The McMathPierce Solar Telescope Stellar Spectrograph

1
The McMath-Pierce Solar Telescope Stellar
Spectrograph

• ESS 590 Winter 2007 Lecture

2
Scientific Motivation
STIS observations of Io
Jovian System Io Plasma Torus
3
Scientific Summary

• Oxygen and sulfur emission near Io
• Localized position of spots show dependence on
  orientation of Jupiters magnetic field
• Integrated intensity shows dependence on density
  of the Io plasma torus (work in progress)

4
(No Transcript)
5
(No Transcript)
6
R 120,000 (?/??) at 6300 Å
7
Grating basics
http//www.physicsclassroom.com/Class/light/U12L1b
.html
8
Grating basics

• m ? d (sin(?i) sin(?m))

http//www.madsci.org/posts/archives/May2003/10533
50704.Ph.r.html
9
Blazed grating

• Scattering surfaces are tipped at an angle to
  make scattering more efficient at a particular
  angle

http//grus.berkeley.edu/jrg/ins/node3.html
10

• Stellar spectrograph echelle operated at order m
  36 for OI
• Get angular dispersion from derivative of
  diffraction angle wrt wavelenth
• High m ? high dispersion

R 120,000 (?/??) at 6300 Å
11
Io OI line
Example spectrum 2002 Jan 26
12
Io, Telluric and solar lines identified
13
Fitting Software
3600 Io spectra, gt15,000 calibration images
14
Clear Detection of Io OI Signal
15
Variation in Ios OI brightness not quite where
you would expect in System III
16
Why?

• Details of Ios orbit and torus

17
(No Transcript)
18
Correlate Multiple Datasets

• STIS (when we had it)
• Ground-based torus images
• Ground-based Io OI
• Jovian aurora
• Jupiters mag field
• Spacecraft flyby
• Solar wind or jup mag field

19
Cool things to do with the Io OI dataset

• Compare to Io volcanic record
• Compare to solar wind activity
• Compare to Io flux tube footprint on Jupiter
• Complement spacecraft data (a permanent in situ
  probe)
• Model of Io OI emission variation seems to work
  well assuming Io does not disturb the torus. All
  you need is a scaling factor, which does vary on
  different days

20
Example Comparison 1997 Oct 14

• Increase in emission is unusually large in UV
  lines (but we dont have many observations)
• Increases like this in groundbased data are
  common
• Torus images were showing a knot in about the
  right place

21
Observed Asymmetry in torus images, fall 1997
22
Io OI model shows there should be a factor of
2, not 3 in brightening
23
BUT that is using the old hand-reduced data

• Machine reduction with the same line list gives
  the same results

24
BUT that is using the old hand-reduced data

• Machine reduction with expanded line list gives
  different results

25
What does it all mean?
