FAA In Situ Utilization TodayOperations

• Integrated Terminal Weather System (ITWS)
• Fully automated, integrated terminal weather
  information system.
• Provides current conditions / forecasts (up to 60
  min) of terminal weather
• Accurate, easy-to-understand, and immediately
  useable graphical weather information on a
  single, full color display
• Uses sophisticated algorithms to integrate data
  from FAA and NWS sensors, radars, weather models,
  and from aircraft in flight

4
ITWS
Pilots
NEXRAD
TDWR
ASR
1-hr Forecast Microburst Prediction Gust Front
Prediction Storm Location Motion Storm Cell
Information Terminal Winds Tornado
ITWS
ITWS Real-Time Processor
Controllers
AWOS/ASOS
RUC

• Supervisors
• TRACON
• ARTCC TMU
• CWSU

• Airlines
• Dispatch
• Ramp Tower

LLWAS
Aircraft (MDCRS)
Lightning
5
FAA In Situ Utilization TodayOperations

• Integrated Terminal Weather System (ITWS)
• Users
• Air Traffic personnel in the Air Traffic Control
  Tower (ATCT) and Terminal Radar Control (TRACON)
  facility
• Traffic Management and Center Weather Service
  Unit personnel in the Air Route Traffic Control
  Center (ARTCC)
• Air Traffic Control Systems Command Center
  (ATCSCC), airport authorities, airline dispatch
  offices and other Users (i.e. airlines)
• Authorized FAA non-FAA users have internet
  access to ITWS products
• ITWS products will be made compatible with
  NextGen requirements

6
FAA In Situ Utilization TodayResearch

• Aviation Weather Research Program (AWRP)
• Plans and conducts research, development of new
  weather capabilities and technologies to meet
  current and future aviation needs.
• Turbulence Research Team improving detection of
  en route turbulence
• Developed Eddy Dissipation Rate (EDR) algorithms
• Accelerometer-based algorithm in UAL a/c
  improved winds-based algorithm on DAL a/c, in
  process of implementing on SWA a/c
• EDR data displayed on Aviation Digital Data
  Service (ADDS)
• FY09/10 Yearlong demonstration with DAL to
  investigate the benefits of EDR to NAS
  capacity/safety and airline operations
• QCd EDR data displayed on Earth Systems
  Research Laboratory (ESRL) Global Systems
  Division (GSD) AMDAR display
• EDR integrated into the Graphical Turbulence
  Guidance (GTG-2) product, soon to be operational

7
Graphical Turbulence Guidance (GTG)

• Based on RUC NWP model
• GTG1
• Upper-level CAT (gtFL200)
• Operational on ADDS since 3/2003
• http//adds.aviationweather.noaa.gov
• GTG2
• Clear-air sources 10,000 ft MSL-FL450
• On Experimental ADDS since 11/2004
• Will replace GTG1 on operational ADDS in 2009
• Uses a combination of turbulence diagnostics,
  merged and weighted according to current
  performance (pireps, EDR)
• Current work areas
• Probabilistic forecasts of moderate-or-greater
  (MOG) and severe-or-greater (SOG) turbulence
• Optimal use of insitu reports
• Assimilation of turbulence-related observations

8
GTG Weighted ensemble of turbulence diagnostics
0 h forecast valid at 22 Sep 2006 15Z
9
Graphical Turbulence Guidance (GTG)
10
Graphical Turbulence Guidance (GTG)

• Based on RUC, GFS, or WRF NWP forecasts
• Current work areas include
• Optimal use of in situ reports
• Probability of Moderate Or Greater, Severe Or
  Greater gt some EDR threshold
• Global applications (global GFS, regional WRF)
• Incorporate satellite-based feature detectors
• Output expected to populate the SAS of the
  NextGen 4D Weather Data Cube

11
Next Generation Air Transportation System
(NextGen)
Ground-based Navigation and Surveillance Air
Traffic Control Communications By
Voice Disconnected Information Systems Air
Traffic Control Fragmented Weather
Forecasting Airport Operations Limited By
Visibility Conditions Forensic Safety Systems
12
NextGen Aviation Weather

• Today
• Not integrated into aviation decision-support
  systems (DSS)
• Inconsistent/conflicting weather information
• Low temporal resolution (for aviation decision
  making purposes)
• Updated by schedule
• Fixed graphic or text product formats
• Inconsistent access
• Disjointed point-to-point communications
• Human intensive processing

• NextGen
• Totally integrated in DSS
• Nationally consistent weather information
• High temporal resolution
• Updated by events/situation
• Interactive data formats
• Universal common access
• Net-enabled information connection
• Increased machine to machine communications

13
NextGen Network Enabled Weather (NNEW)

• The 4-D Weather Cube will provide common,
  universal access to aviation weather data.
• Improved weather data (observations forecasts)
  available from the 4-D Weather Data Cube will
  improve traffic management capability and reduce
  delays.
• Provide Single Authoritative Source (SAS) of
  weather information for all users.
• Provide access to weather information indexed by
  aircraft and weather type.
• Reduce the need for human interpretation of data
  by direct machine-to-machine access integration
  in decision support tools.

