PERIODICITY

1
PERIODICITY
2
(No Transcript)
3
History of the Periodic Table

• 70 elements had been discovered by the
  mid-1800s, but until Dmitri Mendeleev, no one
  had come up with a way to organize the elements.
• Mendeleev came up with the first working system
  of filing the elements.
• He listed the elements in columns in order of
  increasing atomic mass, and then put columns
  together that were similar

4
(No Transcript)
5
History of the Periodic Table

• Mendeleev left gaps in the table since there were
  no current elements that seemed to fit those
  spots
• Those elements were eventually discovered and
  they fit perfectly into an open spot.
• The 1st scientist that set the table in order of
  atomic number was Henry Moseley

6
History of the Periodic Table

• The modern PT is arranged by increasing atomic
  number
• Increases from left to right, and
  top to bottom
• This establishes the periodic law
• When the elements are arranged in order of
  increasing atomic , there is a periodic
  repetition of their phys chem properties

7
(No Transcript)
8
Periodic Table 101

• Most of the elements
  on the periodic table are metals
• 16 of the elements
  are classified as nonmetals
• There are 7 elements that cant
  be classified as metals or nonmetals,
  and they are called metalloids.
• The noble gases are the last column
  on the table and significant because they are
  chemically inert

9
Periodic Table 101

• There are 2 elements that are liquid at room
  temperature (Br Hg).
• There are 11 gaseous elements (the
  noble gases, H, O, N, F, Cl)
• The rest of the elements are solids at room
  temperature
• Elements 1-92 are naturally occurring with the
  exception of Tc, the rest were manufactured with
  an atom smasher

10
Periodic Table 101

• Hydrogen is the most abundant element in the
  universe
• Francium is the least abundant natural element
• The most abundant element on earth
  is Oxygen
• There are over 10,000,000 carbon
  compounds
• The most reactive element is fluorine

11
Periodic Table 101

• The PT is organized into vertical columns called
  groups or families.
• There are 18 columns
• Each family contains elements with similar
  chemical characteristics
• Each element in a family has the same number of
  valence electrons
• This makes it somewhat predictable as to how the
  atom will behave in chemical reaction

12
PNICOGENS
CHALCOGENS
13
Periodic Table 101

• Elements in a group tend to form ions of the
  same charge.
• Modeled by electron configurations.

14
Periodic Table 101
He
O
He
15
The Transition Metals are almost unpredictable,
and sometimes have more than one possible charge
-- due to the d orbitals --
16
Periodic Trend of Ionic Charges
17
Tend to lose electrons to become positive
Tend to gain electrons to become negative
18
Periodic Table 101

• The horizontal rows of elements in the PT are
  called periods.
• Physical and chem characteristics change
  predictably across the period
• Elements close to each other tend to have similar
  characteristics, while elements farther apart
  become increasingly different

19
Periodic Table 101

• The two sets of elements below the PT make up
  what are called the lanthanide and actinide
  series.
• They are metallic and radioactive and should be
  placed after elements 57 89

20
(No Transcript)
21
Periodic Properties

• An elements properties can go hand in hand with
  electron arrangement
• We can use an elements location on the PT to
  predict many properties.
• Atomic radius
• Ionic Size
• Ionization energy
• Electron affinity
• Electronegativity

22
Periodic Properties

• The radius of an atom is defined by the edge of
  its last energy level.
• However, this boundary is fuzzy
• An atoms radius is the measured distance between
  the nuclei of 2 identical atoms chemically
  bonded together - divided by 2.

23
Periodic Properties

• As we examine atomic radius from left to right
  across the PT we see a grad-ual decrease in
  atomic size.
• As e- are added to the s and p sublevels in the
  same energy level, they are gradually pulled
  closer to the highly positive nucleus
• The more e-s in the atom the less dramatic this
  trend looks

24
(No Transcript)
25
Periodic Properties

• The change in atomic radii across the PT is due
  to e- shielding or to the effective nuclear
  charge
• As we move across the
  PT we are adding e- into
  the same gen- eral vol.
  in which case they are
  being shielded
  or screened by interior
  electrons, but the
  shielding isnt
  increasing

26
Periodic Properties

• We are also adding protons into the nucleus which
  increases the p-e- interaction (attraction)
• So the nucleus gains strength while the e- arent
  gaining much distance, so the atom is drawn in
  closer and closer to the nucleus.
• Decreasing the overall radius of
  the atom

27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
Periodic Properties

• How does the size of an atom change when
  electrons are added or removed?

As an Atom loses 1 or more electrons (becomes
positive), it loses a layer therefore, its radius
decreases.
31
Periodic Properties

• How does the size of an atom change when
  electrons are added or removed?

As an Atom gains 1 or more electrons
(negative), it fills its valence layer,
therefore, its radius increases.
32
(No Transcript)
33
Periodic Properties

• Another periodic trend on the table is ionization
  energy (a.k.a. potential)
• Which is the energy needed to remove one of an
  atoms e-s.
• Or a measure of how strongly an atom holds onto
  its outermost e-s.
• If the e-s are held strongly the atom will have a
  high ionization energy

34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
Periodic Properties

• The ionization energy is generally measured for
  one electron at a time
• You can also measure the amount of energy needed
  to reach in and pluck out additional electrons
  from atoms.
• There is generally a large jump in energy
  necessary to remove additional electrons from the
  atom.

38
the amount of energy required to remove a 2p e
(an e- in a full sublevel) from a Na ion is
almost 10 times greater than that required to
remove the sole 3s e-
39
Periodic Properties

• Another periodic trend dealing with an e- is
  electron affinity
• Which is a measure of the ability of an atom to
  attract or gain an electron.
• Atoms that tend to accept an e- are those that
  tend to give a neg. charge.
• The closer to a full outer shell an atom has, the
  higher the affinity (more neg. the measurement)

40
(No Transcript)
41
(No Transcript)
42
Periodic Properties

• An atoms ability to lose an e- or gain an e- can
  be used to understand the Octet Rule
• Octet Rule atoms tend to gain, lose, or share
  electrons in order to acquire a full set of
  valence electrons.
• 2 e- in the outermost s sublevel 6 e in the
  outermost p sublevel a full valence shell

43
(No Transcript)
44
(No Transcript)
45
Periodic Properties

• Electronegativity is a key trend.
• It reflects the ability of an atom to attract
  electrons in a chemical bond.
• F is the most electronegative element and it
  decreases moving away from F.
• Electronegativity correlates to an atoms
  ionization energy and electron affinity

46
(No Transcript)
47
(No Transcript)
48
(No Transcript)
49
BOILING POINT MELTING POINT VS. ATOMIC NUMBER
50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
Electronegativity
Electronegativity
54
Electronegativity
Electronegativity
