Fitness Identification Tracking System FIT System

1
Fitness Identification Tracking System (FIT
System)

• Scott Bugenhagen - Engineer
• Pamela Duda Assistant Project Manager
• Nicole Gregor Project Manager
• Joshua Leeder - Engineer
• Daniel Shefchik - Engineer

2
Project Objective

• Develop a fitness tracking system for use in
  athletic facility running tracks such as is in
  the Kern Center
• Lap counter
• Lap times
• Energy expenditures
• Heart rate tracking
• Distance
• Average speed

3
Components
RFID transponders
RFID reader
RFID antenna
Wristwatch Cheststrap
4
Components continued
Wireless Transceiver Module
Microcontroller
Database (Software)
5
Block Diagram of the FIT System
6
Potential Market Places

• Private and public heath clubs
• 2,400 YMCAs
• 40 million members
• Elementary and Middle Schools
• High Schools
• Colleges

7
Market Competition

• Patent 6,823,036
• Wrist watched-typed pedometer with wireless
  heart rate monitor
• Patent 6,418,394
• Measuring device and method of controlling
• Patent 6,345,197
• Age based heart rate target zone method and
  apparatus
• Patent 6,334,848
• Remote Pedometer
• Other products use GPS technology to monitor
  distance and speed

8
Equipment List
9
Quality Function Deployment (QFD)
10
Survey Objectives

• Investigate interest in the FIT System for the
  Kern Center
• Determine interest for different features under
  consideration
• Solicit input as to possible additional features
  to improve the product

11
Survey Results

• Question one
• A) Would you be interested in using an exercise
  tracking system in the Kern Center?
• B) If yes, how often would you use the system per
  week?

12
Survey Results

• Question 1 continued
• C) How often do you work out per week at the Kern
  Center?
• Question 2
• What features would you be interested in having
  in this system?

13
(No Transcript)
14
Survey Results

• Question 3
• Please write any other features that you would be
  interested in
• Weightlifting features
• Step counter
• MP3 player

15
House of Quality
16
Heart Rate
17
How to Find Max Heart Rate

• Used to find level of physical exertion
• Formula for Males
• 210 - 0.5(age) 0.05(weight) 4 Max HR
• Formula for Females
• 210 - 0.5(age) 0.01(weight) Max HR

18

• Five exercise heart rate zones
• 50 to 60 max heart rate
• 60 to 70 max heart rate
• 70 to 80 max heart rate
• 80 to 90 max heart rate
• 90 to 100 max heart rate
• Each zone represents a different level of
  physical exertion

19
Weight Exercise
20
Workout Intensity Energy Sources

• High intensity workouts ? carbohydrates
• limited amount of glycogen can be stored in
  muscles sustainable only for short periods of
  time
• Low intensity workouts ? fat
• large stores of fat sustainable for long
  periods of time

21
Calorie Charts
Calories burned per minute while running
Calories burned per minute while walking
Mackenzie, Brian. "Energy Expenditure. Sports
Coach. 5 Nov. 2004 lthttp//www.brianmac.demon.co.u
k/energyexp.htmgt.
22
Relationship between exercise intensity and
energy source
Mackenzie, Brian. "Exercise Intensity Energy
Source. Sports Coach. 5 Nov. 2004
lthttp//www.brianmac.demon.co.uk/ensource.htmgt.
23
RFID Technology
24
Basics

• Use of EM (radio) waves to send/receive signals
  between a transponder or RF tag and transceiver
  (with decoder)
• Antennas exist in many shapes
• can be built into doorways, tollbooths, etc.
• Electromagnetic Frequency can be constantly
  present or activated by sensor

25
Passive RFID

• Reflects/absorbs small amount of energy from
  readers signal to generate its own signal, ie.,
  no battery
• Reader must produce large amt. of power
• Small range (lt3m)- only produces power within
  reader range, tag can only transmit very weak
  signal
• Lower cost, longer life than active RFID tags

26
Modern Uses of RFID

• Basic categories
• Transportation and logistics
• Manufacturing and processing
• Security
• Other examples
• Postal tracking
• Electronic monitoring of offenders at home
• Sport time recording

27
RFID Standards
28
Standards

• Currently no universal standards are set for RFID
  frequencies
• ISO (International Standards Organization)
• Sets the standards for many technological devices

• based in Geneva, Switzerland
• Set frequency standards for RFID tags in 2004
  (ISO 18000 series)

29
ISO Standards for RFID Air Interfaces (18000
Series)

• Part 1- generic parameters for air interface
  communication for globally accepted frequencies
• Part 2- parameters for air interface
  communications below 135 KHz
• Part 3- Parameters for Air Interface
  Communications at 13.56 MHz
• ISO standard for high frequency
• Has read/writing capability

30
ISO Standards for RFID Air Interfaces (18000
Series)

• Part 4- Parameters for Air Interface
  Communications at 2.45 GHZ
• Part 5- Parameters for Air Interface
  Communications at 5.8 GHz
• Part 6- Parameters for Air Interface
  Communications at 860-930 MHz
• Part 7- Parameters for Air Interface
  Communications at 433.92 MHz

