Small Fruit Production

1
Small Fruit Production

• Teryl R. Roper
• Dept. of Horticulture
• University of Wisconsin-Madison

2
(No Transcript)
3
Small Fruits for Wisconsin

• Strawberry
• Raspberry
• Blueberry
• Cranberry
• Lingonberry

• Juneberry
• Currants
• Gooseberry

4
Soils for berries

• Well drained loamy soils
• High organic matter
• Amend with compost, etc.
• pH between 6.0 and 7.0
• Except blueberries lingonberries(4.5 to 5.5)

5
Site preparation

• Begin the year before planting
• Soil test add P, K fertilizer if needed
• Adjust pH (if needed possible)
• Control perennial weeds
• Cultivation
• Non-residual herbicides
• Add organic matter
• Manure, green manures, compost

6
Obtaining Plants

• Purchase plants from a reputable nursery
• True to name
• Disease free
• Virus indexed
• Dont save, dont share
• Arrange for spring delivery

7
Strawberry History

• Fragaria vesca Northern hemisphere
• F. moschata European
• F. virginiana Eastern North American
• F. chiloensis Pacific coast

8
Strawberry History

• Amédée François Frézier
• Experienced engineer mathematician
• Amateur botanist
• Jan. 6, 1712 left France for Chile Peru
• June 18, 1712 arrived at Concepcion
• Coincidentally, Frézier means strawberry

9
History

• For two years Frezier mapped the city, noted
  strong and weak points, studied the people, and
  described the agricultural and mineral resources.
• Took note of the large fruited strawberry growing
  there.

10
History

• Feb 19, 1714 Frezier left Chile and took with him
  several potted plants of the Chilean Strawberry.
• August 17, 1714 Frezier arrived in Marseille.
• Five strawberry plants were still alive.

11
Distribution

• 2 plants to ships cargo master
• 1 to minister of fortifications
• 1 or 2 to Antoine de Jussieu, director of the
  Jardin des Plants in Paris (Royal Gardens)

12
Distribution

• News of the large fruited strawberry spread
  quicklyas did plant material
• Brittany
• Netherlands
• Productivity was poor, apparently Frezier had
  selected staminate plants

13
Hybridization

• In gardens and commercial plantings F. virginiana
  was present and proved a suitable pollinator.
• Hybrid seedling plants were large fruited, firm,
  and had better color than F. chiloensis
• These chance hybridizations were the basis for
  modern strawberry production

14
Strawberries

• Now known as F. ananassa
• Name is based on the pineapple like flavor and
  smell of the fruit.
• Our modern strawberries were based on the chance
  meeting of two western hemisphere species in
  France.

15
(No Transcript)
16
Strawberry Plant

• Crown
• Leaves
• Stolons (runners)
• Roots
• Trusses (flowers and fruit)
• Plantings last 3-5 years

17
Flower Truss
25-40
25-40
Crown
50-10
Roots
Stolon or Runner
18
Tertiary
Secondary
Primary
19
(No Transcript)
20
Stolons or Runners
21
Strawberry Flower
Petals
Anther
Stigma
Style
Receptacle
Achene
22
(No Transcript)
23
(No Transcript)
24
Fruiting Habits

• June bearers Short Day
• Everbearers Long Day
• Day Neutral Insensitive

25
Day Neutral Strawberries

• Based on a collection of F. virginiana made in
  Utahs Wasatch mountains by Royce Bringhurst,
  Breeder at UC-Davis.
• Incorporated into breeding program.
• Is now the basis for the strawberry industries in
  California, Florida and other warm climates.

26
Planting

• Spring after danger of frost past
• Proper depth
• Spread roots
• Firm soil around crown

27
PLANTING DEPTH
Shallow
Correct
Deep
28
(No Transcript)
29
(No Transcript)
30
Strawberry planting systems

• Matted Row
• 12 to 18 between plants
• 36 to 40 row spacing
• Beds 12-18 wide
• Runners encouraged

• Spaced Plant
• 6 between plants
• 36 to 40 row spacing
• Single plant row
• Runners removed

31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
Spaced Plant System
35
Spaced Plant System
36
Remove blossoms the first year

• Promotes vegetative growth

37
Irrigation

• Strawberry is shallow rooted
• The soil must not dry out
• Require 1 to 2 inches per week

38
Winter Mulch

• Straw 2-3
• Apply when soil freezes (late)
• Remove in spring as leaves emerge (early)
• Spun-bonded polyester row covers

39
Winter Protection
3 to 4 inches of clean straw
40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
Place mulch between rows
44
Alive ?
Dead ?
45
Frost Protection

