Lisp

1
Lisp Introduction

• ??? ???
• ?????? ??????
• ????? ?' ???"?

2

• http//clisp.cons.org/
• http//sourceforge.net/projects/clisp

3
LISP (LISt Processing)

• 1. Parenthesized prefix notation ( 2 4)
• 2. Expressions can be nested (- ( 2 3 4 5) ( 2
  5))
• 3. Evaluation rule
• apply function to value of arguments.
• 4. Symbolic computation other types
• Primitive numbers, characters, strings,
  symbols.
• Compound lists.
• (append '(a b) '(c d)) --gt (a b c d)
• Quote block the evaluation of the following
  expression.
• '(a b) --gt (a b)
• (a b) --gt error a undefined function.
• 5. Self-evaluating types numbers, characters,
  strings.
• 6. Symbols as variables - not case sensitive.

4
VARIABLES

• 1. Define new objects in terms of others name
  them.
• 2. (setf p '(a b)) --gt (a b)
• p --gt (a b)
• 3. Symbols also used to name functions.

5
SPECIAL FORMS

• 1. Forms not evaluated according to the
  evaluation rule.
• 2. Special forms
• defun, defparameter, setf, let, case, if,
  function, quote.

6
LISTS

• 1. Primitive aggregating type.
• 2. Primitive functions first, second, ...,
  length, last. append, cons, list.

7
DEFINING NEW FUNCTIONS

• 1. (defun ltnamegt (ltparametersgt)
• "doc"
• ltbodygt)
• (defun last-name (name)
• "Select last name from a name represented
  as a list."
• (first (last name)))
• (last-name '(john r vandamme)) --gt vandamme
• (last-name '(john quirk MD)) --gt MD
• 2. Importance of abstraction.
• (defun first-name (name) (first name))

8
USING FUNCTIONS

• 1. (setf names '((john x ford) (peter p rabbit)
  (fabianna f wayne)))
• (mapcar 'last-name names) --gt (ford rabbit
  wayne)
• ' from name of function to function object.
• mapcar primitive.
• 2. (defparameter titles
• '(Mr Mrs Miss Madam Ms Sir Dr Admiral Major
  General))
• (defun first-name (name)
• "Select first name from a list representing
  a name."
• (if (member (first name) titles)
• (first-name (rest name))
• (first name)))
• (if lttestgt ltthen-partgt ltelse-partgt)
• (first-name '(Madam Major General Paula
  Jones)) --gt Paula
• 3. Trace functions

9
HIGHER ORDER FUNCTIONS

• 1. Functions as first-class objects can be
  manipulated, created, modified by running code.
• 2. Apply (apply ' '(1 2 3 4)) --gt 10
• 3. Funcall (funcall ' 1 2) --gt 3
• (funcall ' '(1 2)) --gt
• error (1 2) is not a number.
• 4. Function constructor lambda.
• (lambda (parameter ...) body...)
• non atomic name of a function.
• ((lambda (x) ( x 2)) 4) --gt 6
• (funcall '(lambda (x) ( x 2)) 4) --gt 8
• Can create functions at run time.

10
OTHER DATA TYPES

• 1. Strings (length "abc") --gt 3
• 2. Many number types.

11
LISP EVALUATION RULE

• 1. Every expression is either a list or an atom.
• 2. Every list to be evaluated is either a special
  form or a function
• application.
• 3. A special form expression is a list whose
  first element is a special form operator and is
  evaluated according to the special rule of that
  operator.
• 4. A function application is evaluated by first
  evaluating the arguments (the rest of the list)
  and then finding the function named by the first
  element of the list and applying it to the list
  of evaluated arguments.
• 5. Every atom is either a symbol or a non-symbol.
• 6. A symbol evaluates to the most recent value
  assigned to the variable.
• 7. A non-symbol atom evaluates to itself.

12
WHAT MAKES LISP DIFFERENT

• 1. Built-in support for Lists.
• 2. Automatic memory management.
• 3. Dynamic typing.
• 4. First-class functions.
• 5. Uniform syntax.
• 6. Extensibility

13
Why LISP?

• Especially designed for symbol manipulation.
• Provides built-in support for lists (everything
  is a list..)
• Automatic storage management (no need to keep
  track of memory allocation).
• Interactive environment, which allows programs to
  be developed step by step. That is, if a change
  is to be introduced, only changed functions need
  to be recompiled.

