Cardiac Biomarkers: Past, Present and Future

1
Cardiac BiomarkersPast, Present and Future

• Jeff Sparling, M.D.
• University of Oklahoma Department of Internal
  Medicine

2
Outline

• Overview
• History of cardiac clinical biochemistry
• Current techniques
• Markers of Cardiac Necrosis
• Natriuretic Peptides
• Prognostic Markers and Risk Stratification
• Future research and development
• Questions

3
History

• 1950s Clinical reports that transaminases
  released from dying myocytes could be detected
  via laboratory testing, aiding in the diagnosis
  of myocardial infarction1
• The race to define clinical markers to aid in the
  diagnosis, prognosis, and risk stratification of
  patients with potential cardiovascular disease
  begins
• 1 Circulation 108250-252

4
History

• Initial serum markers included AST, LDH, total CK
  and a-hydroxybutyrate
• These enzymes are all released in varying amounts
  by dying myocytes
• Lack of sensitivity and specificity for cardiac
  muscle necrosis fuels continued research

5
History CK and Isoenzymes

• CK known to be released during muscle necrosis
  (including cardiac)
• Quantitative assays were cumbersome and difficult
  to perform
• Total CK designed as a fast, reproducible
  spectrophotometric assay in the late 1960s

6
History CK and Isoenzymes

• CK isoenzymes are subsequently described
• MM, MB and BB fractions
• 1970s MB fraction noted to be elevated in and
  highly specific for acute MI1
• 1 Clinical Chemistry 50(11) 2205-2213

7
History CK and Isoenzymes

• CKMB now measured via a highly sensitive
  monoclonal antibody assay
• It was felt for a time that quantitative CKMB
  determination could be used to enzymatically
  measure the size of an infarct
• This has been complicated by release of
  additional enzymes during reperfusion

8
History CK and Isoenzymes

• As CK-MB assays become more sensitive,
  researchers come to the paradoxical realization
  that it too is not totally cardiac specific
• The MB fraction is determined to be expressed in
  skeletal muscle, particularly during the process
  of muscle regeneration
• The search for cardiac specificity continues
• Clinical Chemistry 50(11) 2205-2213

9
History

• Research turns towards isolation of and
  development of assays for sarcomeric proteins
• Myosin light chains were originally isolated and
  then subsequently abandoned because of
  specificity issues

10
History Troponin

• Troponin I first described as a biomarker
  specific for AMI in 19871 Troponin T in 19892
• Now the biochemical gold standard for the
  diagnosis of acute myocardial infarction via
  consensus of ESC/ACC
• 1 Am Heart J 113 1333-44
• 2 J Mol Cell Cardiol 21 1349-53

11
History

• This work encourages development of other
  clinical assays for diagnosis and prognosis of a
  wide spectrum of cardiac diseases
• Notable examples
• BNP (FDA approved in November 2000 for diagnosis
  of CHF)
• C-reactive protein

12
Markers of Cardiac Necrosis
13
Markers of Cardiac Necrosis

• Cardiac biomarkers an integral part of the most
  recent joint ACC/ESC consensus statement on the
  definition of acute or recent MI

14
Markers of Cardiac Necrosis

• Typical rise and gradual fall (troponin) or more
  rapid rise and fall (CK-MB) of biochemical
  markers of myocardial necrosis with at least (1)
  of the following
• Ischemic symptoms
• Development of pathologic Q waves
• ST segment elevation or depression
• Coronary artery intervention

15
Markers of Cardiac Necrosis
16
Troponins

• Troponin T (cTnT) and troponin I (cTnI) control
  the calcium-mediated interaction of actin and
  myosin
• cTnI completely specific for the heart
• cTnT released in small amounts by skeletal
  muscles, though clinical assays do not detect
  skeletal TnT

17
Troponins

• The preferred biomarker for the diagnosis of
  acute MI
• Measurement carries a Class I recommendation from
  the ACC/AHA task force on diagnosis of AMI
• As with other biomarkers, do not wait on
  measurement of troponins in the setting of ST
  elevation

