THROMBOPHILIA DVT PROPHYLAXIS VTE MANAGEMENT

1
THROMBOPHILIA DVT PROPHYLAXIS VTE
MANAGEMENT

• DR. ASHISH
• Moderator DR. MEERA KHARBANDA

www.anaesthesia.co.in anaesthesia.co.in_at_gmail.c
om
2
Thrombophilia

• Thrombophilia - propensity for thrombotic events
• Most often manifests clinically in form of venous
  thrombosis (frequently DVT of lower extremity)
• Thrombophilia may result from inherited or
  acquired conditions

3
(No Transcript)
4
Heritable cause of thrombophilia

• Decreased anti thrombotic proteins
• Hereditary antithrombin deficiency
• Hereditary protein c deficiency
• Hereditary protein s deficiency

5
Heritable cause of thrombophilia

• Due to increased prothrombotic proteins
• Factor V Leiden genetic polymorphism
• Prothrombin G20210A genetic polymorphism

6
Acquired causes of thrombophilia

• Myeloproliferative disorders
• Malignancies
• Pregnancy OCP use
• Nephrotic syndrome patients
• Antiphospholipid antibodies

7
Hypercoagulable States and Risk for
Perioperative Thrombosis

• High Risk
• Heparin-induced thrombocytopenia (HIT)
•  Antithrombin deficiency
•  Protein C deficiency
•  Protein S deficiency
•  Antiphospholipid antibody syndrome

8

• Hypercoagulable States and Risk for
• Perioperative Thrombosis
• Moderate risk
• Factor V Leiden genetic polymorphism
• Prothrombin G20210A genetic polymorphism
• Hyperhomocysteinemia
• Dysfibrinogenemia
• Postoperative prothrombotic state
• Malignancy
• Immobilization

9

• Random screening of asymptomatic patients for
  thrombotic risk has not proved cost effective or
  clinically efficacious
• Careful history focusing on prior thrombotic
  events, family H/O thrombosis, concurrent drug
  therapy offers greater predictive value than
  random screening.

10
Common Inherited Thrombotic Disorders

• Factor V Leiden(activated protein C resistance)
• Point mutation of factor V gene
• Results in impaired inactivation of factor V by
  activated protein C
• Factor V leiden stays active in circulation gt N ,
  fostering increased thrombin generation
• Heterozygosity 5x 7x risk of VTE
• Homozygosity 80x risk of VTE

11
Prothrombin gene G20210A mutation

• Prothrombin gene mutation nucleotide position
  20210 G ? A
• Elevated prothrombin levels and activity
• Increased risk of venous thrombosis
• Rare in Asians Africans

12
Protein C deficiency

• Synthesis in the liver Vit-K dependent
• Inactivate factor? and factor?.
• It needs a cofactor protein S
• Protein C def. l/t overabundance of thrombin
• Risk of thrombosis if warfarin therapy started in
  absence of protective anticoagulation by heparin

13
Protein S deficiency

• Synthesis in hepatocytes megakaryocytes
• Vit-K dependent
• Cofactor of activated protein C(APC)
• Protein C have shorter half life than Protein S

14
Antithrombin ? deficiency

• Antithrombin (AT, also called AT III)
  defense against clot formation in healthy vessels
  or at the perimeter of a site of active
  bleeding
• Autosomal dominant trait
• Heterozygosity 20x risk of VTE
• Homozygosity Not compatible with life

15

• In absence of coexisting precipitating
  conditions, absolute thrombotic risk secondary to
  heritable thrombophilia proves limited.
• In the presence of family history or test
  abnormality suggesting thrombophilia with no h/o
  thrombosis, risks a/w long-term preventive
  anticoagulation may outweigh potential benefits.

16

• After a thrombotic complication, however,
  these patients most often are managed with
  life-long anticoagulation.

