Plant Hormones

1
Plant Hormones
2
Plant Hormones

• There are five major types of plant hormones
• Gibberelins
• Cytokinins
• Ethylene
• Abcisic Acid
• Auxins
• The structure and function of each type of
  hormone will be described

3
Gibberellins
4
Overview

• Gibberellins (GAs) regulate and influence
• cell elongation
• seed germination
• dormancy
• flowering
• sex expression
• enzyme induction
• leaf and fruit senescence.

5
Germination

• Signal starch hydrolysis through inducing the
  synthesis of the enzyme a-amylase in the aleurone
  cells
• Gibberellins produced in the scutellum diffuse to
  the aleurone cells where they stimulate the
  secretion a-amylase
• a-Amylase then hydrolyses starch into glucose
• Gibberellins cause higher levels of transcription
  of the gene coding for the a-amylase enzyme

6
Gibberellins Chemical Structure

• Gibberelins have complex ring structures
• Typically contain carboxylic acid groups
• Many specific gibberelins exist
• Numeric naming system (i.e. GA)
• May be classified into two structural types
• C-19 Gibberelins (19 carbon)
• C-20 Gibberelins (20 carbon)

7
Gibberellins Chemical Structure

• Type 1 19 Carbon Gibberelins

8
Gibberellins Chemical Structure

• Type 2 20 Carbon Gibberelins

9
Cytokinins
10
Cytokinins

• Found in a variety of plants and have many
  functions
• Synthesized in meristematic tissues in roots and
  transported to aboveground organs
• Regulate growth and development of tissue
  primarily by promoting cell division
• Involved in germination, shoot differentiation,
  leaf senescence
• Interacts with other plant hormones for some
  functions

11
Cytokinins Function

• Regulates apical dominance and lateral root
  initiation
• Slows down senescence (plant aging) and
  chlorophyll degradation in aging leaves
• Regulates growth of dicot seedlings in the dark
  (in combination with ethylene)
• Involved in development of sex organs and male
  sterility
• Synthesized in meristematic tissues in roots and
  transported to aboveground organs

12
Cytokinins

• Cytokinins contain adenine
• Two structure types
• Isoprenoid
• Isoprene structural units
• Aromatic
• Contain aromatic groups

13
Cytokinins Isoprenoid
Isoprene units
adenine
14
Cytokinins Aromatic
adenine
Aromatic group
15
Cytokinins Aromatic
Aromatic group
adenine
16
Ethylene
17
Ethylene

• Universally produced by all plants
• Angiosperms, Gymnosperms, Ferns, Mosses,
  Liverworts
• Also found in some fungi, yeast and bacteria
• Important roles in
• Abscission
• Germination
• Senescence
• Stress
• response to pathogens

18
Ethylene and Fruit Ripening

• Helps fruits go through color change, softening
  of walls, conversion of starch to sugar
• Ethylene is produced in low amounts throughout
  plant life
• some climacteric plants have sudden peaks in
  ethylene synthesis which signals ripening changes
• Ethylene gas is sprayed on fruit crops to ripen
  at same time

19
Ethylene and Stress

• Some stress situations trigger ethylene
  production
• exposure to heat/cold
• physical damage
• attack by fungal or bacterial pathogens
• flooding that limits oxygen
• Similar to Abscisic acids stress response

20
Growth and Messaging

• Ethylene and growth
• Promotes root growth and root hair growth
• Can cause asymmetric growth in stems and leaves
• Ethylene regulates seedlings horizontal growth
  apical hook formation Triple response of
  seedlings grown in dark
• Can act as second messenger
• Auxin, cytokinin can cause ethylene production in
  seedlings

21
Ethylenes triple response
Apical hook formation
22
Ethylene Chemical Structure

• Ethylene is a very small, simple molecule
  compared to other plant hormones
• Two carbons sharing a double bond
• Ethylene is a gas at room temperature

23
Abscisic Acid
24
Abscisic Acid (ABA)

• Found universally in plants and algae
• Many functions! Important roles in
• plant development
• bud seed dormancy
• Germination
• cell division
• leaf senescence
• Abscission
• cellular response to stress

25
Abscisic Acid

• Acts as a general inhibitor of growth and
  metabolism
• Inhibits growth in hypocotyls, epicotyls, leaves,
  coleoptiles
• Seed dormancy
• ABA promotes seed dormancy so plant seeds can
  withstand desiccation

26
ABA as a Stress Hormone

• ABA increases with various environmental or
  biological plant stresses
• Excess heat, pests, excess salt and/or
  dehydration
• Wilted plants have high levels of ABA
• In a drought, ABA increases in some plants,
  causing the stomata to close, preventing water
  loss
• ABA can also produces osmolytes that protect cell
  membranes from dehydration

27
Abscisic Acid Chemical Structure

• Abscisic acid is a carboxylic acid

Carboxylic acid
28
Auxins
29
Its All in the Name

• Auxins from the Greek word a??a?? "I grow or
  increase".
• They were the first of the major plant hormones
  to be discovered.