31
Wireless Technology
32
Components of a Wireless System
33
Wireless Standards
34
WiFi

• Advantages
• A WiFi network already exists in the Kern Center
• Large bandwidth allows high data transfer rates
• Disadvantages
• High data rate requires large power consumption
• Relatively large circuit board size
• Requires additional hardware to handle ethernet
  style interface
• Network may not cover entire running track
• Operates at resonant frequency of water (2.4GHz)

35
ZigBee

• Advantages
• Range may be adequate
• Narrower bandwidth requires less power
• Small size and low cost
• Disadvantages
• Controller software is complex and difficult to
  learn
• Implementation requires at least 64k of flash
  memory (requires expensive microcontroller)
• Mesh networking is required for reliable
  performance

36
Bluetooth

• The short range would be prohibitively
  problematic
• This standard would not be a good choice for our
  design

37
Proprietary Solutions

• Many proprietary wireless modules offer numerous
  advantages over the standardized solutions
• Longer range
• Better performance
• Easier to implement
• Offer other features such as low power and sleep
  modes that arent present in the standards based
  solutions

Aerocomms AC4790 Transceiver
38
Project Timeline
39
References

• Engineering and Technical Aspects of the Products
• RFID ARTICLES REFERENCES
• Heim, K. (2004, Oct). Razing the bar code Radio
  frequency identification, or RFID, devices have
  the potential to transform business and sow the
  seeds of the next technology wave Fourth
  Edition-Electronic Version. Seattle Times, C.1.
• Melcer, R. (2003, Mar). New security system
  combines biometrics with radio-frequency
  identification Electronic Version. Knight Rider
  Tribune News Service, pg. 1.
• Worlds first smart RFID medication bottle
  Electronic Version. (2004, Mar). Canada
• Newswire, pg.1.
• Jerney, J. (2004, Apr). Tag me The world of
  radio frequency identification Electronic
  Version. The Daily Yomiuri, pg. 1.
• Deleney, K.J. (2002, Sep). Beyond bar codes
  Radio id tags may soon be placed in every product
  imaginable Electronic Version. Wall Street
  Journal (Europe), R.3.
• Seattle marathon runners tracked in real time
  with Texas Instruments RFID technology
  Electronic Version. (2000, Nov). Business Wire,
  pg. 1.
• RFID INFORMATIVE REFERENCES
• Savi Technologies. Active and passive RFID Two
  distinct, but complimentary,
• technologies for real-time supply chain
  visibility (Part 1). Retrieved September

40
References

• Existing Products
• Booth-Thomas, Cathy. The See-It-All Chip.
  Time.com. 9/22/03. Time, Inc. 10/5/04.
  lthttp//www.time.com/time/globalbusiness/article/0
  ,9171,1101030922-485764,00.htmlgt.
• ChampionChip. ChampionChip. 10/5/04.
  lthttp//www.championchip.com/home/index.phpgt.
• RFID Race Timing Systems Pamphlet. 11/02.
  RFID Race Timing Systems. 10/5/04.
  lthttp//www.rfidtiming.com/RFID_Race_Timing_System
  s.pdfgt.
• RFIDtalk.com. 10/5/04. Jelsoft Enterprises,
  Limited. 10/5/04. lthttp//www.rfidtalk.comgt.
• Summary of Conference Proceedings Concerns of
  RFID in Industry
• McGraw Hill Construction. E-Construction
  Innovation. 2004. 18 Oct. 2004.
  lthttp//enr.construction.com/features/technologyEc
  onst/archives/040621n.asp.gt
• McGraw Hill Construction. Next Phase of Baggage
  Screening Goes In-line, Out of View. 2004. 18
  Oct. 2004. lthttp//www.construction.com/NewsCenter
  /Headlines/
• ENR/20031215e.aspgt.
• ProQuest. Precision Dynamics Corporation to
  Showcase Multi-Function RFID and Bar Code Reader
  at the smart Healthcare Conference. 2004. 4 Oct.
  2004. lthttp//proquest.umi.com/pqdwebgt.
• ProQuest. SeeBeyond and SBK Labs Announce
  Alliance Agreement to Develop on
• demand Composite Applications for RFID. 2004. 4
  Oct. 2004. lthttp//proquest.umi.com/pqdwebgt.
• RFID Journal. Frequently Asked Questions. 2004. 6
  Nov. 2004. lthttp//www.rfidjournal.com/article/art
  icleview/207gt.