17
Acquired thrombophilia- Antiphospholipid Syndrome

• Autoimmune disorder ch/by venous and/or arterial
  thromboses , recurrent pregnancy loss.
• 20 to autoimmune disorders such as SLE or RA, or
  occur in isolation.
• Mild prolongation of aPTT testing for lupus
  anticoagulant or anticardiolipin antibodies.

18
Acquired thrombophilia- Antiphospholipid Syndrome

• No increased bleeding risk but risk of
  thrombosis.
• Isolated prolongation of an aPTT in preoperative
  patient consider - antiphospholipid syndrome.
• Risk of recurrent thrombosis - life-long
  anticoagulation.

19
HIT

• Autoimmune-mediated drug reaction - 5 of pt.
  receiving heparin therapy.
• Heparin AT complex also binds to platelet
  factor 4 some pt. develop -
• Heparin- induced ab. that can cross react with
  this platelet binding site to produce platelet
  clumping and subsequent thrombocytopenia
• Can be triggered by low dose heparin as well as
  therapeutic dose heparin

20
MALIGNANCY

• Adenocarcinomas of pancreas, colon, stomach,
  ovaries .
• Pathogenesis - release of procoagulant factor(s)
  by tumor, which directly activate factor X,
  endothelial damage by tumor invasion, and blood
  stasis.
• Lab No abnormalities or some combination of
  thrombocytosis, elevation of the fibrinogen
  level, and low-grade DIC.

21
Pregnancy and OCP Use

• Incidence - 1 in 1500 pregnancies
• Risk of PE highest during 3rd trimester
  immediate postpartum period
• Antithrombin IIIdeficient women high risk
  -anticoagulated throughout pregnancy.
• Factor V Leiden and the prothrombin G20201A
  mutation a/w less risk.
• Women with one of these inherited traits not
  anticoagulated unless h/o PE or recurrent DVT

22
Pregnancy and OCP Use

• Since low-dose estrogen OCP introduction
  -incidence decreased.
• Women - smoke, h/o migraine headaches, inherited
  hypercoagulable defect at increased risk
  (30-fold) of venous thrombosis, PE,
  cerebrovascular thrombosis.

23
Nephrotic Syndrome Patients

• Risk of thromboembolic disease including renal
  vein thrombosis.
• D/t lt N levels of antithrombin III or PC 20
  renal loss of coagulation protein, factor XII
  deficiency, platelet hyperactivity, abnormal
  fibrinolytic activity, gt N levels of other
  coagulation factors.
• Hyperlipidemia and hypoalbuminemia - also
  possible etiologic factors

24
Perioperative venous thromboembolism

• Without prophylaxis, incidence of
• DVT
• 14 in gynaecological surgery
• 22 in neurosurgery,
• 26 in abdominal surgery,
• 4560 in orthopaedic surgery.

25

• Agency for health care research and quality have
  issued report stating that
• Prophylaxis for venous thromboembolism is
  single most important measure for ensuring
  patient safety in hospitalized patients

26
Patients at risk for VTE

• Surgery major surgery abdominal ,
  gynecologic,urologic, orthopedic, neurosurgery,
  cancer related surgery
• Trauma multisystem trauma, spinal cord injury,
  spinal , of hip and pelvis
• Malignancy any malignanacy, risk higher
  during chemo radiotherapy
• Acute medical illness stroke, acute MI, heart
  failure,neuromuscular weakness syndrome(GBS)

27
Patients at risk for VTE

• Patient specific risk factor H/o VTE, Obesity,
  increasing age gt 40yr, hypercoagulable state(
  estrogen therapy)
• ICU related factors prolonged mechanical
  ventilation, neuromuscular paralysis(drug
  induced), CVC, severe sepsis, consumptive
  coagulopathy, HIT

28
Risk assessment model (RAM) from the ACCP

• Low risk
• Uncomplicated minor
• surgery in patients lt40 yr
• with no clinical risk factors
• Minor surgery performed under local anesthesia
  or spinal anesthesia last lt 30 min

