Title: ESMF Code Generation


1
ESMF Code Generation
  • Rocky Dunlap
  • Spencer Rugaber
  • Leo Mark
  • Georgia Tech College of Computing

2
Motivation and Goals
  • Automatically generate Fortran code for coupling
    Earth System Modeling Framework (ESMF)
    components, including
  • A top level driver
  • A coupler component
  • Determine to what extent coupled Earth System
    Models are amenable to code generation
  • Auto-generation of couplers is part of the
    original Curator proposal

The word model is overloaded. When referring to
a computer simulation we will use the term
numerical model or coupled model. Otherwise,
when used alone, the term model refers to an
abstract representation of reality.
3
Process Overview
1
2
3
Describe existing components based on source code
Describe a coupling configuration
Generate the source code for a coupler and a
driver
module comp2
ltcomp1gt ... lt/comp1gt ltcomp2gt lt/comp2gt
module comp1
Code Generator
ltcomp1gt ... lt/comp1gt ltcomp2gt lt/comp2gt
module coupler
program driver
4
Case study ESMF_ArrayRedistSTest
  • One-way coupling scenario with two gridded
    components user_model1 and user_model2
  • user_model1 populates 100x150 global array
  • user_model2 verifies array data
  • user_model1 runs on 4 processors (PETs) with a
    4x1 DELayout (i.e., four 25x150 local arrays)
  • user_model2 runs on 2 PETs with a 1x2 DELayout
    (i.e., two 100x75 local arrays)
  • System test includes the coupler for
    redistributing array data and a t0p level driver
  • Given user_model1 and user_model2, our goal is to
    generate the coupler and the driver code

5
Process Overview Inputs Outputs
  • You have
  • Fortran source code for two ESMF gridded
    components
  • You put in
  • A description of those components
  • A description of a coupling configuration
    composition, schedule, and deployment
  • You get out
  • Fortran source code for an ESMF driver and an
    ESMF coupler component

6
System Architecture
ESMF Code Generation
ESMF Coupler Generator
ESMF Driver Generator
ESMF Conceptual Modeling
FORTRAN Code Generation
ECM Modeling GUI
Java Fortran Object Model (JFOM)
ESMF Conceptual Model (ECM)
StringTemplate
Eclipse Modeling Framework (EMF)
7
Existing Infrastructure Pieces
  • Eclipse Modeling Framework
  • http//www.eclipse.org/emf/
  • a modeling framework and code generation
    facility for building tools and other
    applications based on a structured data model
  • Models are built using a UML-like,
    object-oriented metamodel called Ecore
  • StringTemplate
  • http//www.stringtemplate.org/
  • a Java-based template engine for generating
    formatted text output
  • templates are strings with holes that can be
    populated programmatically and then output

8
The ESMF Conceptual Model (ECM)
  • Built with the Eclipse Modeling Framework
  • A conceptual model of ESMF data structures
  • Gridded and Coupler Component, Import/Export
    State
  • Virtual Machine, PETs, DELayout
  • DistGrid, Array
  • Not included (yet) Field, Grid, Clock, Calendar
  • Also includes new structures for describing
    coupling configurations
  • Composition how the components are connected
  • Schedule order of execution of components
  • Deployment map components to physical resources

9
ECM Graphical User Interface
  • The coupled model designer builds ESMF
    Configuration Instances (ECIs) using a GUI like
    the one shown here
  • This current GUI is generated automatically with
    the Eclipse Modeling Framework

10
JFOM Fortran Conceptual Model
  • ECIs are input to the code generation phase. We
    need an API for manipulating Fortran programs.
  • Java Fortran Object Model (JFOM)
  • built with the Eclipse Modeling Framework
  • a set of Java classes that represent the
    syntactic structures of Fortran programs
  • based on the Fortran 90 grammar
  • allows programmatic manipulation of Fortran
    programs
  • JFOM instances are serialized with StringTemplate

11
JFOM Classes
JFOM classes represent the syntactic structures
of Fortran 90
12
Models and Instances
ESMF Conceptual Model (ECM)
Java Fortran Object Model (JFOM)
FORTRAN 90 ISO Standard
Model level
conform
ESMF Configuration Instance (ECI)
JFOM Instance
FORTRAN source code
Instance level
transform
transform
13
Case study ESMF_ArrayRedistSTest
  • Given user_model1 and user_model2, our goal is to
    generate the coupler and the driver code
  • First step is to build an ECI containing a
    description of user_model1, user_model2, and the
    coupling configuration
  • The ECI is passed to the ESMF Coupler Generator
    and ESMF Driver Generator resulting in two JFOM
    instances
  • The JFOM instances are serialized into Fortran 90
    code and can be compiled with user_model1 and
    user_model2 to recreate the system test

14
What code is generated?
  • Driver program (see source code)
  • Module imports and global variable declarations
  • ESMF_Initialize
  • ESMF_GridCompCreate and ESMF_CplCompCreate
  • ESMF_StateCreate for import/export states
  • Call Init, Run, Finalize for each component (just
    once for now)
  • ESMF_StateDestroy, ESMF_Finalize
  • Coupler module (see source code)
  • Module imports and global variable declarations
  • register, init, run, finalize subroutines
  • init ESMF_StateReconcile and ESMF_ArrayRedistSto
    re
  • run ESMF_ArrayRedist
  • finalize ESMF_ArrayRedistRelease
  • What is not generated?
  • source code for user_model1 and user_model2
  • makefiles, configuration scripts, etc.

15
Design Decisions
  • How much of the ECI (coupling configuration) is
    described explicitly by the modeler and how much
    is inferred?
  • For example, does the user describe component
    connections at the field level, or should the
    system infer field connections by matching names?
  • Tradeoffs Defining things explicitly gives the
    modeler more control. Inferring things means the
    modeler does less work.
  • Where and when is the inferencing done?
  • The UI could provide inferencing tools to fill
    in details of the coupling configuration
    automatically.
  • There is a notion of a completely specified ECI
    in which the code generator does not do any
    inferencing. Should we make the assumption that
    all coupling scenarios coming out of the UI will
    be complete?

16
Design Decisions (cont.)
  • The code generator deals primarily with a models
    communication infrastructure. How do we deal
    with the science embedded in components?
  • Do we provide hooks for science? (Can we get to
    a point where the modeler only has to write the
    scientific code?)
  • What about couplers that have embedded science?

17
Next steps
  • What is the next step for exercising the code
    generator?
  • Other system tests?
  • Real applications?
  • In general, what are the realistic applications
    of code generation for Earth System Models?
  • What will be the role of reverse engineering of
    existing model source codes?
  • How does the approach compare to other frameworks
    (e.g., BFG2, OASIS)? Can we generate
    inter-framework couplers?
  • The ECM and the JFOM are actually distinct
    technologies. What other uses can we imagine for
    them?

18
Thanks! Questions?
code generation its Springtime has finally come a
happy climate
