Title: Intertidal Communities


1
Chapter 13
  • Intertidal Communities

2
Key Concepts
  • The intertidal zone is the coastal area
    alternately exposed and submerged by tides.
  • Organisms that inhabit intertidal zones must be
    able to tolerate radical changes in temperature,
    salinity, and moisture and also be able to
    withstand wave shock.

3
Key Concepts
  • Organisms on rocky shores tend to be found in
    definite bands, or zones, on the rocks.
  • In contrast to sandy shores, rocky shores provide
    a relatively stable surface for attachment.
  • Tide pool organisms must be able to adjust to
    abrupt changes in temperature, salinity, pH, and
    oxygen levels.

4
Key Concepts
  • Biotic factors are most important in determining
    the distribution of organisms on rocky shores,
    but physical factors are most important on sandy
    shores.

5
Characteristics of the Intertidal Zone
  • Daily fluctuations of the environment
  • organisms must tolerate radical changes in
    temperature, salinity and moisture, and endure
    the crushing force of waves
  • Inhabitants are most active during high tide,
    when area is submerged
  • water provides food for filter feeders
  • As the tide retreats, organisms adjust to
    exposure to air and sunlight

6
(No Transcript)
7
Rocky Shores
  • Composed of hard materials
  • Found from California to Alaska on the west coast
    and from Cape Cod northward on the east coast of
    North America
  • Coasts may be recently uplifted, formed from lava
    flows, or highly eroded by wind and waves

8
Rocky Shore Zonation
  • Zonationseparation of organisms into prominent
    horizontal bands defined by color or distribution
    of organisms
  • Rocks provide a stable surface for attachment of
    organisms
  • As tide retreats...
  • upper regions exposed to air, changing
    temperatures, solar radiation, dissication
  • lower regions exposed only a short time before
    tide returns to cover them

9
(No Transcript)
10
Rocky Shore Zonation
  • Zone system for rocky shore proposed by Alan and
    Anne Stephenson
  • supralittoral (maritime) zonearea above high
    water that may extend several miles inland
  • supralittoral fringe (splash zone)uppermost area
    covered only by the highest (spring) tide,
    usually just dampened by spray of crashing waves

11
Rocky Shore Zonation
  • Zone system (continued)
  • midlittoral zonethe true intertidal zone
    extensive part that is regularly exposed during
    low tides and covered during high tides
  • infralittoral fringearea extending from the
    lowest of low tides to the upper limits reached
    by large kelps (laminarians)
  • subtidal (infralittoral) zonethe region of shore
    covered by water, even during low tide

12
(No Transcript)
13
(No Transcript)
14
Rocky Shore Zonation
  • Supralittoral fringe of rocky shores
  • receives very little moisture
  • exposed to drying heat of the sun in summer and
    extreme cold in winter
  • few organisms inhabit this harsh area
  • gray and orange lichens composed of fungi and
    algae are common
  • sea hair a filamentous alga
  • most common animal periwinkles, molluscs of
    Littorina and associated genera

15
Rocky Shore Zonation
  • Supralittoral fringe (continued)
  • other inhabitants include limpets and isopods
  • some periwinkles and isopods breathe air
  • Midlittoral zone of rocky shores
  • inhabitants must avoid desiccation, maintain gas
    exchange, and deal with temperature extremes as
    the tide moves in and out
  • wave shockforce of the waves as they crash
    against the rocks during low tide

16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
Rocky Shore Zonation
  • Midlittoral zone (continued)
  • upper midlittoral zone
  • typical organisms acorn barnacles and rock
    barnacles
  • barnacles permanently attach to surfaces
  • barnacles open their shells to filter feed during
    high tide, and close them to trap water inside
    during low tide
  • barnacles cool themselves by opening the shell
    slightly and allowing a little water to evaporate

