Cytogenetics- Flow cytometry Correlation

1
Cytogenetics- Flow cytometry Correlation

• May 19, 2004
• Dr. Alina Dulau
• Montefiore Medical Center

2
CASE 1 88 year old female, presented with anemia
and leukopenia (11/ 2002)

• CBC Hgb 8.4, Hcr 28.4,WBC 3000/mmc Plt
  300.000/mmc
• Flow cytometry 7-10 CD11b, CD34
  hematopoietic precursors
• Bone marrow biopsy hypocellular (0-30), absent
  stainable iron

3
(No Transcript)
4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
Differential diagnosis of hypocellular BM

• Hypoplastic MDS
• - Cytogenetic abnormalities del(7q)
• - Blasts CD34, dim CD45 expression
• Aplastic anemia
• - Mecs immune destruction of CD34
• - HLA-DR, CD8, CD56

8
FLOW CYTOMETRY

• Flow cytometry 3/2004

9

10
Flow cytometry interpretation

• Blast population (58 of total cells) with
  intermediate intensity CD45 expression and low to
  intermediate side scatter
• CD7(partial), CD11b(partial), CD13,
  CD14(partial), CD33(partial), CD34,
  CD64(partial), CD117, HLA-DR-
• Dx Immature myelomonocytic phenotype c/w Acute
  myelomonocytic leukemia

11
Chromosomal Analysis Unstimulated Peripheral
Blood

• Staining with GTG Band
  Resolution 450
• No. of cells analysed 20 No of cells
  karyotyped 2
• CYTOGENETIC DIAGNOSIS
• 46,XX, inv(3) (q21q26) 2 / 45, idem, -7 15 /
  46, idem, del (7) (p11.2p15) 3

12
46,XX,inv(3)(q21q26),del(7)(p11.2p15)
13
46,XX, inv(3)(q21q26),-7
14
CASE 2 71 year old female with history of
circulating blasts (3) x 3 years

• CBC Hgb 11, Hcr 37.2, WBC 18,600
• Plt 61,000.
• Peripheral smear 7 blasts

15
Flow Cytometry (Jan 2004)-Bone marrowNumber of
blasts, Immunophenotype
16
(No Transcript)
17
(No Transcript)
18

• Flow cytometry interpretation
• 5 CD33, CD117 myeloblasts without
  expression of CD34
• Reduced side scatter of mature myeloid cells

19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
Chromosomal Analysis Unstimulated Peripheral
Blood

• Staining with GTG Band
  Resolution 450
• No. of cells analysed 20 No of cells
  karyotyped 2
• CYTOGENETIC DIAGNOSIS
• 46,XX, dup (1) (q12 q32), 8 20

24
46,XX, dup(1)(q12q23),8
25
MYELODYSPLASTIC SYNDROMES

• Clonal stem cell disorders
• Single or multilineage dysplasia
• Ineffective hematopoiesis
• - Impaired cellular differentiation
• - Increased apoptosis gtprogressive
  pancytopenia
• Accumulation of genetic abnormalities
• 30-75 evolution to acute leukemia

26
Morphologic features

• Dyserythropoiesis
• º Peripheral blood nucleated RBC
• º BM erythroid hyperplasia, megaloblastic
  changes, nuclear budding, karyorrhexis,
  multinucleation, intense basophilia of the
  cytoplasm, vacuolization, poor hemoglobinization,
  PAS cytopl. granules

27
(No Transcript)
28
BM Iron increased, coarse sideroblastic granules

• Dysgranulopoiesis hypogranularity (decreased
  reaction with MPX), abnormal nuclear segmentation
  and lobulation,
• ALIP (abnormal localization of immature
  precursors in the center vs paratrabecular or
  perivascular), immature granulocytes, monocytes,
  blasts in circulation

29
Bone marrow
30
(No Transcript)
31
Myloperoxidase in Bone marrow

32
Clonality of hematopoietic elements involved

• Combined immunophenotyping and FISH (chromosome
  abnormalities)
• Neoplastic transformation of myeloid
  progenitors at the stem cell level
• Involvement of the B lymphoid lineage
• T lymphocytes and NK cells nonclonal

33
Pathophysiology of MDS

• Stepwise accumulation of genetic lesion
• Unbalanced cytogenetic abnormalities
• ? unmasking of oncogenes
• ? inactivation or deletion of tumor
  suppressor genes
• Acquired defective DNA repair
• Genomic instability (telomere shortening)

34
Evolution in MDS

• Early phase Apoptosis is up-regulated
  overweighing proliferation ? peripheral
  cytopenias (apoptosis in BM)
• Leukemic phase abrogated apoptosis (mecs loss
  of function of DAP-kinase due to
  hypermethylation)
• with proliferation of dysplastic clone

35
Prognosis in MDS

• Bone marrow blasts, karyotype, cytopenias
• Good prognosis normal karyotype, Y- only,
• 5q-, 20q-
• Poor prognosis gt/3 karyotypic abnormalities,
  7q-, del(7q)
• Intermediate prognosis all other cytogenetic
  abnormalities

36
Common cytogenetic abnormalities in MDS

• ABNORMALITY
  INCIDENCE
• Loss of all or part of chr 5
  13
• Loss of all or part of chr 7
  5
• Trisomy 8
  5
• del 17p
  lt1
• del 20q
  2
• Loss of X or Y
  2

37
Other cytogenetic changes

• 1 secondary change in disease progression
• 13, 17, 19p, -13q
• Idic (X) (q13)
• Rings and dicentrics in more advanced MDS

38
5q- syndrome

• MDS with del(5q) between bands q31-33
• Refractory anemia
• Middle age to old women
• Macrocytic anemia
• Elevated Platelet count (increased megakaryocytes
  in BM, hypolobated)
• Blasts lt 5

39
Monosomy 7

• Most frequent cytogenetic abnormality of
  childhood MDS
• 20 of children with MDS have other chromosomal
  abnormalities
• Most commonly associated with Downs syndrome and
  Pearson syndrome
• Leukemic evolution similar to adult MDS

40
AML with Myelodysplasia

• gt/ 2 cell lines with dysplastic features
• Myelodysplastic features in gt 10 of the bone
  marrow cells

41
Refractory Anemia with Excess Blasts (RAEB)

• 40 of MDS
• RAEB 1 5-9 blasts in the BM (CD13,
  CD33,CD117)
• lt 5 blasts in the blood
• RAEB 2 10-19 blasts in the BM
• 5-19 blasts in the blood
• Presence of Auer rods
• Genetics8, -5, del(5q),-7, del(7q),del(20q)

42
Molecular abnormalities

• N-ras oncogene
• RAS, FMS mutations aggressive course
• Increased WT1 gene expression evolution AML
• P53
• IRF-1 tumor-suppressor gene
• p15INK4b methylation is associated with del(7q)
• EVI 1, MLL transcription factor genes

43
RAS Gene in MDS

• RAS gene family encodes signal-transducing
  proteins with role in cell growth and
  differentiation
• Normal bone marrow low, uniform levels of p21RAS
• In MDS, p21RAS is overexpressed
• Leukemogenesis in MDS

44
Point mutations of AML1/RUN X1 gene

• Acute Myeloid Leukemia
• Myelodysplastic Syndrome
• AML/ MDS-t (post treatment with alkylating agents)

45
Dysplastic abnormalities in the bone marrow

• Deficiencies of vitamin B12, folate
• Viral infections (HIV)
• Exposure to antibiotics
• Chemotherapeutic agents
• Ethanol
• Benzene
• Lead

46

• Thank you.
