UNIX

1
UNIX LINUX Fundamentals for HPC

• A Short-Series Presentation by
• Evan Lee Turner
• David Carver
• January 24, 2008

2
Purpose of This Lecture

• Fundamentals of using UNIX and UNIX-like systems
• History of UNIX Linux
• Basic system commands
• Data Management
• Constructing basic shell scripts

3
History of UNIX

• "...the number of UNIX installations has grown to
  10, with more expected..."
• Dennis Ritchie and Ken Thompson, June 1972
• "... When BTL withdrew from the project, they
  needed to rewrite an operating system (OS) in
  order to play space war on another smaller
  machine (a DEC PDP-7 Programmed Data Processor
  with 4K memory for user programs). The result was
  a system which a punning colleague called UNICS
  (UNiplexed Information and Computing Service)--an
  'emasculated Multics' no one recalls whose idea
  the change to UNIX was
• A few years later, a colleague named Dennis
  Ritchie suggestd that they rewrite UNIX using the
  C language, which Dennis had recently developed
  from a language called B.
• - Graham Glass and King Ables, 2006

4
Early Movers and Shakers

• Dennis Ritchie Ken Thompson
• PDP11

5
And then there was C

• The idea that an operating system could be
  written in a high level language was an unusual
  approach at that time, since most people felt
  that assembly language was the only language fast
  enough for such an important component of a
  computer system
• - Glass and Ables, 2006

6
Bringing UNIX to the Desktop

• There were two different versions of UNIX SYSV
  and BSD
• Unix was very expensive
• Microsoft DOS was the mainstream OS
• MINIX, tried but was not a full port
• An open source solution was needed!

7
Linux 0.02 October 5, 1991

• Do you pine for the nice days of minix-1.1, when
  men were men and wrote their own device drivers?
  Are you without a nice project and just dying to
  cut your teeth on a OS you can try to modify for
  your needs? Are you finding it frustrating when
  everything works on minix? No more all-nighters
  to get a nifty program working? Then this post
  might be just for you -)
• - Linus Benedict Torvalds
• "I still maintain the point that designing a
  monolithic kernel in 1991 is a fundamental error.
  Be thankful you are not my student. You would not
  get a high grade for such a design -)" (Andrew
  Tanenbaum to Linus Torvalds)

8
1990s Movers and Shakers

• Richard Stallman, father of the GNU Project
• Linus Torvalds Linux Kernel

9
Linux Packaging

• Linus and his group developed a Linux kernel,
  which is the core of the operating system, but
  most distributions of Linux included the GNU
  software utilities developed by the Free Software
  Foundation in their distribution package.
• What most people refer to as Linux is mostly
  utilities and applications from the GNU project.
• The GNU utilities are also available on non-Linux
  systems. Even Windows!

10
GNU Project

• The GNU Project was launched in 1984 to develop
  a complete Unix-like operating system which is
  free software the GNU system.
• The GNU Hurd is the GNU project's replacement for
  the Unix kernel. The Hurd is a collection of
  servers that run on the Mach microkernel to
  implement file systems, network protocols, file
  access control, and other features that are
  implemented by the Unix kernel or similar kernels
  (such as Linux). In 2002 development in general
  has not met expectations, and there are still
  bugs and missing features.
• Developing a whole system is a very large
  project. To bring it into reach, I decided to
  adapt and use existing pieces of free software
  wherever that was possible. For example, I
  decided to use the X Window System rather than
  writing another window system for GNU.
• - Richard Stallman
• www.gnu.org and Richard Stallman

11
Why UNIX/LINUX is Still Used

• 30 years of development
• Many academic, scientific, and system tools
• Open Source
• System Stability
• Lightweight
• Easy Development
• Linux kernel, GNU software, and X windows are
  free software

12
The Basics

• Command-Line
• Interaction with UNIX LINUX is based on
  entering commands to a text terminal
• Oftentimes there are no warnings with commands,
  no undo
• The Shell
• The user environment that enables interaction
  with the kernel, or lower-system OS.
• Internet Explorer would be a shell for Microsoft
  Windows.