29
Risk assessment model (RAM) from the ACCP

• Moderate risk factor
• Major and minor surgery in
• pt. 4060 yr with no
• clinical risk factors
• Major surgery in pt.
• lt40 yr with no additional
• risk factors
• Minor surgery in pt.
• with risk factors
• Major surgery performed under GA and last gt 30
  min
• Other risk factor cancer , obesity, h/o VTE,
  estrogen t/t , hypercoagulable state

30
Risk assessment model (RAM) from the ACCP

• High risk
• Major surgery in patients
• gt40 yr who have additional
• risk factors
• Major surgery performed under GA and last gt 30
  min
• Other risk factor cancer , obesity, h/o VTE,
  estrogen t/t, hypercoagulable state

31
Risk assessment model (RAM) from the ACCP

• Very high risk
• Major surgery in pt.
• gt40 yr plus previous VTE or
• malignant disease or
• hypercoagulable state
• Elective major orthopaedic
• surgery or hip or
• stroke or spinal cord injury
• or multiple trauma

32
THROMBOPROPHYLAXIS FOR GENERAL SURGERY
33
Prophylaxis regimens

• LDUH1 - Unfractionated heparin 5000 u s.c every
  12 hr
• LDUH2 - Unfractionated heparin 5000 u s.c every
  8 hr
• LMWH1Enoxaparin 40 mg s.c O.D or Dalteparin 2500
  u s.c O.D
• LMWH2 Enoxaparin 30 mg s.c every 12 hr or
  Dalteparin 5000 u s.c O.D
• Mechanical aid Graded compression stockings or
  intermittent pneumatic compression

34
Thrombprophylaxis for hip knee Sx.

• Procedures Elective hip knee arthroplasty,
  hip surgery
• Drug regimen Use any one of following
• LMWHEnoxaparin 30 mg s.c every12hr.Give 1st dose
  12-24hr before Sx. Or 6hr after Sx.
• Fondaparinaux 2.5mg s.c O.D .First dose 6-8hr
  after Sx.
• Adjusted dose warfarin to achieve INR of 2-3.
  Give first dose the evening before Sx.

35
Thrombprophylaxis for hip knee Sx.

• Duration of thromboprophylaxis
• For elective hip knee surgery, prophylaxis
  should continue for 10 days after surgery
• B. For hip surgery , prophylaxis should
  continue for 28 to 35 days after surgery

36

• Thromboprophylaxis for other conditions

37
(No Transcript)
38
Prophylaxis regimens

• LDUH1 - Unfractionated heparin 5000 u s.c every
  12 hr
• LDUH2 - Unfractionated heparin 5000 u s.c every
  8 hr
• LMWH1Enoxaparin 40 mg s.c O.D or Dalteparin 2500
  u s.c O.D
• LMWH2 Enoxaparin 30 mg s.c every 12 hr or
  Dalteparin 5000 u s.c O.D
• Leg compression methods Graded compression
  stockings(GCS) or intermittent pneumatic
  compression(IPC)

39
Methods of thromboprophylaxis

• Mechanical - External leg compression
• Graded compression stockings
• Intermittent pneumatic compression
• Pharmacologic
• Low dose unfractionated heparin
• Low molecular weight heparin
• Adjusted dose warfarin
• Fondaparinaux

40
Graded compression stockings

• Thromboembolic deterrent (TED stockings)
• Create 18 mm Hg external pressure at ankles 8
  mm Hg in thigh
• Resulting 10 mm Hg pressure gradient driving
  force for venous outflow from legs
• Shown to reduce VTE when used alone for abdominal
  neurosurgery
• However considered least effective method not
  used alone for moderate high risk of VTE.

