Design Engineering, Injection Mold Manufacturing, Foam Molds,

1

• Design Engineering, Injection Mold Manufacturing,
  Foam Molds,
• Fixtures Trim Dies.

Building Enduring Partnerships
2
Who we are

• Founded in 1995 privately owned and operated.
• Services Include Production Plastic and
  Prototype Injection Molds, Foam Molds, Mold
  Design, Product Design and Project Management,
  Custom Machining CNC, EDM, Water-jet, Laser
  Welding and CMM.

• Industries Served Automotive, Office Furniture
  and Medical.
• Experience in Automotive Lighting, Automotive
  Interior Exterior, Gas Assist, Two Shot Molds,
  Foam Molds, Fixtures and Trim Dies.
• ISO 90012008 Certified
• 8-10 Million Annual Sales (2010)
• 55 Employees

3
Our Mission
To be our customer's partner in providing the
highest quality products. We achieve this through
our strengths of a flexible, technology-driven
resource base, a skilled workforce, modern
information systems and an active continuous
improvement process.

• We take great care in all our services to give a
  high level of quality and value that will
  continuously earn the respect and loyalty of our
  customers.
• We strive to make superior customer service and
  satisfaction the focal point of all our
  activities and efforts by producing top quality
  products and delivering them on time.
• Detail strives to improve the communities we are
  involved in. We will make every effort to
  increase employment and to maintain cleanliness
  and prosperity in our work environment and
  neighborhoods.

4
Commitment to Quality Continuous Improvement
We understand that certification to an ISO 9001
standard does not guarantee quality of products
services it certifies that formalized business
processes are being applied and maintained by our
robust Quality Management System.

• We achieve high first shot quality.
• Exceptional production team with many years of
  building superior quality tooling and machined
  part production.
• Performance driven.
• On-Time delivery.
• Measured results.

5
Tooling Services
Detail Technologies serves its customers from
concept to delivery with world-class mold design,
development and program management, as well as
excellence in all our manufacturing processes.

• Design Engineering
• Plastic Injection Mold Manufacturing
• Foam Molds, Trim Dies and Fixture Fabrication
• CMM and Reverse Engineering
• Project Management Global and Domestic
• Custom machining CNC, EDM, Waterjet Laser
  Welding

6
Upfront Mold Design
By involving the tool designer, builder and
molder early in product development, you can
reduce turnaround time by weeks or even months,
shave weeks off the mold build cycle and reduce
costs by eliminating potential product design
troubles.
7
Quality Expertise
8
Quality People
9
Quality Machining
10
Our Goal is Net Shape Machining - Zero Benching
11
Our Goal is Net Shape Machining - Zero Benching
12
Our Goal is Net Shape Machining - Zero Benching
13
Quality Results
14
Equipment List

• Electrical Discharge Machines (EDM) Travel
• (1) Ingersoll Gantry 1200 (submerged ram)
  40 (X) x 60 (Y) x 26 (Z)
• (1) Mitsubishi FX 10 (submerged wire) 13.8 (X) x
  9.8 (Y) x 8 (Z)
• (1) Mitsubishi FA-V 20 (submerged wire) 19.7 (X)
  x 13.8 (Y) x 11.8 (Z)
• (1) Mitsubishi EX 8 (submerged ram) 11.7 (X) x
  9.7 (Y) x 9.8 (Z)
• (1) Ingersoll Gantry 500 (submerged ram) 20.7
  (X) x 15.7 (Y) x 14.7 (Z)
• (1) Current EDM Drilling System 12 (Z) and .006
  to .25 dia. holes
• _________________________________________________
  _________________
• CNC Milling
• (2) OKK HM-1250S 67 (X) x 55 (Y) x 49 (Z)
• (1) Fidia K199 Continuous 5-Axis 65 (X) x 30
  (Y) x 33 (Z)
• (1) Parpas Diamond Continuous 5-Axis 87 (X) x
  59 (Y) x 39 (Z)
• (1) Roku-Roku HC-658 w/ 6-Axis Robot 24 (X) x
  20 (Y) x 16 (Z)
• (1) OKK VM 7III 60(X) x 29.5 (Y) x 26 (Z)
• (1) OKK VP 600 44 (X) x 24 (Y) x 18.1 (Z)
• (1) Yasda YBM 640 V High-Speed/hard mill 24 (X)
  x 18 (Y) x 14 (Z)
• (1) Hurco VMX50 50 (X) x 26 (Y) x 24 (Z)
• (1) Johnford DMC-1500H 59.1 (X) x 35.43 (Y)
  x 30(Z)
• (1) KT CNC Data Mill-Horizontal Mill 48 (X) x
  96 (Y) x 24 (Z)

15
Equipment List

• Coordinate Measuring Machine (CMM)
• (1) Numerex DCC 48 (X) x 81 (Y) x 36 (Z)
• (1) LDI RPS 450 Rapid Laser Scanner - with
  Geo-Magic,
• Geo-Measure and Checkmate software
• _________________________________________________
  ______________________
• Waterjet
• (1) Jet Edge Water-jet cutting system 96 (X) x
  48 (Y) x 12 (Z)
• 55K PSI, PC Controlled dual cutting heads
  144 (X) x 60 (Y)
• Aluminum/Steel/Stainless Steel/Titanium/Polycarbo
  nate/Plastic
• Kevlar/Fiberglass/Carbon Fiber/Clad Exotic
  Materials
• _________________________________________________
  _____________________
• Other Support Equipment
• (1) Haas HL124P Yag / Laser Welder 40 (X) x 20
  (Y) x 18 (Z)
• Stainless Steel/Inconel/Steel A2, D2 H13, S7,
  P20 M2/Aluminum
• Titanium/Hastalloy X, C B/Ampco Bronze/Mold
  Max
• Mitsubishi RV-3SDB-S15 6-axis Robot
  127245270642 mm
• _________________________________________________
  _____________________
• Software
• Visi Modelling Mold, CimatronE, Solid
  Works2009, Work NC, Cam Tool, Mastercam X2,
  Autocad-Mechanical Desktop, Water-jet Sigma
  Nest, Wire Esprit

16
Attention to DETAIL
Attention to Detail -- Is thorough in
accomplishing a task with concern for all the
areas involved, no matter how small.
Your jobs need people who can handle both the
small and large parts of a project. Our staff
won't overlook what needs to be done and can be
depended on to do each task accurately,
completely and on time.
Detail Technologies pays meticulous attention to
those details its not just in our name its
engrained in our culture.
17
Our Location
Detail Technologies 5900 Crossroads Commerce
Pkwy Wyoming, MI 49519
18
Building True Partnerships
We would like to thank you for this opportunity
to earn your business and look forward to many
successful projects in the future.
