Text Mining

1
Text Mining

• Mike Evans, Doug Svendsen, Stephanie Huls, Matt
  Lietzke

2
Outline

• Text mining mines natural language text
• Preprocessing makes natural text minable
• Many techniques used in text mining
• We will use classification
• SIAM Competition held in Twin Cities
• We will create a program and compare results

3
A Little Bit About Text Mining

• The non-trivial extraction of previously
  unknown, interesting facts from a collection of
  texts.
• Key element
• Linking together of extracted information
• Text Mining vs. Data Mining
• Natural language text vs. structured database of
  facts

4
Origination

• 1950s
• Attempts to understand and model the information
  processing capabilities of the human brain
• Original approach
• analyzed a natural language text at the level of
  individual sentences
• Objective
• create a semantic representation of a sentence in
  the form of structured relations between
  important words comprising this sentence

5
To solve objective

• Pre-developed linguistic molds were tried with
  the sentence and its components
• Match
• corresponding semantic construction was
  associated with the sentence
• Proved to be a good first guidance for
  understanding the meaning of a text

6
Problems

• Too many different pre-developed molds were
  needed to build a set for analyzing different
  types of sentences
• List of exceptional constructions in this
  approach quickly grows prohibitively large
• Works well only for a limited subset of natural
  language texts

7
Not Information Extraction

• Information extraction is
• extracting names, addresses, etc.
• Text mining is
• Finding new pieces of data
• Turn information extraction into text mining
• Find relationships between extracted data
• Human analysis
• Ex. Wireless Technology

8
Applications

• Biosciences
• Links in different subsets of literature to form
  hypothesis
• Ex. Don Swanson
• Genomics
• Ex. Proteins
• Hospital charts
• Improve patient outcomes
• Shorten hospital stays

9
Limitations/Problems

• Programs cannot fully interpret text like the
  human mind
• Needed information is not in textual format
• Conversations
• Radio shows
• Television
• Noise
• Spelling errors
• Abbreviations
• Acronyms

10
Text Characteristics Lead to Problems

• Dimensionality
• Each word/phrase is considered a dimension
• Dependency
• Relevant information in form of complex
  conjunction of words/phrases
• Informality
• Emails R u available

11
Ambiguity

• Word ambiguity
• Pronouns
• He/she
• Synonyms
• Buy/purchase
• Multiple meanings
• Bat mammal/baseball bat
• Semantic ambiguity
• The chicken is ready to eat
• Police squad help dog bite victim
• We saw the Eiffel Tower flying from London to
  Paris
• The police were ordered to stop drinking after
  midnight

12
Historical Text Mining

• Most text mining tools focus on present-day
  English
• Language of text depends upon
• Where When it was created
• Broken text flows

13
Goals

• Improved document classification
• Automatic semantic annotation of documents
• Improved search by semantics and concepts
• Improved clustering of documents by concept
• Summarization

14
Problems with Text Mining

• What it is not
• Data retrieval
• Computational linguistics
• Computers do not understand natural speech and
  text
• Most writing consists of
• Non-technical words
• Slang
• Abbreviations

15
Problems with Text Mining

• Lots of trivial words in text
• Common words unique to subject
• Not helpful
• Verbs, Nouns not in simple forms
• Hard to put value on words
• Not all problems need to be fixed

16
Preprocessing

• Get rid of useless words (conjunctions, articles,
  prepositions)
• Turn all words into basic form (just take stems,
  not prefix or suffix)
• Makes it language specific
• Remove words that are common among all records

17
Preprocessing

• Filtering
• Remove predefined words
• Dictionary of bad words
• Remove extremely common words
• Lemmatization
• Change verbs to infinite
• Nouns to singular
• Difficult and time consuming

18
Preprocessing

• Stemming
• Simpler version of Lemmatization
• Tries to make basic words
• Ex.Takes s and ing off words
• Index Term Selection
• Selects words based on entropy
• Frequent words low entropy

19
Preprocessing

• Other advanced methods commonly used
• Part-of-speech tagging
• Tags words as noun, verb, etc
• Text chunking
• Evaluates chunks of sentences
• Parsing
• Accounts for nearby words in sentences by parsing
  into a tree

20
Competition

• SIAM Text Mining Competition
• SIAM Society for Industrial and Applied
  Mathematics
• Conference in Twin Cities April 28th
• Competition already done
• SIAM Provides
• Preprocessed Text Dataset
• Program evaluator
• Winners results

21
Competition Goal

• Dataset
• Aviation Safety Reports
• No labels given
• Problem
• Document Classification
• Determine problem(s) in document
• What kind of problem
• Report confidence/precision

22
Project Goal

• Use provided dataset
• Possibly try more preprocessing
• Try competition
• Use classification algorithms
• Need to identify problems
• Need to classify documents with problem(s)
• Compare results

23
Dataset

• Aviation Safety Reports
• Already preprocessed
• 21,519 reports with 1 report per record
• All reports in one file
• Standard text mining format
• Average document is over a paragraph long

