1Chapter 15
- Falling, impact, acceleration, lifting, and
vision hazards
2Major Topics
- Causes of falls
- Slip and fall prevention program
- OSHA fall prevention standards
- Ladder safety
- Lifting hazards
- Personal protective equipment (PPE)
- Forklift safety
3Primary causes of falls
- More than 16 percent of all disabling work
related injuries are the result of falls. - The primary causes of falls are
- A foreign object on the walking surface.
- A design flaw in the walking surface.
- Slippery surfaces.
- An individuals impaired physical condition.
4Most Common Kinds of Falls
- Trip and fall accidents occur when worker
encounters an unseen foreign object in their
path. - Stump and fall accidents occur when a workers
foot suddenly meets a sticky surface or a defect
in the walking surface. - Step and fall accidents occur when a worker
encounters an unexpected step down. - Slip and fall accidents occur when the workers
center of gravity is suddenly thrown out of
balance (oily spot). This is the most common type
of fall. - (Falling from ladders is covered later)
5How surface traction is measured
- Use the coefficient of friction which is a
numerical comparison of the resistance of one
surface (shoe or boot) against another surface
(the floor). - Surfaces with a coefficient of friction of 0.2 or
less are very slippery and very hazardous. e.g.
ice is 0.1 - Surfaces with a coefficient of friction of 0.4 or
higher have a good traction. e.g. concrete is 0.43
6Strategies for preventing slips
- Choose the right material from the outset For
walking surfaces, select surface material that
has the highest coefficient of friction. - Retrofit an existing surface Retrofit existing
surfaces with friction enhancement devices such
as runners, skid strips, carpet, grooves,
abrasive coatings, grills, and textured
coverings. - Practice good housekeeping Regardless of the
type of surface, keep it clean and dry. Spilled
water, grease, oil, solvents should be removed
immediately. When cleaning or mopping rope off
area and erect warning signs. - Require nonskid footwear Employees who work in
areas where slipping is likely to be a problem
should be required to wear shoes with special
nonskid soles. - Inspect surfaces frequently Safety and health
professionals should conduct frequent inspections
and act immediately when a hazard is identified.
7Slip and Fall Prevention Programs
- Every year slips, trips, and falls cause more
than one million workplace injuries and
approximately 16,000 deaths. - A policy statement/commitment Statement to
convey managements commitment to safety to
include - intent, scope of activity,
responsibility, accountability, the safety
professionals role, authority, and standards. - Review and acceptance of walkways Contain the
criteria that will be used for reviewing all
walkway surfaces and determining if they are
acceptable. - Reconditioning and retrofitting include
recommendations and timetables for reconditioning
or retrofitting existing walkways that do not
meet review and acceptance criteria. - Maintenance standards and procedures How often
surfaces should be cleaned, resurfaced, replaced
and procedures for meeting maintenance standards. - Inspections, audits, tests and records List of
inspections, audits and tests that will be done,
how frequently and where. Record of results. - Employee footwear program Specify type of
footwear for employees who work on different
types of surfaces. - Defense methods for legal claims Outline of
companys legal defense to show that the company
was not negligent (slip and fall prevention
program). - Measurement of results Explain how the program
will be evaluated, and how often. Record of
results of evaluations.
8Trigger Height Controversy over OSHAs Fall
Protection Standards for Construction
- OSHAs current Fall Protection Standard sets the
trigger height at 6 feet. This means that any
construction employee working higher than 6 feet
off the ground must use a fall protection device
such as a safety harness and line. - The trigger height means that virtually every
small residential builder and roofing contractor
is subject to the standard. Because most
residential builders and roofing contractors are
small, subpart M of 29 CFR 1926 is a source of
much controversy.
9Requirements for personal fall arrest system in
OSHA 1926.451d16
- Personal fall arresting systems, when stopping a
fall shall - Limit maximum arresting force on an employee to
900 pounds when used with a body belt. - Limit maximum arresting force on an employee to
1800 pounds when used with a body harness. - Be rigged such that employee can neither
free-fall more than 6 feet nor contact any lower
level. - Bring an employee to a complete stop and limit
maximum deceleration distance an employee travels
to 3.5 feet. - Have sufficient strength to withstand twice the
potential impact energy of an employee
free-falling a distance of 6 feet or the free
fall distance permitted by the system, whichever
is less.
10What is a Lanyard
- A lanyard is a flexible line of rope, wire rope,
or strap that generally has a connector at each
end for connecting the body belt or harness to a
deceleration device, lifeline or anchorage.
11OSHAs recommendation for effective fall
protection
- Slip and fall injuries account for approximately
one million workplace injuries every year. - Have a plan An organization should develop a
written fall protection plan that contains a
statement of commitment from both management and
employees, rules and regulations relating to fall
protection, and explanation of the training
programs and training requirements. - Establish proper fall protection requirements
Require the use of fall protection equipment
anytime an employee works more than 4 feet above
the floor in general industry, 6 feet or more in
construction, and 10 feet or more when on a
scaffolding. - Provide proper fall protection equipment and
procedures and require their use Might include
personal fall arrest systems, guardrails, safety
nets, positioning devices, warning lines,
controlled access zones, and safety monitoring. - Ensure proper use and type of equipment Proper
type for the situation, employees inspect it
before putting it on, fits properly, and is
properly attached to anchor points. - Provide Training Fall protection training for
supervisors and employees including how to
recognize fall hazards and how to properly use
all equipment.