41
References

• Medical/Clinical Foundations and
  Discipline-Specific Literature
• HEART REFERENCES
• (Heart 1) -. "Aerobic Training." Netfit. 5 Nov.
  2004 lthttp//www.netfit.co.uk/wkaer.htmgt.
• (Heart 4) Crupi, Jeffreyl. "Strengthening Your
  Heart." Teaching Pre K-8. Norwalk Feb
  2004. Vol. 34, Iss. 5  pg. 12. 18 October 2004.
  lthttp//gateway.proquest.com/openurl?url_verZ39.8
  8-2004res_datxripqdrft_val_fmtinfoofi/fmtke
  vmtxjournalgenrearticlerft_datxripqddid00
  0000534825551svc_datxripqilfmthtmlreq_datxr
  ipqilpq_clntid9090gt.
• (Heart 7) Mackenzie, Brian. "Heart Rate Training
  Zones." Sports Coach. 5 Nov. 2004
  lthttp//www.brianmac.demon.co.uk/hrm1.htmgt.
• (Heart 5) Mackenzie, Brian. "Maximum Heart Rate."
  Sports Coach. 5 Nov. 2004 lthttp//www.brianmac.dem
  on.co.uk/maxhr.htmgt.
• WEIGHT REFERENCES
• (Weight 1) Mackenzie, Brian. "Facts about Fat.
  Sports Coach. 5 Nov. 2004
• lthttp//www.brianmac.demon.co.uk/fat.htmgt.
• (Weight 2) Mackenzie, Brian. Fat Burning Zone."
  Sports Coach. 5 Nov. 2004
• lthttp//www.brianmac.demon.co.uk/fatburn.htmgt.
• (Weight 3) Waehner, Page. "The Truth About the
  Fat Burning Zone." About. 5 Nov.
• 2004lthttp//exercise.about.com/cs/cardioworkouts/1
  /aa022601a.htmgt.
• BLOOD PRESSURE REFERENCES
• (BP 1) -. "Blood Pressure Chart." Netfit. 5 Nov.
  2004 lthttp//www.netfit.co.uk/ty4.htmgt.
• (BP 2) -. "Definition of Blood Pressure." 5 Nov.
  2004 lthttp//www.icomm.ca/geneinfo/glos-b.htmgt.

42
References

• ENERGY USAGE REFERENCES
• (Energy 1) Mackenzie, Brian. "Energy
  Expenditure. Sports Coach. 5 Nov. 2004
  lthttp//www.brianmac.demon.co.uk/energyexp.htmgt.
• (Energy 2) Mackenzie, Brian. "Energy Pathways.
  Sports Coach. 5 Nov. 2004 lthttp//www.brianmac.dem
  on.co.uk/energy.htmgt.
• (Energy 3) Mackenzie, Brian. "Exercise Intensity
  Energy Source. Sports Coach. 5 Nov. 2004
  lthttp//www.brianmac.demon.co.uk/ensource.htmgt.
• (Energy 4) Mackenzie, Brian. "Lactic Acid.
  Sports Coach. 5 Nov. 2004 lthttp//www.brianmac.dem
  on.co.uk/lactic.htmgt.
• (Energy 5) Mackenzie, Brian. "Muscle Types.
  Sports Coach. 5 Nov. 2004 lthttp//www.brianmac.dem
  on.co.uk/muscle.htmgt.
• (Energy 6) Mackenzie, Brian. "Oxygen Debt.
  Sports Coach. 5 Nov. 2004 lthttp//www.brianmac.dem
  on.co.uk/oxdebit.htmgt.
• (Energy 7) Mackenzie, Brian. "VO2 Max. Sports
  Coach. 5 Nov. 2004 lthttp//www.brianmac.demon.co.u
  k/vo2max.htmgt.
• -.Grant Application Basics. National Institute
  of Health. 11 May 2005 13 May 2005.
  lthttp//www.niaid.nih.gov/ncn/grants/basics/basics
  _pf.htmgt.
• 2LXE, Inc. (2003). RF/Wireless basics An
  intro to wireless data collection networks,
  products, standards and solutions. Retrieved May
  5, 2005, from http//www.rmsomega.com/documents/Wh
  ite_Paper_RF_Basics.pdfsearch'RF/
• Wireless20Basics'
• Maney, Kevin "Club Health Integrated Personal
  System." USA Today. 9 May 2005.lthttp//www.usatoda
  y.com/printedition/money/20041222/5b_maney_22.art.
  htmgt.
• 1McConnell, E. A. (2000). Wireless technology
  Freedom to roam electronic version. Retrieved
  May 5, 2005, from http//www.findarticles.com/p/ar
  ticles/mi_qa3689/is_200009/ai_n8903946
• 3Montgomery, S. (2004). Wireless 101
  Components of an embedded wireless link.
  Retrieved May 5, 2005, from http//www.radiotronix
  .com/datasheets/W101-
• CEWL.pdf
• 4Montgomery, S. (2004). Wireless 101 Designing
  robust embedded wireless systems. Retrieved May
  5, 2005, from http//www.radiotronix.com/datasheet
  s/W101-
• DREWS.pdf
• -. "Physi-Cal Mio Select Heart Rate Monitor."
  REI. 29 April 2005. lthttp//www.rei.comgt.
• -. "Physi-Cal Mio Sport Heart Rate Monitor
  Watch." REI. 29 April 2005.lthttp//www.rei.com/pro
  duct/47860832.htm?gt.

43
Questions?