22
Rocky Shore Zonation
  • Midlittoral zone (continued)
  • middle and low midlittoral zone
  • oysters, mussels, limpets, and periwinkles
    dominate
  • oysters and mussels survive low tides by trapping
    water in their shells
  • limpets and chitons graze algae at high tide
  • common periwinkles bury themselves in seaweed to
    retain moisture during low tide
  • rock urchins survive wave shock by hollowing out
    a space in the rock and wedging into it

23
Rocky Shore Zonation
  • Midlittoral zone (continued)
  • seaweeds of the midlittoral zone
  • rockweeds (brown algae) grow on rocks without
    full exposure to the sea
  • rockweeds compete with barnacles for space by
    sweeping the rocky surface with their blades,
    preventing cyprid larvae of barnacles from
    settling
  • some rockweeds are toxic to deter grazing
  • rockweeds produce a gelatinous covering that
    retards water loss and prevents desiccation
  • they form large mats that trap water and provide
    a haven for animals during low tide

24
Rocky Shore Zonation
  • Midlittoral zone (continued)
  • tide poolsdepressions in the rocks which retain
    water during low tide
  • water loses oxygen as it heats in the sun
  • salinity may change owing to rainfall or
    evaporation of water by the sun
  • oxygen in tide pools containing algae may change
    drastically high during the day when algae are
    active, low ( low pH) at night
  • salinity, temperature, pH abruptly returned to
    ocean conditions when tide reaches the pool

25
(No Transcript)
26
Rocky Shore Zonation
  • Midlittoral zone (continued)
  • tide pool organisms
  • e.g. algae, sea stars, anemones, tube worms,
    hermit crabs, molluscs
  • many are filter feeders
  • biotic interactions help structure tide pool
    communities
  • e.g., in New England, Irish moss lives in tide
    pools where common periwinkles eat the green alga
    Enteromorpha, which normally outcompetes Irish
    moss

27
(No Transcript)
28
Rocky Shore Zonation
  • Infralittoral fringe of rocky shores
  • transitional area submerged except at spring
    tides
  • rich flora and fauna of organisms that can
    tolerate limited air exposure
  • rocks may be covered with seaweeds
  • in cooler waters, molluscs, sea stars and brittle
    stars live among large kelps
  • other animals include hydrozoans, anemones, sea
    urchins, spider crabs

29
(No Transcript)
30
Tropical Rocky Shores
  • Less temperature variation and seasonal rainfall
  • higher temperatures are more stressful
  • less temperature variation and fewer storms are
    less stressful
  • Zonation patterns on intertidal rocks
  • supralittoral fringe and midlittoral fringe each
    have major subdivisions evident in tropical areas

31
Supralittoral Fringe
  • White zonethe true border between the land and
    the sea
  • hermit crabs, isopods, knobby periwinkles
  • Gray zone
  • knobby (and other) periwinkles
  • nerites an exclusively tropical group that
    tends to replace limpets in higher intertidal
    zones
  • farthest zone from low tide line where
    macroscopic marine algae grow

32
Supralittoral Fringe
  • Black zone
  • immersed only at the highest spring tides
  • lacks knobby periwinkle
  • several species of algae and cyanobacteria
    dominate
  • smaller periwinkles, other nerites, fuzzy chitons

33
Midlittoral Fringe
  • Yellow zone
  • microscopic boring algae covering its surface
    give it a yellow or green color
  • barnacles, limpets, fuzzy chitons, rock snails,
    irregular worm snails

34
(No Transcript)
35
Midlittoral Fringe
  • Pink zone
  • sometimes underlies the yellow zone
  • characterized by widespread encrustation of
    coralline algae
  • irregular worm snail, mats of anemones, keyhole
    limpets, gastropods

36
(No Transcript)
37
Infralittoral Fringe
  • surf zone includes the edge of the lower rocky
    platform and parts of the reef
  • rocks may be covered with algae such as Sargassum
  • boring urchins, anemones, sponges, bryozoa, sea
    cucumbers, keyhole limpets

