990). Neocortical expansion An
  attempt towards relating phylogeny and ontogeny.
• Journal of Cognitive Neuroscience, 2, 1-17.
• Kolb, B. (1995). Brain plasticity and behavior.
  Hillsdale, NJ Lawrence Erlbaum Associates Inc.
• Kolb, B. Wishaw, Q. (1996). Fundamentals of
  human neuropsychology (4th ed.). New York W.H.
• Freeman.

46
References

• Matsumoto, T., Takahashi, S., Sato, A.,
  Imaizumi, M., Higano, S., Sakamoto, K., Asakawa,
  H., Tada, K.
• (1995). Leukoencephalopathy in childhood
  hematopic neoplasm caused by moderate-dose
  methotrexate
• and prophylactic cranial radiotherapy An MR
  analysis. International Journal of Radiation
  Oncology
• and Biological Physics, 32, 913-918.
• Molliver, M.E., Kostovic, I., Van der Loos, H.
  (1973). The development of synapses in cerebral
  cortex in
• the human fetus. Brain Research, 50, 403-407.
• OLeary, D. (1989). Do cortical areas emerge
  from a protocortex? Trends in Neurosciences, 12,
  400-
• 406.
• Ounstead, C., Lindsey, J.T., Norman, R.M.
  (1966). Biological factors in temporal lobe
  epilepsy
• (Clicnics in Developmental Medicine No. 22).
  London Heinemann Medical Books.
• Paakko, E., Vainionpaa, L., Lanning, M.,
  Laitinen, J., Pyhtinen, J. (1992). White matter
  changes in
• children treated for acute lymphoblastic
  leukemia. Cancer, 70, 2728-2733.
• Papalia, D. Olds, S. (1992). Human Development
  (5th ed.). New York McGraw-Hill.
• Rakic, P. (1988). Specification of cerebral
  cortical areas. Science, 241, 170-176.
• Valk, J. Van der Knapp, M.S. (1992). Toxic
  encephalopathy. American Journal of
  Neuroradiation, 13,
• 747-760.