24
Dataset Example

• 1AFTER takeoff ON runway _ A loudnoise WAS hear
  come FROM FRONT AREA OF aircraft.FOR A WHILE I
  AND CREW THOUGHT IT WAS THE AIR drive generate
  THAT deploy FROM right NOSE OF aircraft.UPON
  FURTHER troubleshoot FOUND THAT THE AIR drive
  generate COULD NOT HAVE deploy DUE TO ABSENCE OF
  icon AND message ON THE engineindicationandcrewale
  rtingsystem system.WE immediate return TO THE
  airport FOR AN UNEVENTFUL land.FURTHER examine AT
  THE GATE show THE OXYGEN accesspanel pop OPEN
  AFTER takeoff cause THE NOISE.PRIOR TO flight THE
  normalpreflight show NO AJAR OR OPEN panel ON THE
  aircraft.moderateturbulence WAS encounter AFTER
  takeoffdue TO STRONG crosswind AND
  lowlevelwindshearadvisories IN EFFECT.
• 2taxi OFF THE parkingramp THE brake system fail
  TO STOP THE aircraft.LATER determine TO BE A BAD
  TRUNION SWITCH IN THE right maingear NEITHER
  pilot HAD ani control OVER THE aircraft speed AND
  DUE TO frequencycongestion WE COULD NOT ALERT
  ground OF OUR problem.BECAUSE OF THIS WE WERE
  UNABLE TO HOLD SHORT OF THE control PORTION OF
  THE airport.THE INCURSION ON THE taxiway DID NOT
  PUT US IN DANGER OF collide WE DID BLOCK AN
  intersect AFTER WE coast TO A STOP.ground WAS
  immediate notify AND COMPANY WAS call TO GET A
  TUG AND BRING US BACK TO THE RAMP.I HAVE NEVER
  see train TO DEAL WITH brakefailure ON THE ground
  IN AN aircraft BUT I SURE WOULD LIKE TO.

25
Problems with Dataset

• Words run together - generalaviation
• Possibly introduced by SIAM for competition
• Noise
• Label suggestions
• Too common for typos
• Abbreviations
• Missing spaces
• Overall, text mining is flexible

26
Preprocessing Our Dataset

• PLADS SIAM
• Performed stemming and acronym expansion
• Removed non-informative terms
• Place names, etc
• With our goal, place names are not necessary
• Additional preprocessing
• Fix spaces by periods

27
Pre Post Preprocessing

• Preprocessing
• After takeoff on runway Zeta a loud noise was
  heard coming from the front area of hanger Alpha.
• Post-processing
• 1AFTER takeoff ON runway _ A loudnoise WAS hear
  come FROM FRONT AREA OF hanger _.

28
Classification

• Classification is used to generate class labels
• For text mining, it is used to classify documents
• For our dataset, we could classify the type of
  problem that submission was about

29
Our Data Set and Classification

• Some of the classification we could use
• Service problems, Time delay problems
• Part Problems
• Personnel Problems
• Etc.
• Part of the dataset we are working with is to
  determine all of the class labels

30
Using ARM to generate Keywords

• Using Apriori, we can generate our keywords from
  our dataset
• Modify The algorithm with highly preprocessed
  data.
• Filter our data for frequent items (keywords)
• (augmented with exclusion list)
• Generate Frequent Item sets and rule generation.
• Use rules generated to draw relational keywords
  and frequency

31
ARM Applied to our date set

• Relationships
• Noise implies Engine
• Runway implies Landing Gear

32
How to use Classification

• Steps to proper classification use
• Define Keywords List
• Use Information Gain Equation
• This equation determines how effective a word is
  based on frequency in known documents
• Use Match Files Technique
• This techniques takes a list of words the user
  has supplied or based on desired search terms or
  thesaurus and dictionary entries
• Compare list on data to redefine keywords

33
Information Gain Equation Explained

• Here p(Lc) is the fraction of training documents
  with classes L1 and L2, p(tj1) and p(tj0) is
  the number of documents with / without term tj
  and p(Lcjtjm) is the conditional probability of
  classes L1 and L2 if term tj is contained in the
  document or is missing. It measures how useful tj
  is for predicting L1 from an information-theoretic
  point of view. We may determine IG(tj) for all
  terms and remove those with very low information
  gain from the dictionary

34
Keyword set for our Dataset

• We can create different keywords for different
  types of problems
• E.g. Part Problem keywords
• Emergency Landing
• Landing Gear
• Noises
• Engine
• Wings
• Pressure Failure
• Service problem, Time delay problems
• Delay
• Time
• Emergency Landing
• Personal Problems Keywords
• Security Personnel
• Illegal
• Fight

35
How to use Classification

• Use appropriate algorithm
• Nearest Neighbor Classifier
• Take unknown document and plot against know
  documents
• Compute the distance from nearest neighbor, based
  on k number of neighbors
• Based on how many of different classes there are,
  give new document class based on neighbors
• Decision trees
• You create master collection of words in a
  document.
• Next, you create the tree based on presence of
  keywords (e.g. This document does not have the
  word sport in it, nor football, basketball, ect.)
• Based on that decision, you continue down the
  tree, making decisions based on the word of the
  node

36
Application of Algorithm applied to our Data Set

• An FP tree can be used to split on keywords list
• Example Personnel Problem class label
• Keywords Fight, Cabin Crew Assistance, ect.