38
Subtidal Zone
  • Relatively barren compared to subtidal zone in
    temperate climates
  • Small, turf-forming red algae dominate
  • lack of larger algae present in higher zones
    thought to be owing to herbivory
  • in experiments, exclusion of herbivores permitted
    erect algae to establish themselves where they
    were not found previously

39
Comparison of Temperate and Tropical Rocky
Intertidal Systems
  • Higher stress and predation in tropical
    environment
  • Abundant mobile invertebrates, but fewer sessile
    ones in the tropics
  • Large body size or residence in higher areas more
    important means of avoiding predators in
    temperate areas
  • Macroalgae have less impact on community
    structure in the tropics

40
Intertidal Fishes
  • Resident species
  • typically have special adaptations for surviving
    harsh intertidal conditions
  • small size absent, reduced or firmly attached
    scales compressed/elongate or depressed body
    shape absent or reduced swim bladder greater
    body density
  • tolerant of temperature and salinity changes
  • some intertidal fish can leave the water to feed
  • Temporary inhabitants
  • tidal, seasonal and accidental visitors

41
Ecology of the Rocky Shore
  • East coast rocky shores
  • barnacles dominate upper zones
  • below the barnacles are mussels
  • algae and consumers survive on protected shores
  • West coast rocky shores
  • barnacles compete with algae mussels displace
    barnacles by growing over them
  • balance maintained by ochre sea stars, the
    keystone predator

42
Ecology of the Rocky Shore
  • Rocky shores in the tropics
  • total predation is strong, and control of
    competitively dominant species is spread over a
    number of consumers
  • Top-down and bottom-up factors
  • top-down factorsfactors whose effects flow down
    the food chain competition, herbivory and
    predation
  • bottom-up factorsfactors that affect the basal
    level of food chains nutrient availability,
    recruitment

43
Sandy Shores
  • Many temperate and tropical shorelines consist of
    sandy beaches
  • Extend almost continuously from Cape Cod south to
    the Gulf Coast on the east coast of North America

44
Role of Waves and Sediments
  • Sediment particle size influences the beachs
    nature, porosity of sediments, ability of animals
    to burrow
  • Wave action influences sediment type
  • heavy wave action coarse sediments
  • little wave action fine sediments
  • Beach slope results from interaction of waves,
    sediment particle size, and relationship of swash
    and backwash

45
Role of Waves and Sediments
  • swashwater running up a beach after a wave
    breaks
  • backwashwater flowing down the beach
  • Types of beaches
  • dissipative beachwave energy is strong but is
    dissipated in a surf zone some distance from the
    beach face
  • usually flat with fine sediment
  • reflective beachwave energy is directly
    dissipated on the beach
  • usually steep with course sediment

46
Role of Waves and Sediments
  • On all sandy beaches, a cushion of water
    separates the grains of sand below a certain
    depth
  • especially true on beaches with fine sand where
    capillary action is greatest
  • Fine sand beaches have a greater abundance of
    organisms
  • greater water retention
  • sediment is more suitable for burrowing

47
(No Transcript)
48
Comparison of Rocky and Sandy Shores
  • Sandy shores lack readily apparent pattern of
    zonation
  • wave action is most important factor in
    determining organism distribution
  • temperature has less effect because of insulating
    properties of sand and water retention
  • oxygen levels may be low beneath the sand owing
    to lack of water exchange

49
Sandy Shore Zonation
  • Less defined pattern of longitudinal zonation
  • Vertical zonation exists among organisms buried
    in the sand
  • depends on amount of water trapped at each level
  • 3 major zones
  • supralittoral
  • midlittoral
  • subtidal (infralittoral)

50
(No Transcript)
51
Life above the High Tide Line
  • Supralittoral fringe stretches from the high tide
    line to the point where terrestrial vegetation
    begins
  • sand dunes may border uppermost extent
  • Below is zone of drying sand, where moisture
    reaches only during the highest tides and
    gradually evaporates
  • inhabited mostly by infaunaorganisms that burrow
    in the sand to survive dry periods and intense
    heat from the sun