12Assessing workplace for eye hazards
- Do employees perform tasks that may produce
airborne dust or flying particles? - Do employees work near others who perform tasks
that may produce airborne dust or flying
particles? - Do employees handle hazardous liquid chemicals or
blood? - Do employees work near others who handle
hazardous liquid chemicals or blood? - Do employees work in situations that may expose
their eyes to chemical or physical irritants? - Do employees work in situations that might expose
their eyes to intense light or lasers? - Based on the answers to these questions, the
vision protection program can be developed.
13Eye protection training
- Ensures that eye protection devices are used
properly. Shows employees that they have a
critical role to play in protecting their eyes.
OSHA recommend the following topics - Why is it important to use the eye protection
devices - How the devices protect the eyes
- Limitations of the devices
- When the devices should be used
- How the devices are properly worn
- How straps are adjusted for both comfort and
effectiveness - How employee can identify signs of wear that may
lessen the effectiveness of the devices - How the devices are cleaned and disinfected and
how often
14Inspecting ladders
- The National Safety Council recommends the
following - See if the ladder has the manufacturers
instruction label on it. - Determine whether the ladder is strong enough.
- Read the label specifications about weight
capacity and applications. - Look for the following conditions cracks on side
rails loose rungs, rails or braces or damaged
connections between rungs and rails. - Check for heat damage and corrosion.
- Check wooden ladders for moisture that may cause
them to conduct electricity. - Check metal ladders for burrs and sharp edges.
- Check fiberglass ladders for signs of blooming
deterioration of exposed fiberglass.
15Evolution of Hard Hats
- Originally introduced in 1919, the hard hats
first introduced for head protection in an
industrial setting were inspired by the helmets
worn by soldiers in World War I. They were made
of varnished resin impregnated canvas. - Todays hard hats are made from the thermoplastic
material polyethylene using injection molding
process. - They are designed to provide limited protection
from impact primarily to the top of the head and
thereby reduce the amount of impact transmitted
to the head, neck and spine. - Hard hats are tested for a 40 foot pound impact,
which is equivalent to a two pound hammer falling
about 20 feet. - OSHA standard 29 CFR 1010.135 requires hard hats
since 1971 in an industrial setting in which
falling objects are likely.
16Kinds of Injuries to Foot and Toes
- OSHA regulations for foot protection are found in
29 CFR 1910.132 and 126 - Foot and toe injuries account for almost 20 of
all disabling work place injuries in the United
States. There are over 180,000 foot and toe
injuries in the workplace each year. Major
injuries are - Falls and impacts from sharp or heavy objects
(accounts for 60 of all injuries). - Compression when rolled over or pressed between
heavy objects. - Punctures through the sole of the foot.
- Conductivity of electricity or heat.
- Electrocution from contact with an energized
conducting material. - Slips on unstable walking surfaces.
- Hot liquid or metal splashed into shoes or boots.
- Temperature extremes.
17Typical Causes of Back Injuries
- Back injuries account for approximately 12
billion in workers compensation costs annually. - Lower back injuries account for 20 to 25 of all
workers compensation claims. - 33 to 40 of all workers compensation costs are
related to lower back injuries. - Each year there are approximately 46,000 back
injuries in the workplace. - Back injuries cause 100 million lost workdays
each year. - Approximately 80 of the population will
experience lower back pain at some point in their
lives. - Back injuries are typically caused by improper
lifting, reaching, sitting, and bending. - Lifting hazards such as poor posture, ergonomic
factors and personal lifestyles also contribute
to back problems. - Companys overall safety and health program
should have a back/safety lifting component.
18Six Step Back Safety Lifting Program
- 1. Display Poster Illustrations Proper lifting,
reaching, sitting, and bending techniques
strategically throughout the workplace. - 2. Pre-employment Screening Identify people who
have back problems. - 3. Regular Safety Inspections So corrective
action can be taken immediately. - 4. Education and Training To help employees
understand how to lift, bend, reach, stand, walk,
and sit safely. - 5. Use external services Identify local health
care providing agencies and organizations. - 6. Map out the prevention program First five
steps should be incorporated into companys
overall safety and health program. Reviewed
periodically and updated as needed.
19Ways to Minimize Standing Hazards
- Anti-Fatigue Mats provide cushioning between
feet and hard working surfaces. Reduce muscle
fatigue and lower back pain. - Shoe inserts For employees on the move. Reduce
lower back, foot and leg pain. - Foot Rails allow employees to raise one foot at
a time four or five inches. Relieves pressure on
spinal column. - Workplace Design Adjust height of workstation to
match physical needs. - Sit/Stand Chairs Give feet, legs and back
occasional rest. - Proper Footwear Well fitting comfortable shoes
for employees who stand prolonged periods of time.
