Camera Culture

1
Camera Culture
Ramesh Raskar Associate Prof, Media Lab, MIT
Course WebPage http//raskar.info/course.html
2
Todays Plan

• Summary, Camera for image search
• Visual Social Computing Citizen Journalism
• Next class big question
• Opportunities in Pervasive Public Recording
• Big concept
• (Last week)
• Understanding Camera Constraints
• (This week)
• What matters in photography pixels (Low-level
  cues) or low-dimensional features (Mid-level
  cues)?
• Decomposing pixels into meaningful values

3
Camera for image search

• How can we augment the camera to support best
  'image search'?
• 'Search'segment/identify/recognize/transform/comp
  are/archive
• Or more precisely, object matching across images.
• (For example, if we find to find a specific face
  image, we need a procedure to segment and
  identify (detect) the pixels likely to belong to
  a face, then recognize the candidate face by
  transforming into a representation where we can
  match with that specific face image. Currently,
  this is all performed in software using
  traditional cameras. Typically, the algorithms
  try to reduce the image to lower-dimensional
  'features' and do the matching in this
  feature-space. Unlike text search, where the
  search pipeline is simple thanks to easy matching
  process, object-matching-in-images is quite
  difficult. What can we additional data can we
  capture while recording pixels and what new
  algorithms can exploit this augmented photo?)
• How can we make the scene ingredients machine
  readable so that we can easily perform the
  'search'? Is this the key problem? 3D
  reconstruction (so that it is view independent,
  )? Hardware and software solutions? Crowdsourcing
  (let people do
• marking/sorting/indexing for others)? Metadata
  tagging (tag highlevel text labels rather than
  pixel-level tagging)?
• Do we need to capture Material index (where is
  all the wood in this image)? Segmentation
  boundaries (shape versus reflectance edges)?
  Repeatable view and illumination invariance (be
  able to recreate image from a given view so it
  can be compared with another image, or create
  images that look same independent of
  time-of-day)?
• Some ideas (i) to locate all 'images' with
  faces, record the iris biometric which validates
  if a photo includes a human eye, and then we can
  search all images across an album with that
  face/eye/iris, (ii) embed RFID tag (electronic
  bar-code) in every object and record the binary
  index with an RFID reader.

4
Next Class

• Homework
• What are the opportunities in pervasive recording
  of public spaces?
• Pervasive public recordingsurveillance/GoogleEart
  hLive/Subscription cameras
• Technology
• See thru fog, time-lapse processing,
  day-nite/season/multi-modal fusion, how to
  consume these images, how to merge with
  static/dynamic content, merge with static/dynamic
  cameras, support object recognition, refine GPS
  coords, crowdsourcing, metadata (video frame)
  tagging
• Society
• Commerce (real-estate, reviews, remote
  maintenance), Environment (earthquake-prediction
  like opportunities, Politics (protests)
• Volunteer
• Class notes Lav (today), next ..
• Select/read/present/paper
• Visual Social Computing Tom
• Mobile Photography Eugene
• Beyond Visible Spectrum Brandon
• Emerging sensors Matt
• Developing Countries Lav/ Tilke
• Sols for Visually Challenged James

5
Today 3pm

• Less is More Coded Computational Photography
• Speaker Ramesh Raskar, MIT Media LabDate
  Wednesday, February 20 2008Time 300PM to
  400PM Refreshments 245PM Location Star
  Seminar Room (32-D463)

6
Topics

• Imaging Devices, Modern Optics and Lenses
• Emerging Sensor Technologies
• Mobile Photography
• Visual Social Computing and Citizen Journalism
• Imaging Beyond Visible Spectrum
• Computational Imaging in Sciences
• Trust in Visual Media
• Solutions for Visually Challenged
• Cameras in Developing Countries
• Future Products and Business Models

7
Feedback

• What are your questions about camera/technology/so
  ciety?
• Your expectations from the course?

8
Topics

• Other courses
• Art and Photography
• CSAIL Computational Photography
• MechE Optics
• Fall2008
• Intro to Computational Camera and Photography
• I will teach course in Fall
• Current course
• More emphasis on future cameras
• Faster review of technology and then look at
  impact/applications/opportunities
• Big ideas/technologies/applications,
• Understand rules-of-thumb and trade-offs
• Ideal for thesis/projects/research
  papers/business models
• Learn fun stuff before the nitty gritty

9
Photography Full of Tradeoffs...

• Available light vs. exposure time vs. scene
  movement vs. field of view vs. focus depth vs.
  sensitivity vs. noise vs. color rendition vs.
  color gamut vs. contrast vs. visible detail vs. .

Flash
10
Available Light vs Parameter/Specs box
Exposure
Dynamic Range
Focus distance
Resolution/Frame rate
Focal Length (zoom)
Field of view
Depth of field
Aperture
Limited Parameters
Limited Abilities
11
Dynamic Range
Short Exposure
Goal High Dynamic Range
Long Exposure
12
Phase 1 of Better Photography

• Epsilon Photography
• Low-level vision
• Best pixel and pixel-features
• Vary focus, exposure, polarization, illumination
• Vary time, view
• Better than any one photo (resolution/frame rate,
  fov, dynamic range etc)
• Achieve effects via multi-photo fusion
• Create a Super-camera
• Mimic human eye

13
Phase 1.1 of Better Photography

• Create a Super-camera
• Mimic human eye
• What aspect of human eye are critical/ useless?
• Eye Feedback wrt brain, After-image/illusions,
• Camera geometry/stereo pair, multispectral,unifor
  m res, memory,
• What are other parameters/Design/Features to
  improve?
• Very small camera/thin camera ..
• Tight loop with illumination
• ..