13
Common Shells

• sh The original UNIX shell still
  located in /bin/sh
• Bash is a Unix shell written for the GNU
  Project and is installed on most Linux systems.
• csh C Shell, modeled after the C
  programming language used by UNIX systems
• tcsh C Shell with modern improvements such
  as filename completion
• echo SHELL Displays what shell your account
  is using.
• chsh Changes your shell

14
Before We Go Further

• Read the Manual.
• man command
• man section command
• man k keyword (search all manuals based on
  keyword)
• Most commands have a built-in UNIX manual, even
  the man command!
• Commands without manuals have help too, with h,
  --help, or /? option.
• Google is your friend

15
The Manual

• The manual pages are divided into eight sections
  depending on type of command.
• 1 commands and applications
• 2 system calls
• 3 C library functions
• 4 special files
• 5 file formats
• 6 games
• 7 misc.
• 8 system administration utilities

16
Why Sections are Important
17
Conventions for this Lecture

• This lecture is too short to give you all of the
  options, so look at the manual for specific
  syntax for commands.
• Commands will be in bold, options will be in
  italics.
• command arguments
• Output will be shown in its own bordered table

18
Command Conventions

• In help files and manuals, commands will have
  required input and optional input
• cp OPTION source destination
• Optional arguments are in brackets, required
  arguments are not.
• cp R or cp - -recursive
• Short options -, long options - -

19
Directories

• What is a working directory?
• The directory your shell is currently associated
  with. At anytime in the system your login is
  associated with a directory
• pwd View the path of your working directory
• ls View your working directory

20
Whos Path is it Anyway?

• UNIX treats the directory structure as a
  hierarchy of individual paths

/
/ (root directory) /home /home/david
usr
home
dev
david
bin
21
Finding Your Home

• Each user has a home directory which can be found
  with
• cd
• cd david
• cd HOME
• The tilde character will tell the shell to
  auto-complete the path statement for the cd
  command
• HOME refers to an environment variable which
  contains the path for home.

22
More File Commands

• cd directory
• Change your current working directory to the
  new path
• ls l show hidden files
• Hidden files are files that begin with a period
  in the filename .
• mv Moves one file to another
• cp Copies files or directories
• rm Remove files directories
• rm rf Remove everything with no warnings
• rm rf Most dangerous command you can run!

23
Recursive Directories

• Oftentimes a manual will refer to recursive
  actions on directories. This means to perform an
  action on the given directory and recursively to
  all subdirectories.
• cp R source destination
• copy recursively all directories under source
  to destination

24
The Bit Bucket

• /dev/null
• Throw items away into /dev/null and they will be
  gone forever. Good place to redirect trash
  output to.
• Other interesting files on the system
• /dev/rand
• Psuedo random number generator
• /dev/zero
• Fill zeros. Very fast ,use with caution
  otherwise you may get nasty email from
  administrator.

25
Relative vs Absolute Path

• Commands expect you to give them a path to a
  file. Most commands will let you provide a file
  with a relative path, or a path relative to your
  working directory.
• ../directory the .. refers to looking at
  our previous directory first
• ./executable . says this directory, or our
  working directory
• Absolute, or Full paths are complete. An easy
  way to know if a path is absolute is does it
  contain the / character at the beginning?
• /home/user/directory/executable
• (a full path to file executable)

26
Poking Around in Home

• How much space do I have?
• quota
• Command to see all quotas for your
  directories, if any.
• How much space am I taking up?
• du
• Command to find out how much space a folder or
  directory uses.
• df
• Display space information for the entire
  system

27
Helpful Hints on Space

• Almost all commands that deal with file space
  will display information in Kilobytes, or Bytes.
  Nobody finds this useful.
• Many commands will support a -h option for
  Human Readable formatting.
• ls lh
• Displays the working directory files with a
  long listing format, using human readable
  notation for space

28
Representing Space

• Bit either a 1 or 0
• Byte 8 bits 0000 1111, or x0F, or 16
• KB, Kilobyte - 1024 Bytes
• MB, Megabyte 1024KB
• GB, Gigabyte 1024MB
• TB, Terabyte 1024 GB
• PB, Petabyte 1024 TB

29
Permissions

• The NIX systems are multi-user environments
  where many users run programs and share data.
  Files and directories have three levels of
  permissions World, Group, and User.
• The types of permissions a file can contain are

30
Permissions Cont.

• File permissions are arranged in three groups of
  three characters.
• In this example the owner can read write a
  file, while others have read access

31
Changing Permissions

• chmod
• Change permissions on a file or directory
• chown
• Change file ownership to another user
• Both options support -R for recursion.

32
All About Me

• Every userid corresponds to a unique user or
  system process
• whoami Returns the userid of the current
  user
• passwd Change password
• What is my group? support!

33
Everyone Else

• who Show all other users logged in
• finger Show detailed information about a
  user

34
What Everyone Else is Up To

• top
• Show a detailed, refreshed, description of
  running processes on a system.
• uptime
• Show the system load and how long the
  system has been up.
• load is a number based on utility of the cpus
  of the system.
• A load of 1 indicates full load for one cpu.

