Speech and speaker normalization (in vowel normalization)

1
Speech and speaker normalization (in vowel
normalization)

• Venice International University
• Phonetic and technological aspects of speaker
  characteristics
• Prof. Dr. J. Harrington
• Presented by
• Clara Tillmanns
• clarainindia_at_yahoo.com
• 18.10.2007

2
Contents

1. Speech and speaker normalization in vowel
   normalization definition
2. Influencing parameters and instruments for vowel
   normalization
3. Theories
4. Studies Johnson 1990 and 1999
5. Recapitulation

3
Definition

• Normalization.
• We know there is extensive variation in speech.
  How come that listeners agree in their perception
  of vowels?

4
Fig. 1 Scatter plot of first and second formant
values of American English vowels. From Peterson
Barney 1952
5
Definition

• Normalization.
• Which information influences this decision?

6
Definition

• Normalization.
• And, which mechanism leads to the decision?

7
Contents

• Speech and speaker normalization definition
• Influencing parameters and instruments for vowel
  normalization
• Context
• Formant ratio
• F0
• Visual information
• Auditory gestalts
• Theories
• Studies Johnson 1990 and 1999
• Recapitulation

8
Influencing parameters and instruments for vowel
normalization

• Extrinsic Intrinsic

Context
Formant ratio
F0
Auditory gestalts
Visual information
9
Influencing parameters and instruments for vowel
normalization
Syllable internal
Syllable external

• Extrinsic Intrinsic

Context
Formant ratio
F0
Auditory gestalts
Visual information
10
Influencing parameters and instruments for vowel
normalization
Syllable internal
Syllable external

• Extrinsic Intrinsic

Context
Formant ratio
Vocalic
Prosodic
F0
Tonal
Auditory gestalts
Visual information
11
Influencing parameters and instruments for vowel
normalization

• Context
• Perceived vowel quality is influenced
• by the formant frequencies of context vowels
  (Ladefoged Broadbent 1957)
• by the F0 range of the carrier phrase (Johnson
  1990)
• Tones Pitch range of a context utterance
  influences Mandarin Chinese tones (Leather 1983)

12
Influencing parameters and instruments for vowel
normalization
Syllable internal
Syllable external

• Extrinsic Intrinsic

Context
Formant ratio
Vocalic
Relative patterns
Prosodic
Gender
F0
Tonal
Auditory gestalts
Visual information
13
Influencing parameters and instruments for vowel
normalization

• Formant ratio
• Vowels are relative patterns - no absolute
  frequencies

14
Influencing parameters and instruments for vowel
normalization

• Formant ratio
• Fig. 2 Spectrogram of a man and a woman saying
  cat. The three lowest vowel formants (vocal
  tract resonant frequencies are marked as F1, F2
  and F3) (Johnson 2004)

15
Influencing parameters and instruments for vowel
normalization

• F0
• Miller 1953
• doubled F0 and found vowel category shift for
  most American English vowels
• Fujisaki Kawashime 1968
• Found F1 boundary shifts from 100Hz to 200Hz for
  F0 shifts of 200Hz

16
Influencing parameters and instruments for vowel
normalization
Syllable internal
Syllable external

• Extrinsic Intrinsic

Context
Formant ratio
Vocalic
Relative patterns
Prosodic
Gender
F0
Tonal
Auditory gestalts
Visual information
Articulatory gestures
Gender / Age
17
Influencing parameters and instruments for vowel
normalization

• Visual information
• Gender boundary shift much like the F0 shift
  (Strand Johnson 1996)
• Age
• Vowel quality boundary shift through differing
  visual phonetic information (Johnson 1999)
• Sociocultural Speech intelligibility is reduced,
  when the voice is associated with an Asian
  looking face (Rubin 1992)

18
Influencing parameters and instruments for vowel
normalization

• Auditory gestalts - secondary cues
• Duration
• Formant frequency movement trajectories
• Lehiste Metzger 1973
• Fixed duration vowels synthesized with
  steady-state formant frequencies (51 correct)
• - mixed lists of the original vowels from men,
  women and children 79 correct.
• Hillenbrand Neary 1999
• Flat-formant vowels were correctly identified 74
  of the time, while vowels synthesized with the
  original formant frequency trajectories were
  correctly identified 89 of the time.

19
Contents

• Speech and speaker normalization in vowel
  normalization definition
• Influencing parameters and instruments for vowel
  normalization
• Theories
• 3.1 Vocal tract normalization (VTN)
• 3.2 Talker normalization (TN)
• 4. Studies Johnson 1990 and 1999
• 5. Recapitulation

20
Theories - VTN

• Vocal tract normalization theories consider that
  listeners perceptually evaluate vowels on a
  talker specific coordinate system. (Johnson
  2004)
• Context vowels (reference)
• Visual information about the size of the vocal
  tract

21
Theories - VTN

• But Talkers may differ from each other at the
  level of their articulatory habits of speech
• Perception may not be able to depend on vocal
  tract normalization to remove talker
  differences by removing vocal tract differences.
  (Johnson 2004)
• ? Speaker/speech variation depends on anatomical
  differences only?

