SafeHull Condition Assessment Program SH CAP

1
SafeHull Condition Assessment Program (SH CAP)
Presented to INTERTANKO On 24 July 2003 in Miami,
FL
2
ABS SH Condition Assessment Program
History

• Initiated in 1995, with SH development and VELA
  requirements for CAP ratings.
• Has included a fatigue analysis and buckling
  check since 1995, became mandatory with the BP
  requirement in 2001.
• Has maintained its structure since its inception,
  assess the whole vessel.
• Has adjusted to industry requirements

3
ABS SH Condition Assessment Program
History

• Over 250 vessels through program to date. On
  pace for 65 this year.
• More charterers initiating CAP requirements,
  such as STATOIL, and Petronas.
• New players including Governments such as
  Indias announcement that foreign flag vessels
  over 20 years must have CAP 1 or 2 to enter
  terminals in India.

4
ABS Condition Assessment Program

• Review of Class Records (Only IACS classed
  vessels)
• Fatigue Analysis to inform the owners surveyors
  of areas of concern
• SafeHull Condition Assessment Survey
• Verification of Gaugings
• SafeHull Structural Evaluation
• Grade assigned by Committee

5
1. Review of Class Records

• Review of Class Records (IACS members)(LR, ABS,
  DNV, RINA, )
• Used by surveyors on board.
• Used by engineers for fatigue analysis for any
  modifications / steel renewals / repetitive
  fractures or lay-up periods.
• Not normally a deliverable.

6
2. Fatigue Analysis

• Fatigue assessment of longitudinal stiffener
  connections.
• Fatigue assessment projected for 5 years.
• Identification of critical areas for owners and
  surveyors prior to survey.
• Identify areas for increased monitoring or repair.

7
(No Transcript)
8
(No Transcript)
9
3. Condition Assessment Survey (Onboard)

• Independent of Class survey. But can be done in
  conjunction with ISH or SSH.
• Two approved surveyors.
• Close-up surveys of hull, machinery, equipment.
  This includes a close-up of 100 of the ballast
  and cargo tanks in the cargo block.
• Close-up survey of Hot Spot areas identified
  by fatigue analysis.
• Survey of vessel on dry-dock or UWILD.
• Representative photographs (Over 200).

10
4. Verification of Gaugings

• Three girth belts within the 0.4L (cargo area)
  for tankers
• Surveyors will verify scope and accuracy of
  gaugings. The gaugings are conducted by clients
  contractor (ABS-approved external specialist)
• Input for structural (strength) evaluation of
  current condition

11
5. SafeHull Structural Evaluation

• Strength of current structure compared to
  SafeHull criteria. Then against the as built
  requirements.
• S Curvesrenewal requirements vs. as gauged.
• Identify areas for increased monitoring or
  repair. A vessel with substantial corrosion,
  although OK for Class will not receive a Grade 2
  unless repaired within the 120 day survey period
  for the CAP.

12
SafeHull Structural Evaluation

• Buckling
• Since its inception in 1995 SafeHull has
  incorporated the t3 minimum thickness (using the
  as-gauged condition) for buckling as a rule
  requirement for plates.
• Due to an influx of lighter scantling vessels
  applying for SHCAP a buckling check was added to
  the program in 2002 to address the deck and
  bottom longitudinals. This calculation uses the
  industry standard b/t (h/t) criteria.
• We use the h/t requirement as a first indicator
  and can do additional calculations to determine
  the minimum web thickness.

13
SH CAP Structural Evaluation Categories

• No special comments or attention
• Under Class Every member is allowed to corrode
  a certain percentage before it must be replaced.
• SafeHull modifies this percentage it establishes
  a new as-built requirement for each member.
• In Strength the member properties are greater
  than 105 of the SafeHull renewal value.
• In Fatigue the connection has a continued life
  expectancy over the next 5 years.
• I.e., no additional requirements or attention
  beyond the normal Class requirements.

14
SH CAP Structural Evaluation Categories

• Less sensitive
• In Strength the member properties are between
  100 and 105 of the SafeHull renewal value
  (Current ABS rules).
• If the member is Category 2 because of corrosion
  should be scheduled for replacement during next
  DD.
• In Fatigue the connection has an increased
  probability of failure in the next 5 years.
  Actual probability depends on age of vessel,
  trading conditions, time spent in DD.
• These members require increased monitoring and
  identified as must seen during regular
  inspections. For ABS-classed vessels these
  members may be passed on to ABS Class Document
  Center.

15
SH CAP Structural Evaluation Categories

• Most sensitive
• In Strength the member is less than 100 of the
  SafeHull requirement
• In Fatigue the connection has a likely
  probability of failure in the next 5 years.
  Actual probability depends on age of vessel,
  trading conditions, time spent in DD.
• These members require replacement or increased
  monitoring on an annual or more regular basis.
• For ABS-classed vessels These members are passed
  on to ABS Class Document Center.

16
What is Critical?
i.e., items that will be reported to Class for
regular inspection

• Category 3 in Section Modulus (the vessel no
  longer has 90 of the IACS required Section
  Modulus and MAY be considered for Class removal).
• Category 3 in Fatigue (likely probability of
  failure within the next 5 years).
• Category 3 in Strength Analysis - if substantial
  corrosion exists (less than 100 of SafeHull
  required renewal value remains). Vessel can not
  receive Grade 1 or 2 with Substantial
  corrosioni.e., items in Category 3 in Strength
  that do not have substantial corrosion may not
  necessarily require immediate repair (especially
  if they do not have history of failure)

17
What is Increased Monitoring?
The vessel meets Class requirements but the
following items do not meet SafeHull requirements
and need to be examined more often than every 5
years

• Category 3 in Fatigue Repair or Inspect
  annually. The grading committee determines.
• Category 2 in Fatigue Inspection on an annual or
  2.5 years interval (inspections after SEVERE
  weather, minimum).
• Category 3 in Strength Analysis no substantial
  corrosion and no history of failures - inspect on
  an annual basis or 2.5 years along with the
  Category 2 connections.

18
6. Condition Assessment Grading
Committee is made up of designated survey,
engineering, technology and management staff to
keep consistent application of the grading
process. Each member has a designated alternate
to assist in keeping the process moving.
19
Deliverables for Condition Assessment

• Executive Summary
• Description of Program and the recap of the
  vessel grading
• Inspection Recommendations for Class Society
• Certificate with Grade
• Structural/Fatigue Analysis
• Condition Assessment Survey Report
• Photographs (To be provided electronically)

20
SHCAP Improvementsduring the last year

• ABSC Average Certificate Turnaround Time
  7.0 weeks vs. 14.0 weeks for Competition
• Improved Overall Report Format, and include a
  Table of Recommendations Related to Fatigue
  Analysis/Structural Evaluation.
• Length for SHCAP moved 150 m to 130 m in
  length.
• Reduction in Size of Deliverables.

21
SHCAP Improvementscoming in 2003

• Clearer presentation of gauging data relative
  to required.
• All deliverable information to be provided on
  CD
• SHCAP to cover LNG vessels

22
Comments/Questions?