20Strategies for proper lifting
- Plan ahead
- Determine if you can lift the load.
- Decide if you need assistance.
- Check your route to see whether it has
obstructions or slippery surfaces. - Lift with your legs, not your back
- Bend your knees, keeping your back straight.
- Position your feet close to the object.
- Center your body over the load.
- Lift straight up do not jerk.
- Keep your torso straight do not twist while
lifting or after the load is lifted. - Set the load down slowly and smoothly with
straight back and bent knees do not let go until
the object is on the floor. - Push do not pull
- Pushing puts less strain on your back.
- Use rollers under the object whenever possible.
21Critical Factors when selecting Gloves
- Choose depending on type of hazard
- Leather offers comfort, excellent abrasion
resistance, and minimum cut resistance. - Cotton offers comfort, minimal abrasion
resistance and minimum cut resistance. - Aramids offer comfort. Good abrasion resistance,
excellent cut resistance, and excellent heat
resistance. - Polyethylene offer comfort, excellent abrasion
resistance, minimal cut resistance. Should not be
subjected to high temperatures. - Stainless steel cord (wrapped in synthetic
fiber) offer comfort, good abrasion resistance
and optimal cut resistance. - Chain link or metal mesh offer very little
comfort, bit maximum abrasion and cut resistance. - Butyl rubber offer little comfort, but has
excellent resistance to heat, ozone, tearing, and
certain chemicals. - Viton rubber offer little comfort, but perform
well with chemicals that butyl rubber cannot
protect against.
22Getting employees comfortable when wearing PPE
- Personal protective equipment (PPE) is critical
in head, hand, back, eye, face, foot, skin and
breathing protection. - Make maximum use of engineering and
administrative controls PPE should be the last
line of defense. - Ensure optimum choice of PPE by using risk
assessment employees who know that the PPE
provides adequate protection from hazards will be
more likely to use it. - Involve employees in all aspects of PPE program
may provide valuable input, and are more likely
to buy into support and use. - Provide comprehensive education and training
programs employees need to understand why PPE is
important and how to use it. - Reinforce proper use and challenge improper use
Compliments should be given publicly, corrections
should be done in private. - Be sensitive to fit, comfort and style issues
ill fitting PPE may not provide proper
protection, and make employees reluctant to wear
it. - Work to make PPE a normal part of the uniform
using PPE will become standard operating
procedure and its proper use will cease to be an
issue.
23Training equipment contained in OSHA 29 CFR
1910.178 (powered industrial trucks)
- Before operating industrial truck (forklift)
employees are required to complete OSHA CFR
1910.178 initial training - 1. Operating instructions, warnings, and
precautions. - 2. Differences between truck and automobile.
- 3. Truck controls and instrumentation where they
are located and how to use them. - 4. Engine or motor operation.
- 5. Steering and maneuvering.
- 6. Visibility (including restrictions due to
loading). - 7. Fork and attachment adaptation, operation and
use limitations. - 8. Vehicle capacity.
- 9. Vehicle stability.
- 10. Vehicle inspection and maintenance.
- 11. Refueling and charging/recharging the
batteries. - 12. Operating limitations.
- 13. Other operating instructions, warnings,
precautions listed in operators manual. - 14. Work place related topics including surface
conditions where vehicle will be operated,
composition of loads, stability, load
manipulation, stacking, unstacking, pedestrian
traffic, etc.
24Summary
- The primary causes of falls are a foreign object
on the walking surface, a design flaw in the
walking surface, a slippery surface, and a
persons impaired physical working condition. - Strategies for preventing slips include the
following choose the right material from the
outset, retrofit an existing surface, practice
good housekeeping, require nonskid footwear, and
inspect surfaces frequently. - OSHAs requirements for fall protection include
the following have a plan, establish
requirements, provide equipment and procedures,
ensure proper use and type of equipment, and
provide training.
25Summary
- Dos and do nots of ladder safety include
checking for slipperiness, allowing only one
person on the ladder at a time, securing the base
and top on a level surface, facing the ladder
while climbing, avoiding leaning, and always
holding with one hand. - Protection from impact injuries from falling
objects include PPE to protect the head (hard
hats), eyes and face (goggles or shields), and
feet (footwear). - Before using PPE, every feasible engineering and
administrative control should be employed.
26Home work
- Answer questions 1, 4, 5, 7, 9, 18, and 21 on
page 354. - 1. List the primary causes of falls.
- 4. List and briefly explain 5 strategies for
preventing slips. - 5. Describe the various components of a slip and
fall prevention program. - 7. What are the requirements of personal fall
arrest systems in OSHA regulation
1926.451(d)(16). - 9. Explain OSHAs recommendations for effective
fall protection, and what action to take when a
worker is dangling from his fall arrest gear. - 18. Explain the strategies for proper lifting
that should be taught as part of the safety
program. - 21. Explain the training requirements contained
in OSHAs standard 29 CFR 1910.178 (powered
industrial trucks).
