VxWorks & Memory Management

1
VxWorks Memory Management

• Group A7
• CSE8343

2
Agenda

• General Overview
• High level overview of how VxWorks thinks about
  memory
• Virtual Memory
• Caching
• Specific example of how VxWorks allocates memory
  on a Synergy Dual Processor

3
General Overview

• In basic VxWorks, all memory can be conceived as
  a singular linear array of words.
• All processes (theoretically) can access all
  words.
• Or what ever the appropriate addressing unit
  is byte, word, long word

4
Memory Layout (VxWorks on PPC)

• Interrupt Vector Table
• Exception/Interrupt vectors
• Shared Memory Anchor (if necessary)
• Boot Line
• ASCII string of boot parameters
• Exception Message
• ASCII string of the(prior) fatal exception message

5
Memory Layout, II

• Initial Stack
• Initial stack for usrInit( ), until usrRoot( )
  allocates the real stack.
• System Image
• VxWorks itself (three sections text, data, bss).
  The entry point for VxWorks is at the start of
  this region, which is BSP dependent. The entry
  point for each BSP is as follows

6
Memory Layout, III

• Host Memory Pool
• Memory allocated by host tools. The size depends
  on the the macro WDB_POOL_SIZE. Modify
  WDB_POOL_SIZE under INCLUDE_WDB.
• Applications downloaded to processor are
  allocated space here.
• Interrupt Stack
• Size is defined by ISR_STACK_SIZE

7
Memory Layout, IV

• System Memory Pool
• Size and location depend on the size of the
  system image. Malloc() allocates space from here.
• Many of these items can be changed by modifying
  various macros (ISR_STACK_CHANGE, WDB_POOL_SIZE
  are just two) and then recompiling VxWorks.

8
Memory Access (Translations)

• Untranslated physical address is used unchanged
  (physical virtual)
• The processors usually boot into this mode until
  MMU hardware is initialised.
• BAT Registers
• Set of four/eight registers which define (large)
  blocks of memory
• Each logical address is converted by BAT
  registers
• Responsibility of user to correctly set BAT
  registers

9
Memory Access, II

• Page mode
• As you would expect logical addresses are
  decoded through segment registers and TLB page
  tables to construct physical address
• Be careful on size mapping 1GB gt 16MB of page
  table space!
• User must correctly set-up page table entries for
  certain (non-standard) memory locations.
• Usually a combination of BAT and Page is used,
  depending on size of memories to map (VME / PCI /
  IO, etc). Page mode is preferred for use with
  Virtual Memory and Caching.

10
Virtual Memory

• VxWorks does not require a Memory Management Unit
  (MMU)
• Not all systems have a MMU
• System performance is best when a MMU is used
• vmBaseLib allows 1 global Virtual Memory mapping
  for the system
• vmBaseLib allows user to set cacheable /
  uncacheable memory blocks

11
VxWorks Memory, ctd

• Extensive Virtual Memory support available is
  separate product (VxMI, aka vmLib)
• Allows private virtual memory contexts
• User could set up each task with a separate VM
  context
• But increased context switch time, user must
  manage contexts correctly
• Not normally used in my companys embedded
  products.

12
VxWorks and Caching

• VxWorks is designed to the worst case scenario
  (greatest number of coherency issues)
• Harvard architecture (separate Instruction and
  Data caches)
• copy-back mode
• DMA transfers and devices
• Multiple bus masters
• No Hardware support

13
More on Caching

• VxWorks supplies the functions to control cache
  settings (write-through/ copy-back)
• It is the responsibility of the user to handle
  the intricacies of cache / dma / virtual memory.
• User must indicate whether memory buffers are
  cacheable / noncacheable
• User must handle cache invalidation / cache
  flushing to maintain cache coherency
• User must correctly set up DMA transfers with the
  use of the MMU and cache
• Most of the time, the default settings are fine.
  Only when accessing other devices does this
  become some thing that must be fully analyzed.
• VxWorks / BSP supply the functions, the user
  supplies how/when to use them.

