The Andes Intelligent Tutoring System: Five years of evaluations

1
The Andes Intelligent Tutoring SystemFive years
of evaluations

• Kurt VanLehn
• Pittsburgh Science of Learning Center (PSLC)
• University of Pittsburgh

2
The physics LearnLab course committee

• Andes development
• Anders Weinstein
• Brett van de Sande
• Kurt VanLehn (co-chair)
• U.S. Naval Academy
• Don Treacy (co-chair)
• Bob Shelby
• Mary Wintersgill
• Kay Schulze

• Experimenters
• Scotty Craig
• Sandy Katz
• Bob Hausmann
• Michael Ringenberg
• Meet weekly
• Thursdays 330

3
Funding

• The U. S. Office of Naval ResearchCognitive
  Science Program
• The U.S. National Science FoundationPittsburgh
  Science of Learning Center

4
Research question

• Given
• Whole semester of instruction
• No change to content of course
• No change to lectures labs assignments
• Standard exams (not designed by experimenters)
• Can a homework helper increase learning

5
Prior work with answer-only tutoring steps

• Web-based homework grading systems
• E.g. Web-assign CAPA Mastering Physics
• Provide feedback hints on the answer only
• Compared to ordinary paper-based homework
• Positive benefits
• When paper-based homework is collected graded
• No benefits (Pascarella 2002 Dufresne Mestre
  Rath 2002)
• Interpretation
• Motivating students to do their homework provides
  benefits but the answer-only tutoring system
  provides no additional benefits

6
Prior work with tutoring systems that give
feedback hints on steps

• Lisp Tutor (Corbett 2001) and many others
• Same homework problems text
• Experimenters exams only
• But not a whole semester (only 5 lessons)
• Pump curriculum Pat tutor (Koedinger et al)
• Whole year of high-school algebra
• Both experimenters exams standard exams
• But content confounded with tutoring system
• Earlier evaluations of Andes
• First half-semester only
• Experimenters exams only

7
Why does it matter

• Ideally an intelligent homework helper
• can increase learning without changing the
  course and
• the increase is strong enough to show in final
  exam
• The diligent always do well slackers always do
  poorly
• Cramming
• If not
• still useful if it facilitates content upgrades
  and
• the upgrades cause robust increases in learning

8
Outline

• Andes
• Evaluation
• Discussion

Next
9
What kind of physics

• US university introductory physics courses
• US high school advanced physics courses
• A typical problem

If a 2000 kg car at the top of a 20 degree
inclined driveway 20 m long slips its parking
brake and rolls down. If we ignore friction and
drag what is the magnitude of the velocity of
the car when it hits the garage door
10
Andes user interface
Read a physics problem
Draw vectors
Type in equations
Type in answer
11
Andes feedback and hints
What should I do next
Whats wrong with that
Green means correctRed means incorrect
Dialogue hints
12
Major challenges

• Dealing with equations
• Giving red/green feedback
• Undoing algebraic combination
• For what should I do next
• Analyzing errors in equations
• Scale-up
• 13 chapters 500 textbook pages
• 350 problems
• 300 principles

13
Outline

• Andes
• Evaluation
• Method
• Main results
• Which students benefited
• Which knowledge benefited
• Interpretation of results
• Discussion

Next
14
Evaluations of Andes at the US Naval Academy

• Fall semesters 2000 2001 2002 2003
• Only the homework modality was varied Andes vs.
  paper-based
• Same textbook
• Similar lectures labs recitations
• Similar homework problems
• Same exams
• Students were motivated to do paper-based
  homework
• Either collected and graded
• Or 1 homework problem on each quiz

15
Exams

• Midterm exam
• 1 hour 4 problems
• Scored on derivation answer
• Drawings (30)
• Variable definitions (20)
• Equations (40)
• Answers (10)
• Final exam
• 3 hours 50 problems
• Multiple choice