14
NextGen and the 4-D Weather Cube
15
Reduce Weather Impact (RWI)

• A portfolio of NextGen capability improvements to
  mitigate the effects of weather in future NAS
  operations.
• Provide consistent weather information that will
  support more effective and timely decision making
  through the use of automated decision support
  tools.

16
Reduce Weather Impact

• Two major elements
• Weather Forecast Improvements
• Integrate weather information tailored for
  Decision Support Tools (DSTs) and systems into
  NextGen operations
• Implement improved forecasts by transitioning
  advanced capabilities from aviation weather
  research
• Develop metrics to evaluate the effectiveness of
  weather improvements in the NAS
• Develop probabilistic forecasts which can be used
  for traffic flow management
• Determine the most effective solution for a
  processor architecture to support these
  capabilities
• Propose recommendations for transitioning FAA
  legacy weather systems into NextGen.

17
Reduce Weather Impact

• Two major elements
• Weather Observation Improvements
• Optimize the weather sensor network to eliminate
  redundancy and inconsistencies among sensor
  types, configurations, and ground infrastructure
  reducing cost and improving performance
• Determine the right sensor mix among
  ground-based, satellite, and airborne atmospheric
  sensor networks
• Improve the resolution of the weather sensor
  network
• Effort being worked jointly with government,
  industry, and academic agencies

18
Weather Technology in the Cockpit (WTIC)

• A portfolio of related research and development
  (RD) activities to ensure the adoption of
  cockpit, ground, and communication technologies,
  practices, and procedures that will
• Provide pilots with shared and consistent weather
  information to enhance common situational
  awareness
• Provide airborne tools to exploit the common
  weather picture
• Utilize the aircraft as a node functions to
  autonomously exchange weather information with
  surrounding aircraft and ground systems
• Facilitate integration of weather information
  into cockpit NextGen capabilities (e.g.
  Trajectory Based Operations)

19
Weather Technology in the Cockpit (WTIC)
20
QUESTIONS?
21
Back-up Slides
22
Corridor Integrated Weather System (CIWS)

• Background
• CIWS is an automated weather processing system
  that ingests weather sensor and model data to
  generate a suite of convective weather forecast
  (0 2 Hr) products for the northeast corridor.
• CIWS does not incorporate airborne sensor data
• Integration of CIWS products with Traffic Flow
  Management Decision Support Tools
• CIWS functionality will be component in NextGen
  Weather Processor
• CIWS products are currently disseminated to 15
  FAA facilities (ATCSCC, ARTCCs, TRACONs),
  airlines operations centers, and several RD
  organizations.
• CIWS was developed, operated and maintained by
  MIT Lincoln Laboratory

23
Corridor Integrated Weather System (CIWS)
24
Corridor Integrated Weather System
(CIWS)Graphical Coverage
25
Corridor Integrated Weather System (CIWS)Display
Color Bars
System Menus

• Product Status Button colors
• White the product is not displayed
• Green the product is displayed
• Yellow the product is displayed but filtered
• Red the product is unavailable
• Left-click to toggle right-click for menus

Loop Controls
Additional Products
Base Products
View Menu
Base Product Forecast
26
ITWS-How does it fit into the NAS?

• ITWS is integrated into the FAAs Strategic
  Management Plan
• ITWS helps fill the performance gap identified in
  the FAAs Greater Capacity goal
• Objective 1 Increase airport capacity to meet
  projected demand
• Strategy 1 Improve technologies to make air
  traffic flow more efficiently during periods of
  adverse weather
• ITWS provides significant economic benefits in
  airline operations efficiencies and passenger
  time savings
• Estimated benefits to cost ratios as high as
  19.81

27
Graphical Turbulence Guidance (GTG)

• Based on RUC, GFS, or WRF NWP forecasts
• Current work areas include
• Optimal use of in situ reports
• Probability of Moderate Or Greater, Severe Or
  Greater gt some EDR threshold
• Global applications (global GFS, regional WRF)
• Incorporate satellite-based feature detectors
• Output expected to populate the SAS of the
  NextGen 4D Weather Data Cube
• Dr. Bob Sharman
• sharman_at_ucar.edu
• 303-497-8457
