Diathermy Interactions with Implanted Leads and Implanted Systems with Leads

1
Diathermy Interactions with Implanted Leads and
Implanted Systems with Leads

• Marian Kroen
• Office of Surveillance and Biometrics
• Issues Management Staff
• May 29, 2003

2
Adverse Events

• Interactions of diathermy therapy in patients
  with Deep Brain Stimulators
• Two patients treated with shortwave diathermy
• One pt. treated after oral surgery
• One pt. treated at thoracolumbar region
• Both patients went into a coma and subsequently
  died

3
What is Deep Brain Stimulation?
4
What is Diathermy?

• Diathermy can be thought of as an
  electro-magnetic heating pad. While a heating
  pad only heats the skin, this heats inside the
  body.
• Diathermy means deep heat, but can be used in
  both heating and non-heating modes.
• Used for relief of pain, sprains, strains,
  bursitis, muscle spasms.

5
Diathermy
6
Who Uses This?

• Diathermy is used by
• physical therapists
• occupational therapists
• sports trainers
• others..

7
Three Kinds of Diathermy

• Shortwave (radio-frequency)
• 13 to 27.12 MHz
• Newer models use 27.12 MHz
• Microwave
• Ultrasound

8
Medtronic Testing

• Medtronic performed in vitro testing to assess
  the effect of diathermy on DBS systems and
  provided the results to FDA
• Results
• Temperature rise of 55º C at DBS lead electrode
  during 15 minute diathermy exposure (max.
  diathermy settings)
• Temperature rise of 27º at pulse rate of 8 and
  amplitude of 10 (setting for adverse event)

9
What Information Do We Need?
?
10
What is the Scope of The Problem?

• Expert committee determined need for more testing
  to determine scope of interaction problem
• Are all implants affected?
• Are all metal implants affected?
• Does the shape of metal implants matter?
• Is the problem only with active implants?

11
OST Tested Active Implants

• Temperature rise at the lead electrode is high.
• Temperature rise occurs whether or not a
  pacemaker is connected.
• Cardiac lead and pacemaker system showed the
  highest temperature rise of 48.8 degrees C
• Spinal Cord Stimulator system and lead had 2nd
  highest temperature rise of 27.6 degrees C.
• The temperature rise with leads was highest where
  a shallowly implanted lead was simulated.

12
OST Tested Non-Active Implants

• Minimal heating (1 to 3.6 degrees C) for
• 4 inch long screw
• Fracture Plate
• Fracture plate screws
• Titanium rod
• Stainless Steel rod

13
Conclusions

• Diathermy Interactions with dangerously high
  temperatures limited to
• Implantable systems with metallic (conductive)
  leads
• implanted metallic leads themselves

14
Theory

• Implanted lead acts like an antenna to receive
  energy.
• Power is dissipated in the tissue where there is
  no insulation (electrodes).
• The current density, and thus the temperature, at
  the lead electrodes can be very high, due to the
  small surface area of the electrodes.

15
Can All Types of Diathermy Cause this Interaction?

• Both Shortwave and Microwave diathermy produce an
  electro-magnetic field which can interact with
  implanted leads.
• Ultrasound diathermy would have a different mode
  of interaction with implants (mechanical rather
  than electro-magnetic).

16

Taking Action
Alerts
Recalls
Education
Labeling
17

FDA Actions

• Labeling on Metallic Leads and Lead Systems
• Labeling on Diathermy Equipment
• FDA issued a Public Health Notification
• Journal Articles
• Patient Safety News

18
Hmm, Why No Injuries from Pacers?

?
19
Why are There No Reported Injuries for
Interactions of Diathermy with Cardiac Pacemakers
and Leads?

• Testing shows high pacing lead electrode
  temperatures
• Pacemakers and leads have long history.
• Two reports of damage to the pacemaker (but not
  to the heart) with diathermy use.

20
Possible Reasons for Lack of Pacing/Diathermy
Injuries

• Warnings adequate?
• Blood flow in heart carries away heat
• Distance, diathermy to heart
• Damage, but nobody put 2 2 together
• Brain has no pain receptors, heart does

21
Thoughts?

?
