Introduction to Chemistry – Background for Nanoscience and Nanotechnology

1
Introduction to Chemistry Background for
Nanoscience and Nanotechnology

• Prof. Petr Vanýsek
• NIU Chemistry and Biochemistry

2
Introduction to Chemistry Principles
3
Introduction to measurements

• Distance/size
• dynamics of the scale from the wavelength of
  x-rays to astronomic distances.
• focus on the middle scale size from visible
  objects person, hand (where did inch come
  from?), fingernail thickness, hair diameter,
  mite, microbe, virus, finally atom and a
  molecule.

4
Wide dynamic range of dimensions

• Electromagnetic spectrum

Relevant dimensions kilometers (103
m) meters centimeters (2-1/2 1
inch) millimeter nanometers Angstroms (10-10
m) size of an atom
Atom Electrons going around the nucleus
5
The scale of things
6
Units of Measurement

• SI Units
• There are two types of units
• fundamental (or base) units
• derived units.
• There are 7 base units in the SI system
• distance (length) is one of them
• the fundamental unit is meter

7
Some measurements are too small or too large to
use the basic unit. Therefore, we use prefixes.
SI Units
Selected Prefixes used in SI System
8
Why dimensions matter? Nanomaterials particles
of nanometer size
Nano-scale materials often have very different
properties from bulk materials e.g. color and
reactivity

• 3nm iron particle has 50 of atoms on the
  surface
• 10nm particle has 20 of atoms on the surface
• 30nm particle has 5 of atoms on the surface

9
Temperature

• SI Units
• Other important unit is unit for temperature.
  Temperature relates to the state of matter (gas,
  liquid, solid) and is fundamentally important in
  materials science.

10
Change of volume with temperature

• Thermal expansion volumetric thermal expansion.

11
Mercury thermometer

• Gallium nanothermometer

12
Forms of materialCARBON - GRAPHITE
13
Forms of materialDIAMOND - GRAPHITE
14
Form of materialGRAPHITE - FULLERENE
15
Fullerenes
16
Fullerenes
17
Classification of Matter

• States of Matter
• Matter can be a gas, a liquid, or a solid.
• These are the three states of matter.
• Gases take the shape and volume of their
  container.
• Gases can be compressed to form liquids.
• Liquids take the shape of their container, but
  they do have their own volume.
• Solids are rigid and have a definite shape and
  volume.

18
Properties of Matter

• Physical vs. Chemical Properties
• Physical properties can be measure without
  changing the basic identity of the substance
  (e.g., color, density, odor, melting point)
• Chemical properties describe how substances react
  or change to form different substances (e.g.,
  hydrogen burns in oxygen)
• Intensive physical properties do not depend on
  how much of the substance is present.
• Examples density, temperature, and melting
  point.
• Extensive physical properties depend on the
  amount of substance present.
• Examples mass, volume, pressure.

19
Properties of Matter
Physical and Chemical Changes
2 H2 O2 ? 2 H2O
20
Properties of Matter

• Physical and Chemical Changes
• When a substance undergoes a physical change, its
  physical appearance changes.
• Ice melts a solid is converted into a liquid.
• Physical changes do not result in a change of
  composition.
• When a substance changes its composition, it
  undergoes a chemical change
• When pure hydrogen and pure oxygen react
  completely, they form pure water. In the flask
  containing water, there is no oxygen or hydrogen
  left over.

21
Why Study Chemistry?

• Chemistry is the study of the properties of
  materials and the changes that materials undergo.
• Chemistry is central to our understanding of
  other sciences.
• It is substantial part of nanoscience and
  nanotechnology

.
22
The Study of Chemistry

• The Molecular Perspective of Chemistry
• Matter is the physical material of the universe.
• Matter is made up of relatively few elements.
• On the microscopic level, matter consists of
  atoms and molecules.
• Atoms combine to form molecules.
• As we see, molecules may consist of the same type
  of atoms or different types of atoms.

23
Molecular Perspective of Chemistry
24
Matter

• Solution A uniform mixture of two substances
  such that molecules are separate from each other
  and move around randomly. Usually these are
  liquids. Solutions are usually transparent.
• Colloids A mixture of much larger particles
  ranging from 20 nm to 100 µm. Milk and paint are
  colloids.
• Grains Some materials are made up of many small
  crystals called grains. A grain is an individual
  crystal of such a solid. Different grains may
  have the crystal lattice oriented in different
  directions.

25
Grain Structure in Steel
26
Elements, Atoms and Molecules

• Atoms All matter is made up of tiny particles
  called atoms.
• Molecules Sometimes two or more atoms are found
  bound together to form molecules.
• The atoms can be categorized into about 115
  different types based on the charge of the
  nucleus.
• Elements are made up of only one type of atom.
• The element carbon takes the form of graphite,
  diamond and buckminsterfullerene as well as
  others.
• It is only possible to change one type of atom
  into another through nuclear processes such as
  take place in a nuclear power plant, the sun,
  atomic bombs or particle accelerators.
• The elements do not change in ordinary chemical
  reactions.

27
Diagram Atom of helium
Protons Electrons Neutrons Electrons, on the
outside, are responsible for bonds
28
Chemical Bonding

• Covalent bonds
• Ionic bonds
• Metal bonding

29
How to go about making materials?Through
chemistry
30
Forms of materialCARBON GRAPHITE - DIAMOND
31
Phase diagram for carbon
From F.P. Bundy, The P,T Phase and Reaction
diagram for elemental Carbon, 1979 J. Geophys.
Res. 85 (B12) (1980) 6930.
32
How to go about making nanomaterials?
33
Diamond is hard, has high thermal
conductivity It is desirable material, how to
make it synthetically
34
Swiss Diamond Pan
35
(No Transcript)
36
Now, please turn to your group mates and discuss
the questions. You have about 10 minutes to do
that. Write down your answers.
37
Claims and/or facts Pressure Cast Aluminum for
non-warping and great thermal characteristics
with no hot spots. Reinforced Non-Stick
coating using Nano-Composite Technology with
Diamond Crystals. Perfectly flat bottoms for
cooking on all major surfaces. Ergonomic
Handles- oven safe 500ºF. Dishwasher and Metal
Utensil Safe. Patented Non-Stick Exclusive.
Hardest material known to man. Diamonds Make
the Difference! Perfect Heat Distribution The
8 pan cost (mail order) 55 As a chemist,
engineer, student, cook, consumer Discuss each
point and decide whether it is a useful or a good
value and design a test how to verify the claim.
Discuss what methods have to be mastered to make
such a pan. Where do you get the diamonds, for
example.
38
(No Transcript)
39
(No Transcript)
40
Large diamonds, though not of the jewelry
quality, can be made at high pressures. How
about small particles with properties of diamond,
having also properties on nano-materials (e.g,
large surface to volume ratio. This has been
achieved by chemical vapor deposition (CVD).
41
Why make nanodiamonds hard surface, good heat
conductivity, low adherence to water. Ideal
technological material for a household item A
frying pan.
42
WHAT IS NANO?
43
Top-down and bottom-up approach
44
The top-down approach
Machining or etching larger blocks and composites
to smaller structures

• Compare to traditional sculpture
• Size of detailed features depends on size of
  tools

45
The bottom-up approach
Small molecules or particles pre-designed to
self assemble into larger, organised structures
e.g. surfactants
Hydrophilic head group Water loving
oil
oil
oil
water
Hydrophobic tail Water hating
oil
oil
Spherical micelle
46
(No Transcript)
47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
The Periodic Table
53
Acceptance of nanotechnology