Next
16
Checking prior competence of Andes and control
students

• Grade-point averages equal
• Distribution of majors equal
• Engineering majors vs.
• Science majors vs.
• Other majors

17
Midterm exam results(All differences reliable p
lt .01)
How to calculate effect size
18
Calculating effect size over 4 different midterm
exams

• Normalize each score
• z_score(student)
• raw_score(student) mean(exam) /
  standard_deviation(exam)
• For each condition pool z-scores across years
• Effect size

0.61
19
Final exam

• Exam covers 100 of course but Andes didnt
• Does now
• Use 2003 exam only Andes covered 70
• 89 Andes students
• 823 non-Andes students

20
Prior competence not equal

• Majors not equally distributed
• Andes group had more engineering majors
• GPAs not equally distributed
• Andes group had marginally higher GPAs
• Factor out prior competence statistically
• For each major regress GPA on final exam score
• Residual_score(student) raw_score(student)
  predicted_score(students major students GPA)

21
Final exam results
Difference is reliable (p 0.028) Effect size
0.25
22
Outline

• Andes
• Evaluation
• Method
• Main results
• Which students benefited
• Which knowledge benefited
• Interpretation of results
• Discussion

Next
23
Benefits same regardless of GPA
24
Benefits varied by major on final exam but not on
midterm exam
25
Outline

• Andes
• Evaluation
• Method
• Main results
• Which students benefited
• What knowledge benefited
• Interpretation of results
• Discussion

Next
26
Effect sizes for subscores of midterm exam
27
Interpretation of results

• Engineering science majors learned the red path
  and prefer it
• Andes does not increase their final exam scores
• They use blue path on the midterm
• Andes increases their midterm exam scores
• Other majors do not have red path so they use
  the blue path on both exams
• Andes increases both exams scores
• On midterm exams subscores measure components of
  blue path separately
• Biggest benefit for diagrams variables
• Smaller on equations none on answer

Problem
Andes
Diagram variables
Prior physics
Andes
Equations
Prior math physics
Answer
28
Summary of results

• Main result Andes provides benefits
• Midterm exam effect size 0.61
• Final exam effect size 0.25
• Andes helps students learn conceptual skills
• Effect sizes on conceptual subscores 1.21 0.69
• Effect sizes on calculational subscores 0.11
  -0.08
• Some students appear to have a non-conceptual
  method for solving problems
• Competes with the conceptual method taught by
  Andes
• They use it on the (answer-only) final exam
• This dilutes the benefit of Andes on final exam

29
Outline

• Andes
• Evaluation
• Discussion
• Andes compared to others
• Why is Andes effective

Next
30
Effect sizes on experimenters standard exams
of 3 tutoring systems
31
Interpretation of the comparison with other tutors

• Andes is about the same as other tutoring systems
  that give feedback and hints on steps
• Perhaps the PumpPat benefits are due solely to
  the tutoring system and not the content upgrade

32
Summary Studies of homework helpers when content
is controlled
Ordinary paper-based homework
Large benefits
Motivated paper-based homework
No benefits
Feedback hints on answer only
Large benefits
Feedback hints on steps
33
Outline

• Andes
• Evaluation
• Discussion
• Andes compared to others
• Why is feedback hints on steps so effective

Next
34
Hypothesis Andes increases the number of
successful knowledge events

• Without feedback hints on steps students skip
  them
• Guess
• Copy similar examples step edit
• Copy edit a higher goals outcome
• Doing a step correctly requires
• Figuring out how the first time (sense-making)
• Figuring out why the second third times
  (refinement)
• Recalling why how the other times (fluency
  building)
• This increases number of successful knowledge
  events
• Wherein a student constructs or applies a
  knowledge component

35
Thanks for your attention!

• At www.andes.pitt.edu
• Download stand-alone version of Andes
• Try OLI version of Andes
• Download papers on Andes
• Sorry but Andes only runs on Windows
