Urban Meteorology

1
Urban Meteorology
Rick Peltier Sangil Lee
Chris Hennigan Ehsan Arhami
2
The Urban Heat Island
3
Urban Heat Island

• The increased air temperatures in urban areas as
  contrasted to the cooler surrounding rural areas.

Source Lawrence Berkeley National Lab.
4
Rapid Urbanization

• Lack of surface water (soil water) and
  vegetation.
• Low short-wave reflectivity (albedo).
• increased heat release.

Source EPA Rice University
5
Mesoscale circulation and convection
Gradient wind condition
Stagnant condition
Source NASA Global Hydrology and Climate Center
6
Mesoscale circulation and convection
Convective precipitation associated with the
excess heat.
Source NASA Global Hydrology and Climate Center
7
Mesoscale circulation and convection

• Mean monthly rainfall during the warmer season
  (May Sept.) from 19982000.

• Increased precipitation (7 50 greater).
• Maximum rainfall rates (48 116 greater)
  downwind of major cities.

Source NASA Global Hydrology and Climate Center
8
Air Quality Issues
Urban heat islands are not only uncomfortably
hot, they are also smoggier. (i.e., the incidence
of smog increases by 3 per F above 70F.)
Source Heat Island Group, Lawrence Berkeley
National Lab. NASA Global Hydrology and Climate
Center
9
Urban Pollution Dispersion

• Topographical Effects of Urban Area

Picture from corbis.com
10
Overview

• Effect of Topography on Flow
• Urban Boundary Layer
• Urban Canopy

11
Geographically Modified Flow
Pictures from Stull book
12
Urban Boundary Layer
Picture from Fisher et al. report
13
Sketch of Urban Boundary Layer and Urban Plume
Pictures from Stull book
14
Layers Within The Urban Boundary Layer
Picture from Stull book
15
What Happens to Wind Profile Between the Buildings
Wind Velocity
Pollutant Distribution
Pictures from Gerdes et al., paper
16
Pollutant Dispersion in Urban Street Canopies
Pictures from Xia et al., paper
17
Identical Building Upstream

• Low Building

• High Building

Pictures from Xia et al., paper
18
Urban Meteorology case studies

• Tehran, Iran
• Graz, Austria
• Sydney, Australia
• Atlanta, GA

19
Tehran, Iran
From www.lonelyplanet.com
20
Tehran, Iran
Alborz Mountains
From www.lib.utexas.edu/maps/historical/tehran_ira
21
Tehran Pollution
From Asadollah-Fardi
22
Valley Pollution Dispersion
From www.uoregon.edu/dpardue/overheads/mainpage/ov
erheads-entire.html
23
Valley Circulation
From http//bigmac.civil.mtu.edu/public_html/class
es/ce459/study.html
24
Graz, Austria
From www.siteatlas.com
25
Graz, Austria
From www.atlapedia.com
26
Graz Pollution

• Pollution Event January 7, 1991

Pollutant Max Concentration
NO 0.350 ppm
NO2 0.110 ppm
CO 8 ppm
SO2 0.03 ppm
From Sturm, Almbauer, Kunz
27
Mountain Lee Phenomenon
From www.atsb.gov.au/public/facts/turbulence.cfm
28
Sydney, Australia
From http//www.ga.gov.au/map/images.html
29
Sydney, Australia
From www.ga.gov.au/map.images.html
30
Sydney Pollution

• From 1980 to 1992, Sydney averaged 20 days per
  year with peak O3 gt 80 ppb
• Diurnal O3 variation

From Physick
31
Sea Breeze
From USA Today
32
Atlanta, GA
Atlanta Supersite, 1999
UGA Agricultural Research Station Griffin, GA
33
The Urban Environment - Overview

• Regional and local scale models often do not
  predict very local conditions
• Urban-Specific Problems
• Indoor/Outdoor correlations
• Socioeconomic status (SES)

34
Urban Modeling
35
Urban Modeling
36
Urban-Specific Problems

• Local (unmodelled/unmeasured) Exposures
• Urban Heat Island
• Humidity/Heat Index
• Stress
• Pollutant Specifics and the Urban Environment

37
Urban Health Air Toxics

• Typically increased (small) local sources of air
  toxics
• 1,3-Butadiene, benzene, etc
• Very source specific

38
Indoor/Outdoor Meteorology

• Harsh Urban Environment Mitigation (A/C, etc.)
• Meteorology drives people inside/outside
• Meteorological Phenomena sensitivity

39
Urban Health - SES

• Urban sites typically populated by many low-SES
  families
• Low SES increased susceptibility

40
Our Urban Environment?

• Tehran 12,000 persons/sq km
• Graz 4730 persons/sq km
• Sydney 2474 persons/sq km
• Atlanta 1303 persons/sq km

41
Summary/Conclusions

• Urban Heat Island
• Urban Topography
• Case Studies of the Urban Environment
• Applications in the Urban Environment

42
References

• Stull R. B., An introduction to boundary layer
  meteorology, Kluwer Academic Publishers, 1988,
  596-612.
• Fisher B., Kukkonen J. and Schatzmann M.,
  Meteorology applied to urban air pollution
  problems COST 715, Report from atmosphericenvironm
  ent website.
• Gerdes, F., Olivari, D., 1999. Analysis of
  pollutant dispersion in an urban street canyon,
  Journal of Wind Engineering and Industrial
  Aerodynamics 82, 105-124.
• www.corbis.com
• Xia J. and Leung D.Y.C., Pollutant dispersion in
  urban street canopies, Atmospheric Environment 35
  (2001) 2033-2043.
• Asadollah-Fardi, G. Air Quality Management in
  Tehran, www.unescap.org
• Physick, W.L. Photochemical smog studies in
  Australian cities, Urban Air Pollution, Volume
  2. ed. H. Power and N. Moussiopoulos.
  Computational Mechanics Publications, 1996.
• Sturm, P.J., R. A. Almbauer, and R. Kunz. Air
  quality study for the city of Graz, Austria,
  Urban Air Pollution, Volume1. ed. H. Power, N.
  Moussiopoulos, and C.A. Brebbia. Computational
  Mechanics Publications, 1994.
• Heat Island Group, Lawrence Berkeley National
  Lab. NASA Global Hydrology and Climate Center

43
Questions?

• Classmates Free!
• Dr Wang - 5 per question