30
Overview

• essential for cell growth
• affects both cell division and cellular
  expansion.
• may promote axial elongation (as in shoots),
  lateral expansion (as in root swelling), or
  isodiametric expansion (as in fruit growth)
• auxin-promoted cellular expansion occurs in the
  absence of cell division.
• auxin-promoted cell division and cell expansion
  may be closely sequenced within the same tissue
  (root initiation, fruit growth)

31
Important Functions

• coordination of many growth and behavioral
  processes in the plant life cycle
• stimulate or inhibit the expression of specific
  genes.
• coordinate development at all levels in plants,
  from the cellular level through organs and
  ultimately the whole plant.

32
Master Hormone

• indole-3-acetic acid (IAA).
• the most important member of the auxin family
• the most potent native auxin
• generates the majority of auxin effects in intact
  plants

33
Working Together

• patterns of active transport are complex
• typically act in concert with, or in opposition
  to other plant hormones
• auxins and other plant hormones nearly always
  interact to determine patterns of plant
  development.

34
Auxin Shared Functions

• stimulates cell elongation by stimulating wall
  loosening factors, such as elastins, to loosen
  cell walls (with gibberellins)
• stimulates cell division (with cytokinins)
• applied to callus, rooting can be generated (with
  cytokinin)
• xylem tissues can be generated (with cytokinins)

35
More Auxin Shared Functions

• promotes femaleness in dioecious flowers (with
  ethylene)
• inhibits or promotes leaf and fruit abscission
  (with ethylene)
• stimulate cell division in the cambium andin
  tissue culture (with cytokinins)

36
Auxin Functions

• Stimulate cell elongation
• stimulate differentiation of phloem and xylem
• Stimulate root initiation on stem cuttings and
  lateral root development in tissue culture
• mediate the tropistic response of bending in
  response to gravity and light
• suppresses growth of lateral buds
• delay leaf senescence

37
More Auxin Functions

• can induce fruit setting and growth in some
  plants
• involved in assimilate movement toward auxin,
  possibly by an effect on phloem transport
• delay fruit ripening
• promote flowering in Bromeliads
• stimulate growth of flower parts
• stimulate the production of ethylene at high
  concentrations
• inhibit growth by closing the stoma during water
  stress.

38
Auxins Chemical Structure

• Many naturally occurring auxins exist, along with
  many synthetic auxins used in agriculture
• Most naturally occurring auxins contain an indole
  ring group or a phenyl group
• Auxins (natural and synthetic) are carboxylic
  acids
• Halides are also seen in both natural and
  synthetic auxins

39
Naturally Occurring Auxins
Carboxylic acid
IAA, the most important member of the auxin
family
40
Naturally Occurring Auxins
41
Synthetic Auxins
42
Synthetic Auxins
Ether linkage
halogens
43
Sources

• Wikipedia, Auxin, 2010, http//en.wikipedia.org/wi
  ki/Auxin
• Campbell, Neil A., and Jane B. Reece. Biology.
  6th ed. Boston Benjamin-Cummings Company, 2001.
• Delker, C., Raschke, A. and Quint, M., 2008,
  Auxin dynamics the dazzling complexity of a
  small molecules message, Planta, vol 227,
  929-941.
• Gibberellins A Short History, from
  http//www.plant-hormones.info, the home since
  2003 of a website developed by the now-closed
  Long Ashton Research Station
• Wikipedia, Gibberellin, 2010, http//en.wikipedia.
  org/wiki/Gibberellin
• Koning, Ross E. 1994. Auxins. Plant Physiology
  Information Website. http//plantphys.info/plant_p
  hysiology/auxin.shtml. (4-7-2010).
• Litwak, G. 2005. Plant hormones. Elsevier
  Academic Press San Diego, CA.
• Raghavan, V. 1997. Molecular embryology of
  flowering plants. Cambridge University Press. New
  York, NY.
• Srivastava, LM. 2002. Plant growth and
  development hormones and environment. Elsevier
  Science San Diego, CA.
• http//www.plant-hormones.info/auxins.htm the
  home since 2003 of a website developed by the
  now-closed Long Ashton Research Station
