Operative Treatment For Cervical Spine Fractures

1
Operative Treatment For Cervical Spine Fractures

• Dr. T. G. Hogan

2
Occipito-cervical Dissociation
3
Occipitocervical Instability
Basion-Dens-Interval lt12 mm. gt12 mm. Suggests
Vertical Instability Basion-Axial-Interval lt
12mm gt12mm. Suggests Anterior Instability lt0mm.
Suggests Posterior Instability
Basion
Basion Axis Int lt12
BDI lt 12
4
Occipitocervical Dislocation

• Mechanism Unclear
• Rotation Distraction
• Neurological Deficits Confusing
• High Tetraplegia
• Cruciate Paralysis
• Wallenbergs Syndrome
• Ligamentous Injuries Unstable
• Avoid Traction

5
Atlas Fractures Extension

• Anterior Arch
• Hyper-extension
• Avulsion of Longus Colli
• R/O Other Injuries
• 65 (Landells)
• Stewart G, Radiology 1977

6
Atlas Fractures Extension

• Posterior Arch Fractures
• Occipital Pain Numbness
• Stable
• R/O Other Injuries
• (Odontoid )

7
Jefferson Fractures

• Four Part Burst
• Axial Load
• 6.9 mm Overhang
• Spence KF, JBJS, 1970
• 8.1 mm Overhang
• Heller JG, J Spinal Disord, 1993

8
Lateral Mass Fractures of C-1

• Free-Floating Lateral Mass of C-1
• Often Comminuted
• Segal Stauffer, JBJS, 1987

9
Treatment Results C-1 s

• Good Results Reported with
• Halo Traction Vest
• Rigid or Simple Orthoses
• Late Pain
• Ant/Post Arch 50
• Jefferson 70
• Lateral Mass 33
• Landells, VanPeteghem, Spine 1987

10
Anderson DAlonzo Classification (JBJS, 1974)

• Type I
• Type II
• Type III

11
Odontoid fractures
Type 1 Type 2 Type 3
12
Type II Odontoid

• Halo-Thoracic Brace
• Non-union Rate 14-32-75
• Risk Factors
• Failure to Treat
• 5mm Displacement
• gt10 deg. Angulation
• Posterior Displacement
• Elderly

13
Type II Odontoid

• Direct Screw Fixation
• Preserves C1-2 Motion
• No Bone Graft Required
• Avoid Non-Unions
• Avoid Reverse Oblique
• Aebi, Spine 1989

14
Type II Odontoid

• Posterior Fusion
• Primary
• for Non or Delayed Union
• Trans-articular Facet Screws
• 96 Fusion Rate
• Restricted Rotation

15
C2 Magerl screw fixation

• Good stability
• Does not need
• odontoid
• C1 arch
• C2 arch
• Challenging

16
Odontoid stabilisation
Osteosynthesis odontoid screw fixation

• Arthrodesis Magerl screw fixation - challenging
• Good stability
• Does not need odontoid, C1 arch or C2 arch

17
Traumatic Spondylolisthesis C-2(Levine
Edwards, JBJS, 1985)
18
Traumatic Spondylolisthesis C-2(Levine
Edwards, JBJS, 1985)
19
Traumatic Spondylolisthesis C-2(Levine
Edwards, JBJS, 1985)
20
Traumatic Spondylolisthesis C-2(Levine
Edwards, JBJS, 1985)
Dislocated
21
Subaxial C-Spine
22
Flexion-compression...
3
4
2
5
1
23
Checklist Approach

• Applies to trauma and degenerative disease
• The more points the more unstable
• 5 points does not mean surgery occasionally lt5
  need Sx gt5 dont need Sx
• Currently investigated by CSRS
• Different considerations for different levels
• 2-column VS 3-column

24
Sensitivity Settings
25
C2-T1

• Usually for trauma, but applies to all
• Ant./post. Element failure
• Stretch test (1.7mm, gt7.5 degrees)
• X-Ray (gt3.5mm, 11 degrees)
• Flex/ext x-ray (gt3.5mm, 20 degrees)
• Pavlovs ratio (lt0.8) sagittal diameter lt13
• Narrow disc
• Cord damage
• Root damage
• Dangerous loading anticipated

26
Cervical Measurements
27
Mr. Roeth. C-4 Fracture
28
Mr. Roeth. C-4 Fracture
29
CSLP Ant. Post Instability
30
Mr. R. Co. C5 6 Fractures
31
Mr. R. Co. C5 6 Fractures
32
Mr G H C4-5 Facet Dislocation
33
Mr G H C4-5 Facet Dislocation
34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
Cervical trauma

• Case presentations

39
Cervical trauma

• Case 1

40
Patient JM, 16yrs

• Fell boarding 2/52 ago
• winded
• continued 2/7
• hemoptysis 4/7
• saw GP
• neck xrayed
• Full ROM
• Not tender

C6
C6
41
Patient JM, 16yrs
C6
C7
Spot lateral
42
Patient JM, 16yrs
C6
C6
C7
C7
Flexion
Extension
43
Patient JM, 16yrs
C6
C7
CT reformats
44

• New or old injury?
• Snowboarding 2wks ago?
• Dirtbike 2yrs ago?
• Observe only?
• Advice and precautions
• Risks
• Stabilise?
• Anterior or posterior
• Risks

45
Patient EC, 72f
Initial Xray
C5
46
Patient EC, 72f
C5
Right
Left
CT
47
Patient EC, 72f
C5
Postreduction
48
EC
C5
Postop
49
Cervical trauma

• Case 3

50
Patient M, 65yrs
Initial CT
51
Patient M, 65yrs
Initial CT
Left
Right
52
Patient M, 65yrs
Intraoperative
Postop
53
Patient M, 65yrs
Initial CT
54
Patient BB, 32yrs
55
BB
10lbs
56
BB
57
BB
3 months
6 months
