Informal Tools for Multimodal, Context-based User Interface Design

1
Informal Tools for Multimodal, Context-based User
Interface Design

• James A. Landay
• July 7, 1999
• HCC Retreat

2
Natural Tides of Innovation
??
Innovation
Universal Computing
Integration
Personal Computer Workstation Server
Log R
Minicomputer
Mainframe
7/99
Time
3
Universal

• 1 including or covering all or a whole
  collectively or distributively without limit or
  exception
• 2 a present or occurring everywhere b
  existent or operative everywhere or under all
  conditions ltuniversal cultural patternsgt
• 3 a embracing a major part or the greatest
  portion (as of mankind) lta universal stategt
  ltuniversal practicesgt b comprehensively broad
  and versatile lta universal geniusgt
• 4 a affirming or denying something of all
  members of a class or of all values of a variable
  b denoting every member of a class lta universal
  termgt
• 5 adapted or adjustable to meet varied
  requirements (as of use, shape, or size)

4
Away From the Average Device

• Powerful, personal capabilities from specialized
  devices
• small, highly mobile or embedded in environment
• Intelligence immense storage and processing
  in the infrastructure
• Everything connected

Laptops, Desktops
5
HCI Challenges

• Universal computing devices will not have the
  same UI as dads PC
• a wide range of devices
• often w/ small or no screens alternative I/O
• e.g., pens, speech, vision
• special purpose to particular applications
• information appliances
• lots of devices per user
• all working in concert

6
HCI Challenges (cont.)

• Design of good appliances will be hard
• single device design is easy
• hard to design the same application in a
  consistent manner across many devices
• e.g., calendar app. one speech based one GUI
  based
• hard to make different devices work together
• which device is used when?
• multiple UIs modes/device, which to display?
• building awareness of context of use into design
  is the key to some of these issues
• multimodal input is assumed, but little design
  support for creating multimodal interfaces

7
Our Approach

• Build
• novel applications on existing appliances
• e.g., NotePals on the Palm PDA CrossPad
• new information appliances
• Evaluate appliances in realistic settings
• Iterate
• use the resulting experience to build
• more interesting appliances
• better design tools analysis techniques

8
Outline

• HCI Challenges for Universal Computing
• Multimodal interaction
• Why is building MM UIs hard?
• Best practices for designing GUIs
• Proposed approach to building MM UIs
• Using context to our advantage

9
Multimodal Interaction

• When communicating with people we use more than
  one mode at a time!
• gesture speak

• sketch speak
• etc.

• Computers would be easier to use and more useful
  if they also worked like this

10
Benefits of Multimodal (MM) Interaction on
Heterogeneous Devices

• Computers could be used in
• more situations
• when hands are full or vision used for something
  else
• more places
• e.g., walking, car, factory floor, etc.
• Interfaces would be easier to use
• use innate perceptual, motor, cognitive skills
• More people would be able to use computers
• including users w/ vision or motor impairments
• MM UIs likely to become predominant

11
Why is building MM UIs hard?

• Often require recognition technology
• speech, handwriting, sketches, gesture, etc.
• Recognition technology is immature
• finally just good enough
• single mode toolkits just appearing now
• no prototyping tools
• Hard to combine recognition technologies
• still requires experts to build systems
• few toolkits or prototyping tools!
• This was the state of GUIs in 1980

12
Best Practices for Designing GUIs

• Iterative design
• Prototyping tools are key to this success

13
Early Stage UI Design

• Brainstorming
• put designs in a tangible form
• consider different ideas rapidly
• Incomplete designs
• do not need to cover all cases
• illustrate important examples
• Present several designs to client or design team
• No need at this stage for coding

14
Prototyping Tools for Multimodal UI Design Should
Support

• Iterative design methodology
• Informal techniques designers currently use in
  the early stage of UI design
• sketching

15
Prototyping Tools for Multimodal UI Design Should
Support

• Iterative design methodology
• Informal techniques designers currently use in
  the early stage of UI design
• sketching
• storyboarding

16
Prototyping Tools for Multimodal UI Design Should
Support

• Iterative design methodology
• Informal techniques designers currently use in
  the early stage of UI design
• sketching
• storyboarding
• Wizard of Oz

Um. Ill see you in the morning.
17
Our Approach Sketches, Models Context-aware
Design Tools

• Infer models from design sketchesor other
  informal representations
• model is an abstraction of apps UI design
• model for representing contexts UI implications
• Use models to
• semi-automatically generate UIs on diverse
  platforms
• dynamically adapt a particular appliance UI to
  changing context of use

18
How to Specify Events

• We have a good idea how to for visual UIs
• visually!

• But how about speech or gestures?

19
Specifying Non-Visual Events

• How do designers do this now?
• speech
• scripts or grammars (advanced designers only)
• flowcharts on the whiteboard
• Wizard of Oz -gt fake it!
• gestures
• give an example then tell programmer what it
  does
• We can do the same by demonstration (PBD)
• demonstrate example of act (e.g., speech)
• demonstrate result
• system infers program
• just a prototype, so doesnt have to be too
  general

20
Specifying Non-Visual Events
21
Combining the Visual Non-Visual

• How do you see what the system inferred?
• necessary for editing
• generate a visual representation
• flowchart seems like a start (common in speech
  UIs)
• appropriate? what should it look like?