14
The Eyes Lens
15
Varioptic Liquid Lens Electrowetting
Varioptic, Inc., 2007
16
Varioptic Liquid Lens
(Courtesy Varioptic Inc.)
17
Captured Video
(Courtesy Varioptic Inc.)
18
Conventional Compound Lens
19
Origami Lens Thin Folded Optics (2007)
Ultrathin Cameras Using Annular Folded Optics,
E. J. Tremblay, R. A. Stack, R. L. Morrison, J.
E. Ford Applied Optics, 2007 - OSA
20
Origami Lens
Conventional Lens
Origami Lens
21
Optical Performance
Conventional Origami
Scene
22
Compound Lens of Dragonfly
23
TOMBO Thin Camera (2001)
Thin observation module by bound optics
(TOMBO), J. Tanida, T. Kumagai, K.
Yamada, S. Miyatake Applied Optics, 2001
24
TOMBO Thin Camera
25
Captured Image
TOMBO
Scene
Captured Image (Multiple low-resolution copies
of the scene)
26
Reconstructed Image
27
Phase 1 of Better Photography

• Epsilon Photography
• Low-level vision
• Best pixel and pixel-features
• Vary focus, exposure, polarization, illumination
• Vary time, view
• Better than any one photo (resolution/frame rate,
  fov, dynamic range etc)
• Achieve effects via multi-photo fusion
• Create a Super-camera
• Mimic human eye

28
Phase 1.1 of Better Photography

• Create a Super-camera
• Mimic human eye
• What aspect of human eye are critical/ useless?
• ..
• What are other parameters/Design/Features to
  improve?
• Very small camera/thin camera ..
• Tight loop with illumination
• ..

29
Phase 2 of Better Photography

• Coded Photography
• Mid-level cues
• Regions, shapes(depth), edges, motion,
  material-index ()
• Cartoons via Multi-flash camera (depth edges),
  Wavelength profile,
• Visual interface issue (human eye expects pixels)
• Decompose pixel values ()
• Single or few photos
• Create a functionally super-camera
• Dont mimic human eye

30
Multiperspective Camera?

• Jingyi Yu 2004

31
Phase 3 of Better Photography

• Essence Photography
• High-level cues
• Inference, perception, cognition
• Intent based (like biovision systems)
• Not a single-solution fits-all
• ? Single or few photos
• Beats photography
• Dont just mimic human eye, or record
  pixels/mid-level cues
• Create a meaningful representation of visual
  experience
• New art form, new commerce models

32
Visual Social Computing and Citizen Journalism

• What is VSC
• Social Computing is well known, I made up VSC
• My defn of SC Online computation of the people,
  by the people, for the people (old world govt,
  economy, epidemiology)
• Subsets
• Crowdsourcing (CAPTCHA) (by the people, but maybe
  for just one person)
• Participatory sensing (of the people, but no
  active part by individuals, not for the people)
• Recommendation systems (by the people and for the
  people)
• Tagging (Digg) (all three)
• Blogs, social networks, auctions, wikipedia, tags
• 90 of all data will be about people
• Example problem Can we reduce distrust among
  Kenyas groups?
• Easy to predict certain trends ..
• Just add dimensions
• Text, audio/music, images, video, (whats next)
• LP-gtCassette-VHS player -gt CD player -gt DVD
  Player (ok Blue-ray DVD player) -gt (whats next)
• Radio-TV- ..
• Gopher -gt Newsgroups -gtWikipedia _gt (whats next)
• Take anything text/audio based -gt image/video
• Take anything image based -gt video (Flickr -gt
  YouTube)

33
Today 3pm

• Less is More Coded Computational Photography
• Speaker Ramesh Raskar, MIT Media LabDate
  Wednesday, February 20 2008Time 300PM to
  400PM Refreshments 245PM Location Star
  Seminar Room (32-D463)

34
Next Class

• Homework
• What are the opportunities in pervasive recording
  of public spaces?
• Pervasive public recordingsurveillance/GoogleEart
  hLive/Subscription cameras
• Technology
• See thru fog, time-lapse processing,
  day-nite/season/multi-modal fusion, how to
  consume these images, how to merge with
  static/dynamic content, merge with static/dynamic
  cameras, support object recognition, refine GPS
  coords, crowdsourcing, metadata (video frame)
  tagging
• Society
• Commerce (real-estate, reviews, remote
  maintenance), Environment (earthquake-prediction
  like opportunities, Politics (protests)
• Volunteer
• Class notes Lav (today), next ..
• Select/read/present/paper
• Visual Social Computing Tom
• Beyond Visible Spectrum Brandon
• Mobile Photography
• Emerging sensors
• Developing Countries Lav