14
Everything's a List!

• Data
• Functions
• Simple syntax
• (function-name arg1 arg2 )

(a b c)
(defun plus (x y) ( x y))
15
Interpreted interactive

• Interpreted
• Interactive

USER(1) 12 12 USER(2) ( 12 3) 15 USER(3)
(setf Almost-age 31) 31 USER(4)
Almost-age 31 USER(5) 'Almost-age ALMOST-AGE USER
(6)
16
Symbolic

• Why do we care about symbols?
• Understand human cognition with a language like
  symbolic processing

17
Physical Symbol System Hypothesis

• "A physical symbol system has the necessary and
  sufficient means for general intelligent action."
  (Newell Simon 1976)
• Physical symbol system
• Set of entities called symbols - physical
  patterns that can occur as components
• Expressions (or symbol structures) built of
  symbols

18
Dynamic

• Functions are first-class objects
• Pass functions as arguments to other functions

USER(1) ( 1 2 3) 6
USER(2) (apply ' '(1 2 3)) 6
19
One Function, and a Side of Fries, To Go

• Create functions on the fly
• Lisp contains itself eval

USER(1) (funcall '(lambda (x y) ( x y)) 17
14) 31
20
Name Calling

• Lisp remembers function names separately from
  variable names

USER(22) (defun add (x y) ( x y)) ADD USER(23)
(setf add 9) 9
USER(24) add 9
USER(25) 'add ltInterpreted Function ADDgt
21
Basic terminology

• Atoms word-like indivisible objects which can
  be numbers or symbols.
• Lists sentence-like objects formed from atoms or
  other lists, and enclosed in parentheses.
• S-expressions compositions of atoms and lists.
• Procedures step by step specifications how to do
  something.
• Primitives procedures supplied by the LISP
  itself
• Example ( 5 6)
• User-defined procedures procedures introduced by
  the programmer.
• Example (students 'anna)
• Program a collection of procedures working
  together.

22
S-expressions

• An s-expression can have other s-expressions
  nested in it. Examples
• ( ( 5 7) ( / 2 4))
• (This (is a dog) (or a cat))
• Expressions can be interpreted both, procedurally
  and declaratively.
• If interpreted procedurally, an expression
  provides a direction for doing something. Such an
  expression is called a form, and its first
  element is the name of a procedure to be used to
  produce the value.
• The process of computing the value of an
  expression is called evaluation.
• If interpreted declaratively, expressions
  represent data.
• Data and procedures have the same
  syntax.

23
Evaluation of atoms

• The value of a number is the number itself.
• Example 5 gt 5
• The value of a string is the string itself.
• Example Nice day gt Nice day
• The value of the symbol T is T (true).
• The value of the symbol NIL is NIL (false).
• The symbol NIL and the empty list ( ) are the
  same thing.
• Variables are names of memory locations. The
  contents stored in a given memory cell is the
  value of the variable serving as a name of this
  location.
• Example Let x be a variable, and 5 be the
  contents of the memory cell called x. Then, the
  value of x is 5.

24
Numbers

• Integers 179, 45
• Ratio 5/7, 7/9
• Floating point 5.2, 7.9
• Examples
• (/ 25 5)
• 5
• (/ 46 9)
• 46/9 do not divide
  evenly
• (float (/ 46 9))
• 5.111111
• (round (/ 46 9))
• 5 the nearest
  integer
• 1/9 the remainder

25
More numeric primitives

• (- 6)
• -6
• (- -6)
• 6
• (max 5 7 2)
• 7
• (min 5 7 2)
• 2
• (sqrt ( ( 1 3) ( 2 2)))
• 4.0
• ( (round (/ 22 7)) (round (/ 7 3)))
• 5

• ( 2 2.5)
• 4.5
• (expt 3 6)
• 729
• (sqrt 81)
• 9.0
• (sqrt 82)
• 9.055386
• (abs 6)
• 6
• (abs -6)
• 6

26

• Problems
• 1. Write a function (power 3 2) 32 9
• 2. Write a function that counts the number of
  atoms in an expression.
• (count-atoms '(a (b) c)) --gt 3
• 3. (count-anywhere 'a '(a ((a) b) a)) --gt 3
• 4. (dot-product '(10 20) '(3 4)) --gt 10x3 20x4
  110
• 5. Write a function (flatten '(a (b) () ((c))))
  --gt (a b c)
• which removes all levels of parenthesis and
  returns a flat list of
• atoms.
• 6. Write a function (remove-dups '(a 1 1 a b 2
  b)) --gt (a 1 b 2)
• which removes all duplicate atoms from a flat
  list.
• (Note there is a built-in remove-duplicates
  in Common Lisp, do not use it).

27
Solutions 1-3
(defun power (a b) "compute ab - (power 3 2)
gt 9" (if ( b 0) 1 ( a (power a (- b
1))))) (defun count-atoms (exp) "count atoms in
expresion - (count-atoms '(a (b) c)) gt 3"
(cond ((null exp) 0) ((atom exp) 1) (t (
(count-atoms (first exp)) (count-atoms (rest
exp)))))) (defun count-anywhere (a exp) "count
performances of a in expresion - (count-anywhere
'a '(a ((a) b) (a))) gt 3" (cond ((null exp)
0) ((atom exp) (if (eq a exp) 1 0)) (t (
(count-anywhere a (first exp))
(count-anywhere a (rest exp))))))
28
Solutions
(defun flatten (exp) "removes all levels of
paranthesis and returns flat list of atomsi
(flatten '(a (b) () ((c)))) gt (a b c)" (cond
((null exp) nil) ((atom exp) (list exp)) (t
(append (flatten (first exp)) (flatten
(rest exp))))))