18
Troponins
19
Troponins

• 4-6 hours to rise post-infarct, similar to CKMB
• 6-9 hours to detect pathologic elevations in all
  patients with infarct
• Elevated levels can persist in blood for weeks
  the cardiac specificity of troponins thus make
  them the ideal marker for retrospective diagnosis
  of infarction

20
Troponins

• Elevated serum levels are an independent
  predictor of prognosis, morbidity and mortality
• Meta-analysis of 21 studies involving 20,000
  patients with ACS revealed that those with
  elevated serum troponin had 3x risk of cardiac
  death or reinfarction at 30 days1
• 1 Am J Heart (140) 917

21
Troponins GUSTO IV ACS

• Underscored the importance of the degree of
  troponin elevation
• 7000 patients stratified into quartiles based on
  degree of cTnT elevation
• 30-day mortality rate increased from 1.1 to 7.4
  over the first to fourth quartiles

22
CK-MB

• High specificity for cardiac tissue
• The preferred marker for cardiac injury for many
  years
• Begins to rise 4-6 hours after infarction but can
  take up to 12 hours to become elevated in all
  patients with infarction
• Elevations return to baseline within 36-48 hours,
  in contrast to troponins

23
CK and CK-MB
24
CK-MB Shortcomings

• Concomitant skeletal muscle damage can confuse
  the issue of diagnosis
• CPR and defibrillation
• Cardiac and non-cardiac procedures
• Blunt chest trauma
• Cocaine abuse

25
CKCK-MB Ratio

• Proposed to improve specificity for use in
  diagnosis of AMI
• Ratios 2.5-5 have been proposed
• Significantly reduces sensitivity in patients
  with both skeletal muscle and cardiac injury
• Also known to be misleading in the setting of
  hypothyroidism, renal failure, and chronic
  skeletal muscle diseases

26
CK-MB and Reinfarction

• CK-MB is the marker of choice for diagnosis of
  reinfarction after STEMI, PCI, or CABG because of
  rapid washout
• The ACC/AHA definition of re-infarction includes
  both
• re-elevation of CK-MB
• supporting criteria including ECG changes, pain
  or hemodynamic instability

27
Myoglobin

• Heme protein rapidly released from damaged muscle
• Elevations can be seen as early as one hour
  post-infarct
• Much less cardiac specific meant to be used as a
  marker protein for early diagnosis in conjunction
  with troponins

28
Markers of Cardiac Necrosis in Chronic Kidney
Disease
29
CKD

• CAD is highly prevalent in patients with CKD,
  making interpretation of cardiac markers
  important
• Despite this, interpretation of elevated cardiac
  enzymes in patients with renal failure is often
  confusing at best

30
CKD and Elevated Troponins

• Elevations in serum troponin often observed in
  asymptomatic patients with chronic kidney disease
• Even using the most conservative cutoff values, a
  disproportionate number of patients still have
  elevated troponins
• The mechanism for this is unclear

31
CKD and Elevated Troponins

• In a 2002 study in Circulation, 733 asymptomatic
  patients with ESRD were evaluated
• Using conservative cutoff values,
• 82 had elevated cTnT
• 6 had elevated cTnI
• Circulation 106 2941

32
CKD and Elevated Troponins

• So, are these numbers meaningless, even in a
  patient population that is at such high risk?

33
CKD and Elevated Troponins

• They provide important information with regards
  to prognosis
• Serial measurements are still of value in the
  patient with chest pain

34
CKD and Elevated Troponins

• Of those 733 asymptomatic patients on HD, 2-year
  mortality rates were 52 in those with cTnI 0.1
  µg/dL
• These data have been corroborated in a number of
  smaller studies in similar populations
• Circulation 106 2941

35
CKD and Elevated Troponins

• Serial measurements are helpful in the setting of
  possible ACS
• cTnI appears to be much less likely to be
  associated with false positives in the CKD
  population than cTnT, making it the preferred
  biomarker in this setting

