WIND

1
WIND

• Janice Moynihan
• Lorelei Schmitt
• Danielle Roy
• 3.6.2005

2
Finding Available Wind Energy

• POWER in the wind (P, watts)
• P.5?Av3 , where
• ? is air density (at sea level .6125 metric or
  .00508 US)
• A is area intercepting wind (m2 or ft2) need
  wind swept area to find A
• v is instantaneous wind velocity (m/s or mph)

3
Finding Available Wind Energy

• To compare P and V at two different sites
• with this equation want to know what the
  relationship between the power at sites with
  different wind speeds
• P2 /P1(V2/V1)3 cubed relationship remember
  Power equation
• ex. If wind speed is 20 greater at one site
  compared to another, the power will be about 73
  greater at that site because of cubic
  relationship.
• when comparing units do not matter

4
Finding Available Wind Energy
r

• Wind Swept Area
• A pr2, where
• r length of 1 blade
• Comparing rotor diameter
• A2/A1 (R2/R1)2 square relationship remember
  area equation
• A wind turbine with a bigger rotor will almost
  always produce more electricity regardless of
  generator rating. ? Important in estimating
  turbines potential.

5
Finding Available Wind Energy

• Distribution of wind speed over time
• estimate/designate resource by annual average
  wind speed
• in off-grid system (w/ batteries) monthly
  average wind speed is used
• periods of gusty wind contribute more to annual
  energy production, steady winds produce less
  power over time
• sum of cube of different wind speeds over time
  amounts to more than cube of average wind speed
• CUBE FACTOR hypothetical distribution that
  accounts for changes in wind speed (temperate
  climates use Rayleigh distribution for
  approximation)

6
http//www.bergey.com/Maps/World.Wind.Lg.htm
If resource measurements are not available by
either direct measurement at site or from a
nearby meteorological station, then a Rayleigh
distribution is used.
7
Finding Available Wind Energy

• Increasing speed and power with height
• assume wind spd. Measurements at least 10m (33ft)
  above ground
• taller towers more power available in less
  turbulent winds

Use Power Law Method V/Vo(H/Ho)a, where Vo
is wind speed at original height V is wind
speed at new height Ho is original height H is
new height a (alpha) is surface roughness
exponent

• Increasing tower height increases wind speed
  exponentially.
• Over rough terrain, alpha 0.25. Over smooth
  terrain (water/ice), alpha 0.1

equation for relationship between power and
height also, just remember cubed
8
Finding Available Wind Energy
Gipe (1999)
9
Gross Amount of Energy Small Turbines Offer (3
methods)

• Manufacturers Specifications
• what to expect from turbines under standard
  conditions with Rayleigh dist. at sea level
• when they present information as range of values
  it reflects uncertainty in estimates of
  performance
• Suppliers of off-grid, battery charging turbines
  present info in kWh/month rather than kWh/year
• Power Curve Method
• no accurate power curves published, all
  guesstimation
• know distribution of wind speed, match to power
  curve, sum energy produced by turbine over range
  of speeds represented by Rayleigh dist.

10
Gross Amount of Energy Small Turbines Offer (3
methods)

• Wind Swept Area Method
• Do-It-Yourself
• Use rotor swept area and avg. annual wind speed
  under ideal conditions to estimate AEO (annual
  energy output)
• Most aerodynamic of turbines CAPTURE 40 of wind
  energy (not the same thing as how much energy it
  INTERCEPTS) ? their generators convert 90 or
  less of energy delivered to them
• OVERALL CONVERSION EFFICIENCY of 20-30 CAPTURE
  of energy available in wind
• perform best in low wind regimes (4-5 m/s or
  9-11 mph)

11
Gross Amount of Energy Small Turbines Offer (3
methods)

• To calculate AEO
• AEO ?Av3cube factor8760h/yr capture(1
  kW/1000W) _____ kWh/yr , where
• ? is air density .00508 US or .6125 metric
• A is wind swept area
• cube factor is 1.9 (for Rayleigh dist. in
  temperate climates)
• wind capture is 20
• this calculation gives the annual kWh that your
  turbine will supply
• compare against load calculation

12
Gross Amount of Energy Small Turbines Offer

• Rarely all the energy intercepted by a turbine is
  captured (put to use) ? usually only 20
• Losses
• Only operating efficiently at rated wind speed
  (usually in low regimes 4-5 m/s or 9-11 mph)
• Full batteries do not accept any more power even
  if turbines are pumping it out ?goes to dump
• Inefficiency of battery storage
• Inverter losses when converting stored DC to AC
  appliances
• Only 70 of the energy delivered to the
  batteries is eventually used productively
• Add 10 for other negligible losses
• this is where in AEO eq. 20 wind capture comes
  from

13
Types

• 3 blades
• Fiberglass or carbon fiber
• Tail vane that furls
• Heavier (weight of turbine relative to wind swept
  area), rugged turbine
• Permanent-magnet, induction alternator
• Micro-, mini-, household-size turbines

14
Off-the-Grid Applications
15
Hybrid Wind and Solar Systems

• Improves the reliability of a stand-alone system
• Cost effective
• Addition of a small amount of wind capacity can
  significantly boost the total energy available