35
Working With Programs

• Commands or programs on the system are identified
  by their filename and by a process ID which is a
  unique identifier.
• ps Display process information on
  the system
• kill pid Terminates the process id
• c (controlc) Terminates the running
  program
• d (controld) Terminates your session.
• Only you and the superuser (root) have permission
  to kill processes you own.

36
Advanced Program Options

• Oftentimes we must run a command in the
  background with the ampersand character
• command options
• Runs command in background, prompt returns
  immediately.
• Match zero or more characters wildcard
• cp destination
• Copy everything to destination.
• This option can get you into trouble if misused

37
Editing Files

• emacs vs vi
• Among the largest nerd battle in history.
  emacs relies heavily on key-cords (multiple key
  strokes), while vi is mode based. (editor mode
  vs command mode)
• vi users tend to enter and exit the editor
  repeatedly, and use the Unix shell for complex
  tasks, whereas emacs users usually remain within
  the editor and use emacs itself for complex tasks

• pico (nano)
• editor originally used for the email client pine,
  simple no-frills editor which resembles notepad
  for windows.

38
Input and Output

• Programs and commands can contain an input and
  output. These are called streams. UNIX
  programming is oftentimes stream based.
• Programs also have an error output. We will see
  later how to catch the error output.
• STDIN standard input, or input from the
  keyboard
• STDOUT standard output, or output to the
  screen
• STDERR standard error, error output which is
  sent to the screen.

39
File Redirection

• Oftentimes we want to save output (stdout) from a
  program to a file. This can be done with the
  redirection operator.
• myprogram gt myfile
• Using the gt operator we redirect the output
  from myprogram to file myfile
• Similarly, we can append the output to a file
  instead of rewriting it with a double gtgt
• myprogram gtgt myfile
• Using the gt operator we append the output
  from myprogram to file myfile

40
Input Redirection

• Input can also be given to a command from a file
  instead of typing it to the screen, which would
  be impractical.
• cat programinput gt mycommand
• This command series starts with the command
  cat which prints a file to a screen.
• programinput is printed to stdout, which is
  redirected to a command mycommand.

41
Redirecting stderr

• Performing a normal redirection will not redirect
  sdterr. In Bash, this can be accomplished with
  2gt
• command 2gt file1
• Or, one can merge stderr to stdout (most popular)
  with 2gt1
• command gt file 2gt1

42
Pipes

• Using a pipe operator , commands can be
  linked together. The pipe will link the standard
  output from one command to the standard input of
  another.
• Very helpful for searching files

43
Searching

• A large majority of activity on UNIX systems
  involve searching for files and information.
• find Utility to find files
• grep The best utility ever written for
  UNIX, searches for patterns inside files and will
  return the line, if found

44
Packing Files

• When creating backups of files, or transferring
  to other hosts, files must be packed into larger
  files. This is needed for ease of manipulation,
  transfer speeds, and file management.
• tar
• Create or extract a packed file.
• tar stands for tape archive.

45
Compressing Files

• Compressing files can gain file space at the
  expense of cpu time to compress and decompress
  files.
• Compression works well for text files, but not as
  well for binary files with random data such as
  float values.
• Compression algorithms commands
• gzip, gunzip, bzip2, bunzip2

46
Using tar to Create Compressed Files

• Tar will create compressed files for you.
• tar czvf mytarfile.tar.gz directory
• Creates a compressed file named
  mytarfile.tar.gz containing all of the files
  in the directory directory
• tar xzvf mytarfile.tar.gz
• Uncompresses all directories and files inside
  the file mytarfile.tar.gz into the working
  directory

47
Testing Compression

• Using an example from a dataset of visual MRI
  binary data that is used for an application
  called Freesurfer three different compression
  methods will be tested. The dataset contains a
  mix of binary and text data.
• The collected data set, which includes 128
  individual 180KB binary files, is 42MB in
  uncompressed form.

48
The Dataset is Compressed using bzip, gzip, and
compress (Z)
49
Results

• The test shows that bzip compression is the most
  efficient at the expense of the most CPU time.
  gzip is generally a good all-around compression
  algorithm because it gives decent performance
  with an average CPU load.
• It is a good idea to test your own dataset.