36
Natriuretic Peptides
37
Natriuretic Peptides

• Present in two forms, atrial (ANP) and brain
  (BNP)
• BNP is used clinically because it exists in a
  much wider range of concentrations in varying
  clinical settings, making it easier to measure

38
Natriuretic Peptides

• Both ANP and BNP have diuretic, natriuretic and
  hypotensive effects
• Both inhibit the renin-angiotensin system and
  renal sympathetic activity
• BNP is released from the cardiac ventricles in
  response to volume expansion and wall stress

39
BNP Assay

• Approved by the FDA for diagnosis of cardiac
  causes of dysnpea
• Currently measured via a rapid, bedside
  immunofluorescence assay taking 10 minutes
• Especially useful in ruling out heart failure as
  a cause of dyspnea given its excellent negative
  predictive value

40
BNP

• Came to market in 2000 based on data from many
  studies, primarily the Breathing Not Properly
  (BNP) study
• Prospective study of 1586 patients presenting to
  the ER with acute dyspnea
• The predictive value of BNP much superior to
  previous standards including radiographic,
  clinical exam, or Framingham Criteria

41
Breathing Not Properly

• Important information about BNP from this study
  included
• Reduced the time and resources needed to diagnose
  heart failure
• BNP plasma concentration directly correlated with
  NYHA classification
• Heart failure due to diastolic dysfunction could
  be diagnosed, though not differentiated from
  systolic dysfunction

42
Breathing Not ProperlyBNP useful in screening?

• The utility of BNP as a mass screening tool for
  LV dysfunction in asymptomatic persons was
  negligible

43
BNP

• BNP has also shown utility as a prognostic marker
  in acute coronary syndrome
• It is associated with increased risk of death at
  10 months as concentration at 40 hours
  post-infarct increased
• Also associated with increased risk for new or
  recurrent MI

44
BNP and ACS Risk Assessment

• PRISM 1,791 patients with non-ST elevation ACS1
• NT-proBNP levels that were elevated from baseline
  at 48 and 72 hours associated with higher event
  rates at 30 days
• Patients with negative Troponin T and elevated
  NT-proBNP levels had risk comparable to
  TnT-positive patients
• 1Circulation 110 3206-3212

45
BNP and Chronic Kidney Disease

• I should be able to cover this topic completely
  in 1 or 2 slides without causing any controversy,
  right?

46

• Wrong.

47
Prognostic Markers and Markers of Risk
Stratification
48
Prognostic Markers and Markers of Risk
Stratification

• C-reactive protein
• Myeloperoxidase
• Homocysteine
• Glomerular filtration rate

49
C-Reactive Protein

• Multiple roles in cardiovascular disease have
  been examined
• Screening for cardiovascular risk in otherwise
  healthy men and women
• Predictive value of CRP levels for disease
  severity in pre-existing CAD
• Prognostic value in ACS

50
C-Reactive Protein

• Pentameric structure consisting of five 23-kDa
  identical subunits
• Produced primarily in hepatocytes
• Plasma levels can increase rapidly to 1000x
  baseline levels in response to acute inflammation

• Positive acute phase reactant

51
C-Reactive Protein

• Binds to multiple ligands, including many found
  in bacterial cell walls
• Once ligand-bound, CRP can
• Activate the classical compliment pathway
• Stimulate phagocytosis
• Bind to immunoglobulin receptors

52
C-Reactive ProteinRisk Factor or Risk Marker?

• CRP previously known to be a marker of high risk
  in cardiovascular disease
• More recent data may implicate CRP as an actual
  mediator of atherogenesis
• Multiple hypotheses for the mechanism of
  CRP-mediated atherogenesis
• Endothelial dysfunction via ? NO synthesis
• ?LDL deposition in plaque by CRP-stimulated
  macrophages

53
CRP and CV Risk

• Elevated levels predictive of
• Long-term risk of first MI
• Ischemic stroke
• PVD
• All-cause mortality
• This relationship persists even when data is
  adjusted for classic CV risk factors (age,
  tobacco, lipid levels, DM, and HTN)

