Title: Solar Voltaic Energy


1
Solar Voltaic Energy
2
Outline
  • Overview of Solar Power
  • How Photo-voltaic (PV) Cells Work
  • How Solar PV Cells are Made
  • Solar PV
  • Applications
  • Efficiencies
  • Economics
  • Facts Trends
  • Research

3
Solar Power Overview
4
http//en.wikipedia.org/wiki/ImageThe_Sun_w920607
.jpg
5
PV Solar Radiation
http//en.wikipedia.org/wiki/Solar_cells
6
Photon Energy
7
Light the Photovoltaic Effect
  • Certain semiconductor materials absorb certain
    wavelengths
  • The shorter the wavelength the greater the energy
  • Ultraviolet light has more energy than infrared
    light
  • Crystalline silicon
  • Utilizes all the visible spectrum plus some
    infrared radiation
  • Heat vs. electrical energy
  • Light frequencies that is too high or too low for
    the semiconductor to absorb turn into heat energy
    instead of electrical energy

8
How PV Cells Work
9
Florida Solar Energy Center
10
Cross Section of PV Cell
http//en.wikipedia.org/wiki/Solar_cells
11
How Solar Cells are Made
12
Solar Cell Construction
  • Materials
  • Crystalline Silicon
  • Gallium Arsenide (more expensive)
  • Grown into large single-crystal ingots
  • Sawed into thin wafers
  • 2 wafers are bonded together (p-n junction)
  • Wafers grouped into panels or arrays

http//en.wikipedia.org/wiki/Solar_panel
13
Creating Silicon Wafers
14
Growing Silicon Ingots
Czochralski Process
http//en.wikipedia.org/wiki/Czochralski_process
15
Drawing a Silicon Ingot
http//www.answers.com/topic/silicon
16
Silicon Ingots Wafers
http//www.sumcosi.com/english/products/products2.
html
17
Creating PV Cells
18
Computer Chips on Wafer
http//d0server1.fnal.gov/projects/silicon/www/svx
19
Silicon Solar Cell
http//en.wikipedia.org/wiki/ImageSolar_cell.png
20
PV Cells have efficiencies approaching 21.5
Florida Solar Energy Center
21
Solar Modules and Arrays
22
Solar PV Systems
  • Cells are the building block of PV systems
  • Typically generate 1.5 - 3 watts of power
  • Modules or panels are made up of multiple cells
  • Arrays are made up of multiple modules
  • A typical array costs about 5 6/watt
  • Still need lots of other components to make this
    work
  • Typical systems cost about 8/watt

23
Florida Solar Energy Center
24
PV Modules have efficiencies approaching 17
Florida Solar Energy Center
25
Florida Solar Energy Center
26
Solar Panel
Solar panel by BP Solar at a German autobahn
bridge
http//en.wikipedia.org/wiki/Solar_panel
27
Florida Solar Energy Center
28
Florida Solar Energy Center
29
Florida Solar Energy Center
30
Florida Solar Energy Center
31
Solar PV Applications
32
Spacecraft
33
Recreational Use (Sailboat)
34
Remote Areas (Mexico)
A solar panel in Marla, Cirque de Mafate, Réunion
http//en.wikipedia.org/wiki/Solar_panel
35
Residential
http//www.californiasolarco.com/photos_html/grid_
tied/rootop_system/nevada-city-2-4.html
36
Commercial
Solar Centre at Baglan Energy Park in South
Wales
http//www.c-a-b.org.uk/projects/tech1.htm
37
Solar PV Efficiency
38
Solar Cell Efficiencies
  • Typical module efficiencies 12
  • Screen printed multi-crystalline solar cells
  • Efficiency range is 6-30
  • 6 for amorphous silicon-based PV cells
  • 20 for best commercial cells
  • 30 for multi-junction research cells
  • Typical power of 120W / m2
  • Mar/Sep equinox in full sun at equator

http//en.wikipedia.org/wiki/Solar_cells
39
Solar Panel Efficiency
  • 1 kW/m2 reaches the ground (sunny day)
  • 20 efficiency ? 200W/m2 electricity
  • Daylight weather in northern latitudes
  • 100 W/m2 in winter 250 W/m2 in summer
  • Or 20 to 50 W/m2 from solar cells
  • Value of electricity generated at 0.08/kWh
  • 0.10 / m2 / day OR 83,000 km2 / day