50
Connecting to Another Machine

• Secure Shell vs Restricted Shell
• ssh is an encrypted remote login program that is
  secure to trust across non secure networks.
• rsh is a non-encryped version of ssh which is
  only used between sites that are inside secure
  networks. rsh will provide faster file transfer
  speeds.
• rsh and ssh take similar arguments
• ssh userid_at_hostname
• rsh userid_at_hostname

51
Copying Files to Remote Hosts

• Copy local file lfile to rfile on remote machine
  rsys
• scp lfile rsysrfile
• -p preserves modification time, access time and
  mode from original
• scp -p lfile rsysrfile
• Copy rfile from remote machine rsys to local file
  lfile
• scp -p rsysrfile lfile

52
Running Commands on a Remote Host

• Commands can be executed on a remote host with
  ssh and rsh
• rsh userid_at_hostname ls
• Run ls on remote host hostname

53
Advanced Movement

• tar -cf foldertoarchive bzip2 rsh
  archive.tacc.utexas.edu "cat gt
  ARCHIVE/myfile.tar.bz2
• This statement creates a bzip tar file and sends
  it to the remote host archive.tacc.utexas.edu
• What is nifty about this
• Since the command is inline, no local backup
  copy is created on the local host.

54
Basic Shell Scripts

• Many times it is helpful to create a script of
  commands to run instead of typing them in
  individually. Scripts can be made to aid in
  post-processing, system administration, and to
  automate menial tasks
• !/bin/bash
• First statement inside a script, will list
  which shell to run this script in
• Says what will follow is a comment and not to
  execute

55
Variables

• By convention system variables are capitalized
• HOME Location of the home directory
• OLDPWD Location of the previous working
  directory
• PATH Locations to look inside for
  executable files
• Setting system variables differs by shell.
• bash uses export
• csh uses setenv
• User defined variables in scripts are lower-case
  by convention
• myvariable10 Sets myvariable to 10
• echo myvariable Prints myvariable

56
My Environment

• View all system variables by the command env
• Depending on shell, startup commands can be
  managed with the files .profile for bash and
  .cshrc with C shell

57
Conditionals

• if condition then condition is zero (true
  - 0) execute all commands up to else statement
  else if condition is not true then execute
  all commands up to fi fi

58
Multilevel Conditionals

• if condition then condition is zero
  (true - 0) execute all commands
• up to elif statement elif condition1 then
• condition1 is zero (true - 0) execute all
  commands up to
• elif statement elif condition2
• then
• condition2 is zero (true - 0) execute all
  commands up to
• elif statement else None of the above
  condtion,condtion1,condtion2 are true (i.e.
  all of the above nonzero or false) execute all
  commands up to fi fi

59
Performing Loops

• Loops are statements that are repeated until the
  conditions are met.
• for variable name in list
• do
• execute one for each item in the list until the
  list is not finished (And repeat all statements
  between do and done)
• done
• for i in 1 2 3 4 5
• doecho "Welcome i times
• done

60
While Loop

• while condition
• do
• command1
• command2
• command3 .. ....
• done

61
Putting it Together

• !/bin/bash
• my first script
• scp replacement
• remotefilelabresults
• myserverhome.utexas.edu
• mylsinfossh myserver -la remotefile 2gt1
• ismissingecho mylsinfo grep ERROR
• if "ismissing"
• then
• echo "remotefile not found! Exiting!"
• else
• ssh -n "cat lt remotefile" gt localfile
• fi

62

• mylsinfossh myserver -la remotefile 2gt1
• Backticks are used to place output from a
  command into a variable
• if "ismissing"
• Is ismissing set (has a value)?
• If so then the expression is true, otherwise
  false

63
What Were Getting at Here

• Tools have been written to interact with the tape
  archive system, which will be announced this
  week. This is in conjunction with the
  announcement for the archive replacement system,
  ranch.
• module load sinc
• sinc Archive data to tape
• unsinc Unpack data from tape
• rls Remote ls

64
Remote LS

• !/bin/bash
• myls(echo ARCHIVER grep archive
  gt/dev/null echo "/etc/dmf/dmbase/bin/dmls")
  (echo ARCHIVER grep ranch gt/dev/null echo
  "/opt/SUNWsamfs/bin/sls")
• if "myls"
• then
• rsh ARCHIVER -n "myls "
• else
• echo "archiver not found"
• exit 1
• fi

65
References

• Graham Glass King Abels UNIX for Programmers
  and Users SE 1999
• Mark G. Sobell A Practical Guide to UNIX System
  V1985
• Amir Afzal UNIX Unbounded A Beginning Approach TE
  2000
• http//www.english.uga.edu/hc/unixhistoryrev.html
• https//netfiles.uiuc.edu/rhasan/linux/