• Proper site is important
• Tarping is the best and easiest solution in home
  gardens
• Tarps
• Blankets
• Row cover material

46
Renovation

• Begin immediately after harvest
• Control weeds
• Mow leaves if leaf diseases serious
• Narrow rows
• Place soil around crowns
• Incorporate mulch
• Fertilize

47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
Fertility

• Amend soil before planting
• Do Not add fertilizer before harvest
• Get leaves, not fruit

51
Fertility

• Year 1 when runners form apply
• ¾ to 1 ½ lbs ammonium sulfate OR
• ½ to 1/3 lbs urea per 100 feet of row
• Bearing years at renovation AND one month later
  apply
• ½ lb ammonium sulfate OR
• 1/3 lb urea per 100 feet of row
• Water thoroughly

52
(No Transcript)
53
(No Transcript)
54
Cultivars

• June bearing
• Earliglow
• Honeoye
• Cavendish
• Winona

• Day neutral
• Selva
• Tribute
• Tristar

55
Questions?
56
Raspberries
57
Origin and History

• Rubus ideaus European
• R. strigosus North American
• First domesticated by Greeks
• Historical records of production throughout
  Europe by middle ages

58
Origin and History

• With the application of modern plant breeding
  techniques, breeders crossed R. ideaus with R.
  strigosus and created stronger, larger fruited,
  disease resistant hybrids
• These now form the basis of cultivated
  raspberries around the world.

59
Raspberry Plant

• Woody perennial
• Crown
• Roots
• Canes Primocanes floricanes
• Leaves
• Flowers

60
Raspberry Plant

• Biennial growth and fruiting habit
• Primocanes
• Floricanes
• Plantings last 8-10 years

61
Tips
Floricanes
Side Branches
Primocanes
Crown
Roots
Crown Buds
62
Immature Buds
70
Fruit buds
20
6
4
Leader Bud
Roots
63
Stigma
Style
Anther
Filament
Ovule
Receptacle
64
(No Transcript)
65
Raspberry Fruiting Habits

• Summer Bearing
• Fruit on one year old floricanes
• Fall Bearing
• Fruit on primocanes

66
Planting Raspberries

• In the spring after danger of frosts is past
• Just lower than in the nursery

67
(No Transcript)
68
Planting Systems

• Rows
• Plants 2-3 feet apart in rows
• Rows 6-10 feet apart
• Hills
• 4 X 4 feet apart

69
Hill System
70
(No Transcript)
71
Hill System
72
(No Transcript)
73
(No Transcript)
74
(No Transcript)
75
(No Transcript)
76
(No Transcript)
77
(No Transcript)
78
Pruning Raspberries

• Summer
• Remove fruited floricanes
• Thin out new shoots
• Dormant
• Head floricanes by ¼
• Remove weak or damaged wood
• Thin canes to 4-6 per foot of row

79
(No Transcript)
80
(No Transcript)
81
BEFORE
AFTER
82
(No Transcript)
83
(No Transcript)
84
(No Transcript)
85
(No Transcript)
86
(No Transcript)
87
Fertility

• 4 to 6 cups per 100 feet of row
• Timing
• Early spring (early May)
• Late spring (early June)

88
Mulching

• Mulches are desirable to
• Retain moisture
• Protect roots
• Reduce weeds
• Straw, shavings, sawdust
• Sod between rows

89
Harvesting

• Red, yellow, black raspberries
• The cap pulls clean leaving the receptacle
• Blackberries
• The receptacle is removed along with the fruit

90
(No Transcript)
91
Other Brambles

• Black raspberries R. occidentalis
• Purple raspberries R. neglectus
• Interspecific hybrids
• Boysenberries red x blackberry
• Tayberries red 4 x black 8
• Blackberries Many species

92
Raspberry Cultivars

• Summer Bearing
• Boyne
• Nova
• Killarney
• Reveille
• Titan

• Fall Bearing
• Autumn Britten
• Autumn Bliss
• Ruby
• Heritage

93
Raspberry Cultivars

• Yellow
• Honeyqueen
• Goldie
• Fall Gold

• Purple
• Amethyst
• Brandywine
• Royalty

94
Break Time!
95
Bush Fruit

• Blueberries
• Juneberries
• Gooseberries
• Currants
• Red
• Black
• Culture is very similar

96
Bushfruit Plant

• Woody perennial
• Crown
• Roots
• Canes

97
Planting

• In the spring after danger of frost
• Plant at same depth as nursery
• Make sure roots are spreading, not spiraling
• Water immediately

