Improving Flash Flood Services

1
Improving Flash Flood Services

• Mary Mullusky
• National RFC Hydrologic Services Program Leader
• Hydrologic Services Division
• Office of Climate, Water and Weather Services

National Hydrologic Program Managers
Conference July 10, 2007
2
Outline
Improving Flash Flood Services Outline

• AHPS Flash Flood Services Theme Team
• Flash Flood Services Projects
• QPE/QPF Improvements
• FFG Improvements
• FFMP Improvements
• Site Specific Hydrologic Predictor Improvements
• Dam Break Tools

3
Outline
Improving Flash Flood Services AHPS Flash Flood
Services Theme Team

• FY07 Team Process
• Team evaluated over 20 AHPS flash flood projects
• Team prioritized projects and created funding
  proposals
• Team leader presented proposals to the AHPS
  Program Coordinator and the AHPS Review Committee

• Hydrology Program Manager has final authority

• Team Members
• Mary Mullusky (NWSH/HSD)
• Bill Lawrence (ABRFC)
• Peter Ahnert (MARFC)
• Greg Smith (CBRFC)
• Brian McInereny (WFO Salt Lake City)
• John Woynick (WFO Topeka)
• Frank Bell (WGRFC)
• George McKillop (ERH/HSD)
• Ernie Wells will be FY2008 team leader

• Technical Representatives
• David Kitzmiller (NWSH/OHD)
• Seann Reed (NWSH/OHD)
• Ed Danaher (NCEP/HPC)
• Mark Glaudemans (NWSH/OHD)
• Mark Fresch (NWS/OHD)
• Reggina Cabrera (NWS/OHD)
• Tom Donaldson (NWSH/HSD)
• Tom Filiaggi (NWSH/MDL)
• Ken Howard (NSSL)

4
Outline
Improving Flash Flood Services QPE/QPF
Improvements

• Super Resolution (Build 10, AWIPS OB 8.2)

• increased reflectivity data resolution from 1 km
  to ¼ km
• increase azimuthal resolution of reflectivity,
  velocity and spectrum width from 1 to 0.5
• extend the range of Doppler data from 230 km to
  300 km
• Derived products will not use super resolution in
  this build
• Nexrad Product Improvement recently tasked OHD to
  compare derived precipitation products from super
  resolution and standard resolution

5
Outline
Improving Flash Flood Services QPE/QPF
Improvements

• Dual Polarization (Build 11, AWIPS OB8.3 2 year
  deployment)

• Improved precipitation estimation, Improved data
  quality, improved hail identification, and
  hydrometeor classification
• 1 degree by ¼ km data for base products and most
  derived products
• DHR will still exist (for now)
• DPR (Digital Precipitation Rate) is the dual
  polarization replacement product for DHR
• FFMP Advanced Design (AWIPS OB 8.3) should be
  able to ingest DPR for monitoring and display

6
Outline
Improving Flash Flood Services QPE/QPF
Improvements

• Enhanced Multisensor Precipitation Estimation
  (EMPE) (AWIPS OB8.3)

• High resolution rain rate and precipitation
  accumulation grids
• spatial resolution 1/4 HRAP mesh length (1x1
  km)
• Update frequency configurable up to 5 minute
  intervals
• DHR used to create radar rain rate estimates
• Gages are NOT used in this version of EMPE,
  however the MPE gage-radar bias table can be used
  in rain rate and accumulation estimation
• Dual Polarization DPR NOT used in this version of
  EMPE

7
Outline
Improving Flash Flood Services QPE/QPF
Improvements

• Multisensor Precipitation Nowcaster (MPN) (AWIPS
  OB9.0)
• An extrapolative forecast of the reflectivity
  field valid for the next hour, updated every 15
  minutes on an HRAP grid. Additional fields for
  AWIPS display include
• 1-hour radar precipitation accumulation forecast
  (with and without bias correction)
• Instantaneous rain rate forecasts at 15 minute
  intervals out through 1-hour (with and without
  bias correction)
• RFC MPE Mean Field Bias to WFO (AWIPS OB8.2)
• WFO operators can select which RFC bias message
  to receive and which bias message to send to the
  RPG
• NMQ/Q2 infusion into NCEP (no targeted build)
• Probabilistic QPE (no targeted build)

8
Outline
Improving Flash Flood Services FFG Improvements
Length to divide
Slope
OHD RDMS Soil Moisture

• ABRFCs Gridded FFG

Area
Static CN
Gridded Runoff

• Produce a flash flood guidance product at a
  resolution similar in scale to FFMP
• Gridded FFG is derived from HRAP resolution (4km
  x4km) of
• Soil moisture conditions from the Hydrology Lab -
  Research Distributed Hydrologic Model
• Dynamic NRCS Curve Number from soil data and land
  use land cover data and distributed model soil
  moisture conditions
• NRCS Unit Hydrograph model combined with a design
  storm to estimate bankfull flow (Thresh-R)
• Method treats each HRAP grid cell as an
  independent headwater basin