52
(No Transcript)
53
Life above the High Tide Line
  • Temperate inhabitants insects, isopods, amphipod
    crustaceans
  • Ghost crabs and fiddler crabs replace amphipods
    in the tropics
  • Ghost crabs have gills, but only make short
    forays into water to wet them
  • Ghost crabs live in burrows, and are nocturnal
    scavengers

54
(No Transcript)
55
Life in the Sandy Shore Midlittoral Zone
  • Vertical zonation
  • less extensive zones of dry and drying sand than
    supralittoral zone
  • zone of retentionretains moisture at low tide
    because of capillary action of water
  • inhabited by isopod crustaceans worldwide
  • zone of resurgencewater is retained at low tide
  • supports crustaceans, polychaete worms
  • zone of saturationconstantly moist supports
    greatest diversity of organisms

56
(No Transcript)
57
Life in the Sandy Shore Midlittoral Zone
  • Animals of the midlittoral zone
  • echinoderms (e.g. sand dollars, sea stars)
  • snails (e.g. moon snails, olive snails)
  • moon snails feed on bivalves by drilling a hole
    in the shell and inserting their proboscis
  • lugworms
  • deposit feeders that leave coiled, cone-shaped
    casts during low tide

58
(No Transcript)
59
(No Transcript)
60
Life in the Sandy Shore Midlittoral Zone
  • Relationship between tides and the activity of
    midlittoral organisms
  • during high tide, bivalves project their siphons
    to filter feed and bathe their gills
  • carnivorous snails hunt bivalves
  • echinoderms emerge in search of food
  • mole crabs and coquinas move up and down the
    beach with the tide, filter feeding
  • predators come in with the tide as well

61
(No Transcript)
62
(No Transcript)
63
(No Transcript)
64
(No Transcript)
65
Life below the Low Tide Line
  • Subtidal zone is truly marine, exposed only
    during lowest spring tides
  • Variety/distribution of organisms primarily
    influenced by sediment characteristics
  • Seagrass beds occur in the subtidal zones of some
    coasts
  • Many species of fish live here
  • Pace of life is constant relative to that on the
    beach

66
Meiofauna
  • Meiofauna
  • microscopic organisms that inhabit the spaces
    between the sediment particles of intertidal and
    subtidal zones
  • pass though a 0.5-mm screen but are retained by a
    62-mm screen

67
(No Transcript)
68
Meiofauna
  • Factors affecting the distribution of meiofauna
  • grain size
  • coarse-grain sediments have greater interstitial
    volume that allows larger organisms to move
    between the particles
  • fine-grain sediments have less space and exhibit
    more burrowing forms
  • water circulation
  • fine sediments can inhibit water flow and produce
    anoxic conditions

69
Meiofauna
  • Factors affecting distribution (cont.)
  • oxygen availability
  • also lower at greater depths
  • temperature
  • upper layers are more variable
  • salinity
  • wave action
  • can suspend sediments along with organisms,
    making them more vulnerable to predation

70
Meiofauna
  • Characteristics of the meiofauna
  • invertebrates from many phyla
  • generally elongated with few lateral projections
  • many are armored to protect them from being
    crushed by moving sand grains
  • include predators, herbivores, suspension feeders
    and detrivores
  • most exhibit brood protection because they
    produce a small number of offspring

71
Meiofauna
  • Factors affecting the size of meiofaunal
    populations
  • seasons (peak during summer months)
  • protection from wave action greater abundance
  • predation can have severe effects in the upper
    layers of sediments

72
Ecology of the Sandy Shore
  • Fauna is less abundant than in rocky shores, and
    does not occupy all available space
  • Competition is not a major factor in determining
    distribution
  • Predation is less important fewer predators
    among invertebrates there
  • Predation and disturbance important on sand flats
  • Greater exposure less influence of competition
    and predation, more influence of abiotic
    (physical) factors
Write a Comment
User Comments (0)
About PowerShow.com