14
How does VxWorks allocate memory?

• VxWorks starts at address 0
• includes exception vector, etc.
• During kernel initialisation, kernelLib will use
  memLib to allocate the system memory partition.
• Malloc() will use the system memory partition for
  kernel memory needs.
• User can create memory partitions by calling
  memPartCreate() in memPartLib.
• This allows user to maintain different pools of
  memory, each of a different size, and allocate
  from those pools.
• Generally these allocates are pulled from the
  system memory partition.
• User can add more memory to the partition, and it
  need not be contiguous.
• With appropriate number and appropriately sized
  partitions (a priori analysis) the effects of
  memory fragmentation can be reduced.

15
One problem with VxWorks

• PPCs addresses are 24 bits-- all code (VxWorks
  application) must be within 32 MB.
• There are several methods of dealing with this
  problem
• Add memory to global memory pool _AFTER_ all
  application code is loaded
• Compile code w/ -mlongcall option (reduced
  efficiency in code due to extra instructions to
  handle long calls)
• User manages extra memory (not visible to VxWorks
  malloc())

16
Specifics of VxWorks

• vmLib.h handles the physical to virtual memory
  mapping
• Data structure sysPhysMemDesc
• Partly filled in by VxWorks at system
  configuration (boot time)
• Filled in by user prior to VxWorks compilation to
  add other memory (memory mapped devices)

17
Example sysPhysMemDesc (Synergy Dual processor
board)

• This is essentially the first page table in the
  system (it contains the first set of Page Table
  Entries)
• It is an array of records
• Virtual Address, Physical Address, Length in
  Bytes Virtual Memory Mask, Virtual Memory Enable
• Note This is a dual processor board, with all of
  RAM accessible to both processors. Different
  board configurations will yield different
  physical memory layouts.

18
sysPhysMemDesc, ctd

• The following are generally completed by the BSP
  vendor
• Element 0 Maps mailboxes, starts at address 0,
  and should be uncached./
• Element 1 Maps gemini registers and ethernet
  data arrays. Starts at 0xF000000
• Element 2 Define the space for VxWorks kernel
  (processor 1). Modified by kernel at run time.
• Element 3 Define the space for VxWorks kernel
  (processor 2). Modified at run time.
• Element 4 Shared Memory. Starts at 0x2000000
• Element 5 Processor 1s RAM. Modified at run
  time.
• Element 6 Processor 2s RAM. Modified at run
  time.
• Element 7 Page tables space. Modified at run
  time.

19
sysPhysMemDesc, ctd

• These elements are the responsibility of the user
  to modify prior to compiling
• PCI SPACE -- 8 entries
• initially zero (so if they are not used, no
  memory is allocated)
• my current project has a mapping here to a device
  on the PCI bus
• VME SPACE -- last 8 entries
• Describe the VME master ports for the
  architecture
• Initially zero (like PCI maps)
• We will add a mapping to a VME device here as
  well
• The base system is untranslated, physical
  virtual

20
What about the BAT registers?

• BAT registers can conflict with the routines in
  cacheLib and vmBaseLib
• ie, OS and HW may not play well together
• BAT registers map memory outside of the
  processors (Flash, PROM, etc)
• Locations where fine-grained control is not
  necessary

21
Conclusion

• VxWorks offers much power to the user
  (application / system programmer) to control
  exactly how memory is addressed, allocated,
  cached.
• With power comes responsibility
• user must not rely on VxWorks to perfectly
  implement an applications memory needs.
• User will need to consider caching (flushing,
  disabling), DMA accesses, etc. as part of design.

22
Definitions

• Board Support Package (BSP) The extensions to
  the generic VxWorks that apply to a specific
  processor and its board.
• Copy-back Only write to memory when necessary
• Direct Memory Access (DMA) Transfering data
  withou processor support.
• Write-through Write to cache and then into
  memory

23
References

• VxWorks Reference Manual
• Synergy User Guide for Dual-PPC
• VxWorks on-line documentation
• VxWorks source code (all the libs)