41
Intermittent pneumatic compression

• Inflatable bladders that are wrapped around lower
  leg
• Inflated create 35 mmHg external compression at
  ankles 20 mmHg at thighs
• Create pumping action by inflating deflating at
  regular interval- augments venous outflow
• Used after intracranial Sx trauma victims who
  are at risk of bleeding

42
Low dose unfractionated heparin

• Rationale for low dose heparin
• Heparin indirect acting drug
• Must bind to cofactor anti-thrombinIII(AT) to
  produce effect
• Heparin-AT complex inactivates factors
  IIa(thrombin), IXa, Xa, Xia XIIa
• Inactivation of IIa is sensitive Rn occur at
  heparin doses far below those needed for
  inactivation of other coagulation factors
• Small doses of heparin can inhibit thrombus
  formation without producing full anticoagulation

43
Low dose unfractionated heparin

• Dosing regimen 5000 u b.d or t.d.s daily
• More frequent dosing (t.d.s) recommended for
  higher risk condition
• Surgical prophylaxis 1st dose 2hr before Sx.
• Postoperative prophylaxis continued for 7-10 days
  or untill pt. fully ambulating
• Effective thromboprophylaxis for high risk
  medical cond. most non-orthopedic surgical
  prophylaxis

44
Low molecular weight heparin

• More potent more uniform anticoagulant activity
  than UFH.
• Advantage Less frequent dosing,lower risk of
  bleeding HIT
• No need for routine anticoagulant monitoring with
  full anticoagulant dosing
• Disadvantage 10 times more costly (per day)
  than UFH
• More effective than UFH for orthopedic procedures
  involving knee hip, major trauma including
  spinal cord injury

45
Low molecular weight heparin

• Dose Enoxaparin O.D. 40 mg for moderate risk
  cond. B.D. 30 mg for high risk cond.
• Dalteparin O.D. dose 2500 U for moderate risk
  cond. 5000 U for high risk cond.
• Timing Non orthopedic Sx. 2 hr before Sx
• Orthopedic Sx. 6 hr after Sx
• Excreted primarily by kidney.
• Pt. in renal failureEnoxaparin dose reduced to
  40 mg o.d for high risk cond.
• No dose adjustment for Dalteparin

46
Adjusted dose warfarin

• Vitamin K antagonist prevents carboxylation
  activation of coagulation factors II, VII, IX,
  and X
• Advantage
• Preop dose not increase bleeding tendency during
  Sx d/t delayed onset
• Can be continued after discharge if prolonged
  prophylaxis
• Disadv.
• Multiple drug interactions
• Monitoring lab test
• Difficulty adjusting doses d/t delayed onset

47
Adjusted dose warfarin

• Dosing regimen
• Initial dose 10mg P.O. evening before Sx
• F/b 2.5 mg daily starting the evening after Sx.
• Dose adjusted keep INR 2-3

48
Fondaparinux

• Synthetic anticoagulant, an anti-Xa
  pentasaccharide
• Predictable anticoagulant effect
• No lab. monitoring required.
• Prophylactic dose 2.5 mg O.D s.c. inj. given 6-8
  hr after Sx.
• Contraindication
• Severe renal impairment creatinine clearance lt
  30ml/hr.
• Wt. lt 50 kg marked increase in bleeding

49
Natural course of thromboembolism

• DVT in lower extremity may arise in calf vein or
  in proximal veins
• Thrombous may extend proximally to iliac veins
  IVC
• Incidence of thrombosis in upper extremity
  increasing d/t widespread use of central venous
  catheter
• DVT may occur in deep pelvic vein or renal vein
• Can be thrombous formation in right side of heart
  d/t atrial fibrillation

50

• Most clinically important fatal pulmonary
  embolism occurs from proximal than distal DVT in
  leg
• PE occur in 50 of pt. with proximal DVT, while
  asymptomatic thrombosis of leg vein is observed
  in 70 pt with PE
• On early ambulation, thrombus in deep veins may
  resolve completely

51

• Post-thrombotic syndrome may develop in 25 of
  patients, 2yrs after initial diagnosis and proper
  t/t of DVT
• Inadequate t/t of DVT result in 20-30 risk of
  recurrent VTE collaterals develop parallel to
  thrombosed segment of vein