http//en.wikipedia.org/wiki/Solar_panel
40
Solar PV Facts Trends
41
World Largest PV Solar Plants
edit
http//en.wikipedia.org/wiki/Solar_panel
42
World Solar Power Production
http//en.wikipedia.org/wiki/Solar_panel
43
Solar Cell Production Volume
Sharp Corporation
http//sharp-world.com/solar/generation/images/gra
44
Solar PV Cell Research
45
Solar PV Components
  • Inverter
  • Converts DC power from solar array to AC for use
    in your home
  • Wiring
  • Connects the system components
  • Batteries
  • Used to store solar-produced electricity for
    nighttime or emergency use
  • Mainly used for remote sites that arent tied
    into the electrical grid
  • Charge controller
  • Prevents batteries from being over charged
  • Disconnect switches
  • Allows power from a PV system to be turned off
  • Electrical meter
  • Measures electrical production and use
  • Often runs backward if system is attached to the
    electrical grid

Total system cost 8.00 / watt
46
Stand Alone Solar PV System
47
Grid Connected Solar PV System
48
Connecting PV to the Grid
49
Net Metering
  • When your system produces more electricity than
    your home uses
  • electricity flows backward out to the grid
  • Meter runs backward and you get credit for the
    electricity you sell to the utility

50
Florida Solar Energy Center
51
Florida Solar Energy Center
52
Siting Designing Solar PV
53
Solar PV Dependencies
  • Location, Location, Location !
  • Latitude
  • Lower latitudes better than higher latitudes
  • Weather
  • Clear sunny skies better than cloudy skies
  • Temperature not important
  • Direction solar arrays face
  • South preferred, east and west acceptable
  • Absence of shade
  • Trees, Flatirons, etc.

54
Solar PV Design Key Factors
  • Location
  • How much solar radiation does the system receive?
  • DC rating
  • How big is the system

55
Solar PV Design Module
  • Module Efficiency
  • How efficiently does the solar system convert
    solar radiation into DC power
  • Best retail systems approaching 17
  • Holy Grail of solar PV research
  • DC to AC derate factor
  • How efficient is the system converting DC to AC
    power

56
Solar PV Array Design
  • Array Flat Panel
  • Remains in a constant fixed position
  • Array tilt (equal to latitude best)
  • Increase solar radiation by 10-20
    compared to 0 tilt
  • Sunnier locations benefit more
  • Array azimuth (180 best)
  • Directly south

57
Solar PV Array Tracking
  • Array 1-axis tracking
  • Tracks sun across the sky during each day
  • Stays at a constant tilt
  • Increase solar radiation by 25-30 compared to no
    tracking
  • Sunnier locations benefit more
  • Array 2-axis tracking
  • Tracks sun across the sky during each day
  • Adjusts tilt more in winter, less in summer
  • Increase solar radiation by 33-38
  • Sunnier locations benefit more

58
PV Design Website
  • National Renewable Energy Lab
  • PVWATTS
  • http//rredc.nrel.gov/solar/calculators/PVWATTS/ve
    rsion2/
  • Examples
  • Portland (97229)
  • Phoenix (85034)
  • Boulder (80309)

59
Solar PV Economics
60
Solar PV Energy Payback
  • Expected lifetime of 40 years
  • Payback of 1-30 years
  • Typically lt 5 years
  • Solar cells 6-30 energy required to make them

http//en.wikipedia.org/wiki/Solar_cells
61
Cost Analysis
  • US retail module price 5.00 / W (2005)
  • Installations costs 3.50 / W (2005)
  • Cost for a 4 kW system 17,000 (2006)
  • Without subsidies
  • Typical payback period is 24 years
  • Honda 4 kW system 12,500 (2007)
  • With subsidies
  • Payback is 12 years

http//en.wikipedia.org/wiki/Solar_cells
62
Economic Example 1/3
  • 4000 watt system _at_ 40o fixed tilt
  • 32,000 initial cost
  • 4000 watt (4 kW) system is about 23.5 m2
  • Assume 5.5 kWh / m2/day
  • 23.5 x 5.5 129.25 DC kWh/day
  • hitting the solar modules

63
Economic Example 2/3
  • Module Efficiency 17
  • 129.25 kWh/day x 0.17 21.97 DC kWh/day
  • Derate factor 77
  • Takes into account inefficiencies in the DC/AC
    conversion and internal module components
  • 21.97 DC kWh/day x 0.77 16.92 AC kWh/day
  • Output 17 kWh / day

64
Economic Example 3/3
  • Pay 32,000, save 555/year
  • 16.92 kWh/day x 0.09/kWh x 365 days/year
  • 1.7 return
  • Over 20 years _at_ 6
  • Cost of Energy 0.452/kWh
  • Compared to 0.09/kWh from Xcel
  • EXPENSIVE!