37
Application of Algorithm applied to our Data Set

• A Nearest Neighbor can be used to plot messages
  against each other with a k variable
• Example
• Based on keywords, the distance of our record
  from the remaining classification results by
  majority vote is 3 votes for equipment problem
• (picture from Imad Rahal Slides)

38
Issues with classification

• Problems with classification
• Over fitting
• Under fitting
• Keyword Cross listing

39
Benefits of Classification

• The information that gain be gleaned from
  Classification is directly applicable to airlines
• The Classes established can assists with
  situation deployment, or continuing customer care

40
Information Extraction

• Extract meaningful information from text
• Identify and classify elements
• Sam went bowling with Tommy in St. Cloud at
  900pm
• People Sam and Tommy
• Place St. Cloud
• Time 900pm
• Basis for many text mining technologies

41
Application of Information Extraction

• JUST PRIOR TO rotate A DEER RAN ONTO THE runway.I
  rotate AND hear A SOUND AND feel AS IF WE MIGHT
  HAVE HIT THE DEER.THE GEAR retract normal.I
  decide TO CONTINUE TO sfo airport figure THAT IF
  WE HAD BLOWN A TIRE OR sustain DAMAGE TO THE GEAR
  ETC THAT IT WOULD BE BETTER TO LAND AT sfo
  airport.
• Place slo, runway
• Thing deer, sound, damage
• Plane element gear, tire
• Actions Ran, rotate, hit, blown, land

42
More In-depth Extraction

• Base weight of word on
• Number of documents it appears in
• Number of times it appears in a document
• High weight
• Appears many times in a document
• Does not appear in many documents
• Low weight to words appearing in many documents.
• Potentially identify important topics in aviation
  dataset.
• Landing gear
• Flaps
• Fog
• Deer

43
Summarization

• Goal Reduced size and detail of document while
  retaining main points.
• Software lacks human ability to understand
  concepts and explain them.
• Solution
• Sentence extraction based on
• Weight
• Key phrases
• Headings
• Problem Must still be evaluated by a human.

44
Categorization

• Treat input as a bag of words
• Count words as the appear.
• Counts are used to identify main topics.
• Use a thesaurus to identify relationships.
• Rank documents based upon frequency of words
  pertaining to a topic.
• Lead to organization based upon problem area,
  place, malfunction, people, etc.

45
Concept Linkage

• Link related documents
• Find links between topics
• Useful in biomedicine
• Find links between symptoms, diseases and
  treatments
• Useful in aviation safety reports
• Find links between symptoms and problems.

46
Clustering

• Goal
• 1. Documents in a cluster are more similar to one
  another.
• 2. Documents in separate clusters are less
  similar.
• Creates vectors for documents based upon how they
  fit into different categories
• Weights are given for how well documents fit into
  a cluster.
• Similar documents can then be found based upon
  their proximities.
• www.clusty.com

47
Conclusion

• Text mining mines natural language text
• It requires preprocessing to eliminate worthless
  words
• Our project uses classification on Airline Safety
  Reports
• Identify problems and compare to SIAM competition
  results

48
Resources

• Fan, Weiguo, Linda Wallace, Stephanie Rich, and
  Zhongju Zhang. Tapping the Power of Text
  Mining. Communictions of the ACM 49.9 (2006)
  76 - 82
• Arora, Ritu, and Purushotham Bangalore. "Text
  Mining Classification \ Clustering of Articles
  Related to Sports." ACM-SE 43 Proceedings of the
  43rd Annual Southeast Regional Conference.
  Kennesaw, Georgia, .
• Hotho, Andreas, Andreas Nürnberger, and Gerhard
  Paaß. "A Brief Survey of Text Mining." LDV Forum
  - GLDV Journal for Computational Linguistics and
  Language Technology 20.1 (2005) 19-62.
• Raymond Y.K. Lau. Context-sensitive text mining
  and belief revision for intelligent information
  retrieval on the web. Centre for Information
  Technology Innovation, Faculty of Information
  Technology, Queensland University of Technology,
  GPO Box 2434, Brisbane, Qld 4001, Australia
• Larsen, Bjornar, and Chinatsu Aone. "Fast and
  Effective Text Mining using Linear-Time Document
  Clustering." KDD '99 Proceedings of the Fifth
  ACM SIGKDD International Conference on Knowledge
  Discovery and Data Mining. San Diego, California,
  United States, .
• Introduction to Data Mining by PN Tan, M
  Steinbach and V Kumar (ISBN 0-321-32136-7)