52
Diagnostic approach to thromboembolism

• The Clinical evaluation
• Clinical presentation of acute pulmonary embolism
  is nonspecific
• No clinical or lab findings that will confirm
  or exclude diagnosis of pulmonary embolism

53
Clinical lab findings in pt. with suspected
pulmonary thromboembolism

54
Plasma d- dimer levels

• Quantitative plasma D-dimer ELISA rises - DVT or
  PE because of plasmin's breakdown of fibrin.
• Elevation of D-dimer indicates endogenous
  although often clinically ineffective
  thrombolysis.
• Sensitivity gt80 for DVT gt95 for PE.
• D-dimer is less sensitive for DVT than PE because
  DVT thrombus size is smaller.
• D-dimer is a useful "rule out" test.

55
Plasma d- dimer levels

• It is normal (lt500 ng/mL) in more than 95 of
  patients without PE.
• In patients with low clinical suspicion of DVT,
  it is normal in more than 90 without DVT.
• D-dimer assay is not specific.
• Levels increase in patients with myocardial
  infarction, pneumonia, sepsis, cancer,
  postoperative state, and second or third
  trimester of pregnancy.

56
(No Transcript)
57
Spiral CT scan

• Computed tomography (CT) of the chest with
  intravenous contrast is the principal imaging
  test for diagnosis of PE
• Pt. must be able to breath hold for 30sec
• Best suited for detecting clots in main pulmonary
  artery
• When imaging is continued below the chest to the
  knee, pelvic and proximal leg DVT can also be
  diagnosed by CT scanning.
• Sensitivty 93 specificity 97

58
Radionuclide lung scan

• 2nd-line diagnostic test for PE.
• Used for patients who cannot tolerate i.v.
  contrast
• Small particulate aggregates of albumin labeled
  with a gamma-emitting radionuclide are injected
  i.v are trapped in the pulmonary capillary
  bed.
• Perfusion scan defect indicates absent or
  decreased blood flow, possibly d/t PE.
• High probability scan two or more segmental
  perfusion defects in presence of N ventilation.
• Diagnosis of PE is very unlikely in pt. with N
  and near-N scans but is about 90 certain in
  patients with high-probability scans.

59
Pulmonary angiography

• Most accurate method for detecting pulmonary
  emboli.
• Invasive catheter-based diagnostic testing
  reserved for patients with technically
  unsatisfactory chest CTs.
• Definitive diagnosis of PE - intraluminal filling
  defect in more than one projection.
• Secondary signs of PE include abrupt occlusion
  ("cut-off") of vessels, segmental oligemia or
  avascularity, prolonged arterial phase with slow
  filling, or tortuous, tapering peripheral vessels

60
ALGORITHM FOR DIAGNOSTIC IMAGING
SUSPECT DVT OR PE
ASSESS CLINICAL LIKELIHOOD
DVT
PE
NOT LOW
LOW
NOT HIGH
HIGH
D - DIMER
D-DIMER
NORMAL
HIGH
HIGH
NORMAL
IMAGING TEST NEEDED
NO DVT
NO PE
IMAGING TEST NEEDED
61
CLINICAL DECISION RULES

• LOW CLINICAL LIKELIHOOD OF DVT IF THE POINT SCORE
  IS ZERO OR LESS

62
CLINICAL DECISION RULES

• HIGH CLINICAL LIKELIHOOD OF PE IF POINT SCORE
  EXCEEDS 4

63
ALGORITHM FOR DVT DIAGNOSIS
64
Color duplex scan of DVT
65
ALGORITHM FOR PE DIAGNOSIS
66
Antithrombotic therapy

• Anticoagulation
• Initial t/t of thromboembolism that is not life
  threatening is anticoagulation with heparin
• Standard t/t of both DVT acute PE is UFH
  continuous i.v infusion using wt. based dosing