98
Pruning

• Renewal pruning
• Remove the oldest 3-5 canes
• Thin out small weak shoots
• Keep the canopy from becoming dense

99
Fertility

• Apply a small amount of high N fertilizer in the
  spring each year
• Base on growth and vigor

100
Currants Gooseberries

• Less popular
• Thorny
• Used in cooking
• Cleaning fruit isdifficult

101
Currants Gooseberries

• Do best in good soils
• With adequate light
• Regular irrigation
• Very winter hardy

102
Planting

• Set plants 1-2 inches deeper than in the nursery
  to promote stronger roots
• Set plants 3-4 feet apart

103
Before
After
104
(No Transcript)
105
Cultivars

• Currants
• Red Lake
• White Imperial
• MN 71
• Black Currants
• Consort
• Crusader

• Gooseberries
• Pixwell
• Captivator
• Hinnonmaki Red
• Hinnonmaki Yellow

106
Juneberries

• Commonly used as an ornamental
• Grows to 6-15 feet tall
• Very hardy (zone 2)
• Also known as
• Saskatoon
• Serviceberry
• Shadberry

107
(No Transcript)
108
Sites

• Prefers soils with high organic matter
• Soil pH 5.5-7.5
• Some drought tolerance, no tolerance to ponding

109
Pruning

• Bear fruit on one year old wood
• Prune out
• Canes 5 years old
• Diseased canes
• Weak spindly canes
• Control height

110
Cultivars

• Smoky
• Honeywood
• Pembina
• Northline
• Propagated by seed

111
Highbush Cranberry

• Viburnum species
• Usually planted as ornamentals
• Three species
• V. opulus European inedible
• V. sargentii Sargent
• V. trilobum American edible

112
Uses

• Fruit is extremely tart
• Processed into jams and jellies

113
(No Transcript)
114
Lingonberries

• Vaccinium vitis-ideae
• Mountain cranberry
• Low growing evergreen shrub related to
  blueberries and cranberries
• Small red fruit mature in the fall

115
Lingonberry

• Soils and sites like blueberries
• Low pH, high OM, well drained

116
(No Transcript)
117
(No Transcript)
118
(No Transcript)
119
Blueberry Production

• Adapted to acid soils
• Must prepare soil before planting
• Must provide winter protection
• Half-high types are best suited to Wisconsin

120
Soil Preparation

• Add copious amounts of organic matter
• Add sulfur at least 1 year prior
• lt¼ lb per square foot, incorporated
• Cultivate to make soil loose, friable.
• Soils with high carbonate content cannot have
  pH adjusted

121
Excavate Replace
No peat
Peat
122
(No Transcript)
123
(No Transcript)
124
Winter Protection
125
Grapes

• Vitis labrusca
• Blue grapes also known as fox grapes. Native to
  western hemisphere. Hardy.
• V. vinifera
• Wine grapes native to Europe. Not hardy
• French-American hybrids
• Hybrids are marginally hardy

126
Grape Plant

• Roots. Root readily from cuttings
• Trunk. May be single or split
• Cordon. Horizontal permanent stems
• Canes. One year old wood. Current season
  growth, too.
• Spurs. Canes pruned off short. 2-3 buds
• Tendrils. Twining structures borne opposite
  leaves or clusters. Helps hold vines to trellis

127
One year old cane
Current season cane
Cluster
Tendril
128
(No Transcript)
129
Hardiness

• French hybrids
• -10F bud and trunk injury
• -20F kill buds and trunks
• American types
• -20F would cause crop reduction

130
Grape training
Training
131
Cordon/Spur
132
Cordon/Cane
133
Head/Spur
134
Head/Cane
135
(No Transcript)
136
Cane vs. Spur
137
J system for cold climates
138
Spur pruned rose
139
Balanced pruning

• American types
• 30 plus 10 system
• 30 buds for first pound of prunings
• 10 buds for each additional pound
• French hybrids
• 20 plus 10 system
• Dont exceed 40-50 buds

140
(No Transcript)
141
Pollination

• Grapes with perfect flowers are self fruitful
• Some wild types have male and female plants.
  Male plants produce flowers, but never produce
  fruit.

142
(No Transcript)
143
Propagation

• Cuttings root easily
• Cut canes with three nodes (bud)
• Put two buds below ground one above
• Vines will readily root and grow
• Can also tip layer

144
Fertility

• Annual nitrogen application in spring
• May need additional potassium
• Micronutrients rarely needed
• Tissue testing based on petioles

145
Questions?
146
Review

• Correct Site
• Correct Species
• Correct Cultivar
• Correct System
• Pre-plant preparations
• Careful Culture