22
Theories - VTN

• Cross-linguistic gender differences
• Bladon, Henton and Pickering (1984)
• The difference between men and women vary from
  language to language.
• Cultural factors are involved in defining and
  shaping male or female speech
• Anatomy does not completely determine the vowel
  formant frequencies

23
Theories - VTN

Fig. 3 Spectral shift needed to normalize male
and female spectra From Bladon, Henton
Pickering (1984)
24
Theories - VTN

• This seems to suggest that talkers choose
  different styles of speaking as social, dialectal
  gender markers.
• A speaker normalization that removes vocal tract
  differences will fail to account for the
  linguistic categorical similarity of vowels that
  are different due to different habits of
  articulation.
• (Johnson 2004)

25
Theories - TN

• Talker normalization is subject to expectations
• Magnuson Nusbaum (1994) compared
• 1-voice with 2-voice instructions in a
  mixed-talker and blocked-talker experiment.
• Advantage of blocked-talker disappeared when
  subjects didnt know about the different F0s of
  the two voices.
• Talker normalization is an active process
• Kato Kakehi (1988) Listener adaptation to
  talker voice
• Increase in recognition accuracy over the course
  of 5 stimuli presented in noise

26
Theories - TN

• In this approach, cognitive categories are
  represented as collections of the stored
  cognitive representations of experienced
  instances of the category,
• rather than as normalized abstract
  representations from which category-internal
  structure has been removed (Johnson 2004)

27
Contents

• Speech and speaker normalization in vowel
  normalization definition
• Influencing parameters and instruments for vowel
  normalization
• Theories
• Studies
• 4.1 Johnson 1990
• 4.2 Johnson 1999
• 5. Recapitulation

28
Studies

• The role of perceived speaker identity in F0
  normalization of vowels (Johnson 1990)
• Presentation of vowels from a hood-hud
  continuum in two different intonational contexts
  which were judged to have been produced by
  different speakers, even though the F0 of the
  test word was identical in the two contexts.

29
Studies

• The role of perceived speaker identity in F0
  normalization of vowels (Johnson 1990)
• Shift in identification as a result of the
  intonational context
• which was interpreted as evidence for the role of
  perceived speaker identity in vowel normalization

30
Studies

• Auditory-visual integration of talker gender in
  vowel perception (Johnson 1999)
• Exp. 1 found, that the gender of
  auditory-visually presented stimuli shift the
  phoneme boundary of a vowel continuum
• Exp. 2 found that visual phonetic information is
  integrated in the boundary shift
• Exp. 3 showed that listeners integrate abstract
  gender information with phonetic information in
  speech perception

31
Contents

1. Speech and speaker normalization in vowel
   normalization definition
2. Influencing parameters and instruments for vowel
   normalization
3. Theories
4. Studies Johnson 1990 and 1999
5. Recapitulation

32
Recapitulation

• Great internal and external influence on the
  perception (of vowels)
• Explanation must integrate repeated learning
• Information on speaker identity influences the
  perception (of vowels)
• But Is the perception of speaker identity
  influenced by certain components of the speech
  signal?
• May speaker identity be manipulated?

33
References

• Bladon, R.A., Henton, C. G. Pickering, J. B.
  (1984) Towards an auditory theory of speaker
  normalization. Language Communication 4, 59-69.
• Fujisaki, H. Kawashima, T. (1968) The roles of
  pitch and higher formants in the perception of
  vowels. IEEE Transactions on Audio and
  Electroacoustics AU-16, 73-77.
• Hillenbrand, J. M. Neary, T. M. (1999)
  Identification of synthesized /hVd/ utterances
  Effects of formant contour. J. Acoust. Soc. Am.
  105, 3509-3523.
• Ladefoged, P. Broadbent, D. E. (1957)
  Information conveyed by vowels. J. Acoust. Soc.
  Am. 29, 98-104
• Leather, J. (1983) Speaker normalization in the
  perception of lexical tone. Journal of Phonetics
  11, 373-382
• Lehiste, I. Metzger, D. (1973) Vowel and
  speaker identification in natural and synthetic
  speech. Language and Speech 16, 356-364.
• Johnson, K., Strand, E. A. DImperio, M. (1999)
  Auditory-visual integration of talker gender in
  vowel perception. Journal of Phonetics 27,
  359-384
• Johnson, K. (2004) Speaker normalization in
  speech perception. Ohio State University
• Johnson, K. (1990) The role of percieved speaker
  identity in F0 normalization of vowels. J.
  Acoust. Soc. Am. 88 642-654
• Kato, K Kakehi, K. (1988) Listener
  adaptability to individual speaker differences in
  monosyllabic speech perception. J. Acoust. Soc.
  Of Japan 44, 180-186
• Magnuson, J. Nusbaum, H. (1994) Are
  representations used for talker identification
  available for talker normalization? Proceedings
  of the International Conference on Spoken
  Language Processing.
• Miller, R. L. (1953) Auditory tests with
  synthetic vowels. J. Acoust. Soc. Am. 25,
  114-121.
• Peterson, G. E. Barney, H. L. (1952) Control
  methods used in the study of vowels. J. Acoust.
  Soc. Am. 24, 175-184
• Rubin, D. L. (1992) Non-language factors
  affecting undergraduates jedgements of
  non-native English-speaking teaching assistants.
  Research in Higher Education 33, 4.
• Strand, E. A. Johnson, K. (1996) Gradient and
  visual speaker normalization in the perception of
  fricatives. In Natural languag processing and
  speech technology results of the 3rd KONVENS
  conference, Bielefeld, (D. Gibbon, Ed.), Berlin
  Mouton de Gruyter (pp. 14-26).
