Title: Intra-uterine Growth Restriction


1
www.totalpregnancycare.com
2
Intra-uterine Growth Restriction
  • Dr Shantala Vadeyar
  • MD, FRCOG, DM
  • Advanced Obstetric Ultrasound (RCOG / RCR)
  • Subspecialist Fetal Maternal Medicine (RCOG)
  • Consultant Obstetrician, Fetal Maternal
    Medicine
  • Kokilaben Dhirubhai Ambani Hospital, Mumbai

3
Definition
  • IUGR is failure to achieve the fetal growth
    potential
  • Difference between size and growth
  • Size - one measurement
  • Growth multiple measurements plotted on a graph
  • Growth charts important in fetuses like in
    children

4
Size v/s Growth
  • Small for gestational age - lt2.5 kg
  • Preterm gestation and small
  • Term gestation and small
  • Healthy but small Constitutionally small
  • Pathologically small IUGR

5
Causes of IUGR 1. Maternal
  • Chronic maternal conditions
  • Renal disease
  • Hypertension
  • Long standing Diabetes
  • Congenital heart disease
  • Smoking
  • Alcohol
  • Anemia - severe

6
Causes of IUGR 2. Fetal
  • Infection TORCH
  • Toxoplasma, Rubella, CMV
  • Malformation
  • Gastroschisis
  • Chromosomal abnormalities
  • Trisomy 18 (Edward syndrome)
  • Multifetal pregnancy
  • Chorionicity determination is vital
  • MC Twins, Twin twin transfusion syndrome

7
Causes of IUGR 3. Placental
  • Placental thrombosis / infarctions
  • Antiphospholipid syndrome
  • Chorioamnionitis
  • Abruptio placentae usually acute, but
    sometimes, small recurrent bleeds
  • Placenta previa

8
Causes of IUGR 4. Uterine
  • Poor uterine blood flow
  • Poor placental blood flow
  • Large fibroids leading to poor placentation
  • Uterine anomalies septate or subseptate uterus

9
IUGR screening
  • Whom to screen?
  • Ideally Symphysis Fundal Height performed
    regularly for all pregnancies
  • SFH in cms weeks of gestation
  • High risk cases will need ultrasound for growth,
    liquor volume, umbilical artery Doppler and
    Biophysical Profile
  • Umbilical Artery Doppler is the best test!

10
Diagnosis
  • Accurate dating is vital!
  • lt 20 weeks of gestation, preferably lt 14 wks
  • Suspect clinically
  • Uterus palpates small
  • Less amniotic fluid
  • Reduced fetal movements
  • High risk maternal, placental, uterine or fetal
    factors

11
Ultrasound diagnosis of IUGR
  • Growth
  • Measure the fetus biometry
  • Head circumference
  • Abdominal circumference
  • Femur length
  • Measure the amniotic fluid- AF index, SDP
  • Evaluate the blood flows- Dopplers!

12
Uterine Artery Doppler
  • Screening test in pregnant women
  • High resistance waveform- notching indicates
    poor placentation
  • Notches are present in early gestation but
    disappear 24 weeks onwards
  • Bilateral notches are significant

13
Uterine A Doppler- Normal
14
Uterine Artery Doppler
  • Notching indicates a high risk pregnancy
  • Increased risk of
  • Pre-eclampsia
  • Growth restriction
  • Placental abruption
  • Intrauterine fetal death
  • Increased monitoring- growth scans, Umbilical
    artery Doppler

15
Uterine A Doppler- Notching
16
Umbilical Artery Doppler
  • Indicates resistance in the feto-placental
    vascular bed
  • Angle of insonation should be lt60o
  • From 16 weeks onwards- positive end diastolic
    flow (EDF)
  • Reduced EDF, Absent EDF and Reversed EDF
    represent increasing resistance in the vascular
    bed

17
Umbilical Artery Doppler
18
Umbilical A AEDF
19
Umbilical A REDF
20
Fetal growth
  • Serial assessments are important
  • Growth trajectory is important, not size!
  • Symmetrically small fetus
  • Constitutionally small
  • Genetic syndromes/ chromosomal abn
  • Very early onset IUGR
  • Asymmetric- HCgtAC suggests growth restriction due
    to placental insufficiency