65
Solar PV Policy
66
CO Amend. 37 Solar Provision
  • 4.50 rebate/watt up to 10 kW
  • Combination rebate/REC for larger systems
  • REC Renewable Energy Credits
  • Funded by a 0.63/month surcharge on all Xcel
    customer bills
  • 20 million/year program for 10 years

67
CO Amend. 37 Solar Provision
  • On-site solar requirement
  • 2007 2010 0.06 of a retail electricity sales
  • 2011 2014 0.12 of a retail electricity sales
  • 2015 On 0.2 of a retail electricity sales
  • Focus on Xcel
  • 44,000 kW of on-site solar by 2015
  • 1500 to 2000 new on-site solar installations
  • Depending on average size
  • 352 million in PV solar installation sales
  • 200 million in rebates

68
Federal Tax Credit
  • 30 tax credit
  • Max of 2,000 for residential installations
  • No maximum for businesses

69
CO Cost Analysis
  • 4,000 watt system
  • 32,000 initial cost
  • 18,000 Amendment 37 rebate
  • 4000 x 4.50
  • 2,000 Federal Tax Credit
  • (32,000 - 18,000) x 0.30 4,200
  • However, maximum of 2,000
  • After rebate/tax credit cost
  • 32,000 - 18,000 - 2,000 12,000

70
Return on Investment
  • For 12,000 you can save 555/year
  • 4.6 return
  • Over 20 years _at_ 6
  • Cost of Energy 0.169/kWh
  • Compared to 0.09/kWh from Xcel
  • Still EXPENSIVE!

71
Solar PV Cell Research
72
Emerging PV Techologies
  • Cells made from gallium arsenide
  • molecular beam epitaxy
  • 35 efficiencies have been achieved
  • Non-silicon panels using carbon nanotubes
  • Quantum dots embedded in special plastics
  • May achieve 30 efficiencies in time
  • Polymer (organic plastics) solar cells
  • Suffer rapid degradation to date

http//en.wikipedia.org/wiki/Solar_cells
73
Thin Film Solar Cells
  • Use less than 1 of silicon required for wafers
  • Silicon vapor deposited on a glass substrate
  • Amorphous crystalline structure
  • Many small crystals vs. one large crystal

http//en.wikipedia.org/wiki/Solar_cells
74
Florida Solar Energy Center
75
Flexible PV Cells
http//www.princeton.edu/chm333/2002/spring/Solar
Cells/potential20images/flexible_pv_cell.jpg
76
http//en.wikipedia.org/wiki/ImageNrel_best_resea
77
Benefits/Costs of Solar PV
  • Reduces pollution
  • Stabilizes electricity costs
  • Lessens dependence on fossil fuels
  • Increases self-reliance
  • Can size for small, on-site installations
  • Not grid dependent
  • Currently expensive

78
Solar Thermal Energy
79
Solar Thermal Collectors
  • Focus the sun to create to create heat
  • Boil water
  • Heat liquid metals
  • Use heated fluid to turn a turbine
  • Generate electricity

80
Solar Thermal Dish Collector
http//www.eia.doe.gov/cneaf/solar.renewables/page
/solarthermal/solarthermal.html
81
Solar Thermal Dish Schematic
82
(No Transcript)
83
Solar Power Towers
http//solstice.crest.org/renewables/re-kiosk/sola
r/solar-thermal/case-studies/central-receiver.shtm
l
84
Solar Trough Scheme
http//solarbridge.org/pedestrians.html
85
Parabolic Trough Cross-Section
http//www.irishsolar.com/howdoes/how_does_1.htm
86
(No Transcript)
87
(No Transcript)
88
(No Transcript)
89
(No Transcript)
90
(No Transcript)
91
(No Transcript)
92
(No Transcript)
93
(No Transcript)
94
Solar Thermal Collector Trends
http//www.eia.doe.gov/cneaf/solar.renewables/page
/solarthermal/solarthermal.html
95
Next weekGeothermal Energy
Write a Comment
User Comments (0)
About PowerShow.com