16
Gipe (1999)

• Batteries and inverters are critical to the
  success of a hybrid system
• Energy storage
• Conversion of DC to AC
• Battery storage is expensive, use of both wind
  and solar energy works to offset this cost
• Improvements of inverter technology have made it
  easier to live off the grid with AC appliances
• DC Source Center eases the integration of the
  wind turbine, battery, and inverter

17
Village Power

• Most rural areas worldwide fall beyond the
  utility network, leaving millions without access
  to electricity
• Hold the potential of a huge market for wind and
  solar hybrids
• Use the same components as off-grid systems in
  developed countries, but in areas where 1
  kilowatt of energy goes a long way

18
Interconnected or Utility Intertie
19

• Induction generators used to synchronize its
  voltage and current with those of the utility
• Modern inverters allow any battery-charging wind
  turbine to produce utility compatible electricity
• If demand exceeds supply, energy is drawn from
  the utility to recharge the batteries
• If there is a surplus generation of electricity,
  the system can feed the excess back to the
  utility network

20

• Ideally, these systems allow for the use of the
  utility as a battery
• Often run into problems because paid less than
  the cost of electricity
• To avoid a surplus, many have begun to match
  consumption with available wind or decreased the
  size of their turbine
• Net metering allows individuals to run their
  kilowatt-hour meter backwards
• Only offered in 22 states in the U.S
• Most states limit it to 10 kW, but in some the
  limit is higher

21
Buying Small Turbines
22
Appropriating Size

• What are you power expectations?
• Small vacation house? Compliment to PV panels?
• Add up you anticipated electrical usage with the
  sites wind availability to determine size of
  turbine needed
• Generally price per Kwh decreases with larger
  turbine diameters.but larger towers/turbines are
  more expensive to purchase

23
Choosing Economically

• Do not only look at price, quality and
  reliability are very important in this sort of
  purchase.
• A good measure is the price of the turbine
  relative to the area swept by its rotor (/m2 or
  /ft2)
• NRELs cost performance ratio purchase
  price/annual energy output

24
Tower Selection

• Tower must be matched to turbine
• Critical to have an appropriate clearance between
  rotor blades and the tower
• Must be able to install and service turbine
• A low-cost and user friendly tower is the
  tilt-up, guyed tubular mast
• NRG makes a well-priced, reliable, and
  installation-easy friendly tower

25
Building your own tower?

• Building your own tower is not recommended.
• If one is feeling determined to build his or her
  own windmill, contact the Centre for Alternative
  Technology in Wales

26
Control Panels

• Control panels are not essential for micro/mini
  turbines but can
• -help one know how the turbine is performing
• -provide a brake switch
• -provide current protection
• World Power provides an attractive control panel

27
How about used turbines?

• Be weary. Be especially skeptical of turbines
  from old large wind farms
• Feel free to call companies and ask for more
  information on how old the unit may be.
• A good resource for finding wind turbines is the
  classifieds in Home Power magazine (which I sure
  hope Gary Flos got a subscription to)

28
Cutting Prices

• Overall, it is hard to cut prices without
  sacrificing reliability
• Collective buying? The govt has done it
• Subsidies?
• Generally only large scale operations are
  eligible
• There may be state-specific experimental
  technology subsidies available, check it out

29
Siting and Safety
30
Siting

• Need Distance From Buildings/Trees
• -To avoid obstruction to wind, enhancing output
• -To reduce noise
• -30 feet above trees/houses recommended
• -Towers should be at least 30-60 feet tall

31
Siting Donts

• Dont mount on roof because house acts an
  obstruction
• Dont mount on trees
• Urban wind doesnt work for practical purposes
• Dont put anchors, guy cables near traveled ways
  including roads and footpathsIf there are farm
  animal fence-in these parts

32
Safety-Maintenance Musts

• No loose long hair, loose clothing, or jewelry
  around turning shaft
• Halt all turbines before performing maintenance
• Never work beneath an operating turbine
• Service turbine regularly to increase life
  expectancy (twice a year, spring and fall)

33
Safety-Electrical Precautions

• Disconnect power supply from turbine to avoid
  electricution
• Fuse all power sources to batteries
• Use caution when working with batteries

34
Installing Small Turbines

• Remember that turbines will need repairswhat
  goes up must come down

35
Tower Raising-Tilt up

• Can be dangerous
• Truck or farm tractor can be effective in raising
  tower IF one has experience around heavy
  equipment
• When using a truck/tractor there needs to be a
  minimum of six people helping (hand signaler,
  driver, and anchors)
• Guyed towers are cheaper and easier to install

36
Griphoists

• Good way to raise tower, can feel tension (but
  may need to adjust tension while raising tower)
• Tractels Super Pull-All is a great model
• If you are going to buy anything for wind
  turbine, buy a griphoist
• Better than hoists
• Readily portable
• Easier to control

37
Tower Conductors

• Never hang from wind turbine leads
• On guyed towers, thread down mast and secure with
  strain relief
• Use in-line compression connectors for making
  vibration-proof connections between wind turbine
  leads and cables carrying power down tower

38
Wind-The Energy of the Future?
39
Winds Future

• Growing demand for small turbines, especially in
  developing countries
• In rural areas it may be cheaper to install and
  maintain hybrid power systems than installing
  lightly used distribution lines
• Certification and standardized testing will
  improve technology
• Commercial wind power growth will advance small
  wind turbines as well