54
Limitations to CRP in Screening

• Low specificity
• What do you do with an elevated CRP?
• No evidence that lowering CRP levels decreases CV
  risk
• Some medications (statins and TZDs) do lower CRP
  levels unclear what the implication is

55
CRP and Existing CAD

• Unclear of the role of CRP in stable CAD acute
  phase response not present in stable angina
• Predictive of worse short- and long-term
  prognosis in non-ST elevation ACS
• Possibly some correlation with poor outcomes
  post-CABG and post-PCI

56
CRP ACC/AHA Recommendations

• Not useful as a public health measure screening
  the entire adult population should be avoided
• It is considered the inflammatory marker most
  useful in clinical practice
• Useful in guiding further evaluation in
  intermediate risk patients (10-20 risk of
  significant CAD in 10 years)

57
CRP ACC/AHA Recommendations

• Should not determine the application of secondary
  prevention measures
• Serial measurements should not be used to gauge
  efficacy of treatment
• Measure hs-CRP serum levels in an outpatient
  setting twice (at least two weeks apart) and
  average the two levels

58
Myeloperoxidase

• Released by activated leukocytes at elevated
  levels in vulnerable plaques
• Predicts cardiac risk independently of other
  markers of inflammation
• May be useful in triage of ACS (levels elevate in
  the 1st two hours)
• Also identifies patients at increased risk of CV
  event in the 6 months following a negative
  troponin
• NEJM 349 1595-1604

59
Homocysteine

• Intermediary amino acid formed by the conversion
  of methionine to cysteine
• Moderate hyperhomocysteinemia occurs in 5-7 of
  the population
• Recognized as an independent risk factor for the
  development of atherosclerotic vascular disease
  and venous thrombosis
• Can result from genetic defects, drugs, vitamin
  deficiencies, or smoking

60
Homocysteine

• Homocysteine implicated directly in vascular
  injury including
• Intimal thickening
• Disruption of elastic lamina
• Smooth muscle hypertrophy
• Platelet aggregation
• Vascular injury induced by leukocyte recruitment,
  foam cell formation, and inhibition of NO
  synthesis

61
Homocysteine

• Elevated levels appear to be an independent risk
  factor, though less important than the classic CV
  risk factors
• Screening recommended in patients with premature
  CV disease (or unexplained DVT) and absence of
  other risk factors
• Treatment includes supplementation with folate,
  B6 and B12

62
Glomerular Filtration Rate

• The relationship between chronic kidney disease
  and cardiovascular risk is longstanding
• Is this the result of multiple comorbid
  conditions (such as diabetes and hypertension),
  or is there an independent relationship?

63
Glomerular Filtration Rate

• Recent studies have sought to identify whether
  creatinine clearance itself is inversely related
  to increased cardiovascular risk, independent of
  comorbid conditions

64
Glomerular Filtration Rate

• Go, et al performed a cohort analysis of 1.12
  million adults in California with CKD that were
  not yet dialysis-dependent
• Their hypothesis was that GFR was an independent
  predictor of cardiovascular morbidity and
  mortality
• They noted a strong independent association
  between the two
• NEJM 351 1296-1305

65
Glomerular Filtration Rate
66
Glomerular Filtration Rate

• Reduced GFR has been associated with
• Increased inflammatory factors
• Abnormal lipoprotein levels
• Elevated plasma homocysteine
• Anemia
• Arterial stiffness
• Endothelial dysfunction

67
So much information!

• What does it all mean?!?

68
The Future of Cardiac Biomarkers

• Many experts are advocating the move towards a
  multimarker strategy for the purposes of
  diagnosis, prognosis, and treatment design
• As the pathophysiology of ACS is heterogeneous,
  so must be the diagnostic strategies

69
Circulation 108 250-252
70
2005 OKC Heart Walk

• Please donate! This years walk is April 30,
  2005
• Contact Jeff, Beau, Soni, or Ross for details
• Any amount helps!

71
Any Questions?