22
Specifying Non-Visual Events
23
Combining the Visual Non-Visual

• How do you see what the system inferred?
• necessary for editing
• generate a visual representation
• flowchart seems like a start (common in speech
  UIs)
• appropriate? what should it look like?
• Combining visual non-visual events
• e.g., end-user dragging truck while saying fast
• use a visual language that combines visual
  storyboard of GUI w/ flowchart for non-visual
• VL better be simple...

24
Supporting Heterogeneous Devices

• Consider sketches as an abstraction
• Infer a model from the sketches
• Use methods from model-based UI tools to
• generate UIs for multiple devices
• generate alternative modes for a single spec. on
  one device
• Hard problems
• how to abstract?
• how do you generate a good UI?
• keep the designer in the loop

25
Take Advantage of Context Monitor Environment
Actions to Improve Interaction

• Which devices are present available?
• there is a wall display -gt use it for my wearable
• device discovery

26
Take Advantage of Context Monitor Environment
Actions to Improve Interaction

• Which devices are present available?
• there is a wall display -gt use it for my wearable
• device discovery
• What is occurring in the environment?
• people are talking -gt dont rely on speech I/O
• speech sensing

• What is the state of the user?
• hands using tools -gt use speech I/O visual Out
• tangible tools or vision processing
• Solution UI design tools that understand context
  as well as multiple devices modalities

27
Design Goals

• Let designers rapidly produce rough cuts
• doesnt need to handle all cases
• Allow end user testing fast modification
• Generate code that can help start UI for multiple
  devices
• designer adds more detail improves interaction
• programmers add necessary code

28
What Weve Accomplished So Far

• Informal tools for UI design
• sketch-based tools for GUI / Web design
• built tested 1st generation, building next gen.
  now

29
What Weve Accomplished So Far

• Informal tools for UI design
• sketch-based tools for GUI / Web design
• built tested 1st generation, building next gen.
  now
• informal tool for speech UI design
• designed implementation in progress

30
What Weve Accomplished So Far

• Informal tools for UI design
• sketch-based tools for GUI / Web design
• built tested 1st generation, building next gen.
  now
• informal tool for speech UI design
• designed implementation in progress
• Automatic generation of simple control UIs
• First cut designs for multimodal
• UI design tool appliance (SpeechCorder w/ ICSI)
• Experience w/ appliances simple context
• NotePals

31
Take Home Ideas

• Universal Computing is about supporting people
• Success will require the design evaluation of
  new appliances (device app UI) that
• take advantage of natural modes of input
• especially multimodal input!
• take advantage of context
• are used in realistic settings
• Experience, new architectures, and new tools will
  make this design problem easier

32
Informal Tools for Multimodal, Context-based User
Interface Design

• James A. Landay
• July 7, 1999
• HCC Retreat

33
Research Plan

• Finish implementation of informal tools
• study usage (especially of speech UI design)
• use results to design multimodal design tool
• Develop algorithms for extracting app model
• Build context-aware applications w/o tools
• two testbeds to create study
• wirelessly networked PDAs in classroom/learning
• extraction of tacit context using social
  networking
• build taxonomy of contexts
• how they should effect UI?

34
Research Plan (Cont.)

• Implement tool for multimodal UI design
• extract model generates UI for 2 diverse
  platforms
• uses simple context ques
• Develop algorithms for capturing context
• Evaluate usage (apps tools) in target settings
• Extend multimodal UI design tool
• generate multi-platform UIs that dynamically
  adapt
• allow context to be fully integrated in decisions

35
HCI Goals of Universal Computing

• Some of the roots of Universal Computing are in
  the ideas of Mark Weiser
• Ubiquitous/Pervasive/Invisible/Calm Computing
• ... does not live on a personal device of any
  sort PDA or dynabook, but is in the woodwork
  everywhere.
• you dont want personal technology, you want
  personal relationships

36
HCI Goals of Universal Computing

• Some of the roots of Universal Computing are in
  the ideas of Mark Weiser
• Ubiquitous/Pervasive/Invisible/Calm Computing
• ... does not live on a personal device of any
  sort PDA or dynabook, but is in the woodwork
  everywhere.
• you dont want personal technology, you want
  personal relationships
• Universal Computing is about
• supporting peoples tasks
• most often includes working with other humans
• making peoples lives easier
• just creating ubiquitous technology does not
  solve this

37
Computers Support Human-Human Communication (HHC)
38
Traditional Software Interfaces

• Force translations to formal representations
• sometimes we want this (e.g., conference slides)
• sometimes we dont (e.g., creative tasks)

39
Traditional Representations

• Rigid and unambiguous
• hard to mix (e.g., few tools support rough
  sketches)
• warp perceptions of the viewer and user
• Increase time
• encourage precision
• Inhibit creativity
• tunnel vision

40
Informal Communications Styles

• Speaking
• Writing
• Gesturing
• Sketching

Informal UIs do not immediately translate
natural input, allowing users to work more
naturally
