Laboratory experiences in a mechanical and aerospace engineering department

1
Laboratory experiences in a mechanical and
aerospace engineering department

• Edward White - ebw_at_aeromail.tamu.edu
• Aerospace Engineering, Texas AM University
• Until recently - Mechanical and Aerospace
  Eng., Case Western Reserve University

2
What to do (and what canbe done) in
undergraduatelab courses

• Edward White - ebw_at_aeromail.tamu.edu
• Aerospace Engineering, Texas AM University
• Until recently - Mechanical and Aerospace
  Eng., Case Western Reserve University

3
Undergraduate lab instruction should produce
competent producers and consumers of experimental
results.
4
We who hire new grads need them to to start work
or grad. school ready to make meaningful
contributions.
5
How should we structure laboratory instruction to
achieve this?Maximum exposure?Stressing
fundamentals?Something in between?(What about
demos for other courses?)Theres limited time,
credit hours and attention. We cant do it all.
6
The right balance prepares students to make
meaningful contributions in the widest range of
applications and roles over the span of their
careers
7
To achieve this, we shouldstress thoughtful
application ofkey principles, not maximum
exposure to state-of-the-art instruments or
rapid-fire labs
8
Why emphasize key principles over introduction
state of the art?
9
Key principles have enduring value the state of
the art is ever changing.So, use limited time
and resources where theyll have the best and
broadest long-term impact.
10
Students capability to absorb and competently
apply new concepts is limited.
Capture Efficiency ? Delivery Rate -(1?)
11
Theres limited time in lectures, lab
sessionsStudents have limited time(typically
enrolled in 4-5 other courses)I have limited
time.
12
Theres limited time in lectures, lab
sessionsStudents have limited time(typically
enrolled in 4-5 other courses)I have limited
time.
13
Theres limited time in lectures, lab
sessionsStudents have limited time(typically
enrolled in 4-5 other courses)I have limited
time
14
The state of the art is expensive!
15
Why emphasize key principles over introduction
state of the art?
16
Mastery of key principles is whats required for
creativity, design and technical leadership
17
What are the key principles?
18
(1) Every measurement is uncertain and the
uncertainty must be understood and quantified
19
Theres subtlety and difficulty in making even
simple measurements
20
Theres not a right answer on which to fall
back (although one should have a pretty good
guess before starting)
21
Theres almost always a variety of means of
making a measurement
22
Instruments and techniques must be calibrated
against known, reliable standards
23
What are the key principles?
24
(2) Instruments and techniques consist of
knowable components that can be understood,
critiqued, and improved upon by
undergraduates.There should be no black boxes.
25
Instruments consist of multiple simpler components
26
Computers do repetitive things quickly.They
dont do things correctly (necessarily) they do
things quickly.
27
What are the key principles?
28
(3) Theres nothing useful about knowing
something if you can communicate it in a clear
and convincing way
29
Ultimately, mastery of these key principles of
experimental work comes through practice and
application.What do we actually do?
30
Perform a few simple labs that teach the key
principles by requiring clear thinking about a
tractable problems
31
Along the way we teach about data analysis and
simple instrumentation as well as demonstrate
physical principles to enhance other courses
32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
OftenSolid Strain Basic UncertaintyMech. Gages
Prop. Of Errors Computerized
DAQHeat TCs Linear RegressionTrans.Fluid Ho
t Fourier AnalysisMech. Wires
36
Example LabMeasure the pressure in an unopened
pop can.
37
Whats the result?
Mayhem ensues. Functional groups ps Range from
15 to 100 psi. All groups have different ps for
the axial and circumferential gages. Some groups
have a gage break, need to improvise. All have
definite opinions about whether this is a good
way to measure pressure! Most groups are able to
make interesting conclusions about what went
right and what went wrong.
38
This is a simple experimentSimply put some
gages on a can and open it.But, its actually a
rich, complex (but tractable) problem that
uncovers a huge range of real experimental issues.
39
This is the sort of foundation from which we
should build.Dont underestimate the rigor
thats needed even for simple thingsUnderstand
and dissect the processUnderstand uncertainty
40
Use this and a few other practice examples of
similar scope, then move on to the more complex,
more modern work.