Duration
2-yr, 3-hr DDF
Dynamic NRCS Curve Number
Variable Threshold Runoff
For more details see the Gridded Flash Flood
Guidance topical breakout session
Gridded FFG
9
Outline
Improving Flash Flood Services FFG Improvements

• ABRFCs Gridded FFG

Fully Operational Under Development To be
developed In FY07
Status Developing 1, 3, and 6 hour FFG and
Thresh-R
10
Outline
Improving Flash Flood Services FFG Improvements

• CBRFCs Flash Flood Potential Index

• Using GIS and digital data of soil type,
  vegetation type and density, slope, and land use
  create a single value index of hydrologic
  response.
• Developed a process to modify FFPI with wildfire
  burn severity information.

Land Use
Soil type
Vegetation type and density
Wildfire
Slopes
11
Outline
Improving Flash Flood Services FFG Improvements

• CBRFCs Flash Flood Potential Index

• Current Status
• Prototypes Completed
• To be completed in FY07
• Future development
• Incorporate dynamic soil moisture component
• Derive FFG from relationships between the FFPI
  and historical event data.

12
Outline
Improving Flash Flood Services FFG Improvements

• Distributed Hydrologic Model Threshold
  Frequency Methodology

Historical
Real-time

• Run distributed hydrologic model in historical
  mode to create a simulated peaks distribution for
  each grid cell
• Run the distributed hydrologic model in real-time
  to create a maximum forecast peak for each grid
  cell
• Use a statistical post-processor to create
  forecast frequencies for each grid cell from the
  maximum forecast peak and the simulated peaks
  distribution
• Compare forecast frequencies with frequency
  threshold from local/regional knowledge

Distributed hydrologic model
Distributed hydrologic model
Initial hydro model states
Simulated peaks distribution (Qsp) (unique for
each cell)
Max forecast peaks
Probability
Statistical Post-processor
Flow (cms)
Local/regional knowledge
Compare
Frequency thresholds
Forecast frequencies
13
Outline
Improving Flash Flood Services FFG Improvements

• Distributed Hydrologic Model Threshold
  Frequency Method

• Benefits
• Relative measure (easier to understand than CMS)
• Inherent bias correction
• Local information often available to help define
  thresholds (e.g. engineering design,
  geomorphology studies)
• Can be used when bankfull flow is not
  meaningful (e.g. slot canyons)
• Limitation
• Required data may not be available everywhere
• Current Status
• Developing prototype for flash flood prone
  Baltimore area

14
Outline
Improving Flash Flood Services Summary of FFG
Improvements
15
Outline
Improving Flash Flood Services FFMP Improvements
AWIPS OB7.2
Zoom X
X
Emphasized Forced Flash Flood Guidance
Virtual Gage Basins
16
Outline
Improving Flash Flood Services FFMP Improvements
AWIPS OB7.2
Basin Trace Fix consistent hatching
17
Outline
Improving Flash Flood Services FFMP Improvements
AWIPS OB8.1
Basin Trace Fix editable
18
Outline
Improving Flash Flood Services FFMP Improvements
AWIPS OB8.3
19
Outline
Improving Flash Flood Services FFMP Improvements
AWIPS OB8.3

• Precipitation Sources
• DHR
• DPR
• EMPE
• NMQ (in prototype)
• SCAN QPF
• MPN (w/ OB9.0)

• Join duration from different sources
• For example a 3 hour duration derived from 1 hour
  MPN and 2 hours EMPE

• FFG Sources
• Legacy FFG
• Gridded FFG
• Debris Flow Guidance

20
Outline
Improving Flash Flood Services WarnGen
OB 8.2 ?

• FFMP Basin names in WarnGen

21
Outline
Improving Flash Flood Services Site Specific
Hydrologic Predictor Improvements OB8.2
Precip visualization and save/reload
Action, minor, moderate, and major stages
displayed (if defined)
Select alternate UHG (if defined)
22
Outline
Improving Flash Flood Services Site Specific
Hydrologic Predictor Improvements

• Future development (targeted for OB9 Gulf
  offices may see earlier)
• Simplified Routing Variable Lag and Variable K
  routing
• A separate variational data assimilation program
  to update the states of the SSHP SAC-SMA rainfall
  runoff model

23
Outline
Improving Flash Flood Services Dam Break Tools

• Goal Review the database and existing tools for
  simplified dam break
• Status Project delayed due to staff shortages in
  the Hydraulics Group of OHD

24
Improving Flash Flood Services

• Thank you!
• Any Questions?

National Hydrologic Program Managers
Conference July 10, 2007