67
Antithrombotic therapy

• UFH
• Target aPTT 23 times the upper limit of
  laboratory normal.
• Usually equivalent to aPTT of 6080 s.
• Nomograms based upon patient's wt. may assist in
  adjusting dose of heparin
• Give an initial bolus of 80 units/kg, f/b an
  initial infusion _at_18 units/kg/hr.
• Check aPTT 6 hr after infusion adjust heparin
  dose

68
Antithrombotic therapy

• LMWH
• Therapeutic dose Enoxaparin 1mg/kg s.c inj.
  every 12hr
• Warfarin anticoagulation
• Pt. with reversible cause of VTE (major Sx.)
• Warfarin can be started on on first day of
  heparin therapy
• When INR 2-3 heparin can be discontinued
• Oral anticoagulation continued at least 3 months

69
Thrombolytic therapy

• Reserved for life threatening cases of PE with
  hemodynamic instability
• Alteplase 0.6mg/kg over 15min
• Reteplase 10U i.v. bolus repeat in 30 min
• Contraindications intracranial disease, recent
  Sx., trauma.
• Overall major bleeding rate 10, including 13
  risk of intracranial hemorrhage.

70
Inferior vena caval filters

• Mesh like filter device can be placed in IVC
• To trap thrombi that break loose from leg vein
  prevent them from trvelling to lungs
• Indications
• (1) active bleeding that precludes
  anticoagulation
• (2) recurrent venous thrombosis despite
  intensive anticoagulation.
• Inserted percutaneously through IJV or femoral
  vein are placed below renal vein if possible

71
Neuraxial blockade in patients who have or will
receive anticoagulant prophylaxis (1) Neuraxial
anesthesia/analgesia should generally be avoided
in patients with known bleeding disorder (2)
Avoided in pt.whose preoperative hemostasis is
impaired by antithrombotic drugs
72

• NSAIDs aspirin do not appear to
• increase risk of perispinal hematoma.
• Thienopyridine platelet inhibitors clopidogrel
  ticlopidine discontiue for 5 to 14 days
• Insertion of spinal needle or epidural catheter
  should be delayed at least 8 to 12 h after s.c.
  dose of heparin or a twice daily prophylactic
  dose of LMWH
• At least 18 h after O.D. LMWH injection

73
(3) Anticoagulant prophylaxis delayed if
hemorrhagic aspirate (ie, a bloody tap)
encountered during initial spinal needle
placement. (4) Removal of an epidural catheter
should be done when the anticoagulant effect
is at a minimum (usually just before the next
scheduled s.c inj.). (5) Anticoagulant
prophylaxis should be delayed for at least 2 h
after spinal needle or epidural catheter
removal.
74

• (6) If warfarin is used - continuous
• epidural analgesia not be used for longer than 1
  or 2 days because of unpredictable anticoagulant
  effect
• If prophylaxis with a VKA is
• used at the same time as epidural analgesia, INR
  should be 1.5 at time of catheter removal.

75

• (7)Postoperative prophylaxis with fondaparinux -
  safe in pt. who have received a spinal anesthetic
• No safety data about its use along with
  postoperative continuous epidural analgesia.
• Long half-life of fondaparinux renal
• mode of excretion raise concerns about potential
  for
• accumulation ,in elderly d/t associated
  impairment of renal function.

76

• With concurrent use of epidural analgesia
  anticoagulant prophylaxis, all patients should be
  monitored for s/s of cord compression.
• Progression of lower extremity numbness or
  weakness, bowel or bladder dysfunction, new
  onset of back pain.
• If spinal hematoma is suspected, diagnostic
  imaging and definitive surgical therapy performed
  rapidly to reduce the risk of permanent paresis.

77
(No Transcript)
78
(No Transcript)
79

80

• THANK YOU

www.anaesthesia.co.in anaesthesia.co.in_at_gmail.c
om