21
Interpretation of Ultrasound findings in IUGR
  • Clinical history
  • Previous poor outcome
  • Antepartum haemorrhage
  • Reduced fetal movements
  • Gestation- how accurate? Viability?
  • U/S- Growth, Biphysical profile, Umbilical Artery
    and Uterine Dopplers
  • CTG (NST)

22
Antenatal Surveillance in IUGR
  • Watch fetal movements
  • Maternal health pre-eclampsia
  • Biophysical Profile Score
  • Comprises 2 points each for-
  • Fetal body movements
  • Fetal tone
  • Fetal breathing movements
  • Amniotic fluid volume
  • CTG

23
Fetal Middle Cerebral Artery Doppler
  • 22-28 weeks- no EDF in MCA
  • 28w to term- some EDF seen- normal
  • Increased EDF ( low PI) suggests brain sparing
    redistribution in IUGR
  • Worsening hypoxia- fetal acidemia- paradoxical
    rise in resistance (high PI)
  • Cerebro-placental ratio increases this is
    indicative of IUGR

24
MCA Doppler
25
MCA Doppler- IUGR
26
What does NOT help
  • Duvadilan / Bricanyl
  • Amnioinfusions
  • Oxygen therapy
  • Amninoacid preparations
  • Bed rest ??

27
Timing of delivery
  • gt34 weeks good neonatal outcome
  • lt34 weeks - Betamethasone inj should be given to
    the mother
  • Fetal pulmonary maturity
  • Reduces risk of intra-ventricular haemorrhage
  • Very preterm gestation - lt28 weeks ?
  • To wait or to deliver

28
Preterm labour in IUGR
  • Often IUGR fetuses / pregnancies tend to go into
    preterm labour
  • Natures way of resolving the problem
  • Important to recognise this and avoid
    prolongation of pregnancy!

29
Mode of delivery
  • Labour is a stressful process for the fetus
  • Every contraction reduces oxygenation, though
    briefly and it recovers
  • Prolonged difficult labours should be avoided!
  • Continuous fetal monitoring is a MUST!
  • Elective LSCS for severe IUGR, abnormal
    presentation, oligohydramnios, abnormal CTG/ NST

30
Outcome
  • Mild moderate IUGR good
  • Severe early onset IUGR some organ systems may
    be compromised
  • Gut - Neonatal necrotising enterocolitis
  • Kidneys renal failure
  • Brain cerebral palsy
  • Genetic syndromes / malformations

31
IUGR in DC twins
  • Dichorionic twins- confirmed by 10-12w scans
  • Twin 1
  • AC dropped from 10th to 5th centile
  • AF 3rd centile
  • Absent EDF in one umb artery initially, then both
  • Bladder seen, normal biophysical score
  • Twin 2
  • AC 50th centile, Normal AF, Normal UA Doppler
  • Normal sized bladder, heart, biophysical scores

32
Management- when to deliver?
  • Monitor biophysical profiles and Umbilical Artery
    Dopplers
  • Risk of preterm delivery versus compromise
  • What is the significance of worsening Umbilical A
    Dopplers?
  • Risks of preterm delivery- respiratory distress
    syndrome, necrotising enterocolitis, infection
  • Risk to well grown fetus of prematurity
  • Intrauterine complications- abruption, worsening
    of maternal PET, IUFD

33
Decision to deliver
  • Twice weekly Biophysical scores
  • Twice daily CTGs, FM monitoring
  • 31 weeks Both Umb A in twin 1 showed absent EDF.
  • Discussion with parents- proceed to LSCS
  • Twin 1 was1 kg, twin 2 was 1.8 kg, both males
  • NEC in Twin 1 recovered
  • Good outcome

34
IUGR- Case 2
  • 25 year old primigravida
  • 34 weeks, presented with severe oedema, raised
    BP, proteinuria
  • Diagnosis PET (pre-eclampsia)
  • Scan Both AC, HC less than 3rd centile
  • Amniotic fluid volume 5th centile
  • Biophysical score 6/10
